Kontron cPCI-MXS64GX Product manual

Ref. : M6004_TECH
www.kontron.com
Note: The latest releases of the Technical Reference Manuals are available at:
ftp://ftp.kontron.ca/Support/Product_Manuals/
cPCI-MXS64GX
6U CompactPCI 64-BIT System Processor
Technical Reference Manual
Version 1.4, May 2002

Historical
Rel. Date Comments
1.0 Jul-2001 Initial document release.
1.1 Aug-2001 N.A.
1.2 Dec-2001 Cover page Version 1.2 , December 2001-12-18
Page 1.2, 3.9 and 3.15 Added 700MHz processor speed
Page 1.2 32-bit AGP SVGA CRT controller
Replaced with :
64-bit AGP SVGA CRT controller
16-bit Ultra Wide up to 40Mbps, 8-bit Fast SCSI-2 up
to 10Mbps, 8-bit Ultra SCSI up to 20Mbps (Adaptec
AIC7880).
Replaced with :
16-bit Ultra Wide LVD SCSI up to 80Mbps (Symbios
SYM53C895)
Page 2.8 Section 2.9 – In table, line 2:
Serial port 2 - changed J3 for J5
Serial port 3 - changed J5 for J3
In table, signal path description
Changed J3 for J5.
Added line :
The infrared COM2 signals (COM2_IRRX and
COM2_IRTX) are available at J3 connector.
Page 2.11 In table, signal path description
Removed the line :
In Infrared mode, signals are available through the J3
CPCI I/O connector.
J3 Connector description :
Page 3.11 Changed “2/3/4” for “3 and 4”
Page 3.14 Removed “2” from J3 connector description
Page 3.32 In section 3.5.2.2 0- SCSI Interface table:
Row 1 : Changed SCD for SD
Page 3.34 In section 3.5.2.6 – IDE 1 Interface
Row 2 : Changed “SDD 0-15” for IDE1_0-15
PART 4 title Section 2 : Removed UPDATING OR RESTORING
THE BIOS IN FLASH
Replaced by : VT100 MODE
Added the note : UPDATING OR RESTORING THE
BIOS IN FLASH (see the Kontron
WEB site and select the “support”
section)
Page E.5 J4 Row A, pin 5 - DS4- changed for SD4-
J4 Row A, pin 10 - R_SYNC changed for R_HSYNC

Historical (continued)
1.3 May 13, 2002 - Replace all occurrences of Teknor Applicom Inc or Teknor by
Kontron, Inc.
- Replace all occurrences of Adaptec and Symbios with LSI.
- Replace in section 3.3.3.1 "...from "8MB to 1.5GB of..." by
"... from 32MB to 1.5GB of...
- Correct COM port assignation & location:
J5= COM1 & 2, J3= COM 3 & 4 + Infrared.
- Replace in section E.4 connector J3 RowD Pin14 " SD8" by "
SD8+".
- Remove BMC/IPMI support and references:
Replace in section E.2 / J1 : (BMC+Xlinx)
C17: “IPMB0_SDA” by “I2C_SDA” (From Xlinx)
B17: “IPMB0_SCL” by “I2C_SCL” (From Xlinx)
C17: “IPMB0_PWR” by “Reseved”
Replace in section E.3 / J2 : (BMC)
D19: “IPMB1_SDA” by “Reseved”
C19: “IPMB1_SCL” by “Reseved”
E19: “IPMB1_ALERT” by “Reseved”
Note: Only I2C support is still available instead of IPMI.
Updated Copywright to 2002

FCC COMPLIANCE STATEMENT
Warning
Changes or modifications to this unit not expressly approved by the party responsible for
the compliance could void the user’s authority to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case the user will be required to
correct the interference at his or her own expense.
European Statement
Warning
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Safety Standard
UL Recognized Component, File # E186339 vol. 1 section 2
Care and handling precautions for Lithium batteries
•Do not short circuit
•Do not heat or incinerate
•Do not charge
•Do not deform or disassemble
•Do not apply solder directly
•Do not mix different types or partially used batteries together
•Always observe proper polarities

FOREWORD
The information in this document is provided for reference purposes only. Kontron does
not assume any liability for the application of information or the use of products described
herein.
This document may contain information or refer to products protected by the copyrights or
patents of others and does not convey any license under the patent rights of Kontron, nor
the rights of others.
Printed in Canada.
Copyright 2002 by Kontron Communications, Inc., Boisbriand, Qc J7G 2A7.

READ ME FIRST
Your computer board has a standard non-rechargeable lithium battery. To preserve the
battery lifetime, the battery enable jumper is removed when you receive the board. If
you do not have any jumper cap, we suggest you to use the Watchdog Timer jumper cap.
EXERCISE CAUTION WHILE REPLACING LITHIUM BATTERY
!WARNING
Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of
used batteries according to the manufacturer's instructions.
!ATTENTION
Il y a danger d’explosion s’il y a remplacement incorrect de la batterie.
Remplacer uniquement avec une batterie du même type ou d’un type
équivalent recommandé par le constructeur. Mettre au rebut les batteries
usagées conformément aux instructions du fabriquant.
!ACHTUNG
Explosionsgefahr bei falschem Batteriewechsel.
Verwenden Sie nur die empfohlenen Batterietypen des Herstellers.
Entsorgen Sie die verbrauchten Batterien laut Gebrauchsanweisung des
Herstellers.
!ATENCION
Puede explotar si la pila no este bien reemplazada.
Solo reemplazca la pila con tipas equivalentes segun las instrucciones del
manifacturo. Vote las pilas usadas segun las instrucciones del manifacturo.

!IMPORTANT
J1 and J2 are de-facto industry standard as defined by PICMG
J3, J4 and J5 are user-defined connectors and will vary from various
manufacturers. Contact our Technical Support to verify pinout
compatibility with other chassis backplane vendors.
!POWERING-UP THE SYSTEM
If you should encounter a problem, verify the following items:
Make sure that all connectors are properly connected.
Verify your boot diskette.
If the system still does not start up properly, you should try booting your
system with only the power cord and video monitor connected to the board
this is the minimum required to see if the board is working).
If you still are not able to start up your system, please refer to the
emergency Procedure in the Appendix Section.
If you still are not able to get your board up and running, contact our
technical Support department for assistance.
!PREVENTING VIRUSES
Kontron Communications, Inc takes every precaution against computer
viruses.
To safeguard against computer viruses in general, do not freely lend your
diskettes and regularly perform virus scans on all your computer
systems.
!ADAPTER CABLES
While adapter cables are provided from various sources, the pinout is often
different. The direct crimp design offered by Kontron allows the simplest
cable assembly. All cables are available from Kontron Sales Department.

UNPACKING AND SAFETY PRECAUTIONS
Static Electricity
Since static electricity can damage the board, the following precautions should be taken:
1. Keep the board in its antistatic package, until you are ready to install it.
2. Touch a grounded surface or wear a grounding wrist strap before removing the board
from its package; this will discharge any static electricity that may have built up in
your body.
3. Handle the board by the edges.
Storage Environment
Electronic boards are sensitive devices. Do not handle or store devices near strong
electrostatic, electromagnetic, magnetic or radioactive fields.
Power Supply
Before any installation or setup, ensure that the board is unplugged from power sources or
subsystems.
Unpacking
Follow these recommendations while unpacking:
1. After opening the box, save it and the packing material for possible future shipment.
2. Remove the board from its antistatic wrapping and place it on a grounded surface.
3. Inspect the board for damage. If there is any damage, or items are missing, notify
Kontron immediately.
When unpacking you will find:
1. 6U CompactPCI®64-bit System Processor board
2. One Quick Reference sheet
3. One CDROM containing drivers.

i
TABLE OF CONTENTS
1. PRODUCT DESCRIPTION
1.1. Product OVERVIEW ........................................................................................................1.1
1.2. Product Specifications......................................................................................................1.2
1.3. Hot Swap capability .........................................................................................................1.4
1.4. Interfacing with the Environment......................................................................................1.6
1.4.1. CPCI...................................................................................................................1.6
1.4.2. Mezzanine...........................................................................................................1.6
1.5. Compatibility with other KONTRON Products...................................................................1.7
1.6. Mezzanine Card Concept.................................................................................................1.8
1.6.1. Kontron’s Mezzanine Concept.............................................................................1.9
1.6.2. PMC Concept......................................................................................................1.9
1.6.3. CompactFlash Feature........................................................................................1.9
2. ONBOARD FEATURES
2.1. CompactFlash Interface...................................................................................................2.1
2.1.1. Setups.................................................................................................................2.1
2.2. Enhanced IDE Interfaces.................................................................................................2.2
2.3. Ethernet Interfaces...........................................................................................................2.3
2.3.1. Front Plate Configuration.....................................................................................2.3
2.3.2. CPCI I/O Configuration........................................................................................2.4

ii
2.4. Floppy Disk Interface.......................................................................................................2.4
2.5. PS/2 Keyboard / PS/2 Mouse Interface............................................................................2.5
2.6. Parallel Port.....................................................................................................................2.5
2.6.1. Standard Mode....................................................................................................2.6
2.6.2. EPP Mode...........................................................................................................2.6
2.6.3. ECP Mode...........................................................................................................2.7
2.7. Power Management.........................................................................................................2.7
2.8. SCSI Interface .................................................................................................................2.7
2.9. Serial Ports......................................................................................................................2.8
2.9.1. SERIAL PORT 1..................................................................................................2.9
2.9.1.1. Remote Reset .......................................................................................2.9
2.9.1.2. Front Plate Configuration.....................................................................2.10
2.9.2. Serial Port 2 ......................................................................................................2.10
2.9.3. Serial Port 3 ......................................................................................................2.10
2.9.3.1. Infrared Mode:.....................................................................................2.11
2.9.3.2. RS-232 Protocol:.................................................................................2.12
2.9.3.3. RS-422 Protocol:.................................................................................2.12
2.9.3.4. RS-485 Protocol:.................................................................................2.12
2.9.4. Serial Port 4 ......................................................................................................2.13
2.10. Thermal Management....................................................................................................2.13
2.11. USB Interfaces...............................................................................................................2.14
2.12. Video Interface...............................................................................................................2.15
2.12.1. Supported Resolutions......................................................................................2.16
2.12.2. Major Features Description................................................................................2.16

iii
3. INSTALLING THE BOARD
3.1. Setting Jumpers...............................................................................................................3.1
3.1.1. Jumper Description for the CPCI-MXS64GX .......................................................3.1
3.1.2. CPCI-MXS64GX – Jumper Settings....................................................................3.2
3.1.3. Register’s description RS232/RS485...................................................................3.3
3.1.4. History and monitor status...................................................................................3.3
3.1.5. Multimedia, History status ...................................................................................3.4
3.1.6. Monitoring status and I/O access.........................................................................3.4
3.1.7. Uart 3 PnP configuration .....................................................................................3.4
3.1.8. Uart 4 PnP configuration .....................................................................................3.5
3.1.9. Digital watchdog..................................................................................................3.5
3.1.10. NMI control..........................................................................................................3.6
3.1.11. 0Register BITs description (summary).................................................................3.7
3.2. Onboard Interconnectivity ................................................................................................3.8
3.2.1. cPCI-MXS64GX Block Diagram ..........................................................................3.8
3.2.2. Mobile Pentium®II / III processor.........................................................................3.9
3.2.3. North Bridge Chipset...........................................................................................3.9
3.2.4. 21154 PCI-to-PCI Bridge.....................................................................................3.9
3.2.5. 82371AB PCI-to-ISA Bridge / IDE Xcelerator (PIIX4).........................................3.10
3.2.6. Onboard Connectors and Headers....................................................................3.11
3.2.7. Front Plate Connectors and Indicators...............................................................3.12
3.2.8. FACEPLATE OPTIONS ....................................................................................3.13
3.2.9. CompactPCI Connectors...................................................................................3.14

iv
3.3. Customizing the Board...................................................................................................3.15
3.3.1. Processor and Fan............................................................................................3.15
3.3.2. Backup Battery..................................................................................................3.16
3.3.3. Memory.............................................................................................................3.17
3.3.3.1. SDRAM System Memory.....................................................................3.17
3.3.3.2. DIMM Installation.................................................................................3.18
3.3.4. Supervision Features ........................................................................................3.19
3.3.4.1. Power Fail Monitoring..........................................................................3.19
3.3.4.2. Watchdog............................................................................................3.20
3.3.4.3. Thermal Management .........................................................................3.22
3.4. Building a CPCI System.................................................................................................3.23
3.4.1. Backplane.........................................................................................................3.24
3.4.2. Rear-Panel I/O..................................................................................................3.25
3.4.3. Storage Devices................................................................................................3.27
3.4.4. Power Supply....................................................................................................3.27
3.4.5. Fan Tray............................................................................................................3.27
3.4.6. Installing the Board into a Bay...........................................................................3.27
3.4.7. Connector Keying..............................................................................................3.28
3.4.8. Bus Mastering...................................................................................................3.29
3.4.9. Connection........................................................................................................3.29

v
3.5. CPCI I/O Signals............................................................................................................3.30
3.5.1. J3 Signal Specification ......................................................................................3.30
3.5.1.1. Ethernet LEDS ....................................................................................3.30
3.5.1.2. Ethernet 1............................................................................................3.30
3.5.1.3. Serial Port 3 ........................................................................................3.30
3.5.1.4. Serial Port 4 ........................................................................................3.31
3.5.1.5. IDE LED Signals..................................................................................3.31
3.5.1.6. IR Serial Port 2....................................................................................3.31
3.5.1.7. Hot Swap HA (High Availability) signals...............................................3.31
3.5.1.8. Miscellaneous Signals.........................................................................3.31
3.5.2. J4 Signal Specification ......................................................................................3.32
3.5.2.1. Power Management ............................................................................3.32
3.5.2.2. SCSI Interface.....................................................................................3.32
3.5.2.3. Video Interface....................................................................................3.33
3.5.2.4. Ethernet 1 Interface.............................................................................3.33
3.5.2.5. Hot Swap HA (High Availability) signals...............................................3.33
3.5.2.6. IDE 1 Interface ....................................................................................3.34
3.5.3. J5 Signal Specification ......................................................................................3.35
3.5.3.1. IDE 0 Interface ....................................................................................3.35
3.5.3.2. USB 0 and 1 Interfaces .......................................................................3.35
3.5.3.3. Floppy Disk Interface...........................................................................3.36
3.5.3.4. Serial Port 2 ........................................................................................3.36
3.5.3.5. Serial Port 2 ........................................................................................3.36
3.5.3.6. Parallel Port.........................................................................................3.37
3.5.3.7. Miscellaneous Signals.........................................................................3.37
3.5.3.8. Keyboard Interface..............................................................................3.37
3.5.3.9. Mouse Interface...................................................................................3.37

vi
4. SOFTWARE SETUPS
4.1. BIOS Setup Program .......................................................................................................4.1
4.1.1 Accessing the BIOS setup program.....................................................................4.1
4.1.2 Main Menu ..........................................................................................................4.3
4.1.3 Setups.................................................................................................................4.4
4.1.4 Standard CMOS Setups......................................................................................4.5
4.1.5 Saving & Exiting Operations................................................................................4.5
4.1.6 BIOS Features Setup..........................................................................................4.6
4.1.7 Chipset Features Setup.......................................................................................4.8
4.1.8 Power Management Setup................................................................................4.10
4.1.9 PnP/PCI Configuration ......................................................................................4.12
4.1.10 CPU/Board Features Setup...............................................................................4.13
4.1.11 Integrated Peripherals.......................................................................................4.14
4.2. VT100 Mode..................................................................................................................4.15
4.2.1 Requirements......................................................................................................4.15
4.2.2Setup& Configuration.........................................................................................4.15
4.2.3Running Without a Terminal................................................................................4.16

vii
PART FIVE.– Installation and Settings
A. BOARD SPECIFICATIONS........................................................................................A-1
B. MEMORY & I/O MAPS ...............................................................................................B-1
B.1 Memory Mapping............................................................................................................B-1
B.2 I/O Mapping....................................................................................................................B-2
C. INTERRUPT LINES................................................................................................... C-1
C.1 IRQ Lines........................................................................................................................C-1
C.2 DMA Channels................................................................................................................C-1
D. BOARD DIAGRAMS.................................................................................................. D-1
D.1 Top Devices Surface Mount............................................................................................D-1
D.2 Assembly Bottom Diagram .............................................................................................D-2
D.3 Mounting Holes...............................................................................................................D-3
D.4 Connector Holes.............................................................................................................D-4
E. CONNECTOR PINOUTS............................................................................................E-1
E.1 cPCI-MXS64GX Connectors and Headers......................................................................E-1
E.2 J1 CPCI Bus...................................................................................................................E-2
E.3 J2 CPCI Bus...................................................................................................................E-3
E.4 J3 CPCI Bus...................................................................................................................E-4

viii
E.5 J4 CPCI Bus...................................................................................................................E-5
E.6 J5 CPCI Bus...................................................................................................................E-6
E.7 J12, Video (VGA)............................................................................................................E-6
E.8 J13, Serial Port 1 - RS-232.............................................................................................E-7
E.9 J14, mezzanine PCI........................................................................................................E-7
E.10 J15/J16, Ethernet 1 and 2...............................................................................................E-8
E.11 J17, PS/2 Keyboard/Mouse ............................................................................................E-8
E.12 J18, CompactFlash Disk..................................................................................................E-8
E.13 J19, Storage mezzanine.................................................................................................E-9
E.14 J20, PMC......................................................................................................................E-10
E.15 J21, PMC......................................................................................................................E-11
E.16 Hot Swap Switch........................................................................................................... E-12
E.17 S1 – Reset Switch ........................................................................................................E-12
E.18 BT1, CMOS Battery Backup Connector........................................................................ E-12
F. BIOS SETUP ERROR CODES ..................................................................................F-1
F.1 POST Beep ....................................................................................................................F-1
F.2 POST Messages............................................................................................................. F-1
F.3 Error Messages .............................................................................................................. F-2
F.4 POST Codes...................................................................................................................F-3
G. EMERGENCY PROCEDURE.................................................................................... G-1
G.1 How to run Emergency Procedure..................................................................................G-1
G.2 Generate an Emergency Floppy Diskette :......................................................................G-2
H. GETTING HELP ........................................................................................................ H-1

1. PRODUCT DESCRIPTION
1. PRODUCT OVERVIEW
2. SPECIFICATIONS
3. HOT SWAP CAPABILITY
4. INTERFACING WITH THE ENVIRONMENT
5. COMPATIBILITY WITH KONTRON PRODUCTS
6. MEZZANINE CONCEPTS
1
P
A
R
T

1.1
1.1. PRODUCT OVERVIEW
Kontron’s 6U CompactPCI®system processor is ideal for data/telecommunication, CTI,
and industrial control/monitoring markets.
The cPCI-MXS64GX 6U CompactPCI system processor brings scalable multiprocessing
capability to the telecom and industrial automation markets. It is designed to operate as a
“system” processor and must be installed in CompactPCI system slot.
Fully hot swappable, the cPCI-MXS64GX communicates with other processor boards
using the CompactPCI backplane as the physical layer of a 1 Gb/s Ethernet.
To provide the necessary interconnect, support local versions of the following OSs:
Microsoft Windows NT, Microsoft Windows 2000, Linux, VxWorks and pSOS.
Multi-level PCI-to-PCI bridging is fully supported. Based on Intel’s 21154 PCI-to–PCI -
transparent bridge, the feature set of the cPCI-MXS64GX includes a rich selection of
standard peripherals.
The cPCI-MXS64GX offers a natural growth path to high performance, high availability as
well as hot swap and scalable multiprocessing technology.
The cPCI-MXS64GX can be ordered in either front I/O interfacing (video, serial port,
2xEthernet, all available on the face plate) or rear I/O interfacing through CPCI I/O
connectors J3, J4 and J5 (no interconnection capability on the face plate).
CompactPCI Connectors
Rear I/O CPCI connectors are PICMG 2.0 Rev 3.0 compliant. CompactPCI connectors are
located at the rear edge of the processor board. The complete CPCI connector configuration
of the cPCI-MXS64GX is composed of four connectors referred to as J1, J2, J3, J4, and J5.
Their function is described below:
J1 32 bit PCI signaling, power
J2 64 bit extension, arbitration, clocks, reset and. power
J3, J4, J5 Handle I/O signals.
CompactPCI

connectors are also known as 2mm Hard Metric connectors.

cPCI-MXS64GX Technical Reference manual
1.2
1.2. PRODUCT SPECIFICATIONS
The cPCI-MXS64GX industrial system processor features:
•Intel’s enhanced performance Pentium®processor.
Low power Mobile Pentium®III 500 and 700MHz, 256KB on-die L2 pipelined
burst cache.
•440GX AGP set.
•Supporting up to 1.5GB SDRAM with parity or ECC.
•PCI Ultra DMA/33 IDE, SCSI-2 .
•64-bit AGP SVGA CRT controller.
•CompactFlash™ Disk interfacing on primary EIDE channel, user upgradable,
master/slave.
•Ports available
•Two Universal Serial Bus (USB).
•Two 10/100Mbps Ethernet.
•Four serial ports (three RS-232 only: Serial Port 1, 2 and 4; one RS-
232/422/485: Serial Port 3).
•One Parallel port, bi-directional with all IEEE 1284 protocols supported with
BIOS selectable IRQs and addressing.
•Mouse and keyboard available through front plate or Rear Transition Module.
•SCSI, supports 16-bit Ultra Wide LVD SCSI up to 80Mbps (LSI 53C895)
•Floppy interface (360KB to 1.44MB).
•Optional hard disk/floppy mezzanine module for high level of integration.
•High availability controller capable to detect the insertion or removal of HA CPCI
peripheral boards.
•J3/J4/J5 connectors to handle I/O signals such as serial, parallel, and USB ports,
Ethernet and video, SCSI, and IDE interfaces, keyboard, speaker, mouse, and
reset signals, SMBus.

Product Description
1.3
Software:
•Enable/disable of Ethernet and SCSI ports by software.
•Enable/disable of video by hardware.
•Serial/parallel port mapping/disable by software
•Remote operation/monitoring (VT-100 serial port console redirection),
•Programmable two-stage watchdog timer by software
•Fully compatible with existing application software using platforms PC and MS-
DOS, Windows3.1, Windows95, WindowsNT, Windows®2000, OS/2
Warp, QNX, NOVELL, and UnixWare.
•Supports: Advanced Configuration and Power Interface (ACPI 1.0), Advanced
Power Management (APM 1.2), advanced thermal management (resume, overheat
alarm and auto slow down) and Green support.
•Hardware monitor (voltages, temperature, and fan speed),
•Power failure circuit
•Two year warranty.
The cPCI-MXS64GX can be purchased either for front plate I/O interfacing (video serial
port, Ethernet) or RTM (Rear Transition Module) I/O interfacing (no interconnection
capability available on the front plate) through CPCI I/O connectors and backplane.
"CompactPCI Connectors
Rear panel CPCI connectors are PICMG 2.0 Rev2.1 CompactPCIspecification compliant.
CompactPCI connectors are located at the rear edge of the board. The complete CPCI
connector configuration is composed of five connectors referred to as J1, J2, J3, J4, and J5.
Their function is described below:
J1/J2 carry out arbitration and PCI bus signals, and power.
J3/J4/J5 handle I/O signals.
CompactPCI

connector is also known as 2mm Hard Metric connector.
