Lamp HES3D-E160 User manual

1
Thank you for selecting our product. Before starting installation,
please read this manual thoroughly to ensure correct installation.
Please keep this manual at hand for future reference.
・Concealed hinge 2 pcs
・Screw cover 4 pcs x 2 bags
・Template 1 pc
・Countersunk head tapping screw
5×25 8 pcs x 2 bags
・Hex Key 4mm 1 pc

INSTALLATION MANUAL
FOR HES3D-E160 CONCEALED HINGE
●This product is a concealed hinge for indoor use, that is
recessed into the cut out on door and doorjamb.
●
Three dimentional adjustment function allows vertical,
horizontal, and depth adjustment.
Min. Door thickness 36 mm
Max. Door weight
55 kg per 2 hinges, 70 kg per 3 hinges
Max. Door size Width: 900 mm, Height: 2400 mm
ABOUT THE PRODUCT
DOOR SPECIFICATION
FOR YOUR SAFE WORK AND CORRECT INSTALLATION
INSTALLATION DRAWING (EXAMPLE)
COMPONENT PARTS (PER BOX)
CUT OUT DRAWING FOR DOOR AND DOORJAMB
30
30
8
×
Ｒ6
118 160 118 160
8
×
Ｒ6
25
10
Reference
surface of
door
Max. 4
(15.2)
30
Max. 4
2525
Max. 5
30
(3.5)
Reference surface of doorjamb
180°
Reference
surface of door
Reference
surface of
door frame
Reference
surface of
door
Max. 5
Reference
surface of
doorframe
※Chamter the marked part with C1, R1,or a larger value.
※
Door
jamb
Door
Door
jamb
Door
Caution
Door
jamb
Door
Prohibited
Warning
Caution Required
Meaning of symbols
Caution: If not followed, injury or damage may result.
It is necessary to manufacture the frame with sufficient strength so that it endures the weight of the door and any impact upon
opening/closing the door. Only use designated screws and ensure that they are fastened firmly. A frame with poor strength or
loose screws might result in the door falling and causing injury.
Do not try to use this product for anything other than its original purpose. Do not use any part for applications outside of its
specification.
Use in conjunction with a door closer is not recommended. For soft-close option, we recommend Sugatsune LDD-V or LDD-S door
damper.
Make sure to follow the designated dimensions, specifications, and horizontal/vertical angles. Make sure that the frame is not
warped, since it may affect the movement of the door.
This product is a part for architectural fittings. After installation, make sure to test the finished product thoroughly to ensure that it is
well-functioning and safe. Please inform the end user about general precautions and safety to prevent improper use.
Make sure to check the screws for slack at regular intervals (one month from first usage, half a year, and then one time every year
is recommended).

2
Before installing base frame into the
Doorjamb, cheak that it is oriented
correctly. If the orientation is incorrect,
the door cannot be installed.
Caution
・
When adjusting the vertical position or the depth, loosen the
screws 360-degree, then hold the door at the suitable position and
re-tighten the screws. Use wedges to support the door.
(Tightening torque is 4.9 N·m.)
・
When adjusting horizontal position, turn Horizontal adjustment screw.
(There are two screws per hinge.)
The gap between Door and Frame will be expanded by turning the
screw clockwise.
Disassembly of Hinge
1
Hanging Door
3Fastening Removable Screws 4
Installing Hinge to Door and Doorjamb
2
Base frame
Vertical adjustment (fastening) screw
Screw cover
Screw cover
Hinge body
Vertical adjustment
(fastening) screw
Loosen this screw
to disassemble
Horizontal
adjustment
screw
Horizontal
adjustment
screw
Backward
Forward
Up

Down

Right
Left
Vertical adjustment
screw
Depth
adjustment screw
Vertical adjustment
screw
Depth
adjustment screw
Door
frame
Door
Door
jamb
Door
INSTALLATION PROCEDURE
ADJUSTING DOOR POSITION
Do not remove the depth adjustment screw. The door may fall and
cause injury.
When adjusting the horizontal position, turn the two screws a little, by
the same amount. The hinge may be broken if you keep turning one
screw only.
Horizontal adjustment range is +3 mm/-2 mm. When turning the screw
to the right, if you move the part more than 2 mm, the cover cannot be
put on, since the part protrudes. If you still turn the screw, the door will
fall.
Caution
SUGATSUNE KOGYO CO.,LTD
Tokyo, JAPAN
Phone: [phone] E-mail:[email protected]
SUGATSUNE KOGYO (UK) LTD
Reading, UK
Phone: [phone] E-mail:[email protected]
SUGATSUNE EUROPE GmbH
Dusseldorf, GERMANY
Phone: [phone] E-mail:[email protected]
SUGATSUNE SHANGHAI Co., LTD
Shanghai, CHINA
Phone: [phone] E-mail:[email protected]
Guangzhou, CHINA
Phone: [phone] E-mail:[email protected]
SUGATSUNE KOGYO INDIA PRIVATE LIMITED
Mumbai, INDIA
Phone: [phone] E-mail:[email protected]
SUGATSUNE AMERICA, INC
California, USA
Phone: [phone] E-mail:[email protected]
Chicago, USA
Phone: [phone] E-mail:[email protected].
SUGATSUNE CANADA, INC.
Phone: [phone] E-mail:[email protected]
2019.09 1317-2
While holding the door,
insert Hinge main body
into the Base frame
on Doorframe. Keep
holding the door and fix
the hinge with the fixing
screws at once.
Vertical adjustment
(fastening) screw
The arrows should point in the direction of adjustment when the door is closed.
