Kuvings NS-995UL User manual

Instruction Manual
Kuvings Silent Juicer
‘Life Tastes Good’Global Company

SAFETY PRECAUTIONS
02 03
The following information is intended so as to prevent damage to the unit or injury.
Please read the following pages and use the appliance properly.
This sign warns risk of death or severe injuries
This sign warns risk of injuries or product damage
Must follow instructions Prevention of electric shock
Prohibited Must take action
Do not dissemble
Must unplug electric cord
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
When using electrical appliances,
basic safety precautions should always be followed including the following:
1. Read all instructions.
2. To protect against risk of electrical shock do not put motor or base of unit in water or other liquid.
3. Close supervision is necessary when any appliance is used by or near children.
4. Unplug from outlet when not in use, before putting on or taking o parts, and before cleaning.
5. Avoid contacting moving parts.
6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions,
or is dropped or damaged in any manner. Return appliance to the nearest authorized service facility for
examination, repair or electrical or mechanical adjustment.
7. The use of attachments not recommended or sold by the manufacturer may cause re,
electric shock or injury.
8. Do not use outdoors (this may be omitted if it is specially designed for outdoor use).
9. Do not let cord hang over edge of table or counter.
10. Do not let cord contact hot surface, including the stove.
11. Always make sure juicer cover is clamped securely in place before motor is turned on.
Do not unfasten clamps while juicer is in operation.
12. Be sure to turn switch to OFF position after each use of your juicer. Make sure the motor stops completely
before disassembling.
13. Do not put your ngers or other objects into the juicer opening while it is in operation.
If food becomes lodged in opening, use food pusher or another piece of fruit or vegetable to push it
down. When this method is not possible turn the motor o and disassemble juicer to remove the
remaining food.
14. Do not use the appliance if the rotating sieve is damaged.
15. When a separable pulp container is provided, Do not operate without the pulp container in place.

Safety warning Safety precaution
04 05
Do not plug in the cord with wet hands or you
could receive an electrical shock. Make sure
your hands are completely dry prior to use.
Do not plug multiple cords into a single outlet
or a re may result.
Do not use the appliance on an uneven
surface.
⻱Note: Otherwise the
appliance can fall or
cause a malfunction.
Please do not insert any silverware, other metals or ngers into the
appliance while the cord is plugged in.
⻱Note: Otherwise an electrical shock will occur.
Please unplug the cord when not in use.
Do not keep or operate the appliance near
infants or small children.
⻱Note: Otherwise, it may injure them.
Do not curve or twist the cord or put
pressure on the cord.
⻱Note: Otherwise, you may cause a
re or harm to yourself.
Do not spray water or ammable sprays on
or near the appliance.
⻱Note: Otherwise, it may cause
an explosion or electrical
shock.
Please do not pull the cord to unplug the
outlet.⻱Otherwise the cord can break and may
cause
electrical shock or re.
Do not use the appliance near any heat source
⻱Note: Otherwise the appliance can
change color.
Do not repair, disassemble the base, or
customize the appliance.
⻱Note: Otherwise, you may cause a re or harm
to yourself.
Do not use any cleaning chemicals to clean
the appliance.
⻱Note: Otherwise it may change the color of the
appliance or could result in a re.
Do not drop the appliance or subject the
appliance to any impact.
⻱Note: Otherwise the appliance
may malfunction.
Do not put the parts in a dishwasher nor very
hot water.
⻱Note: Otherwise, parts will wear faster.
Do not spray water or ammable sprays on or
near the appliance.
⻱ Note: Otherwise, it may cause an explosion or
electrical shock.

06 07
Features Parts
Low speed extraction method
The juicer extracts juice instead of grinding, to retain all the nutrients and enzymes for a healthier,
natural juice every time.
Multi-purpose for food preparation and cooking
Extract vegetable juice, soy juice, fruit juice, homemade tofu and more for convenience and speed.
Easy to clean
The juicing bowl and the base come apart easily for cleaning and assembly.
Two-step safety start system
All parts must be assembled properly and the lid must lock securely into place to start the juicer.
This assures a safe operation.
Handgrip for ease of use
Handgrip feature makes it easier to use and move.
Powerful motor, no heat build-up
The high powered, low speed motor is able to process very high brous fruits and vegetables completely.
The unit stays cool due to the slower processing speed.
Quiet operation
The motor is quiet and extracts juice fast.
Convenient auto purifying
Simply pour water into the appliance after each use for self-cleaning. The juice will taste fresher each
time you make it.
Pusher
Cleaning Brush
hopper(Lid)
Drum (Lid)
Pulp containerJuice cup
Rotation wiper
Juicing bowl
Base
Juicing screw
Assembly
position mark
Assembly position mark
Assembly
position
mark
Strainer
<Two step safety device>
The base and basket must be
assembled properly,
then turn the switch on.
<
P
o
w
e
r
S
w
i
t
c
h
>

Assemble the entire top set onto the base.
- Align the mark on the top set unit into on the
base unit. Turn the top set unit clockwise to match
mark and mark of the base unit.
08 09
How to assemble the parts to a base unit
Disassembly is the reverse steps of assembly steps.
Before attaching Juicing bowl to the base unit, check if the pulp extraction silicon is adjusted properly.
If pulp extraction silicon is not adjusted properly, juice can leak outside of the juicing bowl and the amount
of juice would be less.
12
Make sure the red dot on the strainer
and the red dot on the bowl is aligned.
Place the strainer into a rotation wiper.



Connect the lid and the bowl through
the red spot assemble mark and
assemble it by turning it the clock-wise.
Insert the Juicing screw into center
of strainer.
୔GSpin and push the juicing screw
while inserting into the strainer.
Assembly position markAssembly position mark
Juicing Bowl
assemble mark
Juicing Bowl
assemble mark
୔GMake sure the red spot on the lid
and the red spot on the bowl is aligned.
Juicing Bowl
assemble mark
Strainer assemble mark
Place the strainer and wiper
into the bowl properly.
Stainer + Juicing Bowl
Juicing Bowl
Juicing Bowl
Drum (Lid)
Strainer
Juicing Bowl
6OEFSOFBUIUIF#PXM
5IJTQBSUJT
EFUBDIBCMF
GPSDMFBOJOH
The pulp extraction silicon has to be attached to the pulp outlet. Always insert the rubber gasket properly before use.
Strainer
Rotation wiper
Screw





Place the pulp container under the base
hook.
Place the juice cup properly.
Turn the lid towards‘close’mark.
Turn the Lid clock-wise until mark
on the lid is alignment with mark on
the juicing bowl unit.
*OTFSUJPO%JSFDUJPO 'JSNMZ*OTFSUJPO
Base hook

10 11
How to use the Silent Juicer
2
Clean the fruits or vegetables and cut it in right amount
and then insert into the appliance.
ื(length 10~15cm, width 2~3cm)
Do not insert spoon, chopstick, fingers or any silverware
into the appliance. Please use the pusher to push down
the fruits or vegetables.
1. Please insert the fruits or vegetables one by one, when inserting different fruits or
vegetables, wait until appliance extracts the other items.
2. Please cut high fiber materials into right amount to get the best result.
(length 10~20cm)
3. When extracting carrot, extract with different vegetable with high fiber to get
more juice from the carrot since the carrot has low fiber. Please cut carrot into
quarters before inserting it in to get the best result (Different fruits or vegetables
have different amount of juice to extract)
4. If the fruits or vegetables to be juiced is not fresh, the amount of juice will be less.
To get more juice, dip it in the clean water until the fruits or vegetables gets wet.
Then the fruits or vegetables will have more juice to be extract.
5. Some fruits or vegetables do not have juice that can be extracted
(Arrow root, or strong fiber fruits or vegetables)
Notice
3
If the appliance stops in the middle of operating,
then please press the 'OFF' switch and press the
'REVERSE' switch to push back the fruits or vegetables
that have been stuck between the screw and the juicing
bowl. Then please press the 'FORWARD' switch.
(Repeat the procedures 3 times)
. If the appliance still does not work, then Please disassemble
the parts and clean the fruits or vegetables to use it again.
('REVERSE' button only works while holding the switch)
Be sure to stop the appliance after the pulps and the juices are out of the appliance.
(If all the pulps are not removed out of the appliance, It may be difficult to the appliance to open.)
While operating 'FORWARD' switch, please press 'OFF' switch
and wait until the appliance stops completely to use the
'REVERSE' switch. (If 'reverse' switch is press without being
stopped, it may cause the appliance to malfunction.)
. while operating 'REVERSE' the hopper(lid) may would disassemble,
so please hold on the hopper with one hand when operating
reverse switch.
Pushes down the fruits or
vegetables to extract
pushes up the fruits or vegetables
How to disassemble
When Silent Juicer
stops from operating,
please turn the top set
towards to‘open’ sign.
Please detach the top set from
the base unit by pulling it up
in order to disassemble it.
. The disassembly for the top
set is the reverse order of
assembly for the top set.


1
Please check the power switch is on off then plug the cord into the outlet to turn it on.
ืDo not turn on power switch without anything to
extract. (It may cause a malfunction)
ืCheck if Juice cub and pulp container are set up
properly to prevent leaking juice or pulp.
ืWhile in use, the appliance will be making a beep
noise. The noise is the screw cleaning up the juicing
bowl and it will disappear right after inserting
fruits or vegetables.

Recipe for juice
12 13
Carrot is one of the best vegetables for high nutrition and has a great taste which is a
favorable juice to many people. Carrots have a specially sweet taste which can cover the
bitter taste of different vegetable when they are mixed. Carrots contain high pro-vitamin A
and carotene, however, consuming 2 carrots has enough of 4 times of RDA for Vitamin A.
A Tomato is a typical vegetable juice which itself is a very refreshing juice. Lycopene is a
red pigment which is an antioxidant that causes the inhibition of cell aging and also the
sour taste will boost up the citric acid which is best for morning juice. Cherry tomatoes
have a strong sweet taste which is great to make a variety juices with different fruit.
well being prescription
The juice is enriched with vitamin A and C which effectively prevents Cancer,
stroke, and heart disease. ,The tomato acid is great for recovering fatigue and also
for relieving queasiness.
(Cherry tomatoes has a higher nutrition and higher density with higher calories
which people use often for ingredients of juice)
1. For organic tomato, just rinse them with running water.
If it is not organic, please use degradable natural detergent to clean tomato.
2. Insert the tomatoes into the appliance when they are prepared.
well being prescription
Carrot juice has a high vitamin-A content which prevents skin aging and also
makes eyesight better as well as immunity. Carrot juice contains high dietary fiber
which is great for diet. One carrot juice per day can normalize the body as well as
decrease the chance of getting lung cancer. Carrot juice is one the best drinks for a
woman skin.
1. Non chemically treated carrots are good enough for cleaning with water and chemical treated
carrots must be cleaned with soup.
2. Please cut the carrot into the right
amounts to insert.
3. Insert the prepared carrots into the appliance
and reinsert the extracted carrot juice into the
appliance to make it decrease the
amount of residue in the
appliance, it also makes
the juice clear and fresher.
Maximum rating is based on Model NS-998 under normal load of cutting soaked carrot,
other Models may draw significantly less power.
After juicing, you might observe the layer separation depends on ingredient's concentration.
Carrot JuiceTomato Juice

14 15
How to clean and store
When malfunction occur while using
1
Turn the switch to 'OFF' and then
unplug the cord.
Remove all the fibers in the juicing bowl before
stopping the appliance.
Dissemble the parts reverse way of
assemble.
After use, if the appliance does
not get clean, then it is much
difficult to clean as well as the
reason of the performance
resistance.
3 4
Strainer, juicing bowl and juicing screw
has to be clean with the supplied brush
and medium strong detergent.
Then keep it dry.
2
After using the appliance, hold on to the
juicing outlet and turn the juicing bowl to
'open' mark to dissemble the base unit.
5
Clean the base unit wet soft towel.
Hearing unusual noises
-Turn the switch to 'OFF' then check if the parts are assembled properly.
-Check if fruits or vegetables are cut it in right portion.
When Motor does not work.
-Check if the cord is plugged properly.
-Check if all the parts are assembled properly.
-Turn the switch to 'OFF' and let appliance rest for an hour in order to work again.
When appliance stops in middle of operating or re operating, the reason could be either fruits or vegetables are too
big to be extract or motor is overheated.
When appliance stops in middle of operating.
- When appliance stops in middle of operating then turn the switch to 'OFF' and press
'REVERSE' switch to unclogged the fruits or vegetables in the juicing screw. Then press
the 'FORWARD' switch to push the fruits or vegetables down the screw. (repeat the steps 3times)
If the appliance still does not work, then dissemble the juicing bowl and clean all the fruits or vegetables
that has been clogged.

16 17
Juicer
NS-995UL, NS-996UL, NS-997UL, NS-998UL
AC120V / 60Hz
330W
Less than 30 Min
7kg
245 x 165 x 435 (mm)
NUC Electronics Co., Ltd.
Low speed compression
Product
Model No.
Voltage
Power Consumption
Maximum Use
Weight
Dimensions(W x D x H)
Manufacturer
Compress type
4UBUVT $IFDLMJTU
- Check if the cord is plugged properly.
- Check if any fruits or vegetables are clogged and when motor works then nothing
is wrong with the motor.
- Check if "reverse" switch operates.
When motor stops in
middle of using.
Seems like juicing screw
is grinding.
- Juicing Screw and strainer are stuck together, so do not operate for long time when
there is nothing to be extract.
Amount of juice is little. - Each fruits or vegetables to be juiced may produce a different amount of juice.
- Even same fruits or vegetables can have different amount of juice due to the freshness
of the fruits or vegetables.
- To extract more juice out of the refrigerated fruits or vegetables, put it in the clean water
and wait until the fruits or vegetables are moist enough to be extract.
- Carrot has a low fiber which it is hard to extract it, to get a best result extract carrot
with different high fiber fruits or vegetables. Such as, kale, leafy green vegetable.
Please cut the carrot into quarterly to get a best result.
- Check if the pressure silicon is assembled properly.
After juicing, the amount
of pulp in the juice is great.
Stops middle of operating. - Too much fruits or vegetables in the screw or over heated motor may stop the appliance
in middle of using. Please wait until the appliance is cool down to use it again.
- Please place the motor around cool temperature area.
- When using the fruits or vegetables with the hard seed in it, please remove all the seeds
in the fruits or vegetables to use. It may break down the juicing screw.
Juicing bowl is shaking
in middle of operating.
- It is completely normal that juicing bowl is shaking little bit while operating.
- Check if the pressure silicon is assembled properly.
Juice is leaking from
the juicing bowl.
- If the pressure silicon is not assembled properly, it may leaked the juice out of the
juicing bowl.
The Lid is not opening - Turn the hopper unit to counter clockwise to open the Lid.
Q & A
Specification

Memo Memo
18 19
