Mini Centrifuge User Manual
C1601-B C1601-P
C1601-R C1601-G
Copyright 2017

About This Manual:
This manual is designed to assist you in the optimal usage of your Labnet
Mini Centrifuge. The manual is available in English, French, German, Italian,
Portuguese, and Spanish on our website at:
www.labnetinternational.com
Product Overview:
The Labnet 1601 Mini Centrifuge provides comprehensive designs for a wide
variety of life science research applications. Smart and stable running can deliver
accurate and reliable experimental results from one experiment to another.

Table of Contents
1.0 Specications .........................................................................................1
1.1 Environmental Conditions..................................................................................................................1
2.0 General Information................................................................................1
3.0 Safety Precautions .................................................................................1
4.0 Installation ..............................................................................................2
5.0 Operation................................................................................................2
6.0 Equipment Maintenance.........................................................................2
7.0 Rotors.....................................................................................................3
8.0 Cleaning .................................................................................................3
9.0 Service....................................................................................................3
10.0 Appendix...............................................................................................3
10.1 Spare Parts.......................................................................................................................................3
10.2 Symbols and Conventions................................................................................................................3
10.3 Equipment Disposal - European Regulations...................................................................................3
10.4 Limited Warranty...............................................................................................................................4

Mini Centrifuge | 1
1.0 Specications
Dimensions 5.9 x 5.9 4.6 in/15 x 15 x 11.6 cm
Weight 2.65 lbs/1.2kg
Electrical
Unit Input
AC 100 -- 240V,50/60Hz, 0.35
24VDC 1A
Maximum Speed/RCF 6000rpm/2000 x G
1.1 Environmental Conditions
Indoor use only
Altitude up to 2000m
Temperature 5°C to 40°C
Maximum relative humidity 80% for temperature up to 30°C decreasing linearly to 50% relative
humidity at 40°C
Pollution degree 2
If the centrifuge is used in a manner not specied by the manufacturer, the protection provided by the centrifuge may be impaired.
2.0 General Information
The Labnet C1601 Mini Centrifuge is supplied with two rotors, one for micro tubes and one for 0.2ml PCR
strip tubes. The 8 place rotor is designed to centrifuge up to eight individual 1.5/2.0ml plastic micro centrifuge
tubes. It will also accept 0.5/0.6ml,0.4/0.25ml and 0.2ml tubes with the adapters supplied with the unit. The
strip tube rotor is designed to centrifuge four 8 x 0.2ml strip tubes. It will also accept up to 32 individual 0.2ml
tubes. Both rotors are designed for applications requiring relatively low g-forces, such as microltration, cell
separation and quick spin downs from the walls of tubes.
Please read this manual thoroughly before attempting to operate the centrifuge.
3.0 Safety Precautions
NEVER use the centrifuge in any manner not specied in these instructions.
NEVER operate the centrifuge without a rotor properly attached to the shaft.
NEVER ll tubes while they are in the rotor. Liquid spillage may harm unit.
NEVER put hands in the rotor area unless the rotor is completely stopped.
NEVER move the centrifuge while the rotor is spinning.
NEVER use solvents or ammables near this or other electrical equipment.
NEVER centrifuge ammable, explosive or corrosive materials
NEVER centrifuge hazardous materials outside of a hood or proper containment facility
NEVER try to continue operating the centrifuge if the centrifuge stops working prematurely.
Stop the centrifuge immediately by turning off the main power switch on the back side of the centrifuge. Wait
one minute before turning on the main power switch to operate the centrifuge again.
ALWAYS load the rotor symmetrically. Each tube should be counterbalanced by another tube. Weight of
individual tubes may not exceed of 3.0g.
ALWAYS locate the centrifuge within easy access to an electrical outlet.
ALWAYS use only micro centrifuge tubes made from plastic and designed to withstand centrifugal forces of at
least 2,000 x g.

2 | Mini Centrifuge
4.0 Installation
Adapter body American Australian European British
Push the plug into its position rmly!
5.0 Operation
Before operating the centrifuge, be sure that the power switch on the back of the unit is in the “on” position.
To begin a run, simply close the lid of the centrifuge. No other controls are required.
Fast stop
Press down and release the tab on the front of the lid. This will release the lid lock, allowing the lid
to open and the rotor to come to a braked stop.
Gradually stop
Put the power switch in the “off” position, this will cut the power to the motor, and the
rotor to come to a gradual stop.
Caution: Do not attempt to open the lid or remove samples until the unit has come to a complete stop. Once
the rotor has come to a full stop, the lid can be manually lifted to the full open position and samples may be
removed from the rotor.
Safe operation of the centrifuge requires that the rotor be loaded in a balanced fashion. Failure to load the
rotor properly presents a hazardous condition and may damage the centrifuge. Individual tubes, strip tubes
and/or adapters must always be loaded symmetrically to ensure proper balance. Never run the centrifuge
with only one tube or one strip tube in place.
6.0 Equipment Maintenance
The centrifuge should be cleaned periodically. Ensure that the unit is not plugged in. Use a damp cloth and a
mild, noncorrosive detergent (ph<8). Do not immerse the centrifuge in liquid or pour liquids over it. Excessive
amounts of liquid should be avoided. Liquid should not come into contact with the motor. After cleaning,
ensure all parts are dried thoroughly before attempting to operate the unit.
Should a spill of infectious materials occur within the rotor or rotor chamber, the unit should be disinfected.
This should be performed by qualied personnel with proper protective equipment.
1. Make sure to always install the centrifuge on stable at surfaces only
2. Place the centrifuge near the electrical outlet
3. Power adapter instructions
3.1 Power adapter components

Mini Centrifuge | 3
7.0 Rotors
The centrifuge is supplied with two interchangeable quick release rotors. No tools are required to exchange
the rotors or attach them to the motor shaft. The rotors can be easily exchanged with one hand by way of
the quick release system. Removal of the rotors is done by placing your thumb on top of the motor shaft
and lifting up with two ngers under the rotor. Place the other rotor into position on the motor shaft and
snap in.
8 place tube rotor 4 place strip rotor
8.0 Cleaning
Before using any cleaning or decontamination methods except those recommended by the manufacturer, check
with the manufacturer that the proposed method will not damage the equipment. To clean the centrifuge, use
a damp cloth and a mild, noncorrosive detergent (ph <8). After cleaning, ensure all parts are dried thoroughly
before attempting to operate the unit. Do not immerse the centrifuge in liquid or pour liquids over it.
9.0 Service
Should you have a question about the operation of the Mini Centrifuge or if service is required, contact Corning
at: 800-492-1110. Do not send in a unit for service without rst calling to obtain a repair authorization number.
Should the unit require return to Corning for service, it should be properly packed to avoid damage. Any
damage resulting from improper packaging shall be the responsibility of the user.
10.0 Appendix
8 place tube rotor for Mini Centrifuge
4 place PCR strip rotor for Mini Centrifuge
Adapter, 0.5ml tubes
Adapter, 0.2ml tubes
Adapter, 0.25ml tubes
10.1 Spare Parts
6770-RT
6770-RTS
6770-RTA.5
6770-RTA.20
6770-RTA.25
401025 Power Adapter, 24V for Mini Centrifuge
10.2 Symbols and Conventions
The following chart is an illustrated glossary of the symbols that may be used in this manual or on the
product.
CAUTION This symbol refers you to important operating and maintenance (servicing)
instructions within the product Instruction Manual. Failure to head this information may
present a risk of damage or injury to persons or equipment
10.3 Equipment Disposal - European Regulations
According to Directive 2012/19/EU of the European Parliament and of
the Council of 4 July 2012 on waste electrical and electronic equipment
(WEEE), Labnet C1601-B Mini centrifuge is marked with the crossed-out
wheeled bin and must not be disposed of with domestic waste.
Consequently, the buyer shall follow the instructions for reuse and recycling
of waste electronic and electrical equipment (WEEE) provided with the
products and available at the following link: www.corning.com/weee

4| Mini Centrifuge
10.4 Limited Warranty
Corning Incorporated (Corning) warrants that this product will be free from defects in material and workmanship
for a period of two (2) years from date of purchase. This warranty is valid only if the product is used for its intended
purpose and within the guidelines specied in the supplied instruction manual.
Should this product require service, contact Corning Customer Service department at 1.800.492.1110 or
978.492.1110 to receive a return authorization number and shipping instructions. Products received without proper
authorization will be returned. All items returned for service should be sent postage prepaid in the original packaging
or other suitable carton, and padded to avoid damage. Corning will not be responsible for damage incurred by
improper packaging,.Corning may elect for onsite service for larger equipment.
This warranty does not cover damage caused by accident, neglect, misuse, improper service, natural forces, or
other causes not arising from defects in original material or workmanship. This warranty does not cover motor
brushes, fuses, light bulbs, batteries, or damage to paint or nish. Claims for transit damage should be led with
the transportation carrier.
ALL WARRANTIES INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE ARE LIMITED IN DURATION OF 24 MONTHS FROM THE ORIGINAL DATE OF
PURCHASE
.
CORNING’S SOLE OBLIGATION UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT,
AT CORNING’S DISCRETION, OF A DEFECTIVE PRODUCT.CORNING IS NOT LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGE, COMMERCIAL LOSS, OR ANY OTHER DAMAGES RESULTING FROM THE USE
OF THIS PRODUCT.
Some states do not allow limitation on the length of implied warranties or the exclusion or limitation of incidental or
consequential damages. This warranty gives you specic legal rights.You may have other rights which vary from
state to state
.
No individual may accept for, or on behalf of Corning, any other obligation of liability, or extend the period of this
warranty.
For your reference, make a note of the model and serial number, date of purchase, and supplier here.
Model No._____________________ Serial No.________________________________
Date Purchased ____________________________________________________________
Supplier __________________________________________________________________

Corning Incorporated
271 County Route 64
Big Flats, NY 14814
www.labnetinternational.com
[email protected]
LN177000
