Kohler K-11340X Assembly instructions

Installation and Care Guide
Pedestal Lavatory


1037277-X2-B ©2017 Kohler Co.
K-2018X/K-11340X K-2018X/K-2019X

Thank you for choosing Kohler Company

Thank you for choosing the Bold Look of Kohler. Kohler craftsmanship oers
you a rare combination of proven performance and graceful sophistication
that will satisfy you for years to come. The dependability and beauty of your
Kohler product will surpass your highest expectations. We’re very proud of
our products here at Kohler and we know you will be too.
Please take a few minutes to review this manual before you start installation. If
you encounter any installation or performance problems, please don’t hesitate
to contact us. Our phone numbers and website are listed on back cover.
All information in this manual is based upon the latest product information
available at the time of publication. At Kohler, we constantly strive to improve
the quality of our products. We reserve the right to make changes in product
characteristics, packaging or availability at any time without notice.
Thank you for choosing Kohler Company.
  The Bold Look of Kohler 
 


 

  

 


 
1037277-X2-B 2 Kohler Co.

Before You Begin
CAUTION: Risk of personal injury or product damage. Handle with
care. Product can break, chip, or cause injury if handled carelessly.
Get help lifting the lavatory.

Important Information
IMPORTANT NOTICE TO INSTALLERS!: Please leave these instructions for
the consumer. They contain important information.
In addition to installation procedures, this manual contains important care and
cleaning. Please retain for future reference.
NOTE: Some installation parts might not be provided.
NOTE: The toilet pictured in the installation steps may dier from the model
being installed.
 
 

 
 

CAUTION: Risk of personal injury. This pedestal lavatory is heavy.
Do not aempt to lift or install the pedestal lavatory without assistance.
¨Observe all local plumbing and building codes.
¨Prior to installation, unpack the new lavatory and inspect it for damage.
Return the lavatory to its protective carton until you are ready to install it.
¨ This installation guide provides installation steps for aaching the lavatory
to concrete frame construction. For other installations, supply suitable
bracing and fastening devices of sucient size and strength.
¨ The walls and the oor must be square, plumb, and level.
¨Fixture dimensions are nominal and conform to tolerances established by
Standards TIS.
Kohler Co. 3 1037277-X2-B





 

¨ 
¨ 

¨  

 
¨ 
¨ 
Tools/
1037277-X2-B 4 Kohler Co.

Roughing-In For Semi-Pedestal Lavatory

Dimensions are approximate. Unit: mm.
 
K-2018X-1/K-11340X K-2018X-8/K-11340X
76
313
197
479
610
499
ø44
102102
ø35
76
457
197
230
300
127
216
80
190
440
ø35
ø10 Anchor Holes/รูพุก
ø10 Anchor Holes/รูพุก
1/2" Hot/นํ�าร้อน 1/2" Cold/นํ�าเย็น
Finished Wall/ผนัง
Finished Floor/พื �น
1-1/2" OD
เส้นผ่าศูนย์กลาง
Kohler Co. 5 1037277-X2-B

Roughing-In For Pedestal Lavvatory

Dimensions are approximate. Unit: mm.
 
 
¨ 
¨ 
1. Prepare the site

NOTE: The open position of the supply stop handles must not extend more
than 76 mm from the nished wall.
¨Install the 1/2” water supply lines and 1-1/2” drain piping according to the
roughing-in information.
¨ Install sucient backing behind the nish wall to provide a secure material
for the anchoring devices.
1/2" Hot/นํ�าร้อน 1/2" Cold/นํ�าเย็น
ø10 Anchor Holes/รูพุก Finished Wall/ผนัง
Finished Floor/พื �น
K-2018X-1/K-2019X K-2018X-8/K-2019X
76
313
197 191
479
ø44
610
499
432
270
343
102
127 213
860
108
102 102
76
ø35
ø35
ø10 Mounting Hole
In Pedestal
รูยึดขารองอ่าง
1-1/2" OD
เส้นผ่าศูนย์กลาง
1037277-X2-B 6 Kohler Co.

Install Semi-Pedestal Lavatory

12

Mark the centerline on the wall
and floor.
Install the faucet and drain to
the lavatory.
Install the semi-pedestal to the wall with washers
and nuts.
Insert studs tighten the nuts.


Drill 3 mounting holes on
the wall. Fix hangers on the wall.
4
5


3


Kohler Co. 7 1037277-X2-B

1037277-X2-B 8 Kohler Co.
Install Pedestal Lavatory

4

Apply adhesive
gasket
ติดเทปกาว
กันกระแทก
12

Mark the centerline on the wall
and floor.
Install the faucet and drain to the
lavatory.
Gently up the front of the lavatory and hold it
and position. While the lavatory is being held up,
place the pedestal underneath the lavatory.
Gently lower the lavatory down onto the pedestal.
Fully tighten the nuts.
Install the pedestal to the wall
with clamp accessory pack kit.


Drill 3 mounting holes on
the wall. Fix hangers on the wall.
3
Install the faucet and drain to the lavatory.


5





Care and Cleaning
For best results, keep the following in mind when caring for your product:
• Carefully read the cleaner product label to ensure the cleaner is safe for use
on the material.
• Always test your cleaning solution on an inconspicuous area before applying
to the entire surface.
• Wipe surfaces clean and rinse completely with water immediately after
cleaner application. Rinse and dry any overspray that lands on nearby
surfaces.
• Do not allow cleaners to sit or soak on the surface.
• Use a soft, dampened sponge or cloth. Never use an abrasive material such as
a brush or scouring pad to clean surfaces.
• Be careful not to leave staining materials in contact with the surface for
extended periods of time.
• The ideal cleaning technique is to rinse thoroughly and blot dry any water
from the surface after each use.

 

•   

• 

• 

• 
• 

• 
• 
 
Kohler Co. 9 1037277-X2-B

1037277-X2-B 10 Kohler Co.
