Kohler K-4917X Assembly instructions

Installation and Care Guide
Waterless Urinal


1181553-X2-B ©2012 Kohler Co.
K-4917X K-4918X

1181553-X2-B 2 Kohler Co.

Thank You for Choosing Kohler Company
Thank you for choosing Kohler. Kohler crasmanship oers you a rare
combination of proven performance and graceful sophistication that will
satisfy you for years to come. The dependability and beauty of your Kohler
product will surpass your highest expectations. We’re very proud of our
products here at Kohler and we know you will be too.
Please take a few minutes to review this manual before you start installation. If
you encounter any installation or performance problems, please don’t hesitate
to contact us. Our phone numbers and website are listed on back cover.
All information in this manual is based upon the latest product information
available at the time of publication. At Kohler, we constantly strive to improve
the quality of our products. We reserve the right to make changes in product
characteristics, packaging or availability at any time without notice.
Thank you for choosing Kohler Company.
  
 
 
 
 

  

  


 

Kohler Co. 3 1181553-X2-B
Before You Begin
CAUTION: Risk of personal injury or product damage. Handle with
care. Vitreous china can break or cause injury if handled carelessly.

Important Information
IMPORTANT NOTICE TO INSTALLERS!: Please leave these instructions for
the consumer. They contain important information.
In addition to installation procedures, this manual contains important care and
cleaning. Please retain for future reference.
NOTE: Some installation parts might not be provided.
NOTE: The product pictured in the installation steps may dier from the model
being installed.
 
 

 



¨ Observe all local plumbing and building codes.
¨ Carefully inspect the new urinal for damage.
¨ Roughing-in remains the same when using the optional 3” outlet spud.
¨ Fixture dimensions are nominal and conform to tolerances by ANSI Standard
A112.19.2 and TIS.
¨ Site preparation may require additional tools and hardware.

1181553-X2-B 4 Kohler Co.

  


¨ 
¨ 
¨ 
¨ 
¨ 
Tools/

Kohler Co. 5 1181553-X2-B
Roughing-In/
Dimensions are approximate. Unit: mm.
 
603
Spud Detail
รายละเอียดขอตอนํ้าทิ้ง
2" NPT Tap/ทอ
Finished wall and back of spud should be flush
ดานหลังขอตอทางน้ำเขาควรพอดีกับแนวกำแพง
Finished Wall/แนวกำแพง
Wall Hangers/ขอแขวน
610
356
171
410 to Center
of Hanger Slots
กึ่งกลางรูเจาะ
ขอแขวน
2" NPT ทอ
2’’ NPT
ทอ
752
453
513
Wall
กำแพง
Floor
พื้น
397
152
6152
Spud Detail
รายละเอียดขอตอนํ้าทิ้ง
2’’ NPT
ทอ
Wall
กำแพง
Floor
พื้น
381
343
457
375
30
610
152
197
48 Wall Hangers/ขอแขวน
279
191 to Center
of Hanger Slots
กึ่งกลางรูเจาะ
ขอแขวน
216
K-4917X
K-4918X

1181553-X2-B 6 Kohler Co.
¨ 
¨ 
¨ 
¨
1. Prepare the Site

¨Turn the water supply o.
¨ Install or relocated the supply tubing and waste pipe as neccessary to conform
to the roughing-in dimension.
¨ Install the shut-o valve.
¨ Install adequate support framing as needed.
¨ 
Roughing-in Dimensions

¨Roughing-in dimension are identical if using an optional 3'' outlet spud.

Kohler Co. 7 1181553-X2-B
K-4917X
Wall
กำแพง
Wall Hangers
ขอแขวน
K-4918X
Wall
กำแพง
Wall Hangers
ขอแขวน
Waste Pipe/ทอนํ้าทิ้ง
Gasket/ประเก็น
Screw/สกรู
Screw/สกรู
Washer/แหวนรอง
Bracket/แผงยึด
Collar/ขอตอทางนํ้าออก
Apply Sealant Tape
พันดวยเทปพันเกลียว
Installed Wall Hangers
ขอแขวนที่ติดตั้ง
Strainer/ตัวกรอง
Gasket
ประเก็น
Screw/สกรู
Washer/แหวนรอง
Collar/ขอตอทางนํ้าออก
Waste Pipe/ทอนํ้าทิ้ง
Apply Sealant Tape
พันดวยเทปพันเกลียว
Installed Wall Hangers
ขอแขวนที่ติดตั้ง
Strainer/ตัวกรอง

1181553-X2-B 8 Kohler Co.
¨ Carefully position the urinal on the wall hangers.
¨ Verify the urinal is properly positioned, then remove the urinal from the wall.
NOTE: If adjustment is neccessary, make vertical adjustments along the slots
on each wall hanger until the urinal can be tightened to the collar.
¨ Install permanent screws into the holes on the hangers, as shown on the
installation template.
CAUTION: Risk of product damage. Do not overtighten the cap nuts.
Overtightening may damage the product.
¨ Carefully position the urinal on the wall hangers, then secure the urinal to
the collar (for K-4918X, secure the urinal to the bracket) using the washers
and screws provided.
¨ 
  

¨ 
¨

¨ 

CAUTION: Risk of personal injury or product damage. Handle
with care. Vitreous china can break or chip if the product is handle carelessly.
2. Install the Urinal
¨ Reference the installation template and position each wall hanger at its proper
vertical dimension above the outlet hole show on the template. To allow for
vertical adjustment, place the initial screws through the center of the slots on
the wall hangers.
¨ Apply thread sealant tape to the pipe threads on the drain and install the collar
to the drain.
¨For K-4918X only, Center the bracket on top of the collar. Secure two screws
through the slots on the bracket and into threaded holes on the collar.
¨ Place the gasket onto the collar with the beveled surface facing away from
the collar.

Kohler Co. 9 1181553-X2-B
 


¨ 
¨ 




¨ 



¨ 


¨ 
¨ 
¨ 

¨ 
3. Complete the Installation

¨Pour 1/2 gallon (1.89 L) water into the trapway.
¨Check for leaks. Repair as needed.
¨Pour 3 ounces (89 ml) of sealing liquid (provided) into the trapway.
The sealing liquid will oat on top of the water in the trapway.
¨ Place the strainer in the drain hole.

1181553-X2-B 10 Kohler Co.
Care and Cleaning
To keep the Kohler urinal looking and performing its best, it is important to
follow these care and cleaning procedures.
Use the Kohler products listed below for optimum care and cleaning results.
These products can be purchased from a Kohler distributor or call 0 2204 6222
for ordering information.
128 oz. (3.8 L) sealing liquid 1048656
32 oz. (946 ml) cleaner 1048657
Daily Cleaning
¨Spray the Kohler cleaner over the outer surfaces of the urinal. Allow
some cleaner to run down the drain.
¨Allow the cleaner to stand for approximately one minute.
¨ Wipe the outer surfaces with a clean, non-abrasive cloth.
¨ If necessary, repeat this procedure for heavier soils still present on the
urinal.
To minimize odor and avoid sediment build-up in the trapway, it is important
to ush out your waterless urinal every two weeks. Please follow the Required
Bi-Monthly Flush-out Cleaning. procedure below.
Required Bi-Monthly Flush-Out Cleaning
¨Repeat the daily cleaning procedure.
¨Using a small screwdriver or bent wire, carefully li the strainer vertically
from the drain. Clean the strainer and set it aside.
¨ Quickly pour one gallon of water directly into the drain. Do not let the
urinal overow. This will purge the residual urine and sealing liquid.
¨ Unscrew the spray nozzle from the cleaner bole. Pour 1 oz. (30 ml) or
2 tablespoons of cleaner directly into the drain.
¨ Allow the cleaner to stand for 5 to 10 minutes.
¨ Pour two gallons of water directly into the drain as quickly as possible.
Do not let the urinal overow.
¨ Pour 3 oz. (90 ml) or approximately 1/3 cup of sealing liquid directly into the
drain.
¨ Reinstall the strainer.

Kohler Co. 11 1181553-X2-B
Care and Cleaning (cont.)
IMPORTANT! Failure to perform bi-monthly ush-out cleaning may eventually
result in a clogged urinal. If the urinal becomes clogged a *plunger, *urinal auger,
or non-Kohler brand strong acid cleaner may be used. If a non-Kohler brand strong
acid cleaner is used, thoroughly rinse the urinal with water aer application to
minimize acid corrosion on the seal gasket and downstream piping.
Plunger*
Urinal auger*
