KOBLE Juno DOJUNB4 User manual

Issue 1 - 29/08/23

Step 1
1. Carefully place table top upside down onto a clean flat surface.
2. Assemble leg (with motor) in the location shown.
Secure using fixings and
3. Assemble leg using fixings
Do not locking screws and ，before ensure locking screws are done!
and
Front
Back
Tip：

Step 2
Ensuring the locking screws in transmission rod are undone, slide the hexagonal rod at
one end of transmission rod into the hexagonal hole of the leg .
Ensure it is pushed all the way in up to the metal collar as shown.
Important
Do not retighten the locking screws. Leave loose!
2
Ensure locking
screw is undone.

Front
Back
Ensure
Motor
locking
screw is
undone.
Ensuring the locking screws at the opposite end of transmission rod are undone,
carefully extend transmission rod out and slide the open end over the hexagonal
rod on the motor on leg .
Tip：
If the transmission rod cannot be
aligned with the hexagonal rod on
leg , use spanner to slowly turn
it counterclockwise until it is aligned
with the hexagonal rod.
Step 3
2
If necessary use
spanner to rotate
rod to align
with hole.
Note:
Transmission rod is telescopic. Ensure it remains fully inserted into leg and onto
the motor hexagonal rod on leg .
Once the transmission rod is fully
engaged into both legs and ,
tighten the locking screws at
each end.

Step 4
Step 5
IMPORTANT!
Front
Back
Ensuring feet are the correct
way round as shown, assemble the
feet to legs and using
fixings and
Connect motor cable into the back of the control panel.
Connect power cable
into the power unit on
the underside of the desk.
Do not connect
to mains power
supply yet!!
1
2
1
2

Step 6
Before using the desk for the first time, it must
first be reset and initialised!!
Simultaneously press and keys for 5
seconds to display and then release.
The desktop will enter the initialisation mode
and the desk will automatically run.
Wait until it stops.
Reset is now complete and the
desk ready to use.
IMPORTANT!
With help, carefully turn the desk over.
Connect tothe mains power supply and switch power on.
The desk is heavy. Lift with care.

USB port
Type C
(magsafe)
The control panel has two charging ports (Type-C+USB). Both interfaces can charge electronic devices;

iPhone X Series
iPhone 11 Series
iPhone 12 Series
iPhone 13 Series
iPhone 8 Series iPhone SE2
i
iPhone 14 Series
Phone SE3
Galaxy S6 Series
Mate20 Series
Mate30 Series
Mate40 Series
Mate50 Series
P30 Pro
P40 Pro
Galaxy S7 Series
Galaxy S8 Series
Galaxy S9 Series
Galaxy S10 Series
Galaxy S20 Series
Galaxy S21 Series
Galaxy S22 Series
Galaxy Note7 Series
Galaxy Note8 Series
Galaxy Note9 Series
Galaxy Note10 Series
G
Galaxy Z Flip Series
Galaxy W Flip Series
alaxy Note20 Series
Xiaomi 9 Series
Xiaomi 10 Series
Xiaomi 11 Series
Xiaomi 12 Series
MIX Series
or later
or later
or later
or later

5

Remove case from device.

SAVE THESE INSTRUCTIONS
SERVICING OFDOUBLE-INSULATED PRODUCTS
