Kohler M MODULAR User manual

-1-
M
INSTALLATION INSTRUCTIONS
()
MIRRORED CABINET W/DEFOGGER
K-15512T
M MODULAR
, 2011
Copyright Kohler China Ltd., 2011
13-1 528437
BEFORE YOU BEGINBEFORE YOU BEGIN
·
·
·
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation . This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information-
Before installation carefully inspect the new fixture for any
signs of damage.
Tempered glass cannot be cut.
Don't use acidic or alkalic cleaners or
alcohol to clean the wooden surface. Use a dampened
cloth to clean.
please leave instructions for the
consumer.
WARNING: Risk of injury or product damage.
WARNING:
·
·
·
·
-
PARTS
Parts supplied with your cabinet. (For cabinet body and door
replacement, call customer service with model number.) Be
sure to check the cardboard supports in the carton, glass
parts are packed in them.
ACCESSORIES LISTACCESSORIES LIST
Screws ST3.5 35
ST3.5 35
X5
Screws ST4.2 12
ST4.2 12
X8
Connector Block
X2
Hinge Clips
X2
Glass
X1
2 Level Box
X1
Tissue Box
X1
Wall Anchors
X5
Snap-in Pins
X12
Caps of Screw
X10
Hole Plugs
X40
Top Clips
X2
Mounting Bar
X1
Glass Shelves
X3
1179057-T01-A

-2-
489
116
99
762
682
406
735
ROUGHING-IN
UNIT : mm
PRE-DRILLED HOLEPRE-DRILLED HOLE
Pre-Drilled Hole for Side Kits
Pre-Drilled Hole for Cabinet-to-Cabinet
Pre-Drilled Hole for Recessed Cabinet
1179057-T01-A

-3-
INSTALLATION
NOTE
·
·
The cabinet has two ways of installation:
Recessing mounting.
Surface mounting.
Refer to the following instruction for mirror installation.
·
·
STEP
1
RECESSING THE MIRRORED CABINET INTO THE WALL
The Vertical installation changes the width of the roughout. Please refer to the picture below.
On installations of larger cabinet in combinations of 3 or more, the
center door, when open, may cause the cabinet to bow from the wall.
If this happens, drill a hole at the location shown in Figure J and
install a ST3.5X35 SCREW.
3
ST3.5X35
472mm for Width
472mm
Screws ST3.5 35
ST3.5 35
745mm high
745mm
Fig. 1 1
Figure J
3/4"
(19.1mm)
3/4"
(19.1mm)
Drill a hole through
Top of middle cabinet 3/4" (19.1 mm) from back
19.1mm
1179057-T01-A

-4-
STEP
2
Install screws through holes in mirrored cabinet as shown in Fig.1, 2
DO NOT OVER- TIGHTEN!
Use s .
Note:
12
crews ST3.5 35
ST3.5 35
Fig. 2 2
Top View
Stud and wall surface
Install dome caps over screws
Mirrored cabinet flange fits flush against wall
SURFACE MOUNTING THE MIRRORED CABINET ON A WALL
NOTE:
Install the side kits while surface mounting the mirrored
cabinet on the wall, additional order of the side kits.
Fig. 3 3
STEP
1
As shown in Fig 3, drill two 2- 5mm holes
in bottom mounting bar at indent location,
then drill 4- 6mm holes in wall at locations
shown in Fig 3, insert wall anchors.
35
46
Screws ST3.5 35 & Wall anchor
ST3.5 35
The highest point of table
Drill holes
4- 6mm
4- 6mm
Fix the mounting bar to the
wall, level the mounting bar.
Drill holes
4- 6mm
4- 6mm
20
750
320
1179057-T01-A

COMBINATION INSTALLATION OF SEVERAL MIRRORED CABINETS
-5-
1051705-T01-A
STEP
1
Fig. 5 5
Connect the cabinets by fixing the connector blocks to the side of the mirrored cabinet with ST4.2x12 screws.
ST4.2x12
For surface mounting installation, please fix the side kits bracket at the two sides of the combined cabinets with M4 screws.
M4
STEP
2
Fig. 4 4
Top clips slide into this screw
channel from center opening.
Top of cabinet frame member
2 Top clips
2
WALL
Sit the mirrored cabinet on the mounting bar, then lower and tighten the
screws into place, as shown in Fig.4.
4
Screws ST3.5 35 & Wall anchor
ST3.5 35
Side Kits
Mirrored Cabinet Mirrored Cabinet
Connector Blocks
Mirrored Cabinet
Top clip for
surface mount
2 per cabinet
1179057-T01-A

Fig. 6B 6B
Assemble Removal
Depth Adjustment
Height Adjustment
Side Adjustment
Fig. 6A 6A
AssembleAssemble Removal
-6-
STEP
2
Door adjustments
If no light kit is installed, the hinge clips are not necessary
and the door can be allowed to swing 170 . If the door
hinges come with a 110 black plastic hinge clips are
required, snap the hinge clip over the elbow of the hinge
into the holes located on the hinge.
170
110
Remove the hinge cover or the blumotion before adjustion, see Fig 6A.
6A
Adjust the hinge of door in 3 directions to make sure the door level as shown in Fig.6B.
6B
Fig. 7 7
1179057-T01-A

STEP
3
STEP
4
Push/twist the pins into place & Fill the remaining holes with the plugs
!
!
Push one side of the shelf into the left or right clips.
Snap the shelf down into the opposite side. If the shelf is too tight, repeat the process from the other side.
&
A
B
Fig. 9 9
Fig. 8 8
Fig. 10 10
Put the tissue box, 2 level box and the glass into the cabinet as shown in Fig.8.
-7-
1179057-T01-A

-8-
STEP
5
Fig. 11 11
The step is only for the installation of defogger. See Fig 11,
external power supply.
(220V/50HZ)
220V/50HZ
1.
2.
3.
4.
5. .
6. .
7.
USER MAINTENANCEUSER MAINTENANCE
Warn! Risk of product damage.
1.
2.
3.
4.
5. The mirrored cabinet door and interior are constructed of
mirror and aluminum. Use only a damp cloth to clean.
Spray the cloth, not the mirror when cleaning. Mirrors are
damaged by the use of ammonia or vinegar based
cleaners. Rubbing alcohol can be used for stubborn stains
6. Use no abrasive cleansers on any part of the mirrored
cabinet.
7. The white frame should be cleaned with a damp cloth only.
Many cleansers contain abrasive and chemical substance
which is not suitable for cleaning stainless steel, enamel,
plating or plastic products. You may use mild cleansers or
soaps to clean the surfaces. Wipe any splashes of cleaner
solutions from the surface with clean soft cloth.
Maintain ventilation in the bathroom, and separate the dry
area from the damp one if conditions permit. Try to open
the door and windows of the bathroom and maintain good
ventilation.
Kohler mirrored cabinet are dealt with strict procedures for
damp-proof, whose good damp-proof function ensures
good performance even in bathroom of huge humidity. Yet
do not splash and pour water directly on the mirrored
cabinet. Make sure that the bathroom is not over damp
and wipe any splashes from surfaces immediately.
Maintenance of door board: Clean and wipe door board
regularly, and wipe the condensation vapor with dry and
soft cloth.
.
1179057-T01-A
