KitchenAid KSM15 Series User manual

Manual de Usuario
Batidora
KSM15 Series
KSM150PS Series
KSM175PS Series
KSM180RP Series
KSM180RC Series
KSM185PS Series
W11256121A.indd 1 14/06/2018 15:29:21

W11256121A.indd 2 14/06/2018 15:29:21

ENGLISH
| 3
TABLE OF CONTENTS
PARTS AND FEATURES.........................................................................................4
Parts and accessories......................................................................................4
STAND MIXER SAFETY.........................................................................................5
Important safeguards .....................................................................................5
Electrical requirements ...................................................................................8
Electrical equipment waste disposal ..............................................................8
USING THE STAND MIXER...................................................................................9
Speed control guide.......................................................................................9
Accessory guide ...........................................................................................10
Attaching/removing the bowl.......................................................................10
Lifting/lowering the motor head ..................................................................11
Attaching/removing the flat beater, Flex Edge beater*,
wire whip, or dough hook ............................................................................11
Beater to bowl clearance..............................................................................13
Placing/removing the pouring shield*..........................................................13
Using the pouring shield*.............................................................................14
Operating the speed control........................................................................15
Optional attachments...................................................................................15
TIPS FOR GREAT RESULTS .................................................................................17
Egg whites ....................................................................................................17
Whipped cream ............................................................................................17
Mixing tips ....................................................................................................18
CARE AND CLEANING .......................................................................................19
TROUBLESHOOTING..........................................................................................20
*Included with select models only. Also available as an optional accessory.
W11256121A.indd 3 14/06/2018 15:29:21

4 | PARTS AND FEATURES
PARTS AND FEATURES
PARTS AND ACCESSORIES
Motor head
Attachment hub
Speed
control
lever
Beater height
adjustment
screw
(not shown)
Attachment knob
Motor head
locking lever
(not shown)
Beater shaft
Bowl**
Bowl clamping plate
*Included with select models only. Also available as an optional accessory.
**The bowl design and material depend on the Stand Mixer model.
Pouring shield*
l
M
Wire whip
2.8 L stainless steel bowl*
Dough hook
Flat beater Flex Edge beater*
W11256121A.indd 4 14/06/2018 15:29:22

ENGLISH
STAND MIXER SAFETY | 5
STAND MIXER SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed, including
the following:
1. Read all instructions. Misuse of appliance may result
in personal injury.
2. This appliance is not intended for use by persons,
including children, with reduced physical, sensory,
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instructions concerning use of the appliance in a
safe way and understand the hazards involved.
W11256121A.indd 5 14/06/2018 15:29:23

6 | STAND MIXER SAFETY
3. Children should be supervised to ensure that they do
not play with the appliance.
4. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent, or similarly
qualied persons in order to avoid a hazard.
5. To protect against risk of electrical shock, do not put
appliance in water or other liquid.
6. Never leave the appliance unattended while it is in
operation.
7. Unplug from outlet when not in use, before putting on
or taking off parts, and before cleaning.
8. Avoid contacting moving parts. Keep hands, hair, and
clothing, as well as spatulas and other utensils away
from accessories during operation to reduce the risk of
injury to persons and/or damage to the appliance.
9. Do not operate any appliance with a damaged cord
or plug or after the appliance malfunctions or has
been damaged in any manner. Return appliance
to the nearest Authorised Service Centre for
examination, repair, or adjustment.
STAND MIXER SAFETY
W11256121A.indd 6 14/06/2018 15:29:23

ENGLISH
STAND MIXER SAFETY | 7
STAND MIXER SAFETY
SAVE THESE INSTRUCTIONS
10. Do not let the cord hang over edge of table or counter.
11. The use of attachments not recommended or sold
by KitchenAid may cause re, electric shock, or injury.
12. Do not use the Stand Mixer outdoors.
13. Remove at beater, wire whip, or dough hook from
Stand Mixer before washing.
14. To avoid product damage, do not use the Stand
Mixer bowls in areas of high heat such as an oven,
microwave, or on a stovetop.
15. Refer to the “Care and Cleaning” section for
instructions on cleaning the surfaces in contact with
food.
16. This appliance is intended to be used in household
and similar applications such as:
- staff kitchen areas in shops, ofces or other working
environments;
- farmhouses;
- by clients in hotels, motels and other residential
type environments;
- bed and breakfast type environments.
W11256121A.indd 7 14/06/2018 15:29:23

8 | STAND MIXER SAFETY
ELECTRICAL REQUIREMENTS
STAND MIXER SAFETY
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
Voltage: 220-240 V~
Frequency: 50-60 Hz
Wattage: 300 W
NOTE: To reduce the risk of electrical
shock, this plug will fit in an outlet only
one way. If the plug does not fit in the
outlet, contact a qualified electrician. Do
not modify the plug in any way.
A short power supply cord is supplied to
reduce the risk resulting from becoming
entangled in or tripping over a longer
cord.
If an extension cord is used:
• The marked electrical rating of the cord
set or extension cord should be at least
as great as the electrical rating of the
appliance.
• The cord should be arranged so that it
will not drape over the countertop or
tabletop where it can be pulled on by
children or tripped over unintentionally.
ELECTRICAL EQUIPMENT WASTE DISPOSAL
Disposal of packing material
The packing material is 100% recyclable
and is marked with the recycle symbol
. The various parts of the packing
must therefore be disposed of
responsibly and in full compliance
with local authority regulations
governing waste disposal.
Scrapping the product
- By ensuring this product is disposed
of correctly, you will help prevent
potential negative consequences for
the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product.
- The symbol on the product or
documentation indicates that it may not
be treated like normal household waste,
but must be disposed of in accordance
with current local legislation and
regulations for this type of waste.
W11256121A.indd 8 14/06/2018 15:29:23

ENGLISH
USING THE STAND MIXER | 9
USING THE STAND MIXER
NOTE: The speed control lever can be set between the speeds listed in the above chart
to obtain speeds 3, 5, 7, and 9 if a finer adjustment is required. Do not exceed Speed 2
when preparing yeast doughs as this may cause damage to the Stand Mixer.
SPEED CONTROL GUIDE
SPEED ACTION ATTACHMENT DESCRIPTION
1STIR
For slow stirring, combining, mashing,
starting all mixing procedures. Use to add
flour and dry ingredients to batter, and to add
liquids to dry ingredients. Do not use Speed
1 to mix or knead yeast doughs.
2SLOW
MIXING
For slow mixing, mashing, faster stirring. Use
to mix and knead yeast doughs, heavy batters
and candies, start mashing potatoes or other
vegetables, cut shortening into flour, and mix
thin or splashy batters.
4MIXING,
BEATING
For mixing semi-heavy batters, such
as cookies. Use to combine sugar and
shortening and to add sugar to egg whites
for meringues. Medium speed for cake mixes.
6BEATING,
CREAMING
For medium-fast beating (creaming)
or whipping. Use to finish mixing cake,
doughnut, and other batters. High
speed for cake mixes.
8FAST BEATING,
WHIPPING
For whipping cream, egg whites, and
boiled frostings.
10 FAST
WHIPPING
For whipping small amounts of cream,
egg whites, or for final whipping of
mashed potatoes.
W11256121A.indd 9 14/06/2018 15:29:24

10 | USING THE STAND MIXER
ATTACHING/REMOVING THE BOWL
1To attach bowl: Turn speed control
to “0”. Unplug Stand Mixer. 2Hold the locking lever in the unlock position and tilt motor head back.
3Place bowl on bowl clamping
plate. Turn bowl gently in
clockwise direction. 4To remove bowl: Repeat steps 1
and 2. Turn bowl gently
counterclockwise.
ACCESSORY GUIDE
ACCESSORY USES
Flat beater and
Flex Edge beater*
for normal to heavy
mixtures:
Cakes, creamed frostings,
candies, cookies, pie pastry,
biscuits, meat loaf,
mashed potatoes
Wire whip for
mixtures that need
air incorporated:
Eggs, egg whites, heavy cream,
boiled frostings, sponge cakes,
mayonnaise, some candies
Dough hook for mixing
and kneading yeast
doughs:
Breads, rolls, pizza dough, buns
*Included with select models only. Also available as an optional accessory.
USING THE STAND MIXER
W11256121A.indd 10 14/06/2018 15:29:25

ENGLISH
USING THE STAND MIXER | 11
USING THE STAND MIXER
*Included with select models only. Also available as an optional accessory.
1
To lift motor head: Push the locking
lever to the unlock position and lift
the head. Once lifted, the lever will
automatically go back in the lock
position to keep the head lifted.
2
To lower motor head: Push the
locking lever to unlock and gently
bring the head down. The locking
lever will automatically go back in
the lock position when the head is
down. Before mixing, test lock by
attempting to raise motor head.
LIFTING/LOWERING THE MOTOR HEAD
NOTE: Motor head should always be in the lock position when using the Stand Mixer.
ATTACHING/REMOVING THE FLAT BEATER, FLEX EDGE BEATER*,
WIRE WHIP, OR DOUGH HOOK
1To attach accessory: Turn speed
control to “0”. Unplug Stand Mixer.
W11256121A.indd 11 14/06/2018 15:29:25

12 | USING THE STAND MIXER
USING THE STAND MIXER
4
To remove accessory: Repeat steps 1
and 2. Press accessory upward
as far as possible and turn to the
left. Then pull accessory from the
beater shaft.
2Hold the locking lever in the unlock
position and tilt motor head back. 3
Slip accessory onto beater shaft and
press upward as far as possible. Then,
turn accessory to the right, hooking
accessory over the pin on the shaft.
W11256121A.indd 12 14/06/2018 15:29:26

ENGLISH
USING THE STAND MIXER | 13
USING THE STAND MIXER
PLACING/REMOVING THE POURING SHIELD*
1
To place pouring shield: Turn speed
control to “0”. Unplug Stand Mixer.
Attach your chosen accessory. See
the “Attaching/removing the flat
beater, Flex Edge beater, wire whip,
or dough hook” section.
2
From the front of the Stand Mixer,
slide the pouring shield over the
bowl until the shield is centred. The
bottom rim of the shield should fit
within the bowl.
*Included with select models only. Also available as an optional accessory.
BEATER TO BOWL CLEARANCE
1Turn speed control to “0”. Unplug
Stand Mixer. 2
Lift motor head. Turn screw slightly
counterclockwise (left) to raise flat
beater or clockwise (right) to lower
flat beater. Make adjustment with
flat beater, so it just clears surface
of bowl. If you overadjust the screw,
the bowl lock lever may not lock
into place.
Your Stand Mixer is adjusted at the factory so the flat beater just clears the bottom of the
bowl. If for any reason the flat beater hits the bottom of the bowl or is too far away from
the bowl, you can correct the clearance easily.
NOTE: When properly adjusted, the flat beater will not strike on the bottom or side
of the bowl. If the flat beater or the wire whip is so close that it strikes the bottom
of the bowl, coating may wear off the beater or wires on whip may wear.
W11256121A.indd 13 14/06/2018 15:29:26

14 | USING THE STAND MIXER
USING THE STAND MIXER
3To remove pouring shield:
Turn speed control to “0”.
Unplug Stand Mixer. 4Lift the front of the pouring shield
clear of the bowl rim and pull forward.
Remove attachment and bowl.
USING THE POURING SHIELD*
1
For best results, rotate the shield
so the motor head covers the
U-shaped gap in the shield. The
pouring chute will be just to the
right of the attachment hub as
you face the Stand Mixer.
2Pour the ingredients into the bowl
through the pouring chute.
Use the pouring shield to avoid having ingredients splashing out of the bowl when
mixing, as well as to easily pour ingredients into the bowl while mixing.
*Included with select models only. Also available as an optional accessory.
W11256121A.indd 14 14/06/2018 15:29:26

ENGLISH
USING THE STAND MIXER | 15
USING THE STAND MIXER
OPTIONAL ATTACHMENTS
KitchenAid offers a wide range of optional attachments such as food grinders or
pasta makers. They may be attached to the Stand Mixer attachment power shaft,
as shown here.
1To attach: Turn speed control
to “0”. Unplug Stand Mixer. 2Loosen attachment knob by turning
it counterclockwise. Remove
attachment hub cover.
OPERATING THE SPEED CONTROL
1
Plug the Stand Mixer into a proper
electrical outlet. Always set speed
control lever on lowest speed to start,
then gradually increase speed to
avoid splashing ingredients. See the
“Speed control guide” chart.
2
Do not scrape the bowl while the
Stand Mixer is operating. The bowl
and beater are designed to provide
thorough mixing without frequent
scraping. Scraping the bowl once
or twice during mixing is usually
sufficient.
NOTE: The Stand Mixer may warm up during use. Under heavy loads with extended
mixing time, the top of the unit may become hot. This is normal.
W11256121A.indd 15 14/06/2018 15:29:27

16 | USING THE STAND MIXER
USING THE STAND MIXER
3
Insert attachment shaft housing into
attachment hub, making certain that
attachment power shaft fits into
square attachment hub socket. It may
be necessary to rotate attachment
back and forth. When attachment
is in proper position, the pin on the
attachment will fit into the notch
on the hub rim.
4Tighten attachment knob by turning
clockwise until attachment is
completely secured to Stand Mixer.
5Plug into proper electrical outlet. 6To remove: Turn speed control
to “0”. Unplug Stand Mixer.
7
Loosen attachment knob by
turning it counterclockwise. Rotate
attachment slightly back and forth
while pulling it out.
8Replace attachment hub cover.
Tighten attachment knob by turning
it clockwise.
NOTE: See the Use and Care Guide of each specific attachment for recommended
speed settings and operating times.
W11256121A.indd 16 14/06/2018 15:29:27

ENGLISH
TIPS FOR GREAT RESULTS | 17
EGG WHITES
WHIPPED CREAM
Place room-temperature egg whites in clean, dry bowl. Attach bowl and wire whip.
To avoid splashing, gradually turn to designated speed and whip to desired stage.
AMOUNT SPEED
1 egg white GRADUALLY to 10
2 or more egg whites GRADUALLY to 8
Whipping stages
With your KitchenAid Stand Mixer, egg whites whip quickly. Avoid over-whipping.
Pour cold whipping cream into chilled bowl. Attach bowl and wire whip. To avoid
splashing, gradually turn to designated speed and whip to desired stage.
AMOUNT SPEED
less than 200 mL (3/4 cup) GRADUALLY to 10
more than 200 mL (3/4 cup) GRADUALLY to 8
Whipping stages
Watch cream closely during whipping. Because your KitchenAid Stand Mixer whips so
quickly, there are just a few seconds between whipping stages.
TIPS FOR GREAT RESULTS
W11256121A.indd 17 14/06/2018 15:29:28

18 | TIPS FOR GREAT RESULTS
TIPS FOR GREAT RESULTS
MIXING TIPS
Mixing time
Your KitchenAid Stand Mixer will mix
faster and more thoroughly than most
other electric mixers. Therefore, the
mixing time in most recipes must be
adjusted to avoid over-beating.
To help determine the ideal mixing time,
observe the batter or dough and mix
only until it has the desired appearance
described in your recipe, such as “smooth
and creamy.” To select the best mixing
speeds, use the “Speed control guide”
section.
Adding ingredients
The standard procedure to follow when
mixing most batters, especially cake and
cookie batters, is to add:
1/3 dry ingredients
1/2 liquid ingredients
1/3 dry ingredients
1/2 liquid ingredients
1/3 dry ingredients
Use Speed 1 until ingredients have been
blended. Then gradually increase to
desired speed.
Always add ingredients as close to side of
bowl as possible, not directly into moving
beater. The pouring shield* can be used to
simplify adding ingredients.
NOTE: If ingredients in very bottom
of bowl are not thoroughly mixed, the
beater is not far enough into the bowl.
See the “Beater to bowl clearance”
section.
Cake mixes
When preparing packaged cake mixes, use
Speed 4 for medium speed and Speed 6
for high speed. For best results, mix for the
time stated on the package directions.
Adding nuts, raisins, or candied fruits
Solid materials should be folded in the last
few seconds of mixing on Speed 1. The
batter should be thick enough to keep the
fruit or nuts from sinking to the bottom of
the pan during baking. Sticky fruits should
be dusted with flour for better distribution
in the batter.
Liquid mixtures
Mixtures containing large amounts of
liquid ingredients should be mixed at lower
speeds to avoid splashing. Increase speed
only after mixture has thickened.
Kneading yeast doughs
Always use the dough hook to mix and
knead yeast doughs. Use Speed 2 to mix
or knead yeast doughs. Use of any other
speed creates high potential for unit
failure.
Do not use recipes calling for more than
900 g (7 cups) all-purpose flour or 800 g
(6 cups) whole-wheat flour when making
dough in a 4.3 L bowl.
Do not use recipes calling for more than
1 kg (8 cups) all-purpose flour or 800 g
(6 cups) whole-wheat flour when making
dough in a 4.8 L bowl.
*Included with select models only. Also available as an optional accessory.
W11256121A.indd 18 14/06/2018 15:29:28

ENGLISH
CARE AND CLEANING | 19
2
Bowl, pouring shield*, stainless steel
wire whip*, stainless steel flat beater*,
stainless steel dough hook*, white
flat beater*, Flex Edge beater*, and
white dough hook* may be washed
in a dishwasher. Or, clean them
thoroughly in hot sudsy water and
rinse completely before drying.
Do not store beaters on shaft.
3
IMPORTANT: The standard
wire whip is not dishwasher-safe.
Clean it thoroughly in hot sudsy water
and rinse completely before drying.
Do not store wire whip on shaft.
NOTE: Stainless steel accessories are
dishwasher-safe.
*Included with select models only. Also available as an optional accessory.
CARE AND CLEANING
1
Always be sure to unplug Stand Mixer
before cleaning. Wipe Stand Mixer
with a soft, damp cloth. Do not use
household/commercial cleaners. Wipe
off beater shaft frequently, removing
any residue that may accumulate. Do
not immerse in water.
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
W11256121A.indd 19 14/06/2018 15:29:28

20 | TROUBLESHOOTING
TROUBLESHOOTING
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
Please read the following before calling
your service centre.
1. The Stand Mixer may warm up during
use. Under heavy loads with extended
mixing time periods, you may not be
able to comfortably touch the top of
the unit. This is normal.
2. The Stand Mixer may emit a pungent
odor, especially when new. This is
common with electric motors.
3. If the flat beater hits the bowl, stop the
Stand Mixer. See the “Beater to bowl
clearance” section.
If your Stand Mixer should malfunction
or fail to operate, please check the
following:
• Is the Stand Mixer plugged in?
• Is the fuse in the circuit to the Stand
Mixer in working order? If you have a
circuit breaker box, be sure the circuit
is closed.
• Turn off the Stand Mixer for 10-15
seconds, then turn it back on. If
the Stand Mixer still does not start,
allow it to cool for 30 minutes before
turning it back on.
• If the problem is not due to one of the
above items, see the “Warranty and
service” section.
W11256121A.indd 20 14/06/2018 15:29:28
