Landis+Gyr ULTRAHEAT T350 Series User manual

Static Meter T350 (2WR6…/ XS)
Operating instructions UH304-101u
Issue 29.10.2012
Static Meter 2WR6 / XS Subject to change without prior notice UH 304 –101u1/2
Note: In the following text the term Meter covers the
Heat Meter as well as the Cold Meter if not men-
tioned otherwise.
Introduction
The static meter 2WR6 / XS is a measuring instrument for physi-
cally correct recording of energy consumption. It is required to be
certified by law in Germany and many other countries. The device
consists of a volume measuring unit, two permanently connected
temperature sensors, and an electronic unit that calculates the
energy consumption from the volume flow and temperature dif-
ference.
The volume measuring unit is a non-wearing ultrasonic measur-
ing device without mechanically moving parts. The long-life bat-
tery is designed for the calibration validity period. The meter
cannot be opened without breaking the security seal.
The meter must only be operated under the conditions stated in
the manuals and on the dial plate.
Information on the Display
The displays of the meter are structured on several levels and
may deviate from the standard described here. Each short press
of the button switches to the next display of the user loop (level
1).
▼ indicates what sort of display it is.
User Loop ▼
0054567
kWh
Cumulated energy quantity
00065.43
m³
Cumulated volume
888888
kWh
Segment test
Info
F - - -
Error message on fault with
fault number
Info
Pressing the button for 10 seconds switches from the user loop to
the service loop (level 2).
Exiting the service loop by pressing the button for 3s or auto-
matically after 30 minutes.
Service Loop ▼
0.534
m³/h
Current flow rate
22.9
kW
Current power
84 47
°C
Current supply-return temperature
04.06.08
D
Date
786
Bh
Operating hours
56
Fh
Missing hours
3792701
G
Device number, 7-digit
Info
PulSE
CH
Remote reading option (optional)
Info
123
A
Primary address when option M-Bus
Info
2345678
K
Property number, 7-digit
Info
18.02.08
F0
Date stamp for F0 prewarning
Info
3- 01
FW
Firmware version
Info
31.12.07
V
Previous year's day of storage
Prev. year
0034321
kWh
Energy previous year on set day
Prev. year
00923.12
m³
Volume previous year on set day
Prev. year
12
Fh
Missing hours previous year
Prev. year
- -.- -.- -
C
Code entry for parameterization
Info
01.06.08
M
Previous month's 1-15 day of storage
Prv. month
After pressing button for 3s:
0034321
kWh
Energy previous month on set day
Prv. month
00923.12
m³
Volume previous month on set day
Prv. month
12
Fh
Missing hours previous month on set
day
Prv. month
Monthly Values
The calculator stores the following values for 15 months at each
end of month
- Energy (meter reading)
- Volume (meter reading)
- Missing hours (meter reading)
From the month set day display, press the service button for 3s to
enter the previous month's values.
The month values can also be read out via the optical interface.
Fault Codes and IDs
The meter constantly performs self-diagnosis and can display
various faults.
Fault Code
Fault
Measures
FL nEG
Wrong flow direction
Check / correct flow or
mounting direction
Maybe changing with
DIFF nEG
Negative temperature
difference
Check / exchange
mounting position of
sensors
These operating instructions have to be handed over to the end user
3250 004 101 u
Security seal

Static Meter 2WR6 / XS Operating Instructions UH 304 –101u2/2
Fault Code
Fault
Measures
Maybe changing with
F0
No flow rate can be
measured
Air in the measuring
unit/pipe, vent pipe
(as-delivered state)
F1
Interruption in the supply
sensor
Contact service
F2
Interruption in the return
sensor
Contact service
F3
Electronics for tempera-
ture evaluation defective
Contact service
F4
Battery empty
Contact service
F5
Short-circuit in the supply
sensor
Contact service
F6
Short-circuit in the return
sensor.
Contact service
F7
Fault in internal storage
operation
Contact service
F8
Fault F1, F2, or F3 or F5,
F6 pending for longer
than 8 hours, detection of
fraud attempts. No more
measurements are per-
formed.
This F8 error message
must be reset by
service.
F9
Fault in the
electronics
Contact service
If the response thresholds are exceeded and the flowrate and
temperature are positive, the energy quantity and volume will be
summated. The segment test displays all display segments for
test purposes.
On the yearly set day, the meter readings for energy quantity,
volume, and missing time are placed in a previous year memory
each year.
The flowrate, power, and temperature difference are recorded
signed. Values below the response threshold are preceded by a
"u". The current temperatures are displayed together as integer
°C values on one display line.
The 8-digit property number (secondary address for M-bus opera-
tion) can be set in parameterization mode. The most significant
digit is suppressed on the display. The device number is as-
signed by the manufacturer.
The operating hours are counted from initial connection of the
power source. Missing hours are summated if a fault is pending
that prevents the meter from measuring. The date is incremented
daily.
The firmware version number is assigned by the manufacturer.
Technical Data
Environment class A (EN1434) for indoor installation
Mechanical class M1 *)
Electromagnetical class E1 *)
*) according 2004/22/EG EC directive
Electronic Unit
Ambient temperature 5 - 55°C
Power supply Battery for 6 or 11 years
or 24V AC/DC external (special
version)
Temperature sensor Pt 500
Communication Optical interface standard, M-bus
or pulse output optional
Protocol IEC870, 300 baud in Nb
Splittability Always removable,
cable length 1 m
Ambient humidity < 93% r. h. at 25°C without con-
densation
Flowrate Measuring Unit
(Consider the details on the meter)
qp
Dimensions
0.6
110mm (3/4“)
190mm (1“)
1.5
110mm (3/4“)
190mm (1“)
2.5
130mm (1“)
190mm (1“)
Temperature range 5 - 105°C *)
recommended for…
…heat application 15 to 105°C
…cold application 5 to 50°C
*) national approvals may differ
Nom. pressure 1.6 MPa (PN 16)
Overload qs = 2 x qp, permanent
Mounting position Horizontal or vertical
Measurement range 1:100 approved, calibrated
1:50
Measurement accuracy: EN 1434 cl. 3
Temperature Sensor
Temperature sensor Pt 500 acc. to EN 60751, not
removable
Connection 2-wire, permanent.
Type DS direct short, M10 x
27.5mm acc. to EN1434 or
rod sensor 45 x 5.2 dia. mm
Cable length 1.5m standard, 5 m optional
Max. temperature 105 °C
Installation supply sensor Mounting element for DS 1/2“
x M10, ball valves for DS,
brass pocket 1/2“ for rod
sensor
Installation return sensor Integrated (when meter is for
installation in return)
Notes:
Observe national calibration laws when replacing the battery.
Batteries must not be opened, come into contact with water, or
be exposed to temperatures above 80 °C. The meter contains
Lithium batteries, so it is not allowed to dispose it wih the house-
hold waste. Return of the Lithium batteries must be carried out
professionally. It is possible to return the product after use for
proper disposal to the manunfacturer. Please follow the legal
regulations at the shipment of Lithium batteries, which rules
amongst others the declaration and the packaging of hazardous
good.
EC Declaration of conformity
Landis+Gyr GmbH, Humboldtstr. 64, D-90459 Nürnberg,
herewith declares that the products of type 2WR6 comply
with the requirements of the following directives:
2004/108/EC Electromagnetic compatibility
2006/95/EC Low voltage directive
2004/22/EC Measuring instruments directive
2002/95/EC Directive on the restriction of the use of
certain hazardous substances in electrical and elec-
tronic equipment (RoHS)
This declaration and the corresponding documents are lodged at
Mr. Kolk c/o Landis+Gyr under the number CE 2WR6 006/03.12.
EC type-examination certificate
DE-06-MI004-PTB007
Certificate of the approval of a
quality management system
DE-12-AQ-PTB006MID
Notified body:
PTB Braunschweig und Berlin, Deutschland; Nr. 0102
Landis+Gyr GmbH
Humboldtstr. 64
D-90459 Nürnberg
Germany
