C³™-455
Elongated bidet toilet seat with remote control
K-8298-CR
Features
•Hybrid heater provides continuously heated water for
consistent comfort
•Sleek, handheld remote control with two programmable user
presets
•Front and rear wash modes provide warm water for cleansing
•Adjustable water temperature and water pressure
•Choose oscillating or pulsating spray
•Heated seat with five adjustable temperature settings
•Self-cleaning function uses UV light to automatically clean the
wand surfaces
•LED lighting illuminates the bowl to serve as a nightlight
•Warm-air drying system with adjustable temperature settings
•Automatic deodorization with carbon filter for odor control
•Quiet-Close™functionality to prevent seat from slamming
•Grip-Tight bumpers hold seat firmly in place
•Quick-Release™functionality allows seat to be removed
easily from toilet for convenient cleaning
•Ergonomically contoured seat for user comfort
•Fits most elongated toilets
Material
•Plastic construction
Installation
•Requires connection to toilet water supply line. All hoses and
connections are included
•Requires dedicated electrical GFCI circuit (120V, 15A, 60Hz)
Codes/Standards
ASME A112.4.2/CSA B45.16
UL 1431
CSA C22.2 No. 64
CSA C22.2 No. 68
KOHLER®Intelligent Toilet and C3™
Cleansing Seat Three-Year Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
0 White
96 Biscuit
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-9-2023 04:19 - US/CA

C³™-455
Elongated bidet toilet seat with remote control
K-8298-CR
8-1/4"
(210 mm)
1-1/16"
(27 mm)
Remote Control
2-1/16"
(52 mm)
1-7/16"
(37 mm)
16-3/16"
(411 mm)
20-5/8"
(524 mm)
5-1/8"
(130 mm)
11-3/4"
(298 mm)
8-3/8"
(213 mm)
15-1/2" (394 mm)
18-9/16"
(471 mm) Min
19-3/8"
(492 mm) Max
1-1/4"
(32 mm)
Min
5-1/2"
(140 mm)
Electrical Service Detail
32" (813 mm) R.
6" (152 mm) Min
2"
(51 mm)
13-1/4"
(337 mm)
Min
Required Electrical Service
One dedicated circuit required, protected with Class A Ground-
Fault Circuit-Interrupter (GFCI). Outside North America, this
device may be known as a Residual Current Device (RCD).
120 V, 15 A, 60 Hz
Technical Information
All product dimensions are nominal.
Seat shape type: Elongated
Seat front type: Closed-front
Seat-mounting
holes:
5-1/2" (140 mm)
Power cord length: 43" (1092 mm)
Notes
Install this product according to the installation
instructions.
Connect the seat to a cold water supply of
drinking quality water at a pressure of 20 psi -
80 psi (139 kPa - 551 kPa).
Do not install this seat in a location where: (1)
water might be splashed on the product or
(2) excessive moisture, high humidity levels,
or condensation is present. This will avoid
damage to the electronic components.
CAUTION: Risk of property damage. A single
extension cord may be used provided the cord
“Type” begins with “SJ”, 12 gauge, grounded
(12/3), no longer than 25 feet, and plugged into
a GFCI outlet. Promptly replace any extension
cord that exhibits any sign of damage.
To avoid possible product malfunction, do not
plug in the seat until instructed to do so.
Locate the recepticle at least 6" (152 mm)
above the floor, and within a 32" (813 mm)
radius measured 2" (51 mm) from the bowl
ledge.
