Kontron coolMonster/PM User manual

coolMonster/PM
User’s Guide
Document Revision 1.0
StockCheck.com

coolMONSTER/PM User’s GuideContents
i
CONTENTS
1. USER INFORMATION.........................................1
1.1 About This Manual.....................................1
1.2 Copyright Notice......................................1
1.3 Trademarks............................................2
1.4 Standards.............................................2
1.5 Warranty..............................................2
1.6 TechnicalSupport.....................................3
2. INTRODUCTION.............................................4
2.1 coolMONSTER/PM........................................4
2.2 The coolMONSTER PISA®Family..........................4
3. GETTING STARTED..........................................6
4. SPECIFICATIONS...........................................7
4.1 Functional Specifications.............................7
4.2 Mechanical Specifications.............................9
4.2.1 PISA Bus Connector....................................9
4.2.2 Dimensions............................................9
4.2.3 Height on Top.........................................9
4.2.4 Height on Bottom......................................9
4.2.5 Weight................................................9
4.3 Electrical Specifications............................10
4.3.1 Supply Voltages......................................10
4.3.2 Supply Voltage Ripple................................10
4.3.3 Supply Current (typical).............................10
4.3.4 Supply Current (maximum).............................10
4.3.5 Real-time Clock (RTC) Battery........................12
4.4 MTBF.................................................13
4.5 Environmental Specifications.........................14
4.5.1 Temperature..........................................14
4.5.2 Humidity.............................................14
5. CPU, CHIPSET AND SUPER I/O..............................15
5.1 CPU..................................................15
5.2 Chipset..............................................16
5.2.1 GMCH (855GMEChipset)................................16
5.2.2 ICH4 (82801DB).......................................17
5.3 SuperI/O............................................18
5.4 CPU, Chipset and Super-I/O Configuration.............18
6. SYSTEMMEMORY...........................................19
KONTRON
Contentsii coolMONSTER/PM User’s Guide
7. PISA BUS................................................20
8. FRONT PANEL.............................................21
9. KEYBOARD AND MOUSE INTERFACE............................22
9.1 PS/2-Keyboard Connector..............................22
9.2 PS/2-Keyboard Configuration..........................22
9.3 PS/2-Mouse Connector.................................23
9.4 PS/2-Mouse Configuration.............................23
10. USB INTERFACES..........................................24
10.1 Front Connectors ( USB 0 and USB 1)..................24
10.2 Internal Connector (USB 2)...........................24
10.2.1 Limitations of USB Port 2............................24
10.3 Configuration........................................25
11. ETHERNET INTERFACE......................................26
11.1 Ethernet Controller..................................26
11.2 Connector............................................27
11.3 Configuration........................................27
11.4 Ethernet Technical Support...........................28
12. GRAPHIC INTERFACES......................................29
12.1 Video Controller.....................................29
12.2 CRT Connector........................................29
12.3 DVO Connector........................................30
12.4 Flat Panel LVDS Interface (JILI) Connector...........31
12.5 Display Power Considerations.........................31
12.6 Connecting a LCD Panel...............................32
12.7 Configuration........................................32
12.8 Graphics Technical Support...........................33
12.9 Available Video Modes................................33
12.9.1 Standard IBM-Compatible VGA Modes....................33
12.9.2 Extended VESA VGA Modes..............................34
13. SERIAL-COMMUNICATION INTERFACES.........................35
13.1 Serial Ports COMA to COMD............................35
13.2 RS-232 Connectors....................................35
13.3 RS-485 Connector.....................................36
13.4 Configuration........................................36
13.4.1 RS-485 Diagram.......................................37
14. PARALLEL-PORT INTERFACE.................................38
14.1 Connector............................................38
14.2 Configuration........................................39
15. EIDE INTERFACES.........................................40
15.1 Connector............................................41
StockCheck.com

coolMONSTER/PM User’s GuideContents
iii
15.2 Configuration........................................41
15.3 Signal Descriptions..................................41
15.4 Configuration........................................42
15.4.1 Primary EIDE Pin-out.................................42
15.4.2 Secondary EIDE Pin-out...............................42
15.5 Signal Descriptions..................................44
15.6 Configuration........................................44
16. FLOPPY INTERFACE........................................45
16.1 Connector............................................45
16.2 Configuration........................................46
17. SOUND INTERFACE.........................................47
17.1 Connector............................................48
17.2 Configuration........................................48
17.3 Technical Support for Sound..........................48
18. FEATURE INTERFACE.......................................49
18.1 Connector............................................49
18.2 Configuration........................................49
18.3 Signal Description...................................49
19. FAN INTERFACE...........................................52
19.1 CPU Fan Connector....................................52
19.2 CPU Fan Configuration................................52
20. POWER INTERFACE.........................................53
20.1 Connector............................................53
20.2 Configuration........................................54
21. WATCHDOG TIMER..........................................55
21.1 Configuration........................................55
21.2 Programming..........................................55
21.2.1 Initialization.......................................55
21.2.2 Trigger..............................................55
22. HARDWARE MONITOR........................................56
22.1 Configuration........................................56
23. IMPORTANT TECHNOLOGY INFORMATION........................57
23.1 Max CPU Frequency setting............................57
23.2 Thermal Monitor and Catastrophic Thermal Protection..58
23.2.1 ThermalMonitor......................................58
23.2.2 CatastrophicThermal Protection......................58
23.3 ProcessorPerformanceControl........................59
23.4 Thermal Management...................................59
23.4.1 Processor Clock Throttling...........................60
23.5 I/O APIC vs. 8259 PIC Interrupt mode.................61
KONTRON
Contentsiv coolMONSTER/PM User’s Guide
23.6 Native vs. compatible IDE mode.......................62
23.6.1 CompatibleIDE Mode..................................62
23.6.2 NativeMode..........................................62
23.6.3 NativeMode Configuration............................62
24. APPENDIX A: SYSTEM-RESOURCE ALLOCATION..................63
24.1 InterruptRequest (IRQ) Lines........................63
24.2 Direct Memory Access (DMA) Channels..................64
24.3 Memory Map...........................................65
24.3.1 Using Expanded Memory Managers.......................66
24.4 I/O Address Map......................................67
24.5 Peripheral Component Interconnect (PCI) Devices......68
25. APPENDIX B: BIOS OPERATION..............................69
25.1 Determining the BIOS Version.........................69
25.2 Configuring the System BIOS..........................70
25.2.1 Start Phoenix BIOS Setup Utility.....................70
25.2.2 General Information..................................70
25.3 Main Menu............................................72
25.3.1 Master or Slave Submenus.............................73
25.4 Advanced Menu........................................74
25.4.1 Advanced Chipset Control Submenu.....................74
25.4.2 PCI/PNP Configuration Submenu........................75
25.4.3 PCI Device, Slot #x Submenu..........................75
25.4.4 PCI/PNPISAIRQ Resource Exclusion Submenu...........76
25.4.5 Memory Cache Submenu.................................77
25.4.6 I/O Device Configuration Submenu.....................78
25.4.7 USB Options..........................................78
25.4.8 LAN Options..........................................79
25.4.9 SIO Options..........................................79
25.4.10 Keyboard Features Submenu............................80
25.4.11 Hardware Monitor Submenu.............................80
25.4.12 Watchdog Settings Submenu............................81
25.4.13 Display Control Submenu..............................81
25.4.14 Miscellaneous Submenu................................82
25.5 SecurityMenu........................................83
25.6 Power Menu...........................................84
25.6.1 ACPI Resume Events...................................84
25.6.2 ACPI Control Submenu.................................86
25.7 Boot Menu and Utilities..............................87
25.7.1 MultiBoot XP.........................................87
25.7.2 Boot FirstFunction..................................88
25.8 Exit Menu............................................89
25.9 Kontron BIOSExtensions..............................90
25.9.1 JIDA BIOS extension..................................90
25.9.2 Remote Control Client Extension......................90
25.9.3 LAN PXE ROM..........................................91
StockCheck.com

coolMONSTER/PM User’s GuideContents
v
25.10 Updating or Restoring BIOS Using PhoenixPhlash.......92
25.10.1 Flashinga BIOS......................................92
25.10.2 Preventing Problems When Updating or RestoringBIOS..93
26. APPENDIX C: BLOCK DIAGRAM...............................94
27. APPENDIX D: MECHANICAL DIMENSIONS.......................95
27.1 Top View.............................................95
27.2 Slot View............................................95
28. APPENDIX E: CONNECTOR LAYOUT............................96
28.1 Top Side.............................................96
28.2 BottomSide..........................................97
28.3 Connector Functions and Interface Cables.............98
28.4 Pin-out Table.......................................100
29. APPENDIX F: PC ARCHITECTURE INFORMATION................102
29.1 Buses...............................................102
29.1.1 PISA................................................102
29.1.2 ISA, Standard PS/2- Connectors.....................102
29.1.3 PCI.................................................102
29.2 General PC Architecture.............................103
29.3 Ports...............................................103
29.3.1 RS-232 Serial.......................................103
29.3.2 ATA.................................................104
29.3.3 USB.................................................104
29.4 Programming.........................................104
30. APPENDIX G: DOCUMENT REVISION HISTORY..................105
KONTRON
Contentsvi coolMONSTER/PM User’s Guide
StockCheck.com

KONTRON
coolMONSTER/PM User’s GuideUser Information
1
1. User Information
1.1 About ThisManual
This document provides information about products from KONTRON
Embedded Computers AG and/or its subsidiaries. No warranty of
suitability, purpose, or fitness is implied. While every attempt
has been made toensure that theinformation in this document is
accurate, the information contained within is supplied “as-is”
and is subject to change without notice.
For the circuits, descriptions and tables indicated, KONTRON
assumes no responsibility as far as patents or other rights of
third parties are concerned.
1.2 CopyrightNotice
Copyright © 2005 KONTRON Embedded Computers AG.
All rights reserved. No part of this manualmay be reproduced,
transmitted, transcribed, stored in aretrieval system, or
translated into any language or computer language, in any form
or by any means (electronic, mechanical, photocopying,
recording, or otherwise), withouttheexpresswritten permission
of KONTRON.
JUMPtec Industrielle Computertechnik AG and KONTRON Embedded
Computers AG merged in July 2002. JUMPtec is now known as
KONTRON EmbeddedModules GmbH. Products labeledand sold under
theKONTRON Embedded Modules name (formerly JUMPtec)are now
considered KONTRON products for all practical purposes,
including warranty and support.
DIMM-PC®, PISA®, ETXComponents SBC, ETXexpress, x-board,
JUMPtec®, and KONTRON Embedded Modules are registeredtrademarks
of KONTRON Embedded Modules GmbH©.
KONTRON
User Information 2coolMONSTER/PM User’s Guide
1.3 Trademarks
The following lists the trademarks of components used in this
board.
†IBM,XT, AT, PS/2and PersonalSystem/2aretrademarksof
InternationalBusinessMachinesCorp.
†Microsoftis a registered trademark of Microsoft Corp.
†Intel is a registered trademark ofIntel Corp.
†All otherproducts andtrademarks mentionedin this manual
are trademarks oftheir respectiveowners.
1.4 Standards
KONTRON Embedded Modules is certified to ISO 9000 standards.
1.5 Warranty
ThisKONTRON Embedded Modules product is warranted against
defects in material and workmanship for the warranty period from
the date of shipment. During the warranty period, KONTRON
Embedded Modules will at its discretion, decideto repair or
replace defective products.
Within the warranty period, the repair of products is free of
charge as long as warranty conditions are observed.
The warranty does not apply to defects resulting from improper
or inadequate maintenance or handling by the buyer, unauthorized
modification or misuse, operation outside of the product’s
environmental specifications or improper installation or
maintenance.
KONTRON Embedded Modules will not be responsible for any defects
or damages to other products not supplied by KONTRON Embedded
Modules that are caused by afaulty KONTRON Embedded Modules
product.
StockCheck.com

KONTRON
coolMONSTER/PM User’s GuideUser Information
3
1.6 TechnicalSupport
Technicians and engineers from KONTRON Embedded Modules and/or
its subsidiaries and official distributors are available for
technical support. We are committed to makingour product easy
to use and will help you use our products in your systems.
Before contacting KONTRON Embedded Modules technical support,
please consult our Web site for thelatest product
documentation, utilities, and drivers. If the information does
not help solve the problem, contact us by telephone.
Asia Europe North/South America
Kontron Embedded
Technology(Asia Pacific)
Kontron Embedded Modules GmbH Kontron America
Far East Science Park,2nd
Floor No. 2, Lane 50,Nan
Kang Road Section 3, Nan
Kang District Taipei, Taiwan
Brunnwiesenstr. 16
94469 Deggendorf – Germany 14118 StoweDrive Poway,CA 92064-7147
Tel: [phone]
Tel: [phone] Tel: [phone]
Fax: [phone]
Fax:[phone] Fax:[phone]
KONTRON
Introduction 4coolMONSTER/PM User’s Guide
2. Introduction
2.1 coolMONSTER/PM
ThecoolMONSTER/PM hosts an Intel® Pentium® Mprocessor in
combination withan Intel® 855GME chipset with an integrated
graphic memory controller hub. Celeron Mversionsof this board
are possible, too. OneDDR-SDRAM-DIMM socket for up to 1GB
allows you to use standard DDR DIMM memory modules. ThreeUSB
2.0 ports andone10/100 MBit Ethernet interface extend the
standard connectivity offourserial, one parallel and aPS/2
mouse/keyboard interface.
ThecoolMONSTER/PM is designedin the PISAformat, which
provides the functionality of thePCI and ISA bus on one well-
defined bus. To connect abackplane with aPISA board, you only
need to useone EISA-like edge card connector. The pin-out of
the upper row of the PISA bus connectorcorresponds to the pin-
out of the ISA bus connector. The lower row provides PCI
signals, which makes it easy to design backplanes with up to
four PCI slots and additional ISA slots.
2.2 ThecoolMONSTER PISA®Family
coolMONSTER products represent the best scaleablehalf-size Slot
SBC family. Each coolMONSTER module is characterized by the same
mechanical and electrical pin-out for the Keyboard, COM A-D,
EIDE 40pin and 44pin, LPT, LAN, VGA, USB, and Floppy. These
homogeneous features facilitate easiest upgrades within the
Kontron Embedded Modules GmbH coolMONSTER product family.
PISA® is the proven space saving concept that provides full PCI
and ISA Bus signals on just half-size Slot boards. The ancestors
were full-sized PICMG boards that have the PCI and ISA card
edges inarow -PISA squeezed them to just half-size, still
serving full PCI and ISA busses.Smaller and cheaper enclosures
were possible that way-while all PCI and ISA periphery is
maintained.
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide5Specifications
Whenever aLCD panel is required, coolMONSTER products with
onboard graphics controllers serve as the right choice. Display
connections are simplified when using these units, which come
with aJUMPtec Intelligent LVDS Interface (JILI) or JUMPtec
Intelligent Display Adaption (JIPA). The interface can recognize
which display is connected and then independently set all video
parameters.
As part of the standard features package, all coolMONSTER
modules come with aJUMPtec Intelligent Device Architecture
(JIDA) interface, which is integrated into the BIOS of the SBC
modules. This interface enables hardware independent access to
the coolMONSTER features that cannot be accessed via standard
APIs. Functions such as watchdog timer, brightness and contrast
of LCD backlight and user bytes in the EEPROM can be configured
with ease by taking advantageof this standard coolMONSTER
module feature.
KONTRON
Specifications 6coolMONSTER/PM User’s Guide
3. Getting started
Getting started with thecoolMONSTER/PMis very easy. For
location of the connectors, see Appendix E: Connector Layout.
Take the following steps:
1. Turnoff the powersupply.
2. Connectthepowersupplyto thecoolMONSTER’spower supply
connectoror power theboardthrough a backplane.
3. Pluga memorymodule into the memory socketof the
coolMONSTER/PM.
4. ConnecttheCRTmonitor totheCRTinterface oraLCD panel
totheJILI interface byusingacorresponding adapter
cable.
5. Plugthe keyboardand the mouse tothe PS/2connectorsor
use USBkeyboard ormouse.
6. Connectthefloppy drivecableto thecoolMONSTER’s floppy
interface. Attachthe floppydrivetotheconnector atthe
opposite end ofthecable.
7. Connectthepowersupplyto the floppy’s power connector.
8. Plugahard-drivedatacableto thecoolMONSTER’shard-disk
interface.
9. Attach the harddisk to the connectorat the opposite end
ofthe cable.
10. Ifnecessary,connect the power supply tothehard disk’s
powerconnector.
11. Ifrequired, plugaISA orPCIextensioncardto the
appropriateslot inthe backplane
12. Makesureallyour connectionshavebeen madecorrectly.
13. Turnonpower.
14. Enter theBIOS bypressingtheF2 keyduring boot-up. Make
all changesin the BIOS setup.Seethe BIOSchapter ofthis
manual for details.
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide7Specifications
4. Specifications
4.1 Functional Specifications
†Processor
•Intel® Pentium®-M 1.8GHz CPU
•Intel® Celeron®-M 1.0GHz ULV
•Intel® ZeroCache CPU0.8GHz ULV
•CPU socket supports all Pentium®-M in PGA package
•Further processorsupport planned
†Chipset
•Intel® 855GME Chipset graphics memory controller hub
†PowerSupply
•5V only supply
•Onboard power supply to low voltage technology
†SuperI/O
•SMSC SCH3114
†Cache
•On-die second level cache between512KB and 2MBdepending
on used CPU
†Memory
•One184-pin DIMM unbuffered DDR SDRAM, up to 1GB
†FourSerialPorts(COMA to COM D)
•3 RS232C serial ports (1 DSUB9 at the front, 3internal,
10-pin headers)
•16550 compatible
•COM Dconfigurable as RS422/485
†One Parallel Port(LPT1)
•Enhanced Parallel Port (EPP) and Extended Capabilities Port
(ECP) with bi-directional capability
†Floppy Interface
†IntelligentDriveElectronics(IDE)
•TwoUDMA Peripheral Component Inter-connect (PCI) Bus
Master IDE port(each up to two devices)
†System Monitor Controller for Temperatureand
†UniversalSerial Bus(USB)
KONTRON
Specifications 8coolMONSTER/PM User’s Guide
•3 USB 2.0 ports(2 at the front, 1 internal on feature
connector)
•USB legacy keyboard support
•USB-boot support
†Ethernet
•Integrated Intel® 82562 10/100BASE-T LAN
•Follows the common criteria of the embedded technology
market segment
†OnboardVideoGraphicsArray(VGA)
•Intel® 855GM/GME Chipset graphics memory controller hub
with Intel® Extreme Graphics 2technology
•CRT (Cathode Ray Tube) and LCD flat panel LVDS interface
(JILI)
•LCD (Liquid Crystal Display) flat panel 2x24bit LVDS
interface that uses JILI
†Audio
•Integrated in Intel® SoundBlaster™ AC97
•Windows Sound System™ compatible
†PhoenixBIOS,1024KBFlashBIOS
†NV-EEPROMforCMOSSetupRetention without Battery
†PS/2KeyboardController
†PS/2MouseController
†Watchdog timer (WDT)
†RealTimeClock(RTC) withOnboardBattery Supply
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide9Specifications
4.2 Mechanical Specifications
4.2.1 PISA Bus Connector
†Edgecardconnector,EISA standard, AMP650226-1 (or
compatible)
4.2.2 Dimensions
†Length x Width:176mmx125mm(6.9” x 4.9”)
4.2.3 Height on Top
†Ca40 mm (1.6”)
†Height isdependinguponSDRAMmoduleandCPUcooler/fan.
Thiscan block PCI or ISA slots onsomebackplanes.
4.2.4 Height onBottom
†Maximum4mm (0.16”)
4.2.5 Weight
†320g(full featuredversion withoutSDRAM)
KONTRON
Specifications 10 coolMONSTER/PM User’s Guide
4.3 Electrical Specifications
4.3.1 Supply Voltages
†+5V DC +/- 5%
†Optional +5V DCStandby +/-5%
4.3.2 Supply Voltage Ripple
†100mV peak topeak 0 -20MHz
4.3.3 Supply Current(typical)
ThecoolMONSTER/PMis equipped with power-saving features.
Different power-consumption tests wereexecuted to give an
overview of the electrical conditions for several operational
states. The board used a512MB DDR SDRAM module. The attached
hard disk was not supplied through the measurement path and no
extensioncard was attached tothe system.
†coolMONSTER/PM 1.0GHz(Celeron-M®)
ATPower SupplyOperationState +5V only
DOS Prompt 2.37A
DOSStandby 1.60A
Windows Idle 1.66A
Windows Standby 1.22A
Windows 100%CPU Load 2.52A
†coolMONSTER/PM 1.8GHz
ATPower SupplyOperationState +5V only
DOS Prompt 4.29A
DOSStandby 2.63A
Windows Idle 2.79A
Windows Standby 1.32A
Windows 100%CPU Load 6.39A
4.3.4 Supply Current(maximum)
ATPower SupplyBoard +5V only
coolMONSTER/PM 1.0GHz 3.90A
coolMONSTER/PM 1.8GHz 8.75A
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide11 Specifications
(calculated theoretical values from all components maximum
supply currents)
KONTRON
Specifications 12 coolMONSTER/PM User’s Guide
4.3.5 Real-time Clock (RTC) Battery
†Voltagerange: 1.8V- 4.0V(typ 3.0V)
†Quiescentcurrent: max. 3,5uA@3.0V
English:
CAUTION ! Danger of explosion if battery is incorrectly replaced. Replace only with
the sameor equivalent type recommended by the manufacturer.Dispose of used
batteries according to the manufacturer's instructions.
Deutsch:
VORSICHT! Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz
nur durchdenselben oder einen vom Hersteller empfohlenen gleichwertigen Typ.
Entsorgung gebrauchter Batterien nach Angaben des Herstellers.
French:
ATTENTION !Risque d'explosion avec l'échange inadéquat de la batterie.
Remplacement seulement par le même ouun type équivalent recommandé par le
producteur.L'évacuation des batteries usagées conformément àdes indications du
fabricant.
Danish:
ADVARSEL ! Lithiumbatteri – Eksplosionsfare ved fejlagtig Håndtering. Udskifting
må kun skemed batteri af samme fabrikant og type. Lever det brugte batteri tilbage til
leverand∅ren.
Finnish:
VAROITUS ! Paristo voi rãjãhtãã, jos se on virheellisesti asennettu. Vaihda paristo
ainoastaan laltevalmistajan suosittelmaan tyyppiln. Havita kaytettyparisto
valmistajan ohjeiden mukaisesti.
Spanish:
Precaución ! Peligrode explosión si labateríase sustituye incorrectamente.
Sustituya solamente por el mismo o tipo equivalente recomendado porel fabricante.
Disponga las baterías usadas según las instrucciones del fabricante.
The batteryofthis product is not considered to be accessible bythe end user. Safety
instructions are given onlyinEnglish, German, French, Danish, Finish and Spanish. Ifthe
batteryis accessible bythe end user, it is in the responsibility of thecustomer to give the
corresponding safety instructionsin the required language(s).
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide13 Specifications
4.4 MTBF
The following MTBF (Mean TimeBetween Failure) values were
calculated usingacombination of manufacturer’stest data, if
the data was available, and aBellcore calculation for the
remaining parts. The Bellcore calculation used is “Method 1Case
1”. In that particular method the components are assumed to be
operating at a50 %stress level in a40° Cambient environment
and the system is assumed to have not been burned in.
Manufacturer’s data has been used wherever possible. The
manufacturer’s data, when used, is specified at 50° C, so in
that sense the following results are slightly conservative. The
MTBF values shown below are for a40° Cin an office or
telecommunications environment. Higher temperatures and other
environmental stresses (extreme altitude, vibration, salt water
exposure, etc.) lower MTBF values.
†System MTBF (hours): (171.636) TBD
Notes: Fans usuallyshipped withKontron Embedded Modules GmbH products have
50,000-hour typical operating life. The above estimates assume no fan, but a
passive heat sinking arrangement.
Estimated RTC batterylife (as opposed to batteryfailures) is not accounted forin
the above figures and need to be considered for separately.Batterylife depends
on bothtemperature and operating conditions.When the Kontron unit has
external power;the onlybatterydrain is from leakage paths.
KONTRON
Specifications 14 coolMONSTER/PM User’s Guide
4.5 EnvironmentalSpecifications
4.5.1 Temperature
The IntelMobile Pentium-M is specified for proper operation
when junction temperature is within the specified range of 0°Cto
100°C.
The Intel® 855GM/GME Chipset temperature and the Intel® ICH4 I/O
Controller Hub 4 (82801DB) case temperature are maximum 110°C.
†Operating: 0 to+65C (*)(withappropriate airflow)
†Non-operating: -10 to +85 °C (non-condensing)
Note:(*) The maximum operating temperatureis the maximum measurable
temperature on anyspoton the module’s surface. You must maintain the
temperature according to the above specification.
4.5.2 Humidity
†Operating: 10% to90% (non-condensing)
†Non-operating: 5%to95%(non-condensing)
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide15 CPU, Chipset and Super I/O
5. CPU, Chipset andSuper I/O
5.1 CPU
ThecoolMONSTER/PMis availablewith an Intel® Mobile Pentium®-M
or Celeron®-Mcentral processing unit (CPU) from0.8GHzup to
1.8GHz or 1.8GHz. However, other GHz as well as Celeron®-M
versions (half cache size, no SpeedStep® technology) of this
board are available.
IntelMobile Pentium-M CPU features include:
†SupportsIntel® Architecturewith DynamicExecution
†Highperformance,low-power core
†On-die,primary32-kbyteinstruction cache and 32-kbyte
write-back datacache
†On-die,up to 2-MByte(dependson CPU) secondlevel cache
withAdvancedTransferCacheArchitecture
†Advanced BranchPredictionandDataPrefetch Logic
†StreamingSIMD Extensions 2 (SSE2)
†400-MHz,Source-Synchronous processorsystem bus
†Advanced PowerManagement features,includingEnhanced
IntelSpeedStep® technology(only forPentium® M
processors)
KONTRON
CPU, Chipset and Super I/O 16 coolMONSTER/PM User’s Guide
5.2 Chipset
The chipsetof thecoolMONSTER/PMconsists of the Intel® 855GME
chipset GMCH (Graphics and Memory Controller Hub)and the Intel
® 82801DB ICH-4 (I/O Controller Hub 4).
5.2.1 GMCH (855GME Chipset)
†Processor/Host BusSupport
•Intel® Pentium® Mand Celeron® Mprocessors
•Supports system bus at 400MHz
•Supports Enhanced Intel® SpeedStep® technology
†Memory System
•Directly supports one DDR SDRAM channel, 64-bits wide
•Supports 200/266-MHz DDR SDRAM devices with double-sided
DIMMs (four rows populated)with unbuffered PC1600/PC2100
DDR SDRAM.
•Supports 128-Mbit, 256-Mbit, and 512-Mbit technologies
providing maximumcapacity of 1GB with x16 devices
•All supported devices have four banks
†Internal GraphicsFeatures
•Up to 32MB of dynamic video memory allocation
•Display imagerotation
•Graphics corefrequency
•Display core frequency at 133MHz or 200MHz
•Render core frequency at 100MHz,133MHz, 200MHz
•2D graphics engine
•3D graphics engine
•Single- or dual-channel LVDS panel support up to UXGA panel
resolution withfrequency range from 25MHz to 112MHz
(single channel/dual channel)
†VideoStream Decoder
•Improved hardware motion compensation for MPEG2
•Software DVD at 60 Fields/second and 30 frames/second full
screen
•Support for standard definition DVD (i.e. NTSC pixel
resolution of 720x480, etc.)
•quality encoding at low CPU utilization
†PowerManagement
•APM 1.2 compliant power management
•ACPI 1.0b, 2.0 support
•Enhanced Intel® SpeedStep Technology support
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide17 CPU, Chipset and Super I/O
5.2.2 ICH4 (82801DB)
†PCI 2.2Businterface at33MHz
†Integrated LAN controller
•WfM 2.0 and IEEE802.3 compliant with 10/100 Mbit/s Ethernet
support
†USB
•Two UHCI USB 1.1 or one EHCI high speed USB 2.0 host
controller(s)
•Supporting up to3 ports (2 available on the coolMONSTER
board’s slot connector, 1 on internal feature connector)
†AC-LinkforAC’97support
†Integrated IDEcontroller
•Ultra ATA/100/66/33 and PIO mode support
•Two channelsfor up to 4 devices with independent timing
•Support of “Native Mode” register and interrupts
†InterruptController
•Two cascade 83C59with 15 interrupts
•Integrated I/O APIC capability with 24 interrupts
†EnhancedDMA
•Two cascaded 8237 controllers
•Supports PC/PCI DMA and LPC DMA
•Supports DMA collection buffers
†Timers based on82C54
†PowerManagement Logic
•ACPI 2.0 compliant
•Supports PCI PME#
†Low PinCount(LPC)Interface
†SMBus 2.0 interface(SystemManagementBus)
KONTRON
CPU, Chipset and Super I/O 18 coolMONSTER/PM User’s Guide
5.3 SuperI/O
The super I/Odevice is aSMSC SCH3114 that is connected to the
LPC (Low Pin Count) Bus. This device provides the following
additional features:
†Fourserialports(oneport capableof RS422/RS485
functionality)
†One Multi-Mode Parallel Port
†Floppy DiskController
†PS/2-KeyboardControllerandPS/2-MouseInterface
†5VCPU Fan
5.4 CPU,ChipsetandSuper-I/O
Configuration
See the Advanced Menu and its submenus section of the Appendix
B: BIOS chapter for information on possible settings.
StockCheck.com

KONTRON
JRex-PM User’s Guide 19 System Memory
6. SystemMemory
ThecoolMONSTER/PMsupports 184-pin DIMM DDR-SDRAM memory
modules. Twosocketsare available for 2.5V (power level),
unbuffered double data rate synchronous dynamic random access
memory (DDR-SDRAM) up to 1024MB following Intel’s DDR266/PC2100
Specification.
The supported devices on the DDR-SDRAM module must be 128-Mbit,
256-Mbit or 512-Mbit technologies chips. All modules validated
by Intel with the 845 chipset and minimum DDR266 speed are
electrical ready with the 855 chipset (A similar memory
interface is used on the two chipsets.)
Notes:Some older modules and modules out of specification are designed for2.7V
(power level). These modules maynot work well atthe coolMONSTER/PM.
The total amount of memory available on the DDR-SDRAM modulesis
used for main memory and graphicsmemory on thecoolMONSTER/PM.
Unified Memory Architecture (UMA) manages thesharing of the
system memory between the graphics controller and processor.
Full system memory size is not available for software
applications. Up to 32MB of system memory are used for graphics
memory.
KONTRON
Keyboard andMouse Interfaces 20 coolMONSTER/PM User’s Guide
7. PISA Bus
PISA® is the proven space saving concept that provides full PCI
and ISA Bus signals on just half-size Slot boards. The edgecard
connector provides the ISA signals on the upper row and the PCI
signals on the lower row and uses the same connector known from
EISA systems.
Adetailed description of the signals and its timing
characteristics is beyond thescope of this document. Refer to
the PISA specification PISAD??? (the three questionmarks holding
the revision number) available on the Kontron web sites and the
official ISA-and PCI-specifications for further details.
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide21 Keyboard and Mouse Interface
8. Front Panel
ThecoolMONSTER/PMcomeswithafrontpanel interface that
providesthefollowingconnectivity:
†CRTinterface
†Ethernetinterface
†2USB2.0ports
†PS/2 keyboardconnector
†PS/2 mouseconnector
KONTRON
Keyboard andMouse Interfaces 22 coolMONSTER/PM User’s Guide
9. Keyboard and Mouse Interface
ThecoolMONSTER/PM offers aPS/2-keyboard and PS/2-mouse
interface on ConnectorsX15 and X16.The lowerinterface is for
the Mouse and the upperinterface for the Keyboard connection.
To find the location of the keyboard and mouse connector, please
see the Appendix E: Connector Layout chapter.
9.1 PS/2-KeyboardConnector
The following tableshows thepin-out of the PS/2-keyboard
connector onthe front.
HeaderPinSignalName Function
1KBDATPS/2 Keyboard data (bi-directional I/O)
2MSDATPS/2 Mouse data (bi-directional I/O)
3GND Ground
4VCC *+5V
(max. current 500mA, shared withPS/2 Mouse Con)
5KBCLK PS/2 Keyboard clock(bi-directional I/O)
6NCPS/2 Mouseclock(bi-directional I/O)
Notes:(*)To protect the external power lines of peripheral devices, makesure that:
-- the wires have the right diameter to withstand the maximum available current
-- the enclosure of the peripheral device fulfils the fire-protecting requirements of
-- IEC/EN 60950.
9.2 PS/2-KeyboardConfiguration
Refer to the Keyboard Features submenu and the I/O Device
Configuration submenu in the Appendix B: BIOS chapter for
information on configuration.
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide23 Keyboard and Mouse Interface
9.3 PS/2-Mouse Connector
The following table shows the pin-out of the PS/2-Mouse
connector onthe front.
HeaderPinSignalName Function
1MSDATPS/2 Mouse data (bi-directional I/O)
2NCNot connected
3GND Ground
4VCC *+5V
(max. current 500mA, shared withPS/2 KeyboardCon)
5MSCLK Mouse clock(bi-directional I/O)
6NCNot connected
Notes:(*)To protect the external power lines of peripheral devices, makesure that:
-- the wires have the right diameter to withstand the maximum available current
-- the enclosure of the peripheral device fulfils the fire-protecting requirements of
-- IEC/EN 60950.
9.4 PS/2-Mouse Configuration
You can set the PS/2 mouse to enabled, disabled or auto-detect
from the BIOS Setup. If you enable the mouse, IRQ12 is used as
the interrupt and is no longer available for other devices.
Please refer to the Miscellaneous Submenu in the Appendix B:
BIOS chapter for additional information on configuration.
KONTRON
Ethernet Interface 24 coolMONSTER/PM User’s Guide
10.USB INTERFACES
ThecoolMONSTER/PMoffers 3USB ports. These ports are driven by
either two UHCI USB 1.1 or one EHCIUSB 2.0 controller(s).Two
of the threeUSB ports are available on the coolMONSTER/PM’s
slot connector,and one moreport es available on theinternal
featureconnector.You can expand the ports for up to 127 USB
peripherals by using external USB hubs.
10.1Front Connectors(USB 0 andUSB 1)
Thetwo USB interfaces on the front are available through
Connectors X3and X13. To find the location of the USB
connectors, please see the Appendix E: ConnectorLayout chapter.
The following table shows the pin-out of these USB interfaces.
Header Pin Signal Name Function
1USB_5V *USB-supply(max.500mA)
2USB- Universal serial bus port (-)
3USB+ Universal serial bus port (+)
4USB_GND USB Ground
Notes:(*)To protect the external power lines of peripheral devices, makesure that:
-- the wires have the right diameter to withstand the maximum available current
-- the enclosure of the peripheral device fulfils the fire-protecting requirements of
-- IEC/EN 60950.
The USB power lines are protected with aresetable fuse and are limited to 500mA
10.2InternalConnector(USB2)
Theinternal USBinterface is available through thefeature
Connector X12. To find the location and Pin-Out of the USB
connector, please see the Appendix E: Connector Layout chapter.
10.2.1 Limitations of USB Port 2
There are no dedicated Pins for USB power. When using this USB
port the usermust make sure that apower supply is used which
monitors the drawn current and limits it to 500mA,otherwise a
defective USB device may damage thecoolMONSTER/PM. Kontron
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide25 Ethernet Interface
recommends using aresettable fuse, which follows the USB 1.1
specification, for power on external USB connectors.
10.3 Configuration
You can enable ordisable the two USB UHCI HostControllers in
the BIOS Setup Utility for support of USB 1.1 devices. USB Host
Controller 1serves the two USB Ports 0and 1on the front. USB
host Controller 2serves the USB Port 2on thefeature
connector.
For high-speed USB 2.0 support of all3available ports, enable
the USB EHCI Host Controller.
You also can enable or disable the legacy USB support. Legacy
support is required for aUSB keyboard and aUSB Mouse when used
with non USB aware operating systems such as Unix or DOS. It
also is requiredto boot fromUSBmass storage devices. For more
information, see the I/O Device Configuration Submenu section in
Appendix B: BIOS Operation.
You can download available drivers or get driver download
support information from the Kontron Web site. Kontron offers
the latest Kontron-tested drivers, which can differ from newer
ones. For further technical questions, contact your local
support or get support information and downloadablesoftware
updates from Intel®.
Notes:1. Some operating systems withoutUSB2.0 support do not workwell with
EHCI controllerenabled.Ifyou install such an OSat the
coolMONSTER/PM please
disable the EHCI controller in the Setup Utilitybefore installation.
2. For operating systems not listed on ourWeb site please contact your OS
distributor for an USB2.0 driver.
Weare not allowed bylaw to ship USB2.0 drivers.
KONTRON
Ethernet Interface 26 coolMONSTER/PM User’s Guide
11.Ethernet INTERFACE
ThecoolMONSTER/PMcomes withoneEthernet interface, whichuses
the ICH4’s integrated 32-bit PCI LAN controller in combination
with the Intel® 82562 platform LAN connect device. The network
controllersupports a10/100Base-T interface. The device auto-
negotiates the use of a 10Mbit/sec or 100Mbit/sec connection.
All major network-operating systems and several real-time and
embedded operating systems support the interface.
11.1 EthernetController
The Intel® 82562 features are:
†IEEE802.3 10Base-T/100Base-TXcompliant physicallayer
interface
†IEEE802.3u Auto-Negotiationsupport
†IEEE802.3xFull Duplex FlowControl standard
†DigitalAdaptive Equalizationcontrol
†Linkstatusinterrupt capability
†10Base-T auto-polaritycorrection
†Platform LAN connect interfacesupport
†Diagnostic loopbackmode
†1:1 transmit transformerratiosupport
†Low power(lessthan 300mWin active transmitmode)
†Reducedpowerin “unplugged mode”
Note: The Ethernetinterface worksaccording to the common criteria of the embedded
technologymarket segment.
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide27 Ethernet Interface
11.2 Connector
The 10/100Base-Tinterface is available on astandard 8-pin RJ45
jack.It isavailableat the slot panel of the coolMONSTER/PM
through Connector X7.
To find the location of the Ethernet interface, please see the
Appendix E: Connector Layout chapter.
The following table shows the pin-out of the Ethernet connector.
HeaderPin Signal Name Function In/Out
1TXD+100/10BASE-T Transmit Differential Output
2TXD-100/10BASE-T Transmit Differential Output
3RXD+100/10BASE-T Receive Differential Input
4NC **For internal use only
5NC **For internal use only
6RXD- 100/10BASE-T Receive Differential Input
7NC **For internal use only
8NC **For internal use only
LLeft LED ActivityGreen
RRight LED LinkYellow
NOTE: (**) Do not connect anything to these pins!
11.3 Configuration
The onboard LAN controller can be enabled or disabled in the
BIOS Setup Utility. Additionally it is possible to enable the
onboard LAN PXE boot ROM to allowthe system to boot up via a
network connection from aPXE boot server. Refer to the I/O
Device Configuration Submenu in the Appendix B:BIOS Operation
chapter for additional information on configuration.
You can download available drivers from the Kontron Web site.
For further information readthe read-me file or contact
technical support.
KONTRON
Ethernet Interface 28 coolMONSTER/PM User’s Guide
11.4 EthernetTechnicalSupport
If any problems occur, you can solve some of them by using the
latest drivers for the Intel® LAN controller. Kontron provides
you with the latest Kontron-tested drivers, which can differ
from newer ones. For further technical support, contact either
Kontron or get support information and downloadable software
updates from Intel®.
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide29 Graphic Interfaces
12.Graphic Interfaces
12.1 Video Controller
ThecoolMONSTER/PM uses the graphics accelerator integrated in
the Intel® 855GM/GME chipset, which delivers high-performance
2D, 3D and video capabilities. With its interface to UMA
(Unified Memory Architecture) up to 32MB of system memory are
used as video memory.
The controller can drive four interfaces with its two graphic
engines on the coolMONSTER/PM:
†CathodeRayTube (CRT)interface
†Low VoltageDifferentialSignaling(LVDS)interface
†2 DigitalVideoOutput(DVO)ports
12.2 CRTConnector
The CRT (Cathode Ray Tube) interface is available through a
standard DSUB15 connectorX9, whichis located at the slot
connector.
The following table shows the pin-out of the CRT connector.
HeaderPin Signal NameFunction
1 RED Red Video
2 GRN Green Video
3 BLU Blue Video
4 NC Notconnected
5 GND Ground
6 GND Ground
7 GND Ground
8 GND Ground
9 NC Notconnected
10 GND Ground
11 NC Notconnected
12 DDA DDC Serial Data Line
13 HSYNC Horizontal Sync
14 VSYNC VerticalSync
15 DCK DDC Data Clock Line
KONTRON
Graphic Interfaces 30 coolMONSTER/PM User’s Guide
To find the location of the CRT interface, please see the
Appendix E: Connector Layout chapter.
12.3 DVOConnector
The DVO (Digital Video Output) interface isavailable on
Connector X1, a50-pin, flat-foil connector on the bottom side
of the board. To find the location of the DVO interface, please
see the Appendix E:Connector Layout chapter. DVO interface
usage excludes LVDS interface usage.
The following table shows the pin-out of the DVO connector.
Pin SignalName FunctionPin Signal NameFunction
1DVOCD0Channel-C /Data 02DVOBD0Channel-B / Data 0
3DVOCD1 Channel-C /Data 1 4VCC +5V Power
5DVOBD1 Channel-B / Data 16DVOCD2 Channel-C / Data 2
7DVOBD2 Channel-B / Data 28VCC +5V Power
9DVOCD3 Channel-C /Data 310 DVOBD3Channel-B / Data 3
11 DVOCD4 Channel-C /Data 412 GNDGround
13 DVOBD4 Channel-B / Data 414 DVOCD5 Channel-C / Data 5
15 DVOBD5 Channel-B / Data 516 GNDGround
17 DVOCD6 Channel-C /Data 618 DVOBD6Channel-B / Data 6
19 DVOCD7 Channel-C /Data 720 GNDGround
21 DVOBD7 Channel-B / Data 722 DVOCD8 Channel-C / Data 8
23 DVOBD8 Channel-B / Data824 GNDGround
25 DVOCD9 Channel-C /Data 926 DVOBD9Channel-B / Data 9
27 DVOCD10 Channel-C / Data 10 28 GNDGround
29 DVOBD10 Channel-B / Data10 30 DVOCD11 Channel-C /Data 11
31 DVOBD11 Channel-B / Data11 32 GNDGround
33 DVOBCLK Channel-B / Clock Out 034 DVOBCLK# (*) Channel-B / ClockOut 1
35 GND Ground 36 DVOCCLKChannel-C / Clock Out 0
37 DVOCCLK# (*)Channel-C / Clock Out 138 GNDGround
39 DVOBVSYNCChannel-B Vertical Sync 40 DVOBHSYNC Channel-B Horiz. Sync
41 DVOBBLANK# Channel-B Flicker Blank42 DVOBFLDSTLChannel-B Field Stall
43 DVOCVSYNC Channel-C Vertical Sync44 DVOCHSYNCChannel-C Horiz.Sync
45 DVOCBLANK# Channel-C FlickerBlank46 DVOCFLDSTL Channel-C Field Stall
47 DVOINTLCD Interrupt 48 LTVDAT LCD/TV Data
49 LTVCLK LCD/TV Clock50 VREFReference Voltage
(*)optional
StockCheck.com

KONTRON
coolMONSTER/PM User’s Guide31 Graphic Interfaces
12.4 FlatPanel LVDS Interface (JILI)
Connector
The interface for the LCD Panel is available through the X10
connector (40 pins) on the bottom side of the board. This
connector represents the JILI interface(JUMPtec Intelligent
LVDS Interface). The implementation of this subsystem complies
with the JILI Specification of Kontron Embedded Modules GmbH.
ThecoolMONSTER/PM already supports the JILI3 implementation. A
variety of cables for different display types are available from
Kontron. Please refer to the cable list on the Kontron Web site
for part numbers and cable names. Adetailed description of the
JILI interface standard also is available in aseparate document
JILIM???.PDF. The three question marks represent the document’s
revision number. You can download the document from the Kontron
Web site, or contact your local Kontron technical support to
receiveit.
To find the location of the LCD Panel interface connector,
please see the Appendix E: Connector Layout chapter.
12.5 DisplayPowerConsiderations
When using aLCD Panel, additional voltages may be required to
drive the display’s logic and tosupply the backlight converter
and the display’s contrast voltage.
The display logicmay require +5Vfor standard or+3.3V for low-
power LCDs. Contrast voltages for passive displays are normally
very different and can range from–30V to +30V.Backlight
converters usually are +5V or +12V types. When using aKontron
JILI cable, you do not need todetermine such configurations.
Display logic voltage and contrast voltage come pre-configured
on the JILI cable. On occasion, backlight voltage has to be
adjusted on the cable.
Even though thecoolMONSTER/PM is also available as a+5V-only
board, you need to supply the +12V for the backlightconverter
additionally when using such a converter type.
The onboard 3.3V-circuitry of the coolMONSTER/PMand the+3.3V
logic voltage of low-voltage panels are powered by separate
voltage regulators. The one for the LCD is mounted on the JILI
adapter cable.
KONTRON
Graphic Interfaces 32 coolMONSTER/PM User’s Guide
12.6 Connecting aLCDPanel
To determine whether your panel display is supported, check the
Kontron Web site for panel lists. We regularly update the list
of panels that have been tested with our boards.
Many panel adapters forawide spread variety of displays are
available through Kontron. If you use one of those adapters
supplied by Kontron, configuration is easy:
1. Check whetheryouhave thecorrectadapter and cableforthe
panel youplan touse. Inspectthecable for damages.
2. Disconnect the power from yoursystem.
3. Connect thepaneladapter totheLCDPanel connector (JILI)
onthecoolMONSTER/PM.
4. Connect theotherendofthecableto your display.
5. Connectthebacklightconverter.
6. Supplypower toyour system.
7. Ifno imageappearsonyour display,connect a CRT monitorto
the CRTconnector.
8. Ifnecessary program theEEPROM onthe JILIcablewiththe
matching configurationdata.
9. Ifyoustill donotsee improvement,considercontactingthe
dealerfor technical support.
12.7 Configuration
You can set the general configuration for the graphic controller
in the BIOS setup utility. Refer to the Advanced Chipset Control
submenu and the Display Control submenu in the Appendix B: BIOS
Operation chapter for more configuration information.
You can download drivers forthe graphics controller from the
Kontron Web site. For further information, read the read-me or
help files or contact technical support.
StockCheck.com
