Lantronix Spider User manual

Part Number 900-495
Revision H December 2022
Spider™ and SpiderDuo®
KVM-over-IP Devices User Guide

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 2
Copyright and Trademark
© 2022 Lantronix, Inc. All rights reserved. No part of the contents of this book may be transmitted
or reproduced in any form or by any means without the written permission of Lantronix.
Lantronix is a registered trademark of Lantronix, Inc. in the United States and other countries.
Patented: www.lantronix.com/legal/patents. Additional patents pending.
Windows and Microsoft Edge are registered trademarks of Microsoft Corporation. Mozilla and
Firefox are registered trademarks of the Mozilla Foundation. Chrome is a trademark of Google,
Inc. Safari is a registered trademark of Apple, Inc. All other trademarks and trade names are the
property of their respective holders.
LINUX GPL Compliance
Certain portions of source code for the software supporting the Lantronix® Spider™ family are
licensed under the GNU General Public License (GPL) Version 3, available at
www.gnu.org/gpl-3.0.en.html.
Lantronix has made modifications to this source code (2022); additional details are available upon
request.
Warranty
For details on the Lantronix warranty replacement policy, go to
www.lantronix.com/support/warranty.
Contacts
Lantronix, Inc.
Corporate Headquarters
48 Discovery, Suite 250
Irvine, CA 92618, USA
Toll Free: 800-526-8766
Phone: [phone]
Fax: [phone]
Technical Support
Online: www.lantronix.com/technical-support
Sales Offices
For a current list of our domestic and international sales offices, go to the Lantronix web site at
www.lantronix.com/about/contact.
Disclaimer and Revisions
Operation of this equipment in a residential area is likely to cause interference, in which case the
user, at his or her own expense, will be required to pay for to take whatever measures may be
required to correct the interference.
This equipment has been tested and found to comply with the limits for Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 3
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with this User Guide, may clause interference to radio communications.
Operation of this equipment in a residential area is likely to cause interference, in which case the
user will be required to correct the interference at his own expense.
The user is cautioned that changes and modifications made to the equipment without approval of
the manufacturer could void the user’s authority to operate this equipment.
Changes or modifications to this device not explicitly approved by Lantronix will void the user's
authority to operate the device.
Documentation Changes
The information in this guide may change without notice. The manufacturer assumes no
responsibility for any errors that may appear in this guide. For the latest revision of product
documents, please check our online documentation at www.lantronix.com/support/documentation.
Revision History
Date Rev. Comments
March 2007 A Initial Document
November 2007 B Changed baud rate default to 9600; added Detector utility for assigning IP
address; added ability to enable drive redirection, configure backup/restore,
and reset factory defaults; introduced a CLI and commands.
April 2008 C Added Direct KVM; KVM-only mode; Spider device network web page;
ability to preserve network settings for factory defaults; country code
support; iGoogle gadget; instructions for using the mounting kit.
May 2009 D Updated to firmware version 2.2, VIP access.
September 2009 E Updated and added SpiderDuo.
March 2010 F Updated to firmware version 3.01.
November 2013 G Updated product name and trademark information. Removed mention of
ManageLinx, VIP and DSM.
December 2022 H Updated to firmware version 5.0.0.0.
Removed Java from system requirements. Added ConsoleFlow support.
Caution: This version of the user guide is for devices running
firmware release 5.0.0.0 and newer. Devices with the Kira chip
CANNOT be upgraded to 5.0.0.0; doing so may render the device
inoperable.
To confirm, go to Maintenance > Device Status; if the “Kira Device
Revision” field is present, the device cannot be upgraded to 5.0.0.0.
Please contact Lantronix Technical Support at www.lantronix.com/
technical-support to request the previous revision of this user guide.

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 4
Table of Contents
Copyright and Trademark ____________________________________________________2
LINUX GPL Compliance _____________________________________________________2
Warranty _________________________________________________________________ 2
Contacts _________________________________________________________________2
Sales Offices ______________________________________________________________2
Disclaimer and Revisions ____________________________________________________2
Documentation Changes _____________________________________________________3
Revision History ___________________________________________________________3
1: About This Guide 11
Chapter and Appendix Summaries ____________________________________________11
Conventions _____________________________________________________________12
Additional Documentation ___________________________________________________13
2: Overview 14
Spider Overview __________________________________________________________14
Features _____________________________________________________________14
Functionality __________________________________________________________15
System Configuration and Cables _________________________________________15
Technical Specifications _________________________________________________16
SpiderDuo Overview _______________________________________________________17
Features _____________________________________________________________17
Functionality __________________________________________________________18
System Configuration and Cables _________________________________________18
Technical Specifications _________________________________________________21
Product Information Label ___________________________________________________22
3: Installing the Spider Device 23
Package Contents _________________________________________________________23
Installing the Spider ________________________________________________________23
Target Computer Setup _____________________________________________________26
Video Resolutions and Refresh Rates Configuration ___________________________26
Mouse-to-Cursor Synchronization _________________________________________27
Telnet/SSH Connections to Serial Ports _____________________________________28
Cable Connections for KVM and USB ______________________________________28
Device Failure or Cable Break in the Daisy Chain __________________________28
Client Server Setup ________________________________________________________28
Network Environment ______________________________________________________29
Spider Power _____________________________________________________________29

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 5
4: Installing the SpiderDuo Device 30
Package Contents _________________________________________________________30
Installing the SpiderDuo ____________________________________________________31
Target Computer Setup _____________________________________________________33
Video Resolutions and Refresh Rates Configuration ___________________________34
Mouse-to-Cursor Synchronization _________________________________________34
Telnet/SSH Connections to Serial Ports _____________________________________35
Cable Connections for KVM and USB ______________________________________35
Power Sequencing _____________________________________________________35
Client Server Setup ________________________________________________________35
Network Environment ______________________________________________________36
PCU Power ______________________________________________________________37
5: Web Browser Access 39
Accessing the KVM Console _________________________________________________39
6: Remote System Control 40
Overview ________________________________________________________________40
Remote Console Window ___________________________________________________40
Toolbar ______________________________________________________________41
Screen Display Adjustments ______________________________________________41
Basic Remote Console Operation _____________________________________________42
Auto Video Adjustment _________________________________________________43
Screen Display Adjustments ______________________________________________43
Telnet/SSH/Web Terminal __________________________________________________43
Set up and Enable _____________________________________________________43
Passthrough Use ______________________________________________________43
Terminal Console Use __________________________________________________44
7: Interfaces 45
Network Settings __________________________________________________________45
Network Basic Settings __________________________________________________46
LAN Interface Settings __________________________________________________47
IPv6 Settings _________________________________________________________47
Network Miscellaneous Settings ___________________________________________47
Serial Port Settings ________________________________________________________48
KVM Console Settings _____________________________________________________49
KVM Console Settings __________________________________________________50
Transmission Encoding _________________________________________________50
Miscellaneous KVM Console Settings ______________________________________51
Mouse Hotkey _________________________________________________________51
KVM Console Virtual Keys _______________________________________________51

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 6
Keyboard/Mouse __________________________________________________________51
Keyboard/Mouse Settings _______________________________________________52
8: User Accounts 54
Local vs. Remote Authentication ______________________________________________54
Local User Management ____________________________________________________54
Modifying Passwords ___________________________________________________54
User and Group Management ____________________________________________55
User Management __________________________________________________56
Group Management _________________________________________________57
User Permissions _________________________________________________________57
Remote Authentication _____________________________________________________58
LDAP _______________________________________________________________59
RADIUS _____________________________________________________________60
9: Services 61
Date/Time _______________________________________________________________61
Security _________________________________________________________________62
Login Limitations _______________________________________________________63
Authentication Limitation ________________________________________________63
Certificate _______________________________________________________________63
Event Log _______________________________________________________________66
Event Log Targets _____________________________________________________66
Event Log Assignments _________________________________________________67
SNMP __________________________________________________________________67
KVM Search _____________________________________________________________69
ConsoleFlow _____________________________________________________________70
Client Settings ________________________________________________________71
Cloud Settings ________________________________________________________71
On-Premise Settings ___________________________________________________71
10: Maintenance 72
Device Status ____________________________________________________________72
Configuration/Factory Defaults _______________________________________________73
Update Firmware __________________________________________________________75
View Event Log ___________________________________________________________76
Unit Reset _______________________________________________________________77
11: Command Reference 78
Command Syntax _________________________________________________________78
Command Help ________________________________________________________79
Tips _________________________________________________________________79

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 7
Admin Commands _________________________________________________________80
ConsoleFlow Commands ___________________________________________________81
Date/Time Commands _____________________________________________________83
Diagnostic Commands _____________________________________________________84
History Commands ________________________________________________________84
Log Commands ___________________________________________________________85
Network Commands _______________________________________________________85
Release Commands _______________________________________________________87
Security Commands _______________________________________________________87
Serial Port Commands _____________________________________________________87
Sysconfig Commands ______________________________________________________88
User Commands __________________________________________________________89
User Group Commands ____________________________________________________90
Group Permissions ________________________________________________________91
Appendix A: Troubleshooting 92
Appendix B: Supported Resolutions and Refresh Rates 94
Appendix C: Mounting Bracket Kit 95
Appendix D: Technical Support 97
Appendix E: Compliance 98

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 8
List of Figures
Figure 2-1 Spider System Configuration_______________________________________________15
Figure 2-2 Spider Cable Dimensions _________________________________________________16
Figure 2-4 SpiderDuo System Configuration ___________________________________________19
Figure 2-5 SpiderDuo PS/2 Cable Dimensions__________________________________________19
Figure 2-6 SpiderDuo USB Cable Dimensions __________________________________________20
Figure 2-8 Spider Family Product Information Label______________________________________22
Figure 3-1 Spider RS-232 Serial Port and Pinouts _______________________________________24
Figure 3-3 Spider Login Window_____________________________________________________25
Figure 3-4 Spider Prompts _________________________________________________________25
Figure 3-5 Spider RJ45 Ethernet and Cascade Ports_____________________________________26
Figure 4-1 SpiderDuo RJ45 Port and Power Connector___________________________________31
Figure 4-2 SpiderDuo Local KVM, USB, Computer Input and Serial Ports_____________________32
Figure 4-4 SpiderDuo Login Window _________________________________________________32
Figure 4-5 SpiderDuo Prompts ______________________________________________________33
Figure 4-7 PCU Layout and Dimensions_______________________________________________37
Figure 5-1 Spider Device Home Page ________________________________________________39
Figure 6-1 Remote Console Window Components_______________________________________41
Figure 6-2 Remote Console Window _________________________________________________42
Figure 6-3 Screen Display Adjustments Toolbar_________________________________________43
Figure 6-4 Terminal Console Screen _________________________________________________44
Figure 7-1 Spider Network Settings Web Page _________________________________________46
Figure 7-2 SpiderDuo Serial Port Settings Page_________________________________________48
Figure 7-3 User Remote Console Settings Page ________________________________________50
Figure 7-4 Keyboard/Mouse Settings _________________________________________________52
Figure 8-1 Change Password Page __________________________________________________55
Figure 8-2 Configure User Page _____________________________________________________56
Figure 8-3 User Permissions Page ___________________________________________________57
Figure 8-4 Authentication Page______________________________________________________59
Figure 9-1 Date/Time Settings Page__________________________________________________61
Figure 9-3 Security Settings Page ___________________________________________________62
Figure 9-4 Certificate Signing Request Page ___________________________________________64
Figure 9-5 Certificate Signing Request (Created)________________________________________65
Figure 9-6 Event Log Settings Page __________________________________________________66
Figure 9-7 SNMP Settings Page_____________________________________________________68
Figure 9-8 KVM Search Page _______________________________________________________69

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 9
Figure 9-9 ConsoleFlow Settings Page________________________________________________70
Figure 10-1 Device Status Page _____________________________________________________72
Figure 10-3 Configuration Page _____________________________________________________73
Figure 10-4 Update Firmware Page __________________________________________________75
Figure 10-5 Event Log Page ________________________________________________________76
Figure 10-6 Unit Reset Page________________________________________________________77

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 10
List of Tables
Table 1-1 Chapter/Appendix and Summary ____________________________________________11
Table 1-2 Conventions Used in This Book _____________________________________________12
Table 2-3 Spider Technical Specifications _____________________________________________16
Table 2-7 SpiderDuo Technical Specifications _________________________________________21
Table 3-2 Spider LEDs ____________________________________________________________25
Table 4-3 SpiderDuo Indicator LEDs _________________________________________________32
Table 4-6 Extended Length Cables __________________________________________________35
Table 9-2 Date/Time Settings ______________________________________________________62
Table 10-2 Device Status Settings ___________________________________________________72
Table 11-1 Action and Category ____________________________________________________79

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 11
1: About This Guide
This guide describes how to install, configure, use, and update the Lantronix® Spider™ and
SpiderDuo® distributed keyboard, video, and mouse (KVM) -over-IP devices. It describes how to
remotely and securely provide monitoring and control of one target computer system by one or
more remote users.
This chapter contains the following sections:
 Chapter and Appendix Summaries
 Conventions
 Additional Documentation
Note: The information contained in this guide apply to the Spider and SpiderDuo
devices unless otherwise noted.
Caution: This version of the user guide is for devices running firmware release 5.0.0.0
and newer. Devices with the Kira chip CANNOT be upgraded to 5.0.0.0; doing so
may render the device inoperable.
To confirm, go to Maintenance > Device Status; if the “Kira Device Revision”
field is present, the device cannot be upgraded to 5.0.0.0. Please contact
Lantronix Technical Support at www.lantronix.com/technical-support to request
the previous revision of this user guide.
Chapter and Appendix Summaries
Table 1-1 lists and summarizes each chapter and appendix.
Table 1-1 Chapter/Appendix and Summary
Chapter/Appendix Summary
Chapter 2: Overview Describes the Spider and SpiderDuo features and supported
protocols.
Chapter 3: Installing the Spider Device Provides technical specifications; describes connection
formats and power supplies.
Chapter 4: Installing the SpiderDuo
Device
Provides technical specifications; describes connection
formats and power supplies.
Chapter 5: Web Browser Access Describes method to access the Web browser.
Chapter 6: Remote System Control Describes the remote system control.
Chapter 7: Interfaces Provides instructions for configuring network ports, firewall and
routing settings, and date and time.
Chapter 8: User Accounts Provides instructions for configuring user accounts.
Chapter 9: Services Provides instructions for configuring services, such as date
and time, security settings, and certificates.

1: About This Guide
Spider™ and SpiderDuo® KVM-over-IP Device User Guide 12
Conventions
Table 1-2 lists and describes the conventions used in this book.
Chapter 10: Maintenance Provides instructions for upgrading firmware, viewing system
logs and diagnostics, and generating reports. Includes
information about web pages and commands used to shut
down and reboot the Spider and SpiderDuo devices.
Chapter 11: Command Reference Lists and describes all of the commands available on the
Spider or SpiderDuo Device command line interface.
Appendix A: Troubleshooting Describes troubleshooting methods.
Appendix B: Supported Resolutions and
Refresh Rates
Lists the resolutions and refresh rates that are supported.
Appendix C: Mounting Bracket Kit Describes how to mount the Spider or SpiderDuo Device in a
rack.
Appendix D: Technical Support Lists technical support telephone and fax numbers.
Appendix E: Compliance Provides information about the Spider and SpiderDuo device
compliance with industry standards.
Table 1-2 Conventions Used in This Book
Convention Description
Bold text Default parameters.
Brackets [ ] Optional parameters.
Angle Brackets < > Possible values for parameters.
Pipe | Choice of parameters.
Warning Warning: Before you work on any equipment, you must be aware
of the hazards involved with electrical circuitry and familiar with
standard practices for preventing accidents.
Note Note: Notes contain helpful suggestions, information, or references to
material not covered in the publication.
Caution Caution: You might do something that could result in faulty
equipment operation, or loss of data.
Screen Font
(Courier New)
CLI terminal sessions and examples of CLI input.
Table 1-1 Chapter/Appendix and Summary (continued)
Chapter/Appendix Summary

1: About This Guide
Spider™ and SpiderDuo® KVM-over-IP Device User Guide 13
Additional Documentation
Visit the Lantronix web site at www.lantronix.com/support/documentation for the latest
documentation and the following additional documentation:
Spider View User Guide—Details instructions on using the Spider View utility.
Note: Spider View 2.0.0 is required to manage Spider devices running firmware
5.0.0.0 and newer.
Spider Quick Start Guide—Provides an overview of using the Spider device.
SpiderDuo Quick Start Guide—Provides an overview of using the SpiderDuo.

Spider™ and SpiderDuo® KVM-over-IP Device User Guide 14
2: Overview
Lantronix Spider and SpiderDuo distributed KVM-over-IP devices are designed to remotely and
securely provide monitoring and control of one target computer system by one or more remote
users. The remote user (client) accesses the Spider or SpiderDuo device over a local or wide area
network connection using a standard web browser.
Spider and/or SpiderDuo device is an evolution of the traditional remote KVM device into a
compact package. It is light enough to be cable-supported from the back of a server and takes up
no rack space.
Both devices differ from other KVM-over-IP devices in several ways. Unlike rack mounted KVM-
over-IP devices, the allocation of one Spider device per computer allows add-as-you-grow
scalability and guarantees non-blocked BIOS-level access to mission-critical servers regardless of
the number of remote users or servers that need access.
This chapter contains the following sections:
 Spider Overview
 SpiderDuo Overview
 Product Information Label
Note: The terms Remote Console and KVM Console are synonymous and used
interchangeably throughout the User Guide.
Spider Overview
The Spider device features, functionality, system configuration and cables, and technical
specifications are described in the following sections:
 Features
 Functionality
 System Configuration and Cables
 Technical Specifications
Features
The Spider device is unique in that it is low-enough in power consumption to be powered from the
attached server. The color-coded cable plugs for the keyboard, mouse, USB port and video are
designed to plug directly into the target server. An optional external AC/DC power supply is
available.
The device incorporates two hardware-switched Ethernet ports, one for the primary network
connection and the second for daisy-chaining Spider devices, or aggregating other Ethernet
connections (for example, a dedicated management LAN port on the controlled system). This
provides a cost-effective solution in environments in which numerous cable drops and distance
limitations are challenging when adding servers.
The Spider device comes in the following four models:
One model with both PS/2 and USB keyboard and mouse interfaces (software selectable)
One model for USB-only systems

2: Overview
Spider™ and SpiderDuo® KVM-over-IP Device User Guide 15
One model with cable length of 21”
One model with cable length of 59”
Secure, full BIOS-level control of remote servers over an IP network
Space–saving “zero footprint” package attaches directly to the server that saves rack space
Flexible 1–port design allows growth
Guaranteed non-blocked access to remote servers that ensures lowest “cost-per-remote user”
Browser–based, no client software or special licensing required
Direct KVM minimizes the number of clicks to the remote–server console
Built-in RS-232 serial port that can be configured for serial console port access and host pass-
through access
Ideal for distributed IT system environments such as small branch offices, campuses, test
labs, and server hosting environments
Server-powered design - no external power supply required
Functionality
The Spider device captures the video output from the attached computer, compresses and sends
it over the network to a KVM console window launched by the browser or to a command line
interface on the user system, which displays a replica of the server video output on the user
monitor.
The Spider device also uses KVM console to accept keystrokes and mouse movements on the
user system; recognizes those intended for the target computer; transmits the keystrokes and
mouse movements; and emulates a physically attached keyboard and mouse.
System Configuration and Cables
Figure 2-1 shows the Spider system configuration, and Figure 2-2 shows the cable dimensions.
Figure 2-1 Spider System Configuration

2: Overview
Spider™ and SpiderDuo® KVM-over-IP Device User Guide 16
Figure 2-2 Spider Cable Dimensions
Technical Specifications
Table 2-3 lists the components and general specifications.
Table 2-3 Spider Technical Specifications
Component Specification
Security Remote Authentication: LDAP, RADIUS, Active Directory
User/Group management with permissions control
Configurable port numbers (HTTPS, Telnet, SSH)
Selective disable of Telnet/SSH
Secure encryption of keyboard, mouse, and video data
AES used as cipher for SSH/SSL communications

2: Overview
Spider™ and SpiderDuo® KVM-over-IP Device User Guide 17
SpiderDuo Overview
The SpiderDuo features, functionality, system configuration and cables, and technical
specifications are described in the following sections:
 Features
 Functionality
 System Configuration and Cables
 Technical Specifications
Features
SpiderDuo provides secure, remote KVM and over-IP capabilities as well as transparent local
access. Coupled with the optional single port power control unit (PCU), remote users can also
Target Server Requirements Multiple Operating Systems supported: Windows 10, Unix, Linux,
or MAC OS X
Power/keyboard/mouse: 2 USB ports; or 1 USB and 1 PS/2
keyboard and 1 PS/2 mouse connector
Video Interface: HD15 VGA video output
Client System Requirements Microsoft Edge, Mozilla Firefox 100+, Safari 15+, Google Chrome
107+
Telnet/SSH client for command line (CLI) access
Optional Items Replacement mounting bracket kit (see Appendix C: Mounting
Bracket Kit)
Optional DC power supply with international adapters (100-
240VAC, 50-60 Hz; 5 VDC @ 1A; USB “Mini-B” Type jack)
Interfaces Network: One 10/100/1000 Base-T Ethernet Port with activity
indicators (RJ45)
Cascade: One 10/100/1000 Base-T Ethernet Port with activity
indicators (RJ45)
Serial: RS-232, up to 115,200 bps
Keyboard/Mouse: PS/2 or USB
Video: HD15 VGA
Power Requirements Input: 5 VDC @ 2A max. (Target server powered HD15 VGA)
Optional Auxiliary DC power supply available for redundancy
Environmental Operating: 0º to 45º C (32º to 115º F)
Storage: -20º to 70º C (-4º to 158º F)
Humidity: 0 to 95% RH (non-condensing)
Heat Dissipation: 4 Watts (14 BTU/hr)
Dimensions (H x W x D) 13.2 x 5.8 x 3.1 cm (5.2 x 2.3 x 1.2 in) (See Figure 2-2 for cable
dimensions.)
Weight 185g (6.6 oz)
Shipping Weight .5 kg (1.0 lbs)
Table 2-3 Spider Technical Specifications (continued)
Component Specification

2: Overview
Spider™ and SpiderDuo® KVM-over-IP Device User Guide 18
initiate system power cycles over the network. SpiderDuo allows complete local, plus remote
management of the host machine anytime,from virtually anywhere.
There are two SpiderDuo models: one model with both PS/2 and USB keyboard and mouse
interfaces (software selectable), and one model for USB-only systems. They have the following
features:
Secure, full BIOS-level control of remote servers over an IP network
Space–saving “zero footprint” package attaches directly to the server that saves rack space
Flexible 1–port design allows growth
Guaranteed non-blocked access to remote servers that ensures lowest “cost-per-remote user”
Browser–based, no client software or special licensing required
Direct KVM minimizes the number of clicks to the remote–server console
Built-in RS-232 serial port that can be configured for serial console port access and host pass-
through access
Ideal for distributed IT system environments such as small branch offices, campuses, test
labs, and server hosting environments
Local access and up to 8 simultaneous remote users
Optional power control unit (PCU)
Functionality
The SpiderDuo provides local access for distributed server management in addition to the
following functionality:
Captures the video output from the attached computer.
Compresses the video and sends it over the network to a KVM console window launched by
the browser or to a command line on the user system, which draws a replica of the server
video output on the user monitor.
Uses KVM console to accept keystrokes and mouse movements on the user system;
recognize those intended for the target computer; transmit the keystrokes and mouse
movements; and emulate a physically attached keyboard and mouse.
System Configuration and Cables
Figure 2-4 shows a SpiderDuo system configuration, Figure 2-5 shows the PS/2 cable dimensions,
and Figure 2-6 shows the USB cable dimensions.

2: Overview
Spider™ and SpiderDuo® KVM-over-IP Device User Guide 19
Figure 2-4 SpiderDuo System Configuration
Figure 2-5 shows the PS/2 cable dimensions.
Figure 2-5 SpiderDuo PS/2 Cable Dimensions

2: Overview
Spider™ and SpiderDuo® KVM-over-IP Device User Guide 20
Figure 2-6 shows the USB cable dimensions.
Figure 2-6 SpiderDuo USB Cable Dimensions
Note: The PS/2 cables and USB cables cannot be mixed and matched with each other
due to the unique properties of each. Use the cables that come with your SpiderDuo.
