Knightsbridge BATC Series Instruction Manual

INSTALLATION & MAINTENANCE MANUAL
BATCxx
1
IP
20
ACCESSORIES LTD ACCESSORIES LTD
ACCESSORIES LTD
134

2
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
BATC4 / BATC5 / BATC5H / BATC6 / BATC6H
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for installation
• This product is Class I and must be earthed
• This series is IP20 rated
Note - If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with the
manufacturer of the sensors that they are compatible with LED luminaires.
• Provide power to the required point of installation (refer to BS7671 for correct cabling methods)
• Press the two clips at either end of the luminaire to gain access inside (see Fig. 1)
• Mark the location of the fixing holes and drill the holes ensuring not to infringe with any joists, gas/water
pipes or electrical cables. For distance between fixing centres, please see the table below:
Fig. 1
INSTRUCTIONS –BATCxx
These instructions should be read carefully and retained after installation by the end user for future reference and
maintenance.
These instructions should be used to aid installation of the following products:
BATC4 / BATC5 / BATC5H / BATC6 / BATC6H
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating
of the circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for
installation
•Do not overload this accessory or subject it to conditions outside its rating
•This product is Class I and must be earthed
•This series is IP20 rated
INSTALLATION
Note - If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with
the manufacturer of the sensors that they are compatible with LED luminaires.
•Provide power to the required point of installation (refer to BS7671 for correct cabling methods)
•Press the two clips at either end of the luminaire to gain access inside (see Fig.1)
Press
Fig. 1
•Mark the location of the fixing holes and drill the holes ensuring not to infringe any joists, gas / water
pipes or electrical cables. For distance between fixing centres, please see the table below:
Part Code
Distance
(mm)
BATC4
965
BATC5 / BATC5H
1265
BATC6 / BATC6H
1529

3
• Ensuring correct polarity is observed, carefully wire as shown in Fig. 2
• Choose the required colour temperature by means of the three-position switch (see Fig. 3)
• Switch on and check for correct operation
PART CODE DISTANCE MM
BATC4 965
BATC5 / BATC5H 1265
BATC6 / BATC6H 1529
Live (brown)
Earth (green/yellow)
Neutral (blue)
•Ensuring correct polarity is observed, carefully wire as shown in Fig. 2
Fig. 2
•Choose the required colour temperature by means of the DIP switch (see Fig. 3)
Fig. 3
•Switch on and check for correct operation
WARNING
This luminaire must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
GENERAL
The LED lamps fitted in this product are non-replaceable. The unit should be recycled in the correct manner
when it reaches the end of its life. Check local authorities for where facilities exist.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product.
This product is non-dimmable.
WARRANTY
This product has a warranty of 5 years from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch codes will
invalidate the warranty. If this product should fail within its warranty period it should be returned to the place of
purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve the
right to alter product specification without prior notice.
AVMAR19_V1
Fig. 2
Fig. 3
This luminaire must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
WARNING

4
ML Accessories Limited
LU5 4LT
www.mlaccessories.co.uk AVDEC19_V2
ACCESSORIES LTD ACCESSORIES LTD
ACCESSORIES LTD
The LED lamps fitted in this product are non-replaceable. The unit should be recycled in the correct manner
when it reaches the end of its life. Check local authorities for where facilities exist.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product.
This product is non-dimmable.
This product has a warranty of 5 years from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch codes will
invalidate the warranty. If this product should fail within its warranty period it should be returned to the place
of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve the
right to alter product specification without prior notice.
GENERAL
WARRANTY
