Kohler ALEUTIAN K-24203X Assembly instructions

Kohler Co. 1 1374323-X2-A
BEFORE YOU BEGIN 
ORDERING INFORMATION 
Please read these instructions carefully to familiarize yourself
with the required tools, materials, and installation sequences.
Follow the sections that pertain to your particular installation.
This will help you avoid costly mistakes. In addition to proper
installation, read all operating and safety instructions.
All information in these instructions is based upon the latest
product information available at the time of publication.
Kohler China. reserves the right to make changes in product
characteristics, packaging, or availability at anytime without
notice.
These instructions contain important care, cleaning and warranty
information - please leave instructions for the consumer.
ALEUTIAN bathroom cabinet adopts E1 grade woodbased
panel of high quality, and with further processing, its harmful
emissions will be less than 1.5 mg/L.
Turn off the water supply.
The pluming installation must comply with Water Supply
Regulations/Bye-laws, Building Regulations or any particular
 regulationsandpractices,speciedbythelocalwater
company or water undertakers.The installation should be
carried out by a plumber.
Beforeinstallationcarefullyinspectthenewxtureforany
signs of damage.
This product complies with GB 24977-2010.
This installation covers the following products in the ALEUTIAN
range:
ALEUTIAN bathroom Cabinet................................... K-24203X

 
 
 
 

 
 

 

 
 


 
 





SAFETY: WARNINGS 
Kohler products are precision-engineered and should give
continued superior and safe performance, provided:
1.They are installed, commissioned, operated and maimtained
in accordance with the recommendation given in this Manual.
2. Periodic attention is given, as necessary, to maintain the
product in good functional order. Reccomended guidelines
are given in the MAINTAINANCE section.
Carefullyinspectthenewxtureforanysignsofdamage.
When installing Kohler Products, manufacturers guidelines for
power tool safety should be followed.



 

 
 



INSTALLATION AND CARE GUIDE
ขอแนะนําการติดตั้งและการดูแลรักษา
ALEUTIAN BATHROOM CABINETS
ตู้เฟอร์นิเจอร์สำ�หรับอ่�งล้�งหน้� รุ่นอลูเชียน
K-24203X

1374323-X2-A 2 Kohler Co.
ROUGHING-IN 
UNIT:mm

INSTALLATION 
A. Install Vanity Cabinet
Install the services.
•
Connect hot and cold inlets to the inlet pipes correctly.
• Install the drain in accordance with the menufacturer’s
instructions.
We suggest using P-trap Drain. Connect P-trap pipe with
Vanity drain.
CAUTION: Makesureawatertightsealexistingonall
Vanity.
CAUTION: Provide access to the plumbing connections
for future plumbing maintenance.
Install the hot and cold water supplies with isolating valves.


• 
• 


  
  
  

Fig. 2

Fig.1
575
1164
505


Kohler Co. 3 1374323-X2-A
UNIT:mm

1. Mark the position of hanged bracket according to dimension
as illustrated, and loosen the suspension hook of washba-
sin cabinet.
CAUTION: Avoid the cables and pipes inner set when
drilling in the wall.
Note: Different types of bolts are required for different decora-
tion boards. Please apply suitable bolts and plugs.
2.Drillholesforxingthebracket.Usingalevel,ensurethat
the hanged bracket is level.
3.Usesuitableplugsandbolts,andxthehangedbracketon
the wall.
4. Hang the washbasin cabinet on the wall, and position the
suspension on the hanged bracket. See Fig.4.
Fig.3

Wall Bracket
All installation dimensions are for reference only.
2035541435520
538
175 1164


Fig.4











1374323-X2-A 4 Kohler Co.
Fig.5

MAX1
24
3
1
Fig.7

Fig.6

Fig.8

8
8
5. Set the washbasin cabinet onto the wall bracket. Be sure
the cabinet adjusted level and the back board of cabinet
appressed to the wall by adjusting the screws of wall clips.
See Fig.5.
6. Mark the wall through two holes at the corresponding
positions as illustrated in Fig 6.
7. Dismount the washbasin cabinet and put aside. Drill holes
at the marked position.
Caution! Avoid the cables and pipes inner set when
drilling in the wall.
Note: Different types of bolts are required for different
decoration boards. Please apply suitable bolts and plugs.
8. Insert the plugs into the wall.
9. Take out the middle leg and screw from the hardware pack.
Alignwiththeholeonthebottomboardandxthemiddle
leg, as shown in Fig.7.
10. Set the washbasin cabinet onto the brackets. Be sure the
cabinet adjusted level and the back board of cabinet
appressed to the wall by adjusting the screws of wall clips.
See Fig.5.
11. Apply a washer to the screw before tighten it. Make sure
thewashbasincabinethasbeenxedrmlyonthewall.
See Fig.8.







!










Kohler Co. 5 1374323-X2-A
Fig.9

Fig.10

Faucet
Supply Lines
Shut-off Valve
Drain Assembly




12. Place the hinge cover and plastic cover.
13. Adjust the hinge of door in 3 direction to make sure the
door level.


B. Install the Synthetic Top
Note: Please refer to the installation instructions of synthetic
top for its installation. To protect the cabinet from dampness,
please apply silicone sealant where the synthetic top and the
cabinet connect.
C. Connect Drainage
1. Inwall drainage (P-Trap)
Please install the drain assembly and faucet as shown.
Please set the water supply and drainage position accord-
ing to the suppliers instructions. You can put the pipe into
the U Notch.










1374323-X2-A 6 Kohler Co.
Fig.10

Faucet
Supply Lines
Shut-off Valve
Drain Assembly





Ripple Pipe
USER MAINTENANCE 
1. Many cleansers contain abrasive and chemical substance
which is not suitable for cleaning stainless steel, enamel,
plating or plastic products. You may use mild cleansers or
soaps to clean the surfaces. Wipe any splashes of cleaner
solutions from the surface with clean soft cloth.
2. Maintain ventilation in the bathroom, and separate the dry
area from the damp one if conditions permit. Try to open
the door and windows of the bathroom and maintain good
ventilation.
3. Kohler bathroom cabinet are dealt with strict procedures for
damp-proof, whose good damp-proof function ensures good
performance even in bathroom of huge humidity. Yet do not
splash and pour water directly on thebathroom cabinet.
Make sure that the bathroom is not over damp and wipe any
splashes from surfaces immediately.
4. Clean and wipe cabinet regularly, and wipe the condensation
vapor with dry and soft cloth.
5. Ensure that electrical connections for appliances such as
head lamp is insulated wipe mirror surface with chamois
  regularlytoguaranteethepersistentexcellentperformance.
6. Please do not sit, lean or step on the basin cabinet.
 
    
 
 
 
  
 
 
 
 
 
 
  
 
 
 
 
 
 
2. Floor drainage (S-Trap)
Please install the drain assembly and faucet as shown.
Please set the water supply and drainage position accord-
ing to the suppliers instructions.




WARNING!Risk of product damage. !
