Fireball Galaxy Pro™

High Power LED Octo Blinder

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

For your Safety

• Follow all instructions to maintain Manufacturer Warranty and for your own safety.

• There are no user replacement parts inside the product. Do not open the product for

any reason. This will invalidate your Manufacturer Warranty and may impair the safety

features of the product.

• Do not expose this product to moisture, rain or other fluids.

• Do not use this product near water or other fluids.

• Do not use if the product if you suspect it has been damaged in any way, including

being dropped, is malfunctioning, or has been exposed to liquids or moisture. The unit

must be repaired by an authorised service centre only. Manufacturer Warranty is void

if unit is opened or adapted in any way. Operator safety may be compromised if this

product is not operated and maintained in accordance with the details contained in

this Owner Handbook.

• This appliance must be earthed. Do not remove the earth connection in the plug or

any other location- it is essential for user safety.

• Be aware that products are mains powered and may be capable of producing high

voltages from its outputs and has mains voltages inside the cabinet.

Product Installation, Use & Maintenance

• Keep this Owner Handbook safe for future reference.

• Clean the product with a clean and dry, non-abrasive cloth. Do not use solvents or

liquids to clean the product.

• To prevent overheating, do not obstruct any ventilation opening, fan cover or vent. Do

not install near any sources of heat such as radiators, heaters, other heat producing

items such as amplifiers, power units etc.

• Power connection to the product is via a UK 240 Volt AC three-pin mains plug. Do not

remove or adapt this plug. If necessary, only replace the plug top fuse with one of the

same type, size and value.

• The mains lead must not be crushed or damaged. If any damage occurs, disconnect

from the mains immediately. Replace the damaged cable, or if the mains lead is

captive, return the product to an authorised repair centre for cable replacement.

Do not attempt to repair the cable - it must be discarded and destroyed.

• To maintain the Manufacturer Warranty, only attach authorised accessories and

external devices. This includes cables, connectors and other electrical and/or

mechanical devices.

• Unplug the product from the mains during lightning storms or periods of mains

fluctuations. If the product is going to be unused for long periods, unplug from

the mains.

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

Product Quality & Compliance

Products from Lanta Lighting meet all required safety standards in force at the time of

manufacture and are fully compliant with them.

Unpacking & Inspection

• Inspect the packaging before opening. If the packaging appears to have sustained

significant damage, please take extra care before using the product. If you are in any

doubt, consult a suitably qualified professional.

• If you suspect the product has been damaged, do not use it. Return it to your original

supplier without delay.

• Keep all packaging in a safe place for storage or transport in future.

Manufacturer Warranty

• This Manufacturer Warranty is valid in the UK only.

• Lanta Lighting warrants that this product is free from workmanship defects and material

failure during normal use and operation for a period of 12 months from first use or from

original date of sale (whichever is the earliest) providing all of the terms indicated in the

warranty section have been fully complied with.

• Expressly excluded is our liability for any directly connected or indirectly connected

item or items or any consequential loss associated with the failure of the product

howsoever caused.

• If the product has been opened, modified, tampered with, incorrectly connected,

used inappropriately or in conflict with the instructions herein, or the product model

or serial number has been damaged, removed, tampered with, obliterated or made

partly unreadable by any person or persons, the Manufacturer Warranty is irrevocably

null and void.

• No extension, adaption, alteration or modification to the terms of this Manufacturer

Warranty will be permitted, unless expressly authorised in writing (excluding

email and fax) by a Director of Lanta Lighting. Warranty is transferrable during the

Warranty period.

For Further Information about Lanta Lighting

Our website can be found at www.lantalighting.com and is available for the benefit

of customers worldwide. Please consult for information, advice and support on this and

other high quality products from Lanta.

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

About Lanta Lighting™

Based in the UK, Lanta are committed to providing high quality products at cost-effective

prices to the professional lighting market. Since the first product was launched in 2006,

Lanta has established a reputation for reliability, common sense design and customer

support that has become the envy of others. All Lanta products are specifically designed

for UK operation and are optimized for 240VAC 50Hz UK mains power.

The Lanta Lighting range includes:-

Professional Lighting

Focussing on the use of LED technology, Lanta offer distinctive lighting effects for install

and mobile applications. From washes to floods, spots to projectors, LED technology now

outperforms traditional lights while at the same time requiring significantly lower power

and generating far less unwanted heat.

Performance Lasers

Recent advances have reduced the costs of Lasers, made them more portable and

brought improved performance and reliability. With step and animation lasers in multi

and single colour formats for mobile DJs and static installs, Lanta promise Lasers that

won’t burn a hole in your pocket.

Atmospheric Effects

When you need special atmospherics effects, Lanta have everything from bubble

machines to fake snow, hazers and foggers. There’s also a range of fluids and

consumables specially designed to get the best from the range.

Control Gear

Lightweight and portable, Lanta Control Gear is robust enough to survive life on the road

and smart enough to control DMX kit whatever the venue.

Visit us at www.lantalighting.com for more details.

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

Features of the Lanta Fireball Galaxy Pro™

The Lanta Fireball Galaxy Pro™ lighting fixture features tri-colour Red, Green and Blue LEDs.

It has a built in colour switching, fading and pattern sequencing facilities and can also be

sound activated. A range of features can be DMX controlled from any of the LANTA DMX

controllers or equivalent products.

LEDs 32 3w Tri-colour

DMX Control 2 Channel

Control Connections 3 Pin Female XLR socket, 3 Pin Male XLR socket

Power Requirement 240 Volt AC 50/60Hz

Power Consumption 110 Watts

Dimensions W x D x H 500mm x 170mm x 340mm

Weight 5.5Kg

Power & Control Connections

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

Operation of the Lanta Fireball Galaxy Pro™

To select the various different modes of operation, there is a 4 button keypad and 4 digit

LED display on the rear of the product.

To begin, press the button marked “MODE”. Each press will choose one of the working

modes described below. Once the desired mode has been selected, the button marked

“SETUP” will allow the user to select a parameter that they wish to change (such as speed

etc). To choose a value of the parameter, press either the “UP” or “DOWN” buttons until

the desired setting is achieved.

Note: There is no need to have an “enter” or “store” button, as this is automatically done

for you.

Note: The LED display will enter power saving mode after 20 seconds after the last button

press. It will turn on again after pressing any button.

Note: When first powered on, the display will briefly show the firmware version programmed

into the memory of the controller. This is displayed as a “U” followed by the version number.

(e.g. “U3.01”)

1- Built-in PROGRAM Mode (Single pattern)

To use the built-in program mode – a library of exciting and vibrant patterns and colour

changes, keep pressing the “MODE” button until the LED display shows “PR” followed by a

2-digit number (e.g. PR07). The “UP” and “DOWN” buttons allow the selection of a pattern

and there are more than 20 patterns to choose from.

When you have selected the pattern you desire, you have the option of changing the

speed of the program – i.e. how fast the different colours and patterns appear. To change

the speed, press the “SETUP” button then use the “UP” and “DOWN” buttons to select the

desired speed.

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

2- AUTO Mode

To use the built-in Auto mode – a library of exciting and vibrant patterns and

colour changes, keep pressing the “MODE” button until the LED display shows “AUTO”. In

this mode the unit will run pattern one for a period of time, then automatically run pattern

two and so on. This creates an ever-changing light show without the need for the operator

to intervene.

You have the option of changing two parameters:

(1) How much time will elapse before the next pattern is automatically selected (next)

(2) How fast the patterns will run – (speed)

(1) To change how often the next pattern will be introduces (next), press the “SETUP” button

until the letter “n” appears on the display, followed by a number between 1 and 100.

Use the “UP” and “DOWN” buttons to set the value you require.

(2) To change the speed, press the “SETUP” button until the letters “SP” appear on the

display, followed by a number between 1 and 99. Use the “UP” and “DOWN” buttons

to set the value you require.

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

3- DMX Mode

It is possible to operate the Lanta Fireball Galaxy Pro™ from a remote location by using

either a DMX controller or a PC or laptop with a DMX interface. Lanta products use a 3

pin XLR style connector and usually have an input and output DMX connector. This allows

multiple lighting products to be “daisy-chained” together to build a display controlled by

just one cable back to the DMX controller.

NOTE: In larger installations, there may be limitations regarding the maximum length of

DMX cables and the maximum number of devices that can be used in one daisy-chain

(or node).

NOTE: It is often desirable to terminate the last device on the node to minimize noise

and interference. Interference on a DMX network can make some lighting products to

behave erratically; this is most noticeable with moving head or other motorized products.

This is not a fault with the lighting product.

Please see your DMX controller handbook for further details.

To use the built-in DMX function, it is necessary to set the DMX address. To do so, first

choose the correct mode by pressing the “MODE” button until the LED display shows

“d” followed by a 3-digit number (e.g. d007). The “UP” and “DOWN” buttons allow the

selection of the DMX address and can be selected between 001 and 512.

The Lanta Fireball Galaxy Pro™ uses two adjacent CHANNELs of DMX and the first will be

determined by the DMX address setting - as described above - and the second CHANNEL

will be one CHANNEL higher. E.g. if the DMX address has been set to 105, then the Lanta

Fireball Galaxy Pro™ will be operated by channels 105 and 106. In most applications, it is

sufficient to set the DMX address to 001 as shown in the table below.

When the Lanta Fireball Galaxy Pro™ is connected to the DMX controller, each CHANNEL

will be controlled by a slider or similar control. When the slider is at the bottom the VALUE

is 0. When the slider is at maximum, the VALUE is 256. The value can be set at any level

at any time. The following table explains what the Lanta Fireball Galaxy Pro™ will do when

the value of CHANNEL 001 and 002 are set:-

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

Channel 1

(DMX address 001)

Channel 2

(DMX address 002)

No. DMX Value Function Speed

1 0-10 Off

Value = 0 Off

Speed 0-255

2 11-21 Program 01

3 22-32 Program 02

4 33-43 Program 03

5 44-54 Program 04

6 55-65 Program 05

7 66-76 Program 06

877-87 Program 07

9 88-98 Program 08

10 99-109 Program 09

11 110-120 Program 10

12 121-131 Program 11

13 132-142 Program 12

14 143-153 Program 13

15 154-164 Program 14

16 165-175 Program 15

17 176-186 Program 16

18 187-197 Program 17

19 198-208 Program 18

20 209-219 Program 19

21 220-230 Program 20

22 231-241 Program 21

23 242-255 Sound Mode Sensitivity 0-255

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

4- MASTER /SLAVE Mode

This is a great way of making two or more Lanta Fireball Galaxy Pro™ units do the same

things at the same time, without the need for a DMX controller. The Lanta Fireball Galaxy

Pro™ has a DMX controller of its own, built inside and when a second Lanta Fireball

Galaxy Pro™ (set as SLAVE) is connected to a Lanta Fireball Galaxy Pro™ (set as MASTER)

the SLAVE will follow all of the activity of the MASTER. It is possible to connect several SLAVEs

to a master, creating a magnificent light show!

To use the built-in MASTER/SLAVE function, keep pressing the “MODE” button until the LED

display shows “SLAu”. Then join this SLAVE unit to another Lanta Fireball Galaxy Pro™ that is

in either Program, Auto or sound mode – this acts as the MASTER.

NOTE: The DMX OUT connector of the MASTER should be connected to the DMX IN of the

slave using a 3 pin DMX cable.

respective owners. E&OE. All specifications and details are correct at time of print.

Revision 1

Fireball Par64S Owner Handbook ™

5- SOUND Mode

This mode will really bring your Lanta Fireball Galaxy Pro™ to life. The built-in microphone is

designed to react to the bass notes – the “beat” of the music. Each time the microphone

detects a bass note, it will advance the pattern in time to the music.

To operate the SOUND mode, press the “MODE” button until the LED display shows

“SU” followed by two digits. The numbers represent the microphone’s sensitivity setting.

This will range from SU00-SU31. The louder the music, the lower the sensitivity required to

operate the sound function – and the lower the number the operator needs to select.

If set too high, the Lanta Fireball Galaxy Pro™ will seem to run continuously and not in time

with the beat.

In addition, this effect can be enhanced by use of the speed setting. For slow music, you

may want the setting to be a low number. This will produce small changes in pattern and

colour for each beat of the music. Conversely, setting the speed higher will produce a

more dynamic effect with each beat of the music.

To operate the SPEED mode, press the “MODE” button until the LED display shows

“SP” followed by two digits, ranging from 01-10. 01 is the slowest speed setting, 10 is

the fastest.

www.lantalighting.com

Lanta Fireball Galaxy Pro Par64S User guide

Popular Lighting Equipment manuals by other brands
