Konftel 200W User manual

Conference phones for every situation
English
Quick Guide
Konftel DECT base station

Konftel DECT base station is GAP-compatible for analogue connection to the telephone
network. Seven handsets (or conference phones) can be connected (registered) to one base
station.
DESCRIPTION – KONFTEL DECT BASE STATION
Connection
Connect the base station to a telephone jack and the mains using the power adapter as il-
lustrated.
Wall suspension
The base station can be mounted on the wall. Use the screws provided as illustrated. Make
sure it is securely mounted.
92 mm
Power adapter
KG35-6-300D
Holes for wall
suspension
Power supply Line connectionKey and LED
2 m
Screw

Reg
Base 1
0-9...
PIN:
****
Done
Search
PARK:
DECT system:
Here we explain how to register a Konftel 200W conference phone. To register other makes
of handsets (telephones), simply follow the same procedure. Please refer to your telephone
instruction manual if you are unsure.
Set the Konftel DECT base station in registration mode
 Press and hold the key/LED on the base station until it starts to flash.
The base station is now in registration mode. Once registration has been completed, the
LED will stop flashing. If the base station does
not identify a DECT phone within 2 minutes, the
registration mode will switch off automatically.
 Press the MENU key.
 Select the menu “Tools” using the Up/down key.
 Press OK.
 Select the menu Reg using the Up/down key.
 Press OK.
 Select a base (1–4).
If no base station has been programmed, choose no. 1. Numbers
that are ticked are being used.
 Press OK.
 Select a DECT system.
 Press OK.
 Enter the security code (PIN code) (standard code is 0000).
 Press OK.
 Press OK. (Leave the PARK code blank.)
Your Konftel 200W is now in registration mode and is searching
for a base station in registration mode. Wait until you receive
confirmation that registration has been completed. Registration
can be interrupted by pressing C. If registration was successful,
the word Done will appear in the display.
 Press OK.
The Konftel 200W is now ready to use.
REGISTERING A HANDSET (CONFERENCE PHONE)
Register Konftel 200W with a
Konftel DECT base station

Developed by Konftel AB
Box 268, SE-901 06 Umeå, Sweden
Phone: [phone] Fax: [phone]
E-mail: [e-mail] Web: www.konftel.com
Konftel is a leading company within loudspeaker communication and audio technology. We deve-
lop and sell products and technology for telephone conferences based on cutting-edge expertise
within acoustics and digital signal processing. Characteristic of our products is that all conference
telephones contain the same high quality audio technology – OmniSound® providing crystal clear
sound. Read more about Konftel and our products on www.konftel.com.
3141-61-001 rev A
