laerdal SimJunior User manual

www.laerdal.com
SimJunior
Quick Setup Guide
EN

3
SimJunior
This Quick Setup Guide describes how to assemble and setup your SimJunior patient
simulator. For information about how to use SimJunior, please refer to LLEAP help files
and SimJunior Directions for Use.
Visit www.laerdal.com/downloads to download the latest Directions for Use and
software.

4
INCLUDED COMPONENTS
Simulator
Manuals & Warranty
Hardware Kit
Modelling Wax
9V Power Supply
Eye Set
BP cuff
Lubricant
Baby Powder
SNB IV bag
IVR IV bag
SimJunior Clothing
Blood Concentrate
Shoulder Adaptor

4
5
Instructor PC Patient Monitor
Sp02 probe
Headset
Ethernet switchLink Box
or
SimPad
Power adaptor
Ethernet cable for PC
Ethernet cable for
Patient Monitor
ACCESSORIES
REQUIRED RECOMMENDED

6
1CHARGE BATTERIES
Patient Monitor
Instructor PC SimPad
Link Box

6
7
2A
WIRED SETUP
Link Box
Power Supply
BP Cuff
Headset
Air tube
USB cable
Simulator cable
Ethernet cable
Power cable
Instructor PC
or SimPad
LLEAP

8
2B
SIMPAD WIRELESS SETUP
Sp02
BP Cuff

8
9
Patient Monitor SimPad
Headset
Link Box
Power Supply
Air tube
USB cable
Simulator cable
Ethernet cable
Power cable
SIMPAD
PATIENT
MONITOR

10
2C
WIRED SETUP WITH PATIENT MONITOR
Sp02
BP Cuff

10
11
Ethernet switch
Patient Monitor
Instructor PC
or SimPad
Headset
Link Box
Power Supply
Air tube
USB cable
Simulator cable
Ethernet cable
Power cable
LLEAP
PATIENT
MONITOR

Rev A
© 2014 Laerdal Medical AS. All rights reserved.
Device Manufacturer: Laerdal Medical , P.O. Box 38,
226 FM 116, Gatesville,Texas 76528 USA
www.laerdal.com
