Kontron AdvancedTCA AT8001 User manual

AT8001 User’s Guide
AdvancedTCA
Document Revision 1.0
Ref. : M5002_TECH_1/ Jul
y
2005

i AT8001 User’s Guide
Customer Service
Contact Information: Kontron Canada, Inc.
616 Curé-Boivin
Boisbriand, Québec, Canada
J7G 2A7
Tel: [phone]
[phone]
Fax: [phone]
E-mail:[email protected]om
Visit our site at: www.kontron.com
© 2005 Kontron, an International Corporation. All rights reserved.
The information in this user’s guide is provided for reference only. Kontron does not assume any
liability arising out of the application or use of the information or products described herein. This
user’s guide may contain or reference information and products protected by copyrights or patents
and does not convey any license under the patent rights of Kontron, nor the rights of others.
Kontron is a registered trademark of Kontron. All trademarks, registered trademarks, and trade
names used in this user’s guide are the property of their respective owners. All rights reserved.
Printed in Canada. This user’s guide contains information proprietary to Kontron. Customers may
reprint and use this user’s guide in other publications. Customers may alter this user’s guide and
publish it only after they remove the Kontron name, cover, and logo.
Kontron reserves the right to make changes without notice in product or component design as
warranted by evolution in user needs or progress in engineering or manufacturing technology.
Changes that affect the operation of the unit will be documented in the next revision of this user’s
guide.

ii AT8001 User’s Guide
Contents
Customer Service.................................................................................................i
Contents ........................................................................................................... ii
Safety Instructions........................................................................................... vii
Before You Begin ....................................................................................................viii
When Working Inside a Computer ............................................................................... ix
Preventing Electrostatic Discharge...............................................................................x
Preface............................................................................................................ xi
How to Use This Guide ..............................................................................................xii
Customer Comments ...............................................................................................xiii
Advisory Conventions .............................................................................................. xiii
Unpacking ............................................................................................................. xiv
Powering Up the System .......................................................................................... xiv
Adapter Cables ........................................................................................................ xv
Storing Boards ........................................................................................................ xv
Regulatory Compliance Statements ............................................................................ xv
Limited Warranty.................................................................................................... xvi
1. Product Description .................................................................................. 1-0
1.1 Product Overview.........................................................................................1-1
1.2 What’s Included ..........................................................................................1-2
1.3 Board Specifications ....................................................................................1-2
1.4 Compliance.................................................................................................1-6
1.5 Hot-Plug Capability......................................................................................1-6
1.6 Interfacing with the Environment ..................................................................1-7
2. Onboard Features..................................................................................... 2-9
2.1 Block Diagram...........................................................................................2-10
2.2 System Core ..............................................................................................2-12
2.3 6300ESB ICH.............................................................................................2-15
2.4 W83627HF Super I/O .................................................................................2-19
2.5 i6700PXH Bridge .......................................................................................2-19
2.6 LSIFC929X Fibre Channel (optional).............................................................2-20

iii AT8001 User’s Guide
2.7 Ethernet Interfaces....................................................................................2-21
2.8 Crosspoint Switches ...................................................................................2-22
2.9 Video Interface .........................................................................................2-23
2.10 AMC Mezzanines(optional) .........................................................................2-24
2.11 PMC Mezzanine(optional)...........................................................................2-25
2.12 Redundant BIOS Flash ................................................................................2-25
2.13 Redundant IPMC Flash & FWUM....................................................................2-25
2.14 FPGA........................................................................................................2-26
2.15 Telecom Clock Option .................................................................................2-26
2.16 Hardware Management Overview .................................................................2-27
2.17 Debugging Features ...................................................................................2-36
3. Installing the board.................................................................................. 3-0
3.1 Setting Jumpers ..........................................................................................3-1
3.2 Processor ...................................................................................................3-3
3.3 Memory......................................................................................................3-3
3.4 Onboard Interconnectivity ............................................................................3-5
3.5 Board Hot Swap and Installation....................................................................3-7
4. Building an ATCA System ........................................................................... 4-0
4.1 Building an ATCA System ..............................................................................4-1
5. Software Setup ........................................................................................ 5-0
5.1 AMI BIOS Setup Program...............................................................................5-1
5.2 Boot Utilities ............................................................................................5-24
5.3 Console Redirection (VT100 Mode)...............................................................5-25
5.4 Installing Drivers ......................................................................................5-28
5.5 MontaVista ...............................................................................................5-29

v AT8001 User’s Guide
A. Memory & I/O Maps................................................................................. A-1
A.1 MEMORY MAPPING..........................................................................................A-1
A.2 I/O MAPPING .................................................................................................A-2
A.3 PCI IDSEL and Device numbers .........................................................................A-3
B. Kontron Extension Registers..................................................................... B-1
B.1 FPGA/CPLD REGISTERS DEFINITION .................................................................. B-1
B.2 OVERVIEW .................................................................................................... B-1
B.3 0080H: POSTCODES........................................................................................ B-2
B.4 0081H: EXTENDED POSTCODES......................................................................... B-2
B.5 0A00H: FPGA VERSION ................................................................................... B-2
B.6 0A01H: DEBUG LED........................................................................................ B-2
B.7 0A02H: FWUM............................................................................................... B-3
B.8 0A04H: DEVELOPMENT FEATURES ..................................................................... B-4
B.9 0A08H: TELCLOCK0 (TELECOM CLOCK OPTION).................................................... B-5
B.10 0A09H: TELCLOCK1 (TELECOM CLOCK OPTION)................................................. B-5
B.11 0A0AH: TELCLOCK2 (TELECOM CLOCK OPTION)................................................. B-6
B.12 0A0BH: TELCLOCK3 (TELECOM CLOCK OPTION)................................................. B-7
B.13 0A0CH: TELCLOCK4 (TELECOM CLOCK OPTION) ................................................. B-1
B.14 0A0DH: TELCLOCK5 (TELECOM CLOCK OPTION) ................................................ B-1
B.15 0A0EH: TELCLOCK6 (TELECOM CLOCK OPTION)................................................. B-2
B.16 0A0FH: TELCLOCK7 (TELECOM CLOCK OPTION) ................................................. B-2
C. Connector Pinouts................................................................................... C-1
C.1 CONNECTORS AND HEADERS SUMMARY...............................................................C-1
C.2 FIBER CHANNEL (J1 & J2)................................................................................C-2
C.3 ETHERNET MANAGEMENT (J3)...........................................................................C-2
C.4 USB (LOCATED ON FACEPLATE) (J4)...................................................................C-2
C.5 SERIAL PORT 1 - RS-232 (J5) ...........................................................................C-3
C.6 VIDEO (SVGA) (J6) .........................................................................................C-3
C.7 2.5” IDE HARD DISK (J11)...............................................................................C-4
C.8 POST CODE (J13) ............................................................................................C-4
C.9 AMC B1 & AMC B2 (J18 & J19)..........................................................................C-5
C.10 COMPACTFLASH™ (J21)................................................................................C-6
C.11 TELCO CLOCK (J20) ......................................................................................C-7

vi AT8001 User’s Guide
C.12 ATCA I/O (J23) ATCA 3.1...............................................................................C-8
C.13 RTM Connector (J30) ...................................................................................C-9
C.14 POWER (P10) ........................................................................................... C-10
C.15 JN1 – PMC (JN1) ....................................................................................... C-11
C.16 JN2 – PMC (JN2) ....................................................................................... C-12
C.17 JN3 – PMC (JN3) ....................................................................................... C-13
D. BIOS Setup Error Codes ............................................................................ D-1
D.1 Bootblock Initialization Code Checkpoints........................................................ D-1
D.2 POST Code Checkpoints .................................................................................. D-2
D.3 DIM Code Checkpoints.................................................................................... D-4
D.4 ACPI Runtime Checkpoints ............................................................................. D-5
D.5 Memory initialization ERROR Code................................................................... D-5
D.6 Beep Codes................................................................................................... D-5
E. Software Update .................................................................................... E-1
E.1 Flash BIOS Update Procedure ...........................................................................E-1
E.2 IPMC Firmware Update Procedure .....................................................................E-1
F. Getting Help .......................................................................................... F-1

vii
AT8001 User’s Guide
Safety Instructions
Contents
Before You Begin ........................................................viii
When Working Inside a Computer ...................................ix
Preventing Electrostatic Discharge...................................x

viii
AT8001 User’s Guide
Before You Begin
Before handling the board, read the instructions and safety guidelines on the following pages to
prevent damage to the product and to ensure your own personal safety. Refer to the “Advisories”
section in the Preface for advisory conventions used in this user’s guide, including the distinction
between Warnings, Cautions, Important Notes, and Notes.
♦Always use caution when handling/operating the computer. Only qualified,
experienced, authorized electronics service personnel should access the interior of
the computer. The power supplies produce high voltages and energy hazards, which
can cause bodily harm.
♦Use extreme caution when installing or removing components. Refer to the
installation instructions in this user’s guide for precautions and procedures. If you
have any questions, please contact Kontron Technical Support.
WARNING
High voltages are present inside the chassis when the unit’s power cord is plugged
into an electrical outlet. Turn off system power, turn off the power supply, and
then disconnect the power cord from its source before removing the chassis cover.
Turning off the system power switch does not remove power to components.
WARNING
This product may contain CLASS 1 LASER PRODUCT

ix
AT8001 User’s Guide
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
Turn off the computer and any peripherals.
Disconnect the computer and peripherals from power sources or subsystems to prevent
electric shock or systemboard damage. This does not apply to when hot-swapping parts.
Follow the guidelines provided in “Preventing Electrostatic Discharge“ on the following
page.
Disconnect telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
♦To help avoid possible damage to system boards, wait five seconds after turning off
the computer before removing a component, removing a system board, or
disconnecting a peripheral device from the computer.
♦When you disconnect a cable, pull on its connector or on its strain-relief loop, not on
the cable itself. Some cables have a connector with locking tabs. If you are
disconnecting this type of cable, press in on the locking tabs before disconnecting the
cable. As you pull connectors apart, keep them evenly aligned to avoid bending any
connector pins. Also, before connecting a cable, make sue both connectors are
correctly oriented and aligned.
CAUTION
Do not attempt to service the system yourself, except as explained in this user’s
guide. Follow installation and troubleshooting instructions closely.

x
AT8001 User’s Guide
Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper
ESD procedure to reduce the risk of damage to components. Kontron strongly encourages you to
follow proper ESD procedure, which can include wrist straps and smocks, when servicing
equipment.
Take the following steps to prevent damage from electrostatic discharge (ESD):
♦When unpacking a static-sensitive component from its shipping carton, do not remove
the component’s antistatic packing material until you are ready to install the
component in a computer. Just before unwrapping the antistatic packaging, be sure
you are at an ESD workstation or grounded. This will discharge any static electricity
that may have built up in your body.
♦When transporting a sensitive component, first place it in an antistatic container or
packaging.
♦Handle all sensitive components at an ESD workstation. If possible, use antistatic
floor pads and workbench pads.
♦Handle components and boards with care. Don’t touch the components or contacts on
a board. Hold a board by its edges or by its metal mounting bracket.
♦Do not handle or store system boards near strong electrostatic, electromagnetic,
magnetic, or radioactive fields.
