Koshin FD-12 User manual

22-06 004008907
●Thank you for purchasing this product.
●This manual is prepared for your safety when operating
pump.
Please read carefully and comprehend fully before use.
(Wrong usage could cause injury or death)
●Please keep this manual handy for future reference.
ELECTRIC DRUM PUMP
《FD, FA MODEL》
Please read this manual before operation.
OPERATION MANUAL
SPARE PARTS
http://www.koshinpump.com
For spareparts information, visit
TEL.: [phone] FAX.: [phone]
E-mail: [email protected]
12 Kami-Hachinotsubo Kotari, Nagaokakyo City,
Kyoto 617-8511 JAPAN
www.koshinpump.com

cushion gum
screwfan cover
carbon brush
carbon brush cap
CARBON BRUSH REPLACEMENT
may
3 to 4 places (It depends on models) with a screw driver.
RepairRepair
carbon brush
Use of a carbon brush worn out more than the specified limit reduces the amount of delivery
and may damage the motor.
1

cushion gum
screwfan cover
carbon brush
carbon brush cap
CARBON BRUSH REPLACEMENT
may
3 to 4 places (It depends on models) with a screw driver.
RepairRepair
carbon brush
Use of a carbon brush worn out more than the specified limit reduces the amount of delivery
and may damage the motor.
2

（Ｌ/min）
L 45 L/min 12 U.S.G/min 50 L/min 13 U.S.G/min
20mm
20mm
20mm
8kg
耐油性ゴムホース
2.7 Ａ
ft ft ft
3 Ａ
4.8ｍ15.7ft
Oil-proof Rubber Hose ft
120 7350
（Ｌ/min）
Kerosene
Light oil
Heavy oil A
FD-12
40
40
35
FD-24
45
45
40
FD-100
50
50
45
FD-24
FD-12
製 品 重 量
SPECIFICATIONS
（Kerosene 20℃）
DELIVERY VOLUME PERFORMANCE CURVE
FD-12 FD-24 FA-100
P
U
M
P
Connection dia 20 mm (3/4")
Connection thread Parallel pipe thread
Total head 4 m
13 ft 6 m 20 ft 7 m 23 ft
Discharge volume 40 L/min
10.6 U.S.G/min 45 L/min 12 U.S.G/min 50 L/min 13 U.S.G/min
M
O
T
O
R
Rated voltage DC 12 V DC 24 V
AC 110 -120 V AC 220 - 240V
Ampere 14 A 7A 2.7 A 1 A
Power 80 W / 6000 rpm 90 W / 6700 rpm 120 W / 7350 rpm
Continuous use time Continuous 20 min
Power cord Oil-proof cord 4.8 m 15.7 ft
Fuse 20 A 10 A 3 A
Discharge hose Oil-proof rubber hose 20 mm(3/4") ×2 m 6.5 ft
Oil supply nozzle Aluminum alloy made 20 mm
Net weight 8 kg
3
