Laserworld PL-4500 RGB US User manual

Laserworld Purelight Series US
PL-1200 G US, PL-2000 G US, PL-3500 G US, PL-6000 G US
PL-8000 G US, PL-12000 G US, PL-20000 G US
PL-1600 RGB US, PL-2600 RGB US, PL-3400 RGB US, PL-4500 RGB US
PL-6000 RGB US, PL-8400 RGB US, PL-10900 RGB US, PL-15500 RGB US
PL-2500 RGB Blue Beam US, PL-5000 RGB Blue Beam US
PL-8000 RGB Blue Beam US, PL-16000 RGB Blue Beam US
Manual
Read carefully before u ing thi device!

Manual Purelight Serie US 2 / 8
Revi ion: Dec-10
Checking parts
Plea e check if all li ted part are included, and
are not damaged. Included:
1 x La er projector
1 x Power cable
1 x 9-pin plug
2 x key
1 x afety cord
1 x manual
Safety instructions
If the device ha been expo ed to great temperature change , do not witch it on immediately. Conden ation
water may damage your device. Leave the device witched off until it ha reached room temperature.
The la er mu t only be u ed for how . Any operation ha to be attended and upervi ed by a killed and well-
trained operator.
Never leave thi device running unattended and keep it away from children and unauthorized per on .
Keep away from heater and other heat ource . In order to afeguard ufficient ventilation, leave 50 cm of free
pace around the device.
Never direct the la er beam to people or animal .
CAUTION LASER DIODE: If you open the device for cleaning, alway di connect from main !
HEALTH HAZA D! Never look directly into the light source, as sensitive persons may suffer an
epileptic shock!
The e la er are con idered a definite eye hazard, particularly at the higher power level , which WILL cau e eye
damage. So the e la er erie model upplied with a key witch to prevent unauthorized u e, warning label and
aperture label affixed to the la er.
In tallation afety
Prior to in tallation and operation of the la er, the path of the beam and effect hould be con idered,
particularly with re pect to how they will reach the audience. If direct audience canning i de ired, then the la er
energy in the effect need to be con idered to decide if the effect are afe for direct viewing. Alway en ure, that
the maximum permi ible expo ure (MPE) i not exceeded in the area acce ible to the public. So in tall the la er in
uch a way, that minimum di tance and height en ure the MPE i never exceeded in the public area. When
audience canning i performed, an operator ha to be pre ent. An ea ily acce ible emergency witch ha to be
in talled. When etting up the la er, make ure the la er i affixed firmly, to avoid vibration .
Warning labels on the device
La er radiation Read manual
before u e
Avoid expo ure Operation by qualified
To the beam per onal only
La er cla 4 Never direct la er
Beam at people
Caution of radiation Never look directly
If cover i removed into beam
Indoor u e only
At front opening: Avoid expo ure – la er radiation i emitted.
OPE ATING THE LASE
Don’t remove the warranty/ erial number label - removal void warranty
The operator ha to make ure that la er radiation – for la er cla 4 al o reflected la er radiation – higher than
the maximum permi ible level i avoided by technical or organi ational mea ure . (E pecially with re pect to the
MPE, ee above.)
Make ure to u e the correct voltage. U e a power ocket with earth/ground. Don’t use dimmer, C, or other
electronically switched ocket . Whenever po ible, don’t u e the la er together with large appliance ,
e pecially fog machine , on the ame main !
If the device i u ed in a flying in tallation, the mounting bracket and an appropriate afety-rope mu t be afixed.
In ome countrie , the operator mu t notify the accidence in urance and the authority for indu trial afety, before
operating a la er. For more information, contact the relevant authoritie .
Plea e con ider that unauthorized modification on the device are trictly forbidden due to afety rea on !
If thi device will be operated in any way differently than de cribed in thi manual, the product may uffer
damage and the guarantee become void. Furthermore, any other operation may lead to danger like hort-
circuit, burn , electric hock, etc.
20000 mW

Manual Purelight Serie US 3 / 8
Revi ion: Dec-10
Keep urrounding dry and clean. Thi unit hould be keep dry, do not u e in the rain or damp and du ty
environment, don’t put liquid fileld container on the device. Projector hould be put in a water-proof hou ing
when operated out ide.
Regularly open the device ( ee “cleaning” further down) to check for du t in ide, or if fog fluid conden e in the
hou ing (if o rearrange hazer and/or la er po ition).
Operating temperature i 50~95°F (10~35°C). In a new in tallation, check after ome 15-30 minute whether the
outlet air get too warm. Regularly check the in ide for du t depo it , e pecially around the fan . Let la er cool off
10minute after 2 hour of operation,to en ure maximum lifetime for the diode.
Di tance between la er aperture and projection creen hould be not le than 1 meter.
Do not turn device on and immediately off again frequently.
Do not look into the la er beam directly, e pecially not with optical in trument .
Do not touch the device with wet hand .
When the la er diode become dim or broken, plea e contact your dealer.
When returning la er to dealer/manufacturer alway u e original packaging.
Maintenance hould be performed every 15-day period. See “cleaning” further down.
To en ure maximum lifetime of the la er:
Don’t overheat the la er:
•Alway en ure good ventilation
•Don’t have tage light (e pecially moving head ) directed toward the la er
•Regularly clean the fan and the interior from du t
•In a new in tallation check the temperature after 30 minute of operation
Keep the la er dry
•Make ure fog/hazer fluid doe n’t conden ate in ide the la er - fog ha to be in front of the la er – not
in ide
•A few day after (each new) in tallation, open the cover to check if fluid conden ate in ide
•If fluid conden ate in ide, repo ition the la er or fogger/hazer
Turn the device off, when not u ed. The diode i on, when the device i on. Even if it i not lit.
Using the laser
Caution – use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
Make ure the correct voltage i u ed. Connect main . Connect an emergency witch or the remote control unit
( ee below) to the 9-pin connector on the back ide (pin 1 and 2). If you do not wi h to connect an emergency
witch, connect the 9-pin plug in tead (for te ting purpo e only).
Depending on the mode elected ( ee below), la er light hould come out of the opening on the front panel – be
careful.
emote control unit
The unit i equipped with a remote control unit. Here you
find the following control :
Key witch: key can only be removed in off po ition. Turn
off the blanking ignal of the la er .
Emergency witch: when pre ed the beam i blocked
mechanically ( hutter). To relea e, turn clockwi e (arrow ).
La er emi ion i turned on after a 6 econd time delay.
La er emi ion indicator i on, a long a the mechanical
hutter i open.
Control panel
•MODE: elect mode, or go up in menu
•ENTE : confirm change , or go down in menu
•UP/ DOWN: change DMX addre
3/4 DMX In/Out
5 emotelock: connect remote control unit.
6 Security switch: La er on/off
7 ILDA connector in/out
8 Power switch: power on/off
9 Power: connect to main .

Manual Purelight Serie US 4 / 8
Revi ion: Dec-10
Operating modes:
Automatic mode: built-in pattern are di played
Mu ic active: la er i controlled from built-in microphone
“DMXAddr“: DMX512 mode-. Here you can change the DMX addre :
“Open“: change addre
“Up“ & “down“: increa e/decrea e addre
“Save“: ave new addre
“LCD di play memory function“: ave etting automatically.
La er: On/Off, when et to Off, la er i off in Auto/DMX mode (ILDA mode only)
X/Y-Axi : mirror projection horizontally/vertically
Up ide down: Di play turned up ide down
ILDA mode
When an ILDA compatible interface i connected to the la er, the la er i automatically witched to ILDA mode.
Output i then controlled from a PC running oftware.
The la er u e pin 4 and 17 of the ILDA ignal to detect the pre ence of an ILDA interface.
Further information can be found in the oftware manual.
Please note: the canner are et to a can peed of ca. 22000 PPS at ca. 30° canangle. If you increa e the
can peed, fir t reduce the canangle (image ize). Otherwi e you may damage the canner ! When u ing with
different can peed/ canangle readju tment of the canner driver may be nece ary, if in doubt, contact your
dealer.
DMX mode
Channel
DMX512 value
Function
1
Red
0~255
0~100% Dimmer
2
Green
0~255
0~100% Dimmer
3
Blue
0~255
0~100% Dimmer
4 Colour
0~25
Original colour
26~51
White
52~77
Yellow
78~103
Red
104~129
Green
130~155
Cyan
156~181
Blue
182~207
Purple
208~233
Change colour
234~255
Colour flux, low to fa t
5 Pattern group
0~51
Pattern group 1
52~103
Pattern group 2
104~154
Pattern group 3
155~205
Pattern group 4
2
06~255
Pattern group 5
6
Pattern
0~255
160/5=32pc
7
Horizontal rotation
0~255
low to fa t
8
Vertical rotation
0~255
low to fa t
9
Rotation about Z
-
axi
0~255
low to fa t
10
Horizontal movement
0~255
low to fa t
11
Vertical movement
0~255
low to
fa t
12
Horizontal ize
0~255
low to fa t
13
Vertical ize
0~255
low to fa t
14
Hor. and vert. ize
0~255
low to fa t
15
Drawing peed
0~255
low to fa t
16
Point draw
0~255
low to fa t
17
Scan peed
0~255
low to fa t
18
Pattern ize
0~1
Origin
al ize
2~255
Size (120=original)
Maintenace / cleaning
Alway di connect from main before cleaning/opening the la er. You can open the device by removing the top:
remove the mounting bracket (4 quick lock ), the eyebolt , and the crew along the top cover.
Regularly clean the interior from du t, e pecially en ure operation of the fan . To clean the mirror , ideally u e
acetone and len cleaning paper (fold paper to get an edge with which to clean the mirror ). If not available, you
can al o u e window cleaner, and a paper towel. Be careful, even light cratche reduce the output power of the
la er; alway clean with troke in one direction, to minimize the effect of cratche . Mirror need cleaning, when a
“halo” i noticeable around the beam, or an unu ual high amount of diffu e light can be een in ide the device.
When fog fluid conden e in the device, clean all trace , and rearrange the po ition of fazer and/or la er.

Manual Purelight Serie US 5 / 8
Revi ion: Dec-10
Technical specifications
•Output power (in mW, at the laser):
min.
-
max.
Power/
wavelength green
Power/wavelength red
Power/wavelength blue
Beam (ca.)
PL
-
1200 G
800
-
1200
>800mW 532nm
3mm/1.5mrad
PL
-
2000 G
1200
-
2000
>1200mW 532nm
3mm/1.5mrad
PL
-
3500 G
2500
-
3500
>2500mW 532nm
3mm/1.5mrad
PL
-
6000 G
4500
-
6000
>4500mW 532
nm
3mm/1.5mrad
PL
-
8000 G
6500
-
8000
>6500mW 532nm
3
mm/1.5mrad
PL
-
12000 G
9000
-
12000
>9000mW 532nm
3
mm/1.5mrad
PL
-
20000 G
15000
-
20000
>15000mW 532nm
4mm/1.8mrad
PL
-
1600 RGB
1100
-
1600
>500mW 532nm
>300mW 640nm
>300mW 445nm
3mm/1mrad
PL
-
26
00 RGB
2000
-
2600
>800mW 532nm
>550mW 640nm
>650mW 445nm
3mm/1mrad
PL
-
3400 RGB
2400
-
3400
>1200mW 532nm
>550mW 640nm
>650mW 445nm
3mm/1mrad
PL
-
4500 RGB
3400
-
4500
>14
00mW 532nm
>1000
mW 640nm
>1000
mW 445nm
3mm/1mrad
PL
-
6000 RGB
4500
-
6000
>2500mW 532
nm
>1000mW 640nm
>1000mW 445nm
3mm/1.2mrad
PL
-
8400 RGB
6500
-
8400
>2500mW 532nm
>2000mW 640nm
>2000mW 445nm
3mm/1.5mrad
PL
-
10900 RGB
8500
-
10900
>4500mW 532nm
>2000mW 640nm
>2000mW 445nm
3mm/1.5mrad
PL
-
15500 RGB
13000
-
150
00
>4500mW 532nm
>4500mW 640
nm
>4000
mW
445nm
3mm/1.5mrad
PL
-
2500 RGB
Blue Beam
1550
-
2500
>400mW 532nm
>150mW 640nm
>1000mW 445nm
4mm/>1mrad
PL
-
5000 RGB
Blue Beam
3300
-
5000
>1000mW 532nm
>300mW 640nm
>2000mW 445nm
4mm/>1mrad
PL
-
8000 RGB
Blue Beam
5900
-
8000
>1350mW 532nm
>550m
W 640nm
>4000mW 445nm
4mm/>1mrad
PL
-
16000 RGB
Blue Beam
12000
-
16000
>3000mW 532nm
>1000mW 640nm
>8000mW 445nm
4mm/>1mrad
•Lasersources: air-cooled DPSS la er (green all model ), la er diode (red, blue with RGB model )
•Laser class: 4
•Modes: ILDA, DMX 512, auto
•ILDA: ILDA tandard Sub-D haped 25pin connector
•Galvos: max 50k can peed (at 4°)
•DMX 512: 18 channel
•Patterns: 160
•Scanangle: et to ca. 40° optical (60° max)
•Input voltage: AC 110~120V or 220~240V
witchable 50/60Hz
•Power consumption: 350W
•dimensions: 23.6”x14.6”x16.5” (60 x 37 x 42cm)
(W x D x H)
•Weight: 66lb (30kg) La er, total: 121lb (55kg)
(with flight case)
•Operating temperature: 50~95°F (10°-35°C)
•Loudness: <70db
Change scanner
1. Un crew UK M6 crew and di connect ignal
cable.
2. Loo en M4 x 10 crew and remove galvo.
3. In ert galvo, reconnect and fix ignal cable.
4. Rotate galvo to center projection. Fix galvo.
Adjustable mirror mounts
Loo en et crew , then adju t with X/Y adju table crew . Make
ure beam i centered on canner mirror . Adju t Z- crew
imultaneou ly Tighten et crew .
When combining beam (RGB la er), fir t make ure the beam are
(roughly) on the ame pot on the mirror /dichro . Then u e a te t
pattern (e.g. rectangle) to do fine adju tment. For adju tment ,
alway turn output power down (if po ible).
Troubleshooting
Problem Possible reason Damaged part eplacement
No power Fu e blown Fu e 09-00-3001-01
Power upply defective +-24V 16-03-0039-00
Mu ic mode not working Microphone defective Microphone 16-03-0001-00
Control board defective Control board 26-2A-LT12V2-00

Manual Purelight Serie US 6 / 8
Revi ion: Dec-10
Potentiometer defective Potentiometer 04-03-0104-01
CPU defective IC 00-89C516RD-00
X and/or Y axi no
deflection
Scanner defective Galvo 15-01-2215-00
CPU defective IC 00-89C516RD-00
Control board defective Control PCB 26-2A-LT12V2-00
Power upply defective +-24V 16-03-0039-00
Scanner driver board defective Scanner driver board 26-2A-6800A-00
La er dark or dim
Len e / mirror dirty Clean with alcohol
La er diode defective La er diode Inquire
Control board defective Control board 26-2A-LT12V2-00
Configuration / wrong mode Check configuration ( ee
paragraph control panel)
No output
Configuration / wrong mode Check configuration ( ee
paragraph control panel)
Control board defective Control PCB 26-2A-LT12V2-00
Power upply defective +-24V 16-03-0039-00
Di play board defective Di play 26-2A-YX2012DI-00
Pin 4 and 17 of the ILDA ignal
not connected
See below
La er doe not witch to ILDA mode:
•The interface doe not connect pin 4 and 17 (Interlock) of the ILDA ignal. See interface manual
•The cable doe not connect pin 4 and 17. U e a cable that connect pin 4 and 17.
•U e an adapter, that connect pin 4 and 17.
ILDA signal
Pin out of the tandard ILDA ignal:
1 Scanner X+ -5V..+5V 14 X- +5V..-5V
2 Scanner Y+ -5V..+5V 15 Y- +5V..-5V
3 Inten ity/Blanking+ 0V..2.5V 16 Inten ity/Blanking- 0..-2.5V
4 Interlock A 17 Interlock B
5 Red+ 0..2.5V 18 Red- 0..-2.5V
6 Green+ 0..2.5V 19 Green- 0..-2.5V
7 Blue+ 0..2.5V 20 Blue- 0..-2.5V
8 – 12 Not u ed 23-24 Not u ed
13 Shutter +5V, max. 20 mA 25 GND Signal ground
Please note
Thi device ha left our premi e in ab olutely perfect condition. In order to maintain thi condition and to en ure
a afe operation, it i ab olutely nece ary for the u er to follow the afety in truction and warning note written
in thi u er manual.
La erworld cannot be made liable for damage cau ed by incorrect in tallation and un killed operation!
For ervice contact your dealer, or La erworld.
Subject to change without notice. Error and omi ion expected.
Laserworld (Switzerland) AG
Kreuzlinger tra e 5
8574 Lengwil-Oberhofen
SWITZERLAND
Authorized per on:
Supervi ory board Mr Martin Werner
place of bu ine : 8574 Lengwil-Oberhofen / SWITZERLAND
company number: CH-440.3.020.548-6
Commercial Regi try Kanton Thurgau
www.la erworld.com
info@la erworld.com
repre entative according to EMVG:
Cleantech Europe GmbH
Managing Director: Thoma Schulze
Fürkhof tr. 5
81927 München / DE

Manual Purelight Serie US 7 / 8
Revi ion: Dec-10
Appendix: Technical diagram
Single colour green lasers without blue and red power supply/diode

Manual Purelight Serie US 8 / 8
Revi ion: Dec-10
Position of warning labels and laser aperture
The po ition of the warning label (EN 60825-1) are:
Warning Logotype: Po ition 1 Noninterlocked Protective Hou ing Label: Po ition 1
Aperture Label: Po ition 2
La er Radiation Emi ion Indicator: Po ition 3 and on remote control unit
Laser aperture: la er radiation will be emitted through the window at po ition 4!
1
2
3
4
