INSTALLATION INSTRUCTIONS
K-19044T
VITREOUS CHINA BIDET
SAFETY: WARNINGS
Kohler products are precision-engineered and should give
continued superior and safe performance, provided:
1. They are installed, commissioned, operated and
maintained in accordance with the recommendations given
in this Manual.
2. Periodic attention is given, as necessary, to maintain the
product in good functional order. Recommended guidelines
are given in the section.
Carefully inspect the new fixture for any signs of damage.
When installing Kohler Products, manufacturers guidelines for
power tool safety should be followed.
MAINTENANCE
1.
2.
IMPORTANT !
Before installation carefully inspect the new fixture for any
signs of damage.
The Kohler Bidet is designed for connection to a hot and
cold water supply.
Installer: This manual is the property of the customer and
must be retained with the product for maintenance and
operational purposes.
·
·
·
·
·
·
·
·
·
Observe all local plumbing and building codes.
Turn off the water supply.
Refer to roughing-in sheet for dimensional information.
Site preparation may require additional tools and
hardware.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain import care, cleaning, and
warranty information please leave these instructions for
the consumer.
·
·
·
·
·
·
·
·
·
RECOMMENDED TOOLS AND MATERIALS
(Not Supplied)
·
·
·
·
·
·
·
Hexangular wrench
Safety Glasses
Pencil
Tape Measure
Sealant
Drill
Adjustable Wrench
()
·
·
·
·
·
·
·

-2-
1037581-T01-A
ROUGHING-IN
Plumbing Connections
Hot (H) and Cold inlets must be connected to the correct
inlet pipes.
(H) (C)
SPECIFICATION
()
C
UNIT: mm
K-19044T
155
195
250
275
395
365
35
35 45
265 375
407
605
68
135
180
367
5
OO
30
O
110
250
100
35
120 100
Fixations

-3-
10.Make sure that the clamping
assembly locates under the fixing
bracket on the wall.
11. Use a level to ensure the bidet is
level and is instaaled in the correct
position.
12. Ensure that all the connections are
tight.
13. Use an hexagonal wrench to
tighten the screw on the clamping
bracket assembly, and fit the cover
cap over the screw head.
14. Apply silicone sealant around the
top, sides, and base of the bidet.
10.
11.
12.
13.
14.
P4137040
P4137050
6mm
250 mm
P4137030
Clampig Assembly
5. Secure the fixing bracket to the wall
using suitable screws.
5.
6. Fit the tap to the bidet in
accordance with the manufacture,s
instructions.
7. Fit the clamping assembly inside
the bidet and hold in position with
the fixing screw.
8. Fit the waste and connect the tap to
the hot and cold water supplies.
9. Positon the bidet against the wall.
6.
7.
8.
9.
1037581-T01-A
INSTALLATION
250mm
35 mm
110mm
P4137020
120 mm
100 mm
100 mm
Install the Bidet
1. Install the services.
2. Make sure that the hot and cold
water supply pipes and the waste
are installed correctly.
The hot and cold water supplies
must be installed with isolating valves.
3. Place the fixing bracket against the
wall, and mark the positions of the
fixing holes on the wall.
Make sure that you
avoid hidden cables and pipes
when drilling holes in the wall.
4. Drill the fixing holes, and insert the
wall plugs into the drilled holes.
Note!
Caution!
1.
2.
3.
4.

-4-
1037581-T01-A
LIMITED ONE-YEAR WARRANTYLIMITED ONE-YEAR WARRANTY
Plumbing Fixtures and Fittings Limited
One-year Warranty
Kohler plumbing fixtures and fittings are warranted to be
free of manufacturing defects.
This product is warranted for one year from date of
purchase. Kohler China will be responsible for any
problems caused by manufacturing defects provided with
the invoice. Kohler China will, at its election, repair,
replace or make appropriate adjustment where Kohler
China inspection discloses any such defects occurring in
normal usage within one year after purchase.
Implied warranties including that of merchantability and
fitness for a particular purpose are expressly limited in
duration to the duration of this warranty, Kohler China
disclaims any liability for special, incidental or
consequential damages. Damages to the product caused
by misuse, abuse and installation that is not in
accordance with the owner's manual are not covered by
this warranty.
To obtain quick warranty service, please contact your
dealer, or write to Kohler China. (Original sales receipt
must be provided as the proof of purchase.)
Kohler China Investment Company Ltd.
Central Customer Service Center
19/F, Shanghai Square, 138 Huai Hai Road,
Luwan District, Shanghai, PRC
Zip Code: 200021
This is our exclusive written warranty.
·
·
·
·
·
·
·
·
()
()
138
19
200021
Cleaning
Caution! Risk of product damage.
Caution! Risk of product damage.
Many cleaners
contain abrasive and chemical substances, and should
not be used for cleaning stainless steel, enamel,
plated or plastic fittings. These finishes should be
cleaned using a mild washing up detergent or soap
solution, rinsed and then wiped dry with a soft clean
cloth.
Most toilet bowl
cleaners are not harmful to the vitreous china surface
of the toilet bowl. Please follow the bowl cleaner
maufacturer,s instructions carefully.
USER MAINTENANCEUSER MAINTENANCE
Finish the Installation
Turn on the water supply and check for any leaks.
