Kustom Signals HR-12 User manual

HR-12
HAND-HELDTRAFFIC
RADAR
OPERATOR’SMANUAL
P/N006-0420-00
REV. 3
Uploaded by BSLAWS

Uploaded by BSLAWS

Copyright1992
KustomSignals, Inc.
All rightsreserved
PrintedintheUnitedStatesofAmerica
Thepublicationmaynotbereproduced, storedinaretrievalsystem, ortransmittedinwhole
orinpartinanyformorbyanymeanselectronic, mechanical, photocopying, recording, or
otherwisewithoutpriorwrittenpermissionofKustomSignalsInc., 9325 Pflumm, Lenexa,
Kansas66215-3347.
Uploaded by BSLAWS

Uploaded by BSLAWS

TABLE OFCONTENTS
INTRODUCTION..............................................................................1
CONTROLSAND INDICATORS
RearView.....................................................................................2
SideView.....................................................................................4
RemoteControl.............................................................................5
INSTALLING THE RADAR.............................................................6
TEST SEQUENCE
PowerOn......................................................................................8
Circuit/LampTest.........................................................................8
TuningForkTest..........................................................................8
MovingTest..................................................................................9
DopplerAudio............................................................................10
SYSTEMOPERATION
ControlandFunctionSelections..................................................11
MonitoringTargetSpeeds...........................................................11
LockingandReleasing Targets...................................................12
HoldMode..................................................................................13
GENERALINFORMATION
TheoryofOperation....................................................................14
Interference.................................................................................15
PowerSource fortheHR-12.......................................................16
Groundspeed...............................................................................16
RecommendedCareandMaintenance.........................................16
MicrowaveEmission...................................................................17
TROUBLESHOOTING GUIDE.......................................................18
TECHNICALSPECIFICATIONS....................................................20
REFERENCES
CaseLaw....................................................................................21
FCC Rules..................................................................................22
WARRANTY...................................................................................23
RADARLOG...................................................................................24
Uploaded by BSLAWS

Uploaded by BSLAWS

INTRODUCTION
1
KustomSignals'newHR-12 offersyouthesamequalityandeaseofuseyou
havecometoexpectfromKustomSignals'trafficradarunits. Wehavetaken
ourHR-12 hand-heldmovingradarandupdateditsfeaturestoofferyouan
evenmoreusefulpiece ofequipmentforyourspeedlawenforcementneeds.
WehaveaddedaDay/Nightswitchsoyoucanadjustthebrightness ofthe
LEDdisplaystosuitambientlightconditions. Andwehaveaddedahand-
heldremotecontrolsoyoucan"keepyoureyesontheroad"butstill lock
targetspeedsorputtheunitinHoldMode. Inaddition, therearetwonew
indicatorlights--RFIandHold--togiveyoumoreinformationaboutoperating
conditions.
TogetthemostfromyournewHR-12, weurgeyoutoreadthisoperator's
manualcarefully. Whilethismanualisnotintendedasatrainingmanualand
cannotreplace atrainingclass, itdoesdescribetheHR-12'scontrolsandtheir
functionsaswell asgiveinformationonoperatingprocedures. Ifyouhave
questionsorexperience operatingdifficulty, contactyourKustomSignals
representativeorourCustomerService personnelforassistance.
Uploaded by BSLAWS

CONTROLSANDINDICATORS
2
REAR VIEW
A. POWER/VOLUME. DualpurposecontrolforON/OFF andtargetDoppleraudiovolume.
Turnthecontrolclockwise(pastthe"click")toturntheunitonandtoincreasethelevel
oftheDoppleraudio. Thepilotlight(lowerrightcornerofTARGET display)will light
toindicatetheradarisreceivingpower.
B. LOWVOLTAGE INDICATOR(LOVOLT). Whenlit, indicatesbatteryvoltagehas
droppedbelow10.8Volts. Displayswill beforcedblankunless inLockMode.
C. PATROLDISPLAY. RegistersspeedofthepatrolvehicleintheMovingMode.
D. RFIINDICATOR. Whenlit, indicatesthepresence ofstrongRFinterference. Displays
will beforcedblankinthepresence ofstrongRFunless intheLockMode.
C
D
F
E
G
H
B
PATROL TARGET
LO-VOLT RFI HOLDPOWER
HR
-
12
KUST
OM
POWER VOLUMETEST
A
Uploaded by BSLAWS

CONTROLSANDINDICATORS
3
E. HOLDINDICATOR. Whenlit, indicatestheHOLDswitchoneitherthesideoftheunit
ortheremotecontrolhasbeendepressedandthemicrowavesource isturnedoff. Audio
will beautomaticallysquelchedintheHoldMode.
F. TARGET DISPLAY. RegistersspeedofapproachingvehicleinMovingMode. Registers
speedofapproachingorrecedingvehicleinStationaryMode. Thelowerrightcornerof
thedisplayisthePowerIndicator, whichwill beglowingwhenevertheradarisreceiving
power.
G. TEST. Whenthisbuttonispressed, thesystemwill conductabrieflighttestofall display
segmentsandindicatorsfollowedbyaninternalcircuittest. Ashortsamplingofthe
Doppleraudiowill alsobeheard, indicatingproperfunctioningoftheaudiocomponents.
H. REMOTE CONTROLCONNECTOR. Providesattachment, viacable, totheHR-12's
remotecontrol.
Uploaded by BSLAWS

CONTROLSANDINDICATORS
4
SIDEVIEW
NOTE:Somelocalitiesdonotpermittheuseofanylockingfunction.Forthisreason,your
unitmaynotbeequippedwiththeLOCK-RELfunction.(Thetriggerwill be
presentbutwill notbefunctional,andtherewill benoLOCK-RELbuttononthe
remotecontrol.)
I. POWERCORD. Permanentlyattachedtotheradarunit, thiscordsuppliespowertothe
systemfromthepatrolvehicle'spowerreceptacle, orfromaportablebatterypack. The
fuseislocatedinthetipofthepowerplug.
J. DAY/NIGHT. Allowstheoperatortoadjustbrightness oftheTARGET andPATROL
displaystosuitambientlightconditions.
K
J
L
M
KUSTOM
HR
-
12
I
N
O
Uploaded by BSLAWS

CONTROLSANDINDICATORS
5
K. AIMING SIGHTS. Enablestheoperatortocorrectlyaim theHR-12 antennatoobtain
maximumeffectiverange.
L. STATIONARY/MOVING (STA-MOV). Byslidingtheswitchonthetoppaneltothe
desiredposition, theoperatorcanchooseeitherStationaryorMovingMode.
M. SQUELCH/UNSQUELCH(SQ-UNSQ). Byslidingtheswitchonthetoppanelto
desiredposition, theoperatorcanchooseeithersquelchedorunsquelched(continuous)
audio. IntheUnsquelchedMode, audiowill beheardwhetherornotatargetvehicleis
present.
N. HOLD. PressingtheHOLDswitchwill shutoff microwavetransmissiontoavoid
detectionbytrafficradardetectors. ThisbuttonalsoreleasesthesystemfromtheHold
Mode. (Thisfunctionisalsoavailableontheremotecontrol.)
O. TRIGGER. Pullingthetriggeronce will lockatargetvehicle'sspeedintotheTARGET
display. Pullingthetriggerasecondtimewill releasealocked-inspeed. (Thisfunction
isalsoperformedbytheLOCK-RELbuttonontheremotecontrol.)
REMOTE CONTROL
Theremotecontrolunitallowstheoperatortomaintainvisualcontactwiththetarget
whileperformingthenormalLock/ReleaseandHoldfunctions.
TheLOCK/RELEASE (LOCK-REL)button, ontheface oftheremotecontrol, isusedto
lockandreleasetargetvehiclespeeds. Thisbuttonisnotpresentonunitswithoutlock.
TheHOLDbutton, onthetopoftheremotecontrolunit, isusedtoplace thesysteminthe
HoldMode(sometimesreferredtoasStandby). Thisbuttonalsoreleasesthesystem
fromtheHoldMode.
Uploaded by BSLAWS

INSTALLINGTHERADAR
6
AdashmountisprovidedtoallowyoutomountyourHR-12 onthedashboardofthecar.
Toinstall thedashmount:
1.Place thebracketontopofthedashboard. SlidetheHR-12 intotheU-shapedholding
bracketuntil theradarissecurelylockedintothebracket.
2.Startthevehicle'sengine, thenturnthePWR-VOLcontroltotheON position.
SwitchtheSQ-UNSQcontroltotheUNSQposition. Adjusttheaudiotoa
comfortablelisteninglevelabovetheenginenoise.
3.WiththeHR-12 andmountsittinginthemiddleofthedashboard, andtheantenna
aimedstraightahead, adjusttheheater/airconditionerfanmotortoamid-rangefan
speed.
4.Listenforfannoiseintheaudio;adjustthepositionoftheradar/mountleftorrightas
neededforaNULL ornofannoise.
5.Moistenthebracket'ssuctioncups;slidethebrackettowardthewindshield, keepingit
level. Pushthesuctioncupsfirmlyagainstthewindshield. Attachthestretchcords
tothemountandhookintodefrostervents.
6.Usetheaimingsightsontopoftheradartomakesuretheradarisaimedcorrectly.
DuetothehighlydirectionalbeamtransmittedbytheHR-12, boththehorizontaland
verticalaimingisimportanttotheeffectiveoperationoftheunit.
AnoptionalkitisavailablefromKustomSignalstoallowpermanentmountingtothe
dashboardtoeliminatethepossibilityoftheradarflyingaboutthevehicleintheeventof
asuddenstoporchangeofdirection.
Plug theremotecontrolintothe6-pinconnectorontherearoftheradarunit. Donot
force theconnection--ifthetwoconnectorsarenotmatched, brokenorbentpinswill
resultandtheremotewill notwork.
InserttheHR-12'spowerplug intothevehicle'scigarettelighterreceptacle, auxiliary
powerreceptacle, orportablebatterypack.
NOTE:Ignitionsystemsincertainvehiclessometimesinterferewiththeproperoperationof
any trafficradarsystem.Therefore,anauxiliarypowerreceptacleandshielded
cable,whichcanbemountedunderthedashboardandwireddirectlytothebattery,
isavailableforyourHR-12.
Toinstall theauxiliaryreceptacleandcable:Mountthereceptacleinthedesired
locationandgroundtheblackwiretothereceptaclebracket.Runthecabletothe
battery;attachthewhitewiretothepositiveterminal,andtheblackwiretothe
negativeterminal. Ensureall attachmentsarefirmandwill noteasilyvibrateloose.
Uploaded by BSLAWS

INSTALLINGTHE RADAR
7
Uploaded by BSLAWS

TESTSEQUENCE
8
Toassurefunctionalityandaccuracy, werecommendthatcircuit/lamptest, tuningforktest,
andmovingtestbeconductedatthebeginningandendofeachpatrolshift. Theresultscan
berecordedinaradarlog(suchastheoneattherearofthismanual)forfuturereference. If
theunitfailsanyofthesetests, itshouldberemovedfromservice immediatelyandtakento
anauthorizedservice centerforrepair.
POWERON
TurnthePOWER/VOLUME knobclockwise(pastthe"click"). Checktoensurethe
powerindicatorisglowing. Iftheindicatordoesnotcomeonwhenthe
POWER/VOLUME knobhasbeenturnedpastthe"ON"point, rechecktheconnectionto
thepowersource.
NOTE:Batteryvoltagemustbebetween10.8VDCand16.5VDCforproperoperationof
theHR-12.
Whenfirstturnedon, theHR-12 automaticallyconductsapower-onselftest. The
PATROLandTARGET displayswill register"188""188", followedby"64""64"in
MovingModeand"""64"intheStationaryMode, alongwithabriefsampleofDoppler
audio(volumemustbeturnedup).
CIRCUIT/LAMPTEST
Press andholdtheTEST button. ThePATROLandTARGET displayswill read"188"
"188"followedby"64""64"intheMovingMode, """64"intheStationaryMode, anda
sampleofDoppleraudio.
TUNINGFORKTEST
StationaryMode
1. Place thesystemintheStationaryModebysettingtheMOV-STAswitchtotheSTA
position. TurntheRANGE controlfullyclockwise.
2. Twotuningforks(35 &65 MPHor45 &80 KPH)aresuppliedwiththeHR-12.
Strikethelowerspeedtuningforkonahard, non-metallicsurface, suchastherubber
heelofashoe. Holdthevibratingtuningforkapproximatelyoneinchinfrontofthe
antenna. TheTARGET displayshouldregister"35"(45).
3. Repeattheprocedurewiththehigherspeedtuningfork. TheTARGET displayshould
register"65"(80).
Uploaded by BSLAWS

TESTSEQUENCE
9
MovingMode
1. Place thesystemintheMovingModebysettingtheMOV-STAswitchtotheMOV
position. LeavetheRANGE controlclockwise.
2. Lightlystrikebothtuningforksonahard, non-metallicsurface. Holdthe35 MPH
(45 KPH)tuningforkapproximatelyoneinchinfrontoftheantennauntil the
PATROLdisplayregisters"35"(45). Thenplace thesecondtuningfork
approximatelyoneinchinfrontoftheantenna(bothforksshouldbeinfrontofthe
antennaatthistime). TheTARGET displayshouldregister"30"(35).
Iftheproperreadingisnotobtained:
1.MakesurethatKustomSignalsK-Bandtuningforkshavebeenused("K-Band"is
stampedplainlyoneachfork). X-Bandtuningforks, ortuningforksdesignedforuse
withothermanufacturers'radar, will notgivetheproperreadings.
2.Strikingthetuningforkstoo hardmayproduce falseovertoneswhichmaybereadas
speedsslightlyaboveorbelowthosespecified. Thesepossiblefalsereadingsare
momentary, andtheproperreadingsshouldappearasthefalseovertonesdissipate.
Donotmovethetuningforksafterplacinginfrontoftheantenna.
3.EnsurethesystemisnotintheHoldMode.
4.Extremelycoldorextremelyhottuningforksmaygivereadingsslightlyaboveor
belowthosespecified, duetotheeffectofextremetemperatureonthemetal. Ifthisis
thecase, warmorcooltheforkstonormalroomtemperaturebeforeuse.
NOTE:IfcorrectreadingsarenotobtainedafterPoints1-4havebeenrechecked,the
systemshouldbeshutdownandtakenoutofservice.
MOVINGTEST
Foranadditionalcheckoftheunit, aim theradarstraightahead, drivethepatrolvehicle,
andcomparethereadinginthedisplaywiththevehicle'sspeedometer. Thespeed
registeredinthedisplayandspeedometershouldcoincide, orbewithinreasonablelimits
(allowingforminorspeedometererror). Thesecomparisons, onaday-by-daybasis, area
reliablewaytochecktheaccuracyofyourradar. Iftherearemajor discrepancies
betweenthespeedregisteredandthevehiclespeedometer, thesystemshouldbetakenout
ofservice until thediscrepanciesareresolved. (Thischeckisoneofthebestwaysto
verifytheproperoperationofyourradar.)
Uploaded by BSLAWS

TESTSEQUENCE
10
DOPPLERAUDIO
ToreceiveDoppleraudio, setthePOWER/VOLUME controlpastthePower-Off
position. Volumeoftheaudiocanbeincreasedbyturningthecontrolclockwise. The
audiopitchwill correspondtothespeedbeingdisplayed;thatis, thegreaterthespeed, the
higherthepitch. Audiowill bepresentfromapproachingorrecedingvehicles. The
audiopresentationisespeciallyusefulinthecaseofmultipletargets, whentarget
identificationismoredifficult. Theoperatorhastheoptionofsquelchedorunsquelched
audiobysettingtheSQ-UNSQswitchtothedesiredposition. Whennotargetispresent,
selectingtheUnsquelchedmodeallowstheoperatortolistenforpossibleinterference in
theoperatingarea.
Uploaded by BSLAWS

SYSTEMOPERATION
11
CONTROLAND FUNCTIONSELECTION
SelectMovingorStationaryModebyslidingtheMOV-STAswitchtothedesired
position. UseMovingModewhenthepatrolvehicleiscruisingandmonitoring
approachingtargetvehiclesandStationaryModewhenatafixedpositionandmonitoring
approachingorrecedingtargetvehicles.
AdjustthevolumecontrolforcomfortablelisteningtotheDoppleraudiolevel. Toselect
unsquelched(continuous)audio, slidetheSQ-UNSQswitchtotheUNSQposition.
MONITORINGTARGET SPEEDS
Once theradarhasbeenproperlysetup andtested (see precedingsections), itisreadyfor
use. Acquiringanddisplayingvalidtarget(andpatrol)speedsrequiresobtainingaproper
trackinghistory, asdescribedbelow:
1.Visuallyobservetargetvehicleandestimateitsspeed.
Recheck antennaaim andMOV-STAselection.
Observe othervehicleswhichmaybeintheradarbeamandwhicharepotential
targets(ormayblocktheradar's"view"oftheselectedtarget), especiallythosewhich
arelarger, closer, ormuchfaster thantheselectedtarget.
Bealert toterrainorroadsidefeatures, whichcancauseinterference, incorrect
readings, ordisplayblanking. (Suchfeaturesincludepowerlines, radio/TV
transmitters, bridges, guardrails, andotherlargereflectors, etc.)
2.ListentotheDoppleraudio. Thepitchofthetoneshouldcorrespondtothevisual
estimatemadeabove. Thetoneshouldbeclearandstrong;scratchy, “buzzy”, or
garbledtonescouldindicateinterference ofsomesort.
3.ChecktheradarTARGET display. Thereadingshouldcloselymatchthevisual
estimateandthepitchoftheaudiotone.
4.IfyouareoperatinginMovingMode, checkyourspeedometeragainstthePATROL
display. Thereadingsshouldcorrespond. Discrepanciesindicatetheradarisreading
thePATROLspeedincorrectly, andthusdisplayinganincorrectTARGET speed.
CommoncausesofincorrectPATROLreadingsarelargereflectors(suchastrucks)
immediatelyaheadofthepatrolvehicleorattheroadside. Ifthisisthecase, passing
orputtingmoredistance betweenthepatrolvehicleandthereflectorshouldclearup
thediscrepancy. Properantennaaimingwill helpeliminatecosineerrorinthe
PATROLspeed. Afterobtainingapropergroundspeedreading, repeatsteps1-4.
Uploaded by BSLAWS

SYSTEMOPERATION
12
LOCKINGAND RELEASINGTARGETS
NOTE:Tocomplywithvariousstateandlocalrequirements,yourunitmaynotbe
equippedwiththelockfeature.Referencestothelockfeaturedonotapplytothese
units.
TheMovingModeandtheStationaryModeoflockingandreleasingtargetsarethesame,
exceptnoPATROLdisplaywill registerifinStationaryMode. Thehand-heldremote
controlLOCK-RELbuttonorthetriggerisusedtomanuallylockorreleaseatarget
Toaidinpositiveidentificationofatarget, theHR-12 automaticallyunsquelchesthe
audioassoonasthetargetislockedin. Thismeansthataudiowill continuetobeheard
andtheantennawill continuetotransmitRFenergyandmaythusbedetectedbyradar
detectiondevices. ShouldyouwishtoescapedetectionintheLockMode, youcanuse
theHoldMode(noRFenergywill betransmittedintheHoldMode). Theunitwill
remainintheHoldModeuntil manuallydeactivatedbydepressingtheHOLDbutton
again.
1.Observetargetvehicle;obtainpropertrackinghistory.
2. Press andholdtheLOCK-RELbuttonontheremotecontrolorpull thetriggeruntil
thelocked-inspeedsflashinthedisplaysandtheunithasbeeped.
3.Toreleaseatargetineithermodeofoperation, press theLOCK-RELbuttonorpull
thetriggeragainaftercompletionofthealarmbeep.
NOTE:Priortolocking,theHR-12 performsabrief,internalaccuracytest.(Thistestwill
notappearineitherdisplay.)Ifthesystempassesthetest,itwill allowlockingof
targetandpatrolspeeds.Iftheself-testfails,theTARGET displaywill register"0".
Releaseanylocked-inspeedandtryagain.Iftheunitcontinuestodisplay"0",
removefromservice andtaketoanauthorizedservice centerforrepair.
Uploaded by BSLAWS

SYSTEMOPERATION
13
HOLDMODE
TheadvancedelectronicsintheHR-12 enableittocompletelyescapedetectionbytraffic
radardetectorsbyeliminatingall microwavetransmissionintheHoldMode. Toactivate
theHOLDfunctionineitherMovingorStationaryMode:
1.Press theHOLDbuttonontheremotecontrolorthesideoftheHR-12.
2.Bothdisplayswill becomeblankandtheHOLDindicatorwill light.
3.Visuallyacquirethetargettobegintrackinghistory.
4.Press thesameHOLDbuttonasecondtimetoreleasethesystemfromtheHold
Mode. WhenreleasedfromtheHoldMode, theHR-12 recapturesgroundspeed(ifin
MovingMode)andacquirestargetvehiclespeedalmostinstantaneously.
NOTE:YoumustusethesameHOLDswitchtoreleasetheunitfromtheHoldModeasyou
usedtoplace itintotheHoldMode--thatis,ifyouplacedtheradarinHoldwiththe
remotecontrol,youmustreleaseitfromHoldwiththeremotecontrol.Useofone
HOLDswitch(eitherontheremoteorontheunit)will lockouttheotherHOLD
switch.
Afteracompletetrackinghistoryisobtained, youmaynowperformthelockingfunction
bypressingtheLOCK-RELbuttonontheremotecontrolorbypullingthetrigger.
Uploaded by BSLAWS

GENERALINFORMATION
14
THEORY OFOPERATION
TheHR-12 movingradartransmitsaradiofrequencyof24.150 Gigahertz, incompliance
withFederalCommunicationsCommission(F.C.C.)regulations. Aportionofthe
transmittedsignalstrikesthesurface oftheroadwayandsurroundingterrainandis
reflectedbacktotheantenna. Thisreturningsignalisreferredtoasthe"low"Doppler.
Fromtheantenna, ittravelstotheprocessorwherethesignalistranslatedintothespeed
ofthepatrolvehicle(groundspeed)andregisteredinthePATROLdisplay.
Aportionofthetransmittedsignalstrikesanoncomingvehicle(targetvehicle)and
returnstotheantennaatamuchhigherfrequencybecausethetwoobjects(patrolvehicle
andtargetvehicle)areconverging. Thisreturningsignalisreferredtoas"high"Doppler.
Thentheprocessormeasuresthespeedofconvergence, orcombinedspeed, ofthepatrol
vehicleandtargetvehicle.
Afterreceivingthe"high"Dopplersignal, theprocessorautomaticallycomputesthe
difference betweenthespeedofthepatrolvehicle("low"Doppler) andthespeedof
convergence ("high"Doppler. Thespeedoftheapproachingvehicleisthenregisteredin
theTARGET display.
If, forexample, aHR-12 equippedpatrolcaristraveling55 MPH, the"low"Doppler
frequencyreturnedtotheantennaistranslatedinto55 MPHandisregisteredinthe
PATROLdisplay. Anoncomingvehicleistraveling65 MPH. The"high"Doppler
frequencyreturnedtotheantennaistranslatedinto120 MPH, orthecombinedspeedof
bothvehicles. Theprocessorautomaticallysubtractsthe"low"Doppler55 MPHofthe
patrolcarfromthe120 MPH"high"Dopplerspeedofconvergence. The65 registeredin
theTARGET displayisthespeedoftheapproachingvehicle.
Uploaded by BSLAWS
