Lanier R/C Dart ARF Instruction Manual

Dart ARF
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 ©copyright 1989 Lanier R/C, Inc.
1
1
Thank you for purchasing the Lanier R/C Dart. We are sure you
will be happy with the quality of the kit and happy with the flying
characteristics of the Dart. Because of it’s light weight,the Dart will
fly exceptionally well on a standard .40 size motor. This makes the
Dart a perfect “first time” low wing airplane. The gentle flying char-
acteristics and good aerobatic ability make is a joy to fly.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
2
2
Important Information:
Please inspect the plane before beginning to assemble to make sure you are happy with it. After assembly has begun you cannot return
the kit. If you find a problem before beginning to assemble the plane you must contact us, please do not return it to the dealer. Due to
temperature changes the plane may develop some wrinkles in the covering that you will need to remove with an iron. Be sure to seal
the edges down first so that you do not cause the covering to shrink and leave exposed areas of wood. The model is built light to ensure
good flight characteristics. With the power available from the new breed of engines, it is necessary to use throttle management in order
not to overstress the airframe. You must maintain good tight control linkage with no slop, good servos with plenty of power, and good
servo arms to protect against flutter. Sloppy linkage and over speeding the plane will cause flutter which is not covered in the warranty.
Lanier R/C is proud of the care and attention that goes into the manufacture of parts for its model kits. The company warrants that for
a period of 90 days, it will replace, at the buyers request, any parts or material shown to the company’s satisfaction to have been defec-
tive in workmanship or material at the time of purchase. No other warranty of any kind, expressed or implied, is made with respect to
the merchandise sold by the company. The buyer acknowledges and understands that he is purchasing only a component kit from which
the buyer will himself construct a finished flying model airplane. The company is neither the manufacturer of such a flying model air-
plane, nor a seller of it. The buyer hereby assumes the risk and all liability for personal or property damage or injury arising out of the
buyers use of the components or the finished flying model airplane, whenever any such damage or injury shall occur.
Any action brought forth against the company, based on the breach of the contract of sale to the buyer, or on any alleged warranty
there under, must be brought within 1year of the date of such sale, or there after be barred. This one year limitation is imposed by
agreement of the parties as permitted by the laws of the state of Georgia.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
3
3
1. Start with one wing panel. Make sure all
the hinges are aligned and the aileron has
a 1/32” gap at the wing tip.
Insert a straight pin in the center of the
hinge so the hinges will be one half in the
wing and one half in the aileron.
Push the ailerons in place tight against the
trailing edge of the wing and remove the
pins.
Move the aileron to full deflection in one
direction (about 1/2”) and apply one drop
of thin CA glue to each hinge. Move the
aileron to full deflection in the other direc-
tion and apply one drop of thin CA on each
hinge on that side.
Give the hinge a minute to dry then apply
one more drop to each hinge on each
side.
2. You will need a 6” extension for the
aileron servo lead.Use tape on the plug to
make sure it does not come apart.
Use the string installed in the wing to pull
the servo lead down the wing and out the
hole on the top side.
3. Mount the servo using the hardware sup-
plied with the radio.The output arm should
be to the rear.
Wing Assembly

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
4
4
4. Locate the dihedral brace. Identify the
top side, it is straight, the bottom has a 1
degree angle
top is straight
Trial fit the dihedral brace in one wing half.
Now slide the other wing panel on the
dihedral brace.
5. When satisfied with fit and alignment, take
the wings apart.
Mix 3 oz. of 30 minute epoxy and apply a
liberal amount to the root of both wings,
both sides and the edges of the dihedral
brace, and into the slots of both wings.
Use a scrape piece of wood to work the
epoxy down into the slots in the wings.
6. Slide the dihedral brace into place.
Slide the other wing in place and use
masking tape to hold the wing together till
the epoxy cures.
Check the trailing edge of the wing and
use a pin to make sure it stays in perfect
alignment.
Lay the wing down on a flat surface till the
epoxy cures, don’t stand it on one tip. This
will cause the epoxy to run to one end.
7. When the epoxy is dry, locate the four metal
landing gear straps and the eight #2 x 1/2”
screws.
8. Insert the landing gear wire into the slot in
the wing.
Place one gear strap 1/2” in from the gear
leg and the other 1/2” in from the end of
the wire.
Drill a 1/16” hole at each location and
install the #2 screws.
Repeat for the other wing.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
5
5
2. Measure the stab to make sure it is cen-
tered at the rear.Use a yard stick to meas-
ure from the rear corner of the stab to the
trailing edge of the wing at the fuselage..
Move stab until this measurement is the
same on both sides.
Sight the stab, fin, wing alignment from
the rear of the plane. The alignment can
be changed slightly by pushing up or
down on the stab tip. This is all that should
be needed, but if more is needed you can
sand the stab saddle till the alignment is
perfect.
3. Do the same with the fin.
When happy with the alignment, use a
marking pen and mark a line on the stab,
top and bottom and on both sides of the
fuselage.
Do the same to both sides of the fin.
1. With the wing mounted on the fuselage,
slide the stab into the slot in rear of fuse-
lage.
Slide the fin into place in the slot on the
top of fuselage.
9. Locate the wheels and four wheel collars.
Install a wheel collar on the inside, then
the wheel and the other wheel collar.
Tighten with a 2mm allen wrench.
Tail Assembly

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
6
6
4. Remove stab and fin from fuselage and
using a razor blade, remove the covering
between the lines you just marked.
Cut about 1/8” inside your mark so bare
wood will not be exposed when glued in
place.
Caution: Cut carefully and cut only the covering,
don’t cut the balsa underneath as this
would weaken the stab and fin.
remove
covering
remove covering
Important:
You must install the elevator joiner wire before
installing stab. The elevator wire cannot be
installed after the stab is glued in place.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
7
7
5. Using 30 minute epoxy, glue the stab and
fin in place using the marks made earlier
to align. Use masking tape to hold in place
if necessary. Check alignment and allow
epoxy to cure.
6. Locate the two elevator halves and insert
the CA hinges in the slots.
Use pins in the middle as we did with the
ailerons to keep the hinge centered.
Locate the hole for the elevator joiner wire
in each elevator.
Trial fit the elevators in place making sure
the hinges go all the way in and the joiner
wire fits all the way into the slot.
7. When satisfied with the fit, put some
epoxy in the elevator joiner hole and
install the elevators.
Push the elevators up against the pins,
then remove the pins and push the eleva-
tors flush against the trailing edge.
Flex the elevator to its full travel in one
direction (about 1”) and glue the hinges
using thin CA. Flex in the other direction
and apply glue on the other side of the
hinges.
Hole for elevator joiner wire
8. Locate the rudder and hinge it in place
using the same method we did on the
ailerons and elevators.
Nose Gear Mounting
1. Locate the nose gear, wheel, steering arm
and three wheel collars.
2. Mount the wheel using a wheel collar on
each side. Install another wheel collar 3/8”
above the coil on the top portion.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
8
8
3. Insert the gear into the hole in the bottom
of the fuselage and place the steering arm
on the wire.
Be sure and place the steering arm far
enough away from the firewall so that it
does not jam against the firewall when full
right rudder is applied.(about 1/4”).
Note: It is a good idea to mark the location of the
set screw and remove the nose gear and
file a flat spot on the wire where the set
screw hits.
4. While working on the nose gear go ahead
and apply a drop of CA glue to each of the
nuts that hold the nose gear block in
place.
Locate the 2-56 pushrod and clevis and
attach to the steering arm.
Use a silicone keeper over the clevis.
Insert the 5/32” nylon tube over the
pushrod and let it lay in the bottom of the
tank compartment.
Engine Mounting
1. Locate the two nylon motor mounts, four
3mm engine mounting bolts and nylon
lock nuts, four 4mm bolts and washers
and four blind nuts.
The length of the cowl from the firewall to
the back of the spinner is 4.75”. If you use
a spinner that is flush on the back such as
the Tru-Turn, that will be the distance to
the prop hub. If you use a spinner such as
the Goldberg which is offset at the rear
you will need to add 1/4” to the length.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
9
9
2. After you determine which spinner you will
use, clamp you motor between the two
mounts and set both flat on the table.
Measure from the table to the front of the
prop hub and move the engine until you
have the right length.
Mark the location of the holes and drill a
1/8” at the four spots.
Mount the engine using the 3mm bolts
and nylon lock nuts.
1-13/16”
1-13/16”
3. Measure down from the top of the fuse-
lage 1-13/16” and draw a line across the
fuselage.This should be just at the bottom
of the cheek cowls.
4. Draw a line down the center of the firewall.
Measure over 1/8” to the left side of the
plane and make another line. This will be
the offset for right thrust.
Center you motor mounts on these marks
and mark the location of the mounting
holes.
Before drilling the holes check to make
sure your muffler will clear the bottom of
the fuselage.
5. Drill a 13/64” hole at each location. This is
the size of the shank on the blind nut, not
the bolt.
Using one of the bolts and washers, pull
each blind nut into place on the back of
the firewall.
6. Bolt the engine in place using two flat
washer under each mount on the left side.
Be sure and use thread lock on the bolts.
The engine is shown mounted sideways, it can
me mounted in any position you desire, upside
down or at an angle.
2 flat washers

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
10
10
7. Drill a 5/32” hole in line with your throttle
arm and just below the mount.
Attach the 2-56 pushrod and clevis.
Use a silicone keeper on the clevis.
Insert the 5/32” nylon tube through the
hole and leave about 1” in front of the fire-
wall..
Cowl Mounting
1. Cut four strips of paper 3/4” wide and 2”
long. (Not included)
Tape in place about 1” back from the fire-
wall with the front edge flush with the fire-
wall..Two on top, two on the bottom.
2. Make sure the location you pick is not over
a balsa stringer, we want the screws to go
into the hardwood of the firewall.
Use a pencil and mark 1/8” back from the
edge of the firewall.
3. Mark the location of the top holes 1/8”
back from the firewall.
Remove material to clear carb.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
11
11
4. Slide the cowl in place allowing the tabs of
paper to lay on top of the cowl.
You will probably have to remove some
material in the right cheek cowl to clear
the carb.
5. Install the prop and spinner and place a
1/16” shim between the back of the spin-
ner and the cowl.
Tape the cowl in place top, bottom and
sides. Pay attention to make sure the cowl
is pulled down tight on top and around the
cheek cowl and the stripes are aligned.
6. When satisfied with the fit drill a 1/16” hole
through the marks on the paper tabs into
the firewall. Make sure to hold the drill
square to the firewall.
Remove the cowl and open the holes up
with a 3/32” drill.
7. You can use the same method to locate
the holes for the glow plug, needle valve
and muffler.
8. After the tank is installed and the pushrod
adjusted, mount the cowl using the four
2mm screws and washers
1. Locate the control horns, nut plates and
#2 screws.
Radio Installation

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
12
12
2. Lay a straight edge along the side of the
aileron servo on the outboard side and
make a mark on the aileron.
3. Set the control horn on the aileron at the
mark making sure the holes for the clevis
are aligned over the hinge line.
Mark the hole location for the screws
through the control horn.
Remove the horn and drill a 3/32” hole at
the two marks.
4. Install the control horn with two of the
screws into the nylon nut plate on the top
surface.
5. Locate one of the 6” long 2-56 pushrods
and clevis.
Install a silicone keeper on the clevis and
make sure it is screwed on the wire with
about 1/16” extending into the inner part of
the clevis.
Attach it to the control horn.
6. Put a servo arm on the servo and center it
using your radio.
Make sure the aileron is centered and
mark the location on the wire where it
crosses the servo arm.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
13
13
7. Make a 90 degree bend in the wire at the
location you marked.
8. Cut the wire off leaving 3/8”.
3/8”
9. Insert the rod into the servo arm and retain
using the nylon swing in keeper.
Repeat for the other aileron.
1. Locate the two wooden dowels, two
pieces of 2-56 wire 4” long, two 12” long 2-
56 pushrods, two metal clevis, two sili-
cone keepers, and 4 pieces of shrink tub-
ing.
2. Make a 90 degree bend 1/4” long in the
end of both 4” pieces of wire.
Fit them into the hole in one end of the
wooden dowel and into the groove cut in
the dowel.
3. Put some glue on the wire in the slot,
either CA or epoxy.
Slide the shrink tubing over the wire flush
with the end of the dowel and shrink in
place using a heat gun.
You can use a match if you don’t have a heat
gun.
Push Rod Installation

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
14
14
4. Make a 90 degree bend 1/4” long in the
end of the 12” pushrods and install them
on the other end of the wooden dowel
using glue and shrink tubing.
5. Locate the pushrod exits on each side of
the fuselage under the covering and
remove the covering.
Hint: A pencil tip soldering iron works really well
to remove the covering and seal it at the
same time.
6. Remove the clevis from the pushrods and
insert them into the rear of the fuselage
and out the holes in the rear.
Use the pushrod to line up the rudder con-
trol horn on the right side of the plane.
Make sure the clevis attachment holes are
aligned over the hinge line and mark the
location of the mounting holes.
Drill a 3/32” hole at the mark and mount
the control horn using the screws and nut
plate.
7. Mount the elevator control horn on the
other side of the left side of the fuselage.
Align the clevis holes over the hinge line
and as far inboard as possible on the ele-
vator.
Reinstall the clevis on each pushrod with
a silicone keeper and attach to the control
horns.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
15
15
1. Install three servos in the fuselage using
the hardware supplied with the radio.
The rudder servo should have the output
arm mounted forward on the left side of
the plane.
The elevator servo is mounted on the right
side with the output arm to the rear.
The throttle servo is mounted with the out-
put arm to the right side of the plane.
2. Locate the two adjustable servo connec-
tors and attach one the the throttle servo
arm. A three hole arm (1/2”) is about
right.
Attach the other connector to the inner
most hole on a double sided four hole
(3/4”) servo arm for the rudder and nose
gear.
3. Center the rudder servo with the radio and
attach the pushrod to the connector.
Make sure the nose gear is straight and
tighten the screw.
Set the throttle servo to full high motor
with the radio.
4. Attach the pushrod and push the throttle
barrel full open. tighten the screw.
The excess pushrod can be cut about 3/8”
past the connector.
5. With the rudder servo centered and the
rudder centered, lay the rudder pushrod
on the output arm and mark the location
where it crosses.
Servo Installation

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
16
16
6. Make a 90 degree bend in the wire and cut
off at 3/8”.
7. Install the pushrod in the outer most hole
and retain with the nylon swing in keeper.
Repeat the procedure for the elevator
servo. Use a four hole out-put arm for the
elevator.
8. Install the switch in the side of the fuse-
lage on the opposite side from the
exhaust.
Fuel Tank Installation
1. Locate the fuel tank and hardware.
2. Assemble the cap with large washer in
front and small washer in the rear.
Bend the long tube at a 45 degree angle
so it will reach the top of the tank.
The fuel pickup is straight with about 1/2”
on each side of the cap.

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
17
17
3. Install the silicone fuel tubing on the fuel
pickup line with the clunk on the other end.
Adjust the length of the tube so the clunk
will be 1/4” off the bottom of the tank when
the tank is held vertical.
The vent tube should go to the top of the
tank.
When properly aligned tighten the screw
in the cap to secure it in the tank.
4. Slide the tank into the fuse through the
wing opening.
The tank will sit on the pushrod tubes from
the throttle and nose gear.
Use foam rubber(not supplied) to cushion
the tank.
Access the front of the tank through the
hatch on top and guide the cap assembly
into the hole in the firewall.
Attach fuel line (not supplied)from the vent
line to the muffler pressure tap and from
the fuel pick up line to the carb.
5. Install hatch using a #2 screw into the
block in the rear of the hatch.
1. Trim canopy to fit, cut over-size and trim
down slowly till you have about 1/4” over-
lap.
Glue in place using canopy glue.
Use clear vinyl tape or colored tape to out
line the canopy and make sure it does not
come off.
Canopy Installation

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
18
18
Control Throws
Low Rate
Elevator 1/2” up and down
Aileron 3/8” up and down
Rudder 3/4” each way
High Rate
Elevator 1” up and down
Aileron 1/2” up and down
Rudder 1-1/2” each way
Center of Gravity
3-1/4 to 3-3/4” behind leading edge of
the wing next to the fuselage
Locate the 4mm x 35mm bolts and flat
washers.
Bolt the wing in place into the pre-installed
blind nuts in the fuselage.
1. The battery can be placed under the servo
tray for balance if necessary. It can also
be placed all the way forward under the
tank if needed for balance.
2. The receiver can be place in the opening
between the servo tray and the bulkhead
at the leading edge of the wing.
Be sure to wrap the receiver in at least 1/2” of
foam rubber.
Battery & Receiver Installation

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
19
19
Parts List
Airframe components
1. Fuselage 1
2. Wings 2
3. Aileron 2
4. Stab 1
5. Fin 1
6. Rudder 1
7. Elevators 2
8. Fuel hatch 1
9. Clear Canopy 1
10. Main Landing gear 2
11. Nose gear 1
12. Cowl 1
Wing Hardware
1.Dihedral brace
2. 2
3. Control horns 2
4. Control horn plates 2
5. Control horn screws 4
#2x3/4”
6. 2-56 clevises 2
7. Nylon swing in keepers 2
8. Silicone clevis keepers 2
9 .2-56x 6” pushrod 2
10.Wing bolts 4mm x35mm 2
Elevator, Rudder Hardware
1. Control horns 2
2. Control horn plates 2
3. Control horn screws
(Elevator)#2x3/4” 4
4. 2-56x12” control rods with clevis 2
5. Unthreaded pushrods 4” long 2
6.Elevator joiner wire
7. Nylon swing in keepers 4
8 Silicone Clevis keepers 2
9. 3\8” wooden dowels 2
10. Shrink tubing 4
11. Adjustable pushrod connector 1
Landing Gear Hardware
1. Main gear mounting straps 4
2. #2 screws for straps 8
3. 2-1/2” wheels 3
4. 3/16” wheel collars 7
5. Nose gear steering arm 1
5 2-56 x 15” with clevis. 1
6. 5\32 nylon tube 1
Cowl Mounting Hardware
1. #2 x 1/2 screws 4
Motor Mounting Hardware
1. Nylon motor mounts 2
2. 3mm x 20mm bolts 4
3. 3mm aircraft lock nuts 4
4. 4mm x 25mm bolts 4
5. 4mm blind nuts 4
6. flat washers 4

Assembly Instructions
Lanier R/C, INC. P.O. Box 458 Oakwood, Ga. 30566 PH 770 532 6401 © copyright 1989 Lanier R/C
20
20
Misc. Hardware
Fuel tank 10.8 oz 320cc 1
Decal Sheet 1
Instruction Booklet 1
Tools need to complete the Dart ARF
1. Drill and assorted bits
2. Hobby Knife with #11 blade
3. Masking Tape
4. T-pins or straight pins
5. Felt tipped pen/pencil
6. Rubbing alcohol
7. Paper towels
8. Phillips screwdriver
9. Allen wrenches
10. Metric tap 6mm.
11. Pliers (needle nose)
12. Mixing sticks
13. 36” yard stick or tape measure
14. Scissors
15. Moto tool with sanding drum.
Adhesives
1. Thin CA (cyanoacrylate) glue
2. Medium CA. Glue
3. CA remover/debonder
4. 5-Minute Zap Z-Epoxy
5. 30-Minute Zap Z-Epoxy
6. Zap Z-42 Thread lock
7. Zap Canopy glue.
Equipment Required
1. Four channel radio or better
2. Servos- 46in.oz. or better 5
3. 650mah battery pack or larger
4. Y-connectors 1
5. 6” extensions (Aileron) 2
8. Switch harness (your radio)
9. Motor .40 to .46
10. Prop and 2-1/4”” Spinner for your motor.
11. Fuel line (for gas or glow)
12. Pilot figure (optional)
Throttle Hardware
1. Adjustable pushrod connector 1
2. 18” 2-56 pushrod 1
3. 2-56 clevis 1
4. 5/32” nylon tube 1
5. Silicon clevis keeper 1
