Kohler DEVONSHIRE Series User manual

-1-
BEFORE YOU BEGIN
BEFORE YOU BEGIN
·
·
·
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation . This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information-
Before installation carefully inspect the new fixture for any
signs of damage.
please leave instructions for the
consumer.
·
·
·
·
-
ORDERING INFORMATION
This installation covers the following products in the
DEVONSHIREN, ELOSIS mirror cabinet range:
ELOSIS Mirror Cabinet1526..........................K-15030T-NA
ELOSIS Mirror Cabinet2026..........................K-15031T-NA
ELOSIS Mirror Cabinet2526..........................K-15032T-NA
ELOSIS Mirror Cabinet3026..........................K-15033T-NA
ELOSIS Mirror Cabinet Wood Frame2026 ....K-15034T-NA
DEVONSHIRE Mirror Cabinet PU Frame2030 ..K-15035T-NA
1526...........................................
2026...........................................
2526...........................................
3026...........................................
2026 ...................................
PU 2030 ..................................
K-15030T-NA
K-15031T-NA
K-15032T-NA
K-15033T-NA
K-15034T-NA
K-15035T-NA
PARTS
Parts supplied with your cabinet. (For cabinet body and door
replacement, call customer service with model number.) Be
sure to check the cardboard supports in the carton, glass
parts are packed in them.
(),
.
1056564-T01-A
, 2008
Copyright Kohler China Ltd., 2008
()
158 200436
INSTALLATION INSTRUCTIONS
MIRROR CABINET
K-15030T, K-15031T, K-15032 , K-15033 , K-15034 , K-15035T
DEVONSHIRE
ELOSIS
TTT

PARTS ON LEFT ARE USED WITH ALL CABINETS.
-2-
# 8 X 3/8 Side Kits Screws
#8 X 1 1/2 Phillips
Head Screws
Side Mirrors
4 Side Kits brackets
Wall Anchors
Screw Caps S, W
Hole plugs W
4 Side Kits Bracket Foam tape
Top Clips
Snap-in Pins
#8 X 2 Hex Head Slotted Screws
4
#8X3/8
#8X11/2
S, W
#8X2
W
W
2 Glass Shelves
K-15030T-NA, K-15031T-NA,
K-15034T-NA, K-15035T-NA
11 Mounting Bar for
K-15030T-NA, K-15031T-NA,
K-15034T-NA, K-15035T-NA
ONE DOOR CABINET-Part list
280
K-15030T-NA, K-15031T-NA,
K-15034T-NA, K-15035T-NA
2
K-15030T-NA, K-15031T-NA,
K-15034T-NA, K-15035T-NA
-
TWO DOOR CABINET-Part list
21 Mounting Bar for
K-15032T-NA
K-15033T-NA
530
K-15032T-NA
K-15033T-NA
2 Glass Shelves
K-15032T-NA
K-15033T-NA
2
K-15032T-NA
K-15033T-NA
-
1056564-T01-A

K-15030T-NA K-15031T-NA K-15032T-NA
K-15033T-NA K-15034T-NA K-15035T-NA
ROUGHING-IN
UNIT : mm
INSTALLATION
NOTE
All steps after pg.4 are for all cabinets unless noted. (*)
For recess mount see instructions below.
For surfaces mount instructions see page4.
A surface mounted cabinet requires the optional
Mirror kit supplied with your cabinet.
·
·
·
(*)
()
·
·
·
-3-
1.
A.
1. Recessing the cabinet into the wall
A. The Vertical installation changes the width of the roughout.
Please refer to the picture below.
1056564-T01-A

25 1/4 high
2.
A.
()
2. Surface mounting the cabinet on a wall.
NOTE:
A. Install Mounting Bar.
Installing the cabinet on a wall without the door attached can
make installing easier for one person. Do not mount the doors
until the boxes is in or on the wall.
(Step one varies on type of cabinet
you have, see below.)
Fig. 1 1
14 1/4 W for K-15030T-NA Models
19 1/4 W for K-15031T-NA,
K-15034T-NA,
K-15035T-NA Models
24 1/4 W for K-15032T-NA Models
29 1/4 W for K-15033T-NA
CL15 362 ;
CL20 489 ;
CL25 616 ;
CL30 CL3026-3 743 ;
Mounting location for
#8 x 1 1/2 philips
head screws
#8
B. 1
#8
B. Install screws through holes in cabinet as shown in Fig.1
DO NOT OVER- TIGHTEN!
Use #8 x 1 1/2 Phillips head.
Note:
Top View
Stud and wall surface
Install dome caps over screws
Cabinet flange fits flush against wall
Fig. 2 2
-4-
642
1) For Single Door
Drill two 3/16 holes in bottom mounting bar at indent location.
Use the supplied anchors or locate studs if possible.
1)
5
1056564-T01-A

-5-
1051705-T01-A
2) For Two Door
Drill three 3/16 holes in bottom mounting bar at indent
location. Use the supplied anchors or locate studs if possible.
2)
5
K-15030T-NA
K-15034T-NA
K-15035T-NA
4 1/2" from edge side of cabinet
114
2" from edge side of cabinet
50
3/4 bottom of Cabinet
20
Fig. 3 3
Fig. 4 4
2" from edge side of cabinet
50
3/4 bottom of cabinet
20
K-15030T-NA
3) Drill 1/4 hole in wall for mounting bar anchors at locations
shown in Fig.3.(If you do not use the anchor, drill a 3/32
pilot hole.) After the holes are drilled, fit the mounting bar
onto the wall, refer to Fig. 3 for measurements, and Fig. 5
for information on anchor cinching.
3) 3 7
(2)
35
B.
()
1) 7A
2) 7B
3) 7C
,
4) 8
5)
B. Install Top Clips
(Left and right top clips come connected, hold both clips
and snap them apart).
1) Fit cabinet into position on mounting bar as shown in
Fig.7A.
2) Place clip in position as shown in Fig.7B and mark with a
pencil. Remove clip and cabinet and drill the pilot or
anchor holes where marked.
3) Fix both the clips into position with a screw, and slide the
clip into the up position. Sit the cabinet on the mounting
bar, then lower and tighten the screws into place, as
shown in Fig 7C.
4) See Fig. 5 on next page for proper turns required for
anchor cinching.
5) See page 7 for Side Kit Mirror application.
1056564-T01-A

Cabinet bottom sits in lip on bottom
mounting bar
#8x2"Hex
Head screw &
Wall anchor
(use driver)
#8
x1/4"
Top mount clip
Wall anchor
(if required)
()
#8x2 Hex head screw
(Use 1/4 driver)
#8 .
"
"
Fig. 6 6
7B
7C
Once Screw is bottomed out on
mount clip, turn screw and additional
5 to 7 turns to fully expand the anchor.
57
Side view at top of cabinet
Fig. 7 7
-6-
7A
Fig. 8 8
1056564-T01-A

*
A. 11
B. 13
C. ( )
NOTE: BELOW FOR1&2DOOR CABINET ONLY*
A. This screw releases the door from the cabinet and allows
up and down adjustment. Fig.12
B. These screws allow you to plumb the door as shown in
Fig.13
C. The screws you use for attaching the hinges.
(Supplied with hinges)
A
B
B
3.
A.
1)
2)
B. 10
C.
D.
E.
3)
3. Attaching Side Kits to a Surface Mounted
Cabinet
A. Apply foam tape to Side kit bracket
DO NOT PEEL RELEASE LINER UNTIL YOU HAVE
TEST FIT THE SIDE KITS ON THE CABINET!
1) Peel tape from sheet, leave liner on.
2) Apply as shown to side kit brackets, be sure they are
clean and dry.
3)
B. Attach the side kit brackets to the cabinet as shown in
Fig.10
C. Test fit the side kits, then cleas the back of the side kits
with rubbing alcohol.
D. Peel the release tape from the brackets and apply the side
kits, push firmly to set.
E. Cover the screw heads with the screw caps.
Align top of side kit with top of flange
#8 x 3/8" screws
self thread into
Side Kit brackets
#8
2 pieces
26" high
660
Side kit bracket
(Fits tight under the
flange of cabinet)
()
Side kit brackets
Fig. 9 9
Fig. 10 10
4.
4. Door adjustments
-7-
Fig. 11 11
8-32 x 1/2" (SS829)
6-32 x 3/8" (SS679)
1056564-T01-A

A
B
Fig. 12 12 Fig. 13 13
1
2
5. - 15.5. Installing the shelves- see Fig.15
A.
1) Push one side of the shelf into the left or ritht clips
2) Snap the shelf down into the opposite side. If the shelf is
too tight, repeat the process fron the other side.
B.
Push/twist the pins into place
Fill the remaining holes with the plugs.
A.
1)
2)
B.
Fig. 14 14 Fig. 15 15
-8-
1056564-T01-A

-9-
1056564-T01-A
1064412
Hinge Kits
1064407
Door
381mm
1056546
Side Mirror
1098736
Glass Shelf
322.5mm
1056549
Mounting Bar
280mm
Side Kits Brackets Wall Anchors Top Clips Snap-in Pins Hole Plugs Foam Tape
Screw Caps#8X2
#8X2
" Hex Head Slotted Screws
"
#8 X 1 1/2
#8 X 1 1/2
" Phillips Head Screws
"
#8 X 3/8
#8 X 3/8
" Side Kits Screws
"
1056547
Kits Hardware, Including Following Parts:
SERVICE PARTS PAGE
MIRROR CABINET
K-15030T
DEVONSHIRE
ELOSIS

1064412
Hinge Kits
1064408
Door
508mm
1056546
Side Mirror
1098737
Glass Shelf
450mm
1056549
Mounting Bar
280mm
-10-
1056564-T01-A
MIRROR CABINET
K-15031T
DEVONSHIRE
ELOSIS
SERVICE PARTS PAGE
1056547
Kits Hardware, Including Following Parts:
Side Kits Brackets Wall Anchors Top Clips Snap-in Pins Hole Plugs Foam Tape
Screw Caps#8X2
#8X2
" Hex Head Slotted Screws
"
#8 X 1 1/2
#8 X 1 1/2
" Phillips Head Screws
"
#8 X 3/8
#8 X 3/8
" Side Kits Screws
"

-11-
1056564-T01-A
MIRROR CABINET
K-15032T
DEVONSHIRE
ELOSIS
SERVICE PARTS PAGE
Side Kits Brackets Wall Anchors Top Clips Snap-in Pins Hole Plugs Foam Tape
Screw Caps#8X2
#8X2
" Hex Head Slotted Screws
"
#8 X 1 1/2
#8 X 1 1/2
" Phillips Head Screws
"
#8 X 3/8
#8 X 3/8
" Side Kits Screws
"
1056547
Kits Hardware, Including Following Parts:
1064412
Hinge Kits
1064409
Door
254mm
1098738
Glass Shelf
576.5mm
1056546
Side Mirror
1064413
Mounting Bar
533mm
1064407
Door
381mm

MIRROR CABINET
K-15033T
DEVONSHIRE
ELOSIS
SERVICE PARTS PAGE
-12-
1056564-T01-A
1064412
Hinge Kits
1064409
Door
254mm
1064408
Door
508mm
1056546
Side Mirror
1098739
Glass Shelf
704mm
1064414
Mounting Bar
660mm
Side Kits Brackets Wall Anchors Top Clips Snap-in Pins Hole Plugs Foam Tape
Screw Caps#8X2
#8X2
" Hex Head Slotted Screws
"
#8 X 1 1/2
#8 X 1 1/2
" Phillips Head Screws
"
#8 X 3/8
#8 X 3/8
" Side Kits Screws
"
1056547
Kits Hardware, Including Following Parts:

MIRROR CABINET
K-15034T
DEVONSHIRE
ELOSIS
SERVICE PARTS PAGE
-13-
1056564-T01-A
1064412
Hinge Kits
1064410
Door, Wood Frame
508mm
1056546
Side Mirror
1098737
Glass Shelf
450mm
1056549
Mounting Bar
280mm
Side Kits Brackets Wall Anchors Top Clips Snap-in Pins Hole Plugs Foam Tape
Screw Caps#8X2
#8X2
" Hex Head Slotted Screws
"
#8 X 1 1/2
#8 X 1 1/2
" Phillips Head Screws
"
#8 X 3/8
#8 X 3/8
" Side Kits Screws
"
1056547
Kits Hardware, Including Following Parts:

MIRROR CABINET
K-15035T
DEVONSHIRE
ELOSIS
SERVICE PARTS PAGE
-14-
1056564-T01-A
1064412
Hinge Kits
1064411
Door
PU 508mm
1056546
Side Mirror
1098737
Glass Shelf
450mm
1056549
Mounting Bar
280mm
Side Kits Brackets Wall Anchors Top Clips Snap-in Pins Hole Plugs Foam Tape
Screw Caps#8X2
#8X2
" Hex Head Slotted Screws
"
#8 X 1 1/2
#8 X 1 1/2
" Phillips Head Screws
"
#8 X 3/8
#8 X 3/8
" Side Kits Screws
"
1056547
Kits Hardware, Including Following Parts:
