1. Introduction
This document describes the Lattice Semiconductor USB3-GbE VIP IO Board. This board is designed to work with the
Lattice Video Interface Platform (VIP) board interconnect system.
This user guide includes descriptions of board components, schematics, and bill of materials.
Key features of the USB3-GbE VIP IO Board include:
Onboard industrial grade TI DP83867IR Gigabit Ethernet PHY with support 10/100/1000 Ethernet
Onboard Cypress FX3 USB3.1 controller
Two 60-pin Rugged High-Speed Headers
Figure 1.1 shows the top view of the USB3-GbE VIP IO Board and its key components. Figure 1.2 shows the bottom view
of the board.
JTAG FOR FX3 VIA
USB2
SN65MLVD200
VCCIO Selection
RJ45 Ethernet
FX3 Boot
Configuration
USB 3.0 Micro-B
Connector
SW1
SW2
LED D8
LED D1- D3
LED D4- D7
Figure 1.1. Top View of USB3-GbE VIP IO Board

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal. All other brand or product names are
trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02016-1.0 5
Upstream
Connector (J1)
Upstream
Connector (J2)
TI GigE Phy
JTAG Debugger of FX3
FX3 USB3 Controler
Figure 1.2. Bottom View of USB3-GbE VIP IO Board
1.1. Further Information
The following references provide detailed information on the USB3-GbE VIP IO Board:
Appendix A. USB3-GbE VIP IO Board Schematics
Appendix B. USB3-GbE VIP IO Board Bill of Materials
For more information on boards and kits available for the VIP (Video Interface Platform) system visit
www.latticesemi.com/vip.
For details on the Texas Instruments DP83867IR Gigabit Ethernet PHY, visit the Texas Instruments website at
www.ti.com.
For details on the Cypress FX3 USB3.1 controller, visit the Cypress website at www.cypress.com.

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
6 FPGA-EB-02016-1.0
2. Functional Description
The USB3-GbE VIP IO Board provides USB3 and Gigabit Ethernet connectivity for the ECP5 VIP Processor Board. The
Gigabit Ethernet Phy and the USB3 controller work independently.
TI GigE Phy
DP 83867R RJ45
MDIO
RGMII
SYS Reset Data
USB3 FX3 Controller
CYUSB3014
Two
60-Pin
Connector
J1/J2
Micro
USB
Control
Clock USB
Parallel Data
Figure 2.1. Functional Block Diagram
2.1. Switches and Buttons
The push button switch, SW1, is connected to the CTL10_GPIO signal of the FX3 USB Controller. The push button
switch, SW2, is connected to the System Reset of the board. Pressing SW2 provides logic 0 to the TI DP83687 and
CYUSB3014 Reset pin. The RESET signal is also connected to GSRN on connecter J1, allowing SW2 to control the reset
signal for other connected boards.
2.2. Gigabit Ethernet Interface
The RJ45 connector, J3, provides Gigabit Ethernet connectivity via a standard Cat6 Ethernet cable.
2.3. USB3 Interface
The USB 3.0 Micro-B connector, J4, provides USB connectivity via a Micro USB 3.0 cable.

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal. All other brand or product names are
trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02016-1.0 7
3. High-Speed Connectors
The two 60-pin high-speed headers, connectors J1 and J2, are used to connect ECP5 VIP Processor Board.
Table 3.1. Connector J1
J1 Connector Pin
Signal Name
Device - pin
Description
1
GND
—
—
2
P12
—
—
3
CLK_OUT
—
—
4
P12
—
—
5
FX3_D24
FX3 - DQ24
—
6
P12
—
—
7
GND
—
—
8
P12
—
—
9
FX3_D27
FX3 - DQ27
—
10
FX3_D31
FX3 - DQ31
—
11
FX3_D25
FX3 - DQ25
—
12
FX3_D28
FX3 - DQ28
—
13
GND
—
—
14
GND
—
—
15
FX3_D22
FX3 - DQ22
—
16
FX3_SYNC
FX3 - CTL8_GPIO
—
17
FX3_D21
FX3 - DQ21
—
18
FX3_D26
FX3 - DQ26
—
19
GND
—
—
20
GND
—
—
21
FX3_D19
FX3 - DQ19
—
22
FX3_D16
FX3 - DQ16
—
23
FX3_D18
FX3 - DQ18
—
24
MDIO_DATA
DP - MDIO—
MANAGEMENT DATA I/O
26
GND
—
—
27
FX3_SPI_SCK
SPISCK_UARTRTS_GPIO
—
28
SYS_RST_N
Global System Reset
29
FX3_SPI_MOSI
FX3- GPIO_I2SWS
—
30
MDIO_CLK
DP - MDC
MANAGEMENT DATA CLOCK
31
FX3_SPI_MISO
GPIO_I2SMCLK
—
32
FX3_D29
FX3 - DQ29
—
33
FX3_SPI_CS_N
SPISSN_UARTCTS_GPIO
—
34
GND
—
35
FX3_FPGA_DONE
FX3 - GPIO_I2SCLK
—
37
FX3_FPGA_INIT_N
FX3 - GPIO_I2SSD
—
40
GND
—
—
41
FX3_I2C_SCL
FX3 - I2C_SCL
I2C Interface Clock
43
FX3_I2C_SDA
FX3 - I2C_SDA
I2C Interface Data
46
GND
—
—
52
GND
—
—
55
GND
—
—
25, 36, 38, 39, 42, 44, 45, 47,
48, 49, 50, 51, 53, 54, 56, 57,
59,60
Not Connected
—
—

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
8 FPGA-EB-02016-1.0
Table 3.2. Connector J2
J1 Connector Pin
Signal Name
Device - pin
Description
1, 2, 3, 4
3.3V
—
—
5
FX3_D0
FX3 - DQ0
—
6
FX3_D3
FX3 - DQ3
—
7
FX3_D4
FX3 - DQ4
—
8
FX3_D6
FX3 - DQ6
—
9
FX3_D15
FX3 - DQ15
—
10
FX3_D8
FX3 - DQ8
—
11
FX3_D7
FX3 - DQ7
—
12
FX3_D10
FX3 - DQ10
—
13
FX3_PCKTEND_N
FX3 - CTL7_PKTEND
—
14
FX3_D12
FX3 - DQ12
—
15
FX3_SLRD_N
FX3 - CTL3_SLRD
—
16
FX3_D11
FX3 - DQ11
—
17
FX3_D14
FX3 - DQ14
—
18
FX3_D13
FX3 - DQ13
—
19
FX3_PCLK
FX3 - PCLK_CLK—
—
20, 21
GND
—
—
22
FX3_D9
FX3 - DQ9
—
23
FX3_A1
FX3 - CTL11_A1
—
24
FX3_SLCS_N
FX3 - CTL0_SLCS
—
25
FX3_A0
FX3 - CTL12_A0
—
26
FX3_SLWR_N
FX3 - CTL1_SLWR
—
27
FX3_D17
FX3 - DQ12
—
28
RGMII_RXCTRL
DP -RX_DV/RX_CTRL
RECEIVE DATA VALID or RECEIVE CONTROL
29
FX3_D20
FX3 - DQ20
—
30
RGMII_TXCTRL
DP -TX_EN/TX_CTRL
TRANSMIT ENABLE or TRANSMIT CONTROL
31
FX3_D23
FX3 - DQ23
—
32
RGMII_RXD3
DP -RX_D3
RECEIVE DATA Bit 3
33
FX3_D5
FX3 - DQ5
—
35
FX3_D1
FX3 - DQ1
—
36
RGMII_RXD1
DP -RX_D1
RECEIVE DATA Bit 1
37
FX3_D2
FX3 - DQ2
—
38
RGMII_RXD0
DP -RX_D0
RECEIVE DATA Bit 0
39, 40
GND
—
—
41
FX3_FLAG_A
FX3 - CTL4_FLAGA
—
42
RGMII_TXCLK
DP -GTX_CLK
GMII and RGMII TRANSMIT CLOCK
43
FX3_SLOE_N
FX3 - CTL2_SLOE
—
44
RGMII_TXD0
DP -TX_D0
GMII TRANSMIT DATA Bit 0
45
FX3_FLAG_B
FX3 - CTL5_FLAGB—
46
RGMII_TXD1
DP -TX_D1
GMII TRANSMIT DATA Bit 1
47
FX3_D30
FX3 - DQ30
—
48
RGMII_TXD2
TX_D2
GMII TRANSMIT DATA Bit 2
49
TP1
—
50
RGMII_TXD3
TX_D3
GMII TRANSMIT DATA Bit 3
51
TP2
—
52
RGMII_RXCLK
DP -RX_CLK
RECEIVE CLOCK
54
TP3
—
53, 55 ,56
GND
—
—
57,58, 59, 60
2.5V
—
—

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal. All other brand or product names are
trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02016-1.0 9
4. Power Supply
Board power is supplied through connectors J1 and J2.Figure 4.1 shows the power distribution scheme. Header P2 is
used to select VCCIO for FX3 and GbE PHY.
Status
LED D2
LDO
U1
LDO
U4
Status
LED D8
1.1 V, 500 mA
Status
LED D1
1.2 V, 500 mA
3.3 V from J2
2.5 V from J2
LDO
U2
Status
LED D3
5 V, 500 mA
VIO
P2
12 V from J1
Figure 4.1. Power Distribution Scheme

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
10 FPGA-EB-02016-1.0
5. User LEDs and Headers
Eight discrete LEDs (light-emitting diodes) are available to the user.
Table 5.1. User LEDs
Signal
LED #
Source
Color
LED1
D1
1.2 V LDO
Green
LED2
D2
12 V
Green
LED3
D3
5.0 V
Green
LED4
D4
Activity
Yellow
LED5
D5
Speed 1000
Green
LED6
D6
Link up
Blue
LED7
D7
1.1 V LDO
Green
LED8
D8
FX3 user LED
Blue
The USB3-GbE VIP IO Board has four 3-pin configuration headers. Header J2 allows to configure the applied voltage to
the board. The user can select either 3.3 V or 2.5 V. Header J3, J4, and J5 provide the bootstrapping options for the
Boot selection of the FX3 USB controller.
Table 5.2. Header J2
Description
Header J2 Pin 1
Header J2 Pin2
Header J2 Pin 3
VCCIO
V2R5
VIO
V3R3
Table 5.3. Header J3
Description
Header J3 Pin 1
Header J3 Pin2
Header J3 Pin 3
FX3 Boot Selection
VIO
PMODE0
GND
Table 5.4. Header J4
Description
Header J4 Pin 1
Header J4 Pin2
Header J4 Pin 3
FX3 Boot Selection
VIO
PMODE1
GND
Table 5.5. Header J5
Description
Header J5 Pin 1
Header J5 Pin2
Header J5 Pin 3
FX3 Boot Selection
VIO
PMODE2
GND

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal. All other brand or product names are
trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02016-1.0 11
6. Ordering Information
Please visit www.latticesemi.com/boards for the latest ordering information.
Table 6.1. Reference Part Number
Description
Ordering Part Number
USB3-GbE VIP IO Board
USB3-VIP-EVN

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
12 FPGA-EB-02016-1.0
References
For more information, refer to the following documents:
Lattice Embedded Vision Development Kit User Guide (FPGA-UG-02015)
ECP5 VIP Processing Board (FPGA-EB-02001)
Technical Support Assistance
Submit a technical support case through www.latticesemi.com/techsupport.

1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 4
VIP GbE_USB3
*. *
4/11/2018 11:36:15 PM
D:\Backup\VINOD\JOBS\JOBS_2018\LATTICE_SEMICONDUCTOR\USB3-GbE VIP IO Board\OUTPUTS\041218\GbE_USB3 (4-11-2018 11-31-10 PM)\VIP_GbE_USB3.S chDoc
Title
Size: Number:
Date:
File:
Revision:
Sheet of
Time:
A3
VIP GbE & USB3 Board
Page Title
1
2
3
4
Title, Index, Block Diagram
Gigabit Ethernet PHY and RJ45
connector
Connectors to VIP board stack
USB3 FX3 bridge and connector
1V2,5V generated locally
USB3 interface
VIP connectors
(Pg4)
(Pg3)
GbE interface
(Pg2)
12,2V5,3V3 from VIP stack
USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02016-1.0 13
Appendix A. USB3-GbE VIP I/O Board DisplayPort Schematics
Figure A.1. Block Diagram

1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
2 4
VIP GbE_USB3, GbE PHY and RJ45
*. *
4/11/2018 11:36:15 PM
D:\Backup\VINOD\JOBS\JOBS_2018\LATTICE_SEMICONDUCTOR\USB3-GbE VIP IO Board\OUTPUTS\041218\GbE_USB3 (4-11-2018 11-31-10 PM)\GbE.SchDoc
Title
Size: Number:
Date:
File:
Revision:
Sheet of
Time:
A3
GNDGND
GND
MDIO_CLK
MDIO_DATA
GND
GND
SYS_RST_N
RGMII_TXCLK
RGMII_TXCTRL
RGMII_TXD0
RGMII_TXD1
RGMII_TXD2
RGMII_TXD3
RGMII_RXD0
RGMII_RXD1
RGMII_RXD2
RGMII_RXD3
RGMII_RXCLK
RGMII_RXCTRL
GND
VIO
VIO
V2R5_PHY
V2R5_PHY
V1R1
V1R1
Place one 1000pF cap close to each supply pin of the PHY
GND
GND GND GND
VIO
25 MHz
1 2
Y1 ABM3-25
RESERVED
1
RESERVED
7
RESERVED
9
RESERVED
16
TD_P_A 2
TD_M_A 3
TD_P_B 5
TD_M_B 6
TD_P_C 10
TD_M_C 11
TD_M_D 14
TD_P_D 13
RBIAS 15
TX_CLK
30
TX_D7
31 TX_D6
32 TX_D5
33 TX_D4
34 TX_D3
35 TX_D2
36 TX_D1
37 TX_D0
38
TX_ER
39
GTX_CLK
40
RX_CLK
43
RX_D0
44
RX_D1
45
RX_D2
46
RX_D3
47
RX_D4/GPIO
48
RX_D5/GPIO
49
RX_D6/GPIO
50
RX_D7/GPIO
51
TX_EN/TX_CTRL
52
RX_DV/RX_CTRL
53
RX_ER/GPIO
54
COL/GPIO
55
CRS/GPIO
56
MDC 20
MDIO 21
INT/PWDN 60
RESET 59
XI 19
XO 18
CLK_OUT 22
JTAG_CLK 25
JTAG_TDO 26
JTAG_TDI 28
JTAG_TRSTN 24
LED_2 61
LED_1 62
LED_0 63
VDDIO
23
VDDIO
41
VDDIO
57
VDDA1P8 17
VDDA1P8 64
VDDA2P5
4
VDDA2P5
12
VDD1P1 8
VDD1P1 29
VDD1P1 42
VDD1P1 58
GND 0
JTAG_TMS 27
U3
DP83867
S1S2
TRD1+
TRD1-
TRD2+
TRD2-
TRD3+
TRD3-
TRD4+
TRD4-
VCC
GND
J3
RJ45
402 Ohm
R15
402 Ohm
R6
GND
GND
4.7K Ohm
R16
4.7K Ohm
R11
1M Ohm
R17
22 Ohm
R10
11K Ohm
R7
27pF
C8
27pF
C9
10nF
C25
10nF
C17
10nF
C11
10uF
C10
10uF
C16
10uF
C24
560 Ohm
R12
560 Ohm
R13
560 Ohm
R14
GND
GND
GND
L3
MPZ2012S601A
L4
MPZ2012S601A
GND
Activity Speed 1000 Link up
12
D5
LED G
12
D4
LED Y
12
D6
LED B
OUT_1 1
OUT_2 2
SET 3
IN_7
5IN_8
6
VCtrl
4
Pad 7
U4
LT3085
GND
GND
V3R3
10uF
C35
100nF
C36
110K Ohm
R19
L6
MPZ2012S601A
1uF
C34
1uF
C7
TP6
TP
TP7
TP
MDIO_DAT
MDIO_DAT
MDIO_CLK
MDIO_CLK
TP8
TP
2.2K Ohm
R18
VIO
GND
GND
1uF
C18
1uF
C19
1uF
C20
1uF
C12
1uF
C13
1uF
C26
1uF
C27
1uF
C28
1uF
C29
100nF
C14
100nF
C15
100nF
C23
100nF
C21
100nF
C22
100nF
C30
100nF
C31
100nF
C32
100nF
C33
5.76K Ohm
R8
2.49K Ohm
R9
VIO
I2C_SCL
I2C_SDA
GND
VIO
VIO
GND
100nF
C61
A0
1
SDA 5
A2
3A1
2WP 7
GND 4
SCL 6 VCC
8
U13
AT24MAC402
I2C address 0xAE/0xAF and 0xBE/0xBF
4.7K Ohm
R41
4.7K Ohm
R40
4.7K Ohm
R26
0 Ohm
R44
0 Ohm
R43
0 Ohm
R42
GND
L5
MPZ2012S601A
V2R5
CLK_OUT
22 Ohm
R52
3
1
2
Q2
MMBT2222LT1G
12
D8
LED G
GND
10K Ohm
R51
V1R1
470
R50
V3R3
TRD2P
TRD2N
TRD3P
TRD3N
TRD4P
TRD4N
TRD1N
TRD1P
PIC701
PIC702
COC7
PIC801
PIC802
COC8
PIC901
PIC902
COC9
PIC1001
PIC1002
COC10
PIC1101
PIC1102
COC11
PIC1201
PIC1202
COC12
PIC1301
PIC1302
COC13
PIC1401
PIC1402
COC14
PIC1501
PIC1502
COC15
PIC1601
PIC1602
COC16
PIC1701
PIC1702
COC17
PIC1801
PIC1802
COC18
PIC1901
PIC1902
COC19
PIC2001
PIC2002
COC20
PIC2101
PIC2102
COC21
PIC2201
PIC2202
COC22
PIC2301
PIC2302
COC23
PIC2401
PIC2402
COC24
PIC2501
PIC2502
COC25
PIC2601
PIC2602
COC26
PIC2701
PIC2702
COC27
PIC2801
PIC2802
COC28
PIC2901
PIC2902
COC29
PIC3001
PIC3002
COC30
PIC3101
PIC3102
COC31
PIC3201
PIC3202
COC32
PIC3301
PIC3302
COC33
PIC3401
PIC3402
COC34
PIC3501
PIC3502
COC35
PIC3601
PIC3602
COC36
PIC6101
PIC6102
COC61
PID401
PID402
COD4
PID501
PID502
COD5
PID601
PID602
COD6
PID801
PID802
COD8
PIJ301
PIJ302
PIJ303
PIJ304
PIJ305
PIJ306
PIJ307
PIJ308
PIJ309
PIJ3010
PIJ30S1
PIJ30S2
COJ3
PIL301 PIL302
COL3
PIL401 PIL402
COL4
PIL501 PIL502
COL5
PIL601 PIL602
COL6
PIQ201
PIQ202
PIQ203
COQ2
PIR601PIR602
COR6
PIR701 PIR702
COR7
PIR801 PIR802
COR8
PIR901PIR902
COR9
PIR1001 PIR1002
COR10
PIR1101 PIR1102
COR11
PIR1201
PIR1202
COR12
PIR1301
PIR1302
COR13
PIR1401
PIR1402
COR14
PIR1501
PIR1502
COR15
PIR1601 PIR1602
COR16
PIR1701 PIR1702
COR17
PIR1801
PIR1802
COR18
PIR1901
PIR1902
COR19
PIR2601
PIR2602
COR26
PIR4001
PIR4002
COR40
PIR4101
PIR4102
COR41
PIR4201
PIR4202
COR42
PIR4301
PIR4302
COR43
PIR4401
PIR4402
COR44
PIR5001
PIR5002
COR50
PIR5101PIR5102
COR51
PIR5201 PIR5202
COR52
PITP601
COTP6
PITP701
COTP7
PITP801
COTP8
PIU300
PIU301
PIU302
PIU303
PIU304
PIU305
PIU306
PIU307
PIU308
PIU309
PIU3010
PIU3011
PIU3012
PIU3013
PIU3014
PIU3015
PIU3016
PIU3017
PIU3018
PIU3019
PIU3020
PIU3021
PIU3022
PIU3023
PIU3024
PIU3025
PIU3026
PIU3027
PIU3028
PIU3029
PIU3030
PIU3031
PIU3032
PIU3033
PIU3034
PIU3035
PIU3036
PIU3037
PIU3038
PIU3039
PIU3040
PIU3041
PIU3042
PIU3043
PIU3044
PIU3045
PIU3046
PIU3047
PIU3048
PIU3049
PIU3050
PIU3051
PIU3052
PIU3053
PIU3054
PIU3055
PIU3056
PIU3057
PIU3058
PIU3059
PIU3060
PIU3061
PIU3062
PIU3063
PIU3064
COU3
PIU401
PIU402
PIU403PIU404
PIU405
PIU406
PIU407
COU4
PIU1301
PIU1302
PIU1303 PIU1304
PIU1305
PIU1306
PIU1307
PIU1308
COU13
PIY101 PIY102
COY1
PIR5202
PIC702
PIC802 PIC902
PIC1002 PIC1102 PIC1201 PIC1301 PIC1401 PIC1501 PIC1602 PIC1702 PIC1801 PIC1901 PIC2001 PIC2101 PIC2201 PIC2301
PIC2402 PIC2502 PIC2601 PIC2701 PIC2801 PIC2901 PIC3001 PIC3101 PIC3201 PIC3301
PIC3402 PIC3502
PIC3601
PIC6102
PID402 PID502 PID602
PIJ3010
PIL302
PIL402
PIQ202
PIR602
PIR702
PIR901
PIR1102
PIR1502
PIR1902
PIR4201 PIR4301 PIR4401
PIU300
PIU3031
PIU3032
PIU3033
PIU3034
PIU3039
PIU1304
PIU1307
PIU1306
NLI2C0SCL
PIU1305
NLI2C0SDA
PIR1501
PITP701
PIU3020
NLMDIO0CLK
PIR1801
PITP601
PIU3021
NLMDIO0DAT
PIC701
PIJ309
PIC801
PIR1701
PIU3018
PIY101
PIC901
PIR1702
PIU3019
PIY102
PIC3501
PIL601
PIU401
PIU402
PIU407
PIC3602PIR1901
PIU403
PID401
PIR1202
PID501
PIR1302
PID601
PIR1402
PID801
PIR5001
PID802
PIQ203
PIJ30S1
PIL301
PIJ30S2
PIL401
PIQ201 PIR5101
PIR701 PIU3015
PIR1002 PIU3043 PIR1101 PIU3024
PIR1201
PIU3061
PIR1301
PIU3062
PIR1401
PIU3063
PIR1601 PIU3060
PIR2601
PIR4202
PIU1303
PIR4001
PIR4302
PIU1302
PIR4101
PIR4402
PIU1301
PIR5201 PIU3022
PIU301
PIU307
PIU309
PIU3016
PIU3017
PIU3025
PIU3026
PIU3027
PIU3028
PIU3030
PIU3048
PIU3049
PIU3050
PIU3051
PIU3054
PIU3055
PIU3056
PIU3064
PIR1001
PIR801 PIR902
PIU3053
PIU3044
PIU3045
PIU3046
PIU3047
PIR601
PIU3040
PIU3052
PIU3038
PIU3037
PIU3036
PIU3035
PIU3059
PIJ302PIU303
NLTRD1N
PIJ301PIU302
NLTRD1P
PIJ304
PIU306
NLTRD2N
PIJ303
PIU305
NLTRD2P
PIJ306
PIU3011
NLTRD3N
PIJ305
PIU3010
NLTRD3P
PIJ308
PIU3014
NLTRD4N
PIJ307
PIU3013
NLTRD4P
PIC2401 PIC2501 PIC2602 PIC2702 PIC2802 PIC2902 PIC3002 PIC3102 PIC3202 PIC3302
PIL602
PIR5102
PITP801
PIU308
PIU3029
PIU3042
PIU3058
PIL502
PIC1001 PIC1101 PIC1202 PIC1302 PIC1402 PIC1502
PIL501
PIU304
PIU3012
PIC3401
PIR5002
PIU404
PIU405
PIU406
PIC1601 PIC1701 PIC1802 PIC1902 PIC2002 PIC2102 PIC2202 PIC2302
PIC6101
PIR802
PIR1602
PIR1802
PIR2602 PIR4002 PIR4102
PIU3023
PIU3041
PIU3057
PIU1308
USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
14 FPGA-EB-02016-1.0
Figure A.2. VIP GbE USB3, GbE Phy and RJ45

1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
3 4
VIP GbE_USB3, USB3 interface
*. *
4/11/2018 11:36:16 PM
D:\Backup\VINOD\JOBS\JOBS_2018\LATTICE_SEMICONDUCTOR\USB3-GbE VIP IO Board\OUTPUTS\041218\GbE_USB3 (4-11-2018 11-31-10 PM)\USB3.SchDoc
Title
Size: Number:
Date:
File:
Revision:
Sheet of
Time:
A3
GPIO8
2
GPIO9 3
GND 4
GPIO10 5
GPIO11 6
GPIO12 7
GPIO13 8
GPIO14 9
GPIO15 10
SUSPEND 11
WAKEUP 12
GPIO16 13
USBDP
14 USBDM
15
VCCD
16 GND 17
RESET# 18
VBUS
19 GND 20
GPIO17 21
GPIO18 22
AGND 24
GPIO5
30
GPIO6
31
GPIO7
32
EP 33
VDDD
1
VDDD
23
GPIO1
26
GPIO2
27
GPIO3
28
GPIO4
29
GPIO0
25
U9
CY7C65215
VBUS 1
D- 2
D+ 3
ID 4
GND 5
MP1
6
MP2
7
MP3
8
MP4
9
J5
USB2
DQ0 F10
DQ1 F9
DQ2 F7
DQ3 G10
DQ4 G9
DQ5 F8
DQ6 H10
DQ7 H9
DQ8 J10
DQ9 J9
DQ10 K11
DQ11 L10
DQ12 K10
DQ13 K9
DQ14 J8
DQ15 G8
PLCK_CLK
J6
CTL0_SLCS
K8
CTL1_SLWR
K7
CTL2_SLOE
J7
CTL3_SLRD
H7
CTL4_FLAGA
G7
CTL5_FLAGB
G6
CTL6_GPIO
K6
CTL7_PKTEND
H8
CTL8_GPIO
G5
CTL9_GPIO
H6
CTL10_GPIO
K5
CTL11_A1
J5
CTL12_A0
H5
INT_CTL15
L8 DQ16 K2
DQ17 J4
DQ18 K1
DQ19 J2
DQ20 J3
DQ21 J1
DQ22 H2
DQ23 H3
DQ24 F4
DQ25 G2
DQ26 G3
DQ27 F3
DQ28 F5
DQ29 E1
DQ30 E5
DQ31 E4
GPIO
F2
GPIO_I2SCLK
D1
GPIO_I2SSD
D2
GPIO_I2SWS
D3
SPISCK_UARTRTS_GPIO
D4
SPISSN_UARTCTS_GPIO
C1
SPIMISO_UARTTX_GPIO
C2
SPIMOSI_UARTRX_GPIO
D5
GPIO_I2SMCLK
C4
RESET
C5
I2C_SCL
D9
I2C_SDA
D10
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V01
V02
V02
V02
V02
V02
V02
V02
V02
V02
V02
V02
V02
V02 V03
V03
V03
V03
V03
V03
V03
V04
V04
V04
V04
V04
CVD
V05
V05
U5A
CYUSB3014
PMODE0
G4
PMODE1
H4
PMODE2
L4
SSRX-
A3
SSRX+
A4
SSTX-
A6
SSTX+
A5
R_usb3
B3 R_usb2
C8
OTG_ID
C9
D+
A9
D-
A10
FSLC0
B2
FSLC1
B4
FSLC2
E6
CLKIN
D7
CLKIN_32
D6
XTALIN
C6
XTALOUT
C7
TDI
E7
TDO
C10
TRST
B11
TMS
E8
TCK
F6
O60_CHGDET
D11
VBATT E10
VDD B10
VDD C3
VDD E9
VDD F11
VDD J11
VDD H1
VDD L7
VDD L5
VBUS E11
AVDD A7
CVDDQ B6
U3TXVDDQ B5
U3RXVDDQ A2
VIO1 H11
VIO1 L9
VIO2 F1
VIO3 E3
VIO4 B1
VIO5 C11
U3VSSQ A1
AVSS B7
VSS D8
VSS E2
VSS G1
VSS G11
VSS L1
VSS L6
VSS L11
VSS B8
VSS B9
VSS K4
VSS L3
VSS K3
VSS L2
VSS A8
NC
A11
V01
V01
V01
U3R
U3R
U3T
U3T
U3T
VBUS
VBUS
VBUS
VBUS
CVD
CVD
CVD
CVD
CVD
AVD
AVD
V05
V05
V05
V05
V05
V05
U5B
CYUSB3014
GND
V1R2
V1R2
GND
GND
AVDD
AVDD
L7
MPZ2012S601A
GND
L8
MPZ2012S601A
GND
V1R2
L9
MPZ2012S601A
GND
V1R2
U3TXVDDQ
U3TXVDDQ
U3RXVDDQ
U3RXVDDQ
V1R2
FX3/ECP5 INTERFACE
VIO
VIO
GND
USB_D_N
USB_D_P
USB_OTG
USB_SSTX_N
USB_SSTX_P
USB_SSRX_P
USB_SSRX_N
USB3 CONNECTOR
FPGA BOOT INTERFACE
FX3_TDI
FX3_TDO
FX3_TMS
FX3_TCK
FX3_TRST_N
BOOT SELECTION
EN
1
GND
2OUT 3
VDD 4
U7
OSC_32768
VIO
CLK_32768
CLK_32768
VIO
GND
GND
MSTCLK_FX3
EN
1
GND
2OUT 3
VDD 4
U6
OSC_19M2
GND
GND
VIO
MSTCLK_FX3
VIO
GND
V5
V5
GND
FX3_TDI
FX3_TDO
FX3_TMS
FX3_TCK
FX3_TRST_N
10nF
C57
10nF
C58
10nF
C59
10nF
C60
10nF
C70
10nF
C66
10nF
C67
100nF
C40
100nF
C43
100nF
C46
100nF
C50
100nF
C56
100nF
C55
100nF
C54
100nF
C53
100nF
C63
100nF
C69
100nF
C71
10uF
C45
10uF
C44
10uF
C48
10uF
C49
10uF
C51
10uF
C52
10uF
C64
10uF
C68
4.7uF
C39
4.7uF
C42
4.7K Ohm
R23
402 Ohm
R28
100nF
C41
100nF
C47
100nF
C74
100nF
C75
402 Ohm
R20
200 Ohm
R34
6.04K Ohm
R33
FX3_D0
FX3_D1
FX3_D2
FX3_D3
FX3_D4
FX3_D5
FX3_D6
FX3_D7
FX3_D8
FX3_D9
FX3_D10
FX3_D11
FX3_D12
FX3_D13
FX3_D14
FX3_D15
FX3_D16
FX3_D17
FX3_D18
FX3_D19
FX3_D20
FX3_D21
FX3_D22
FX3_D23
FX3_PCLK
SYS_RST_N
FX3_SLCS_N
FX3_SLWR_N
FX3_SLOE_N
FX3_SLRD_N
FX3_I2C_SCL
FX3_I2C_SDA
GND
GND
GND
L11
MPZ2012S601A
VBUS3
VBUS2
1uF
C76
GND VBUS2
VIO
GND
VBUS2
4.7K Ohm
R25
10K Ohm
R27
VIO
GND
100nF
C80
4.7uF
C79
VBUS2
GND
100nF
C78
4.7uF
C77
VBUS3
GND
100nF
C38
4.7uF
C37
FX3_FLAG_A
FX3_FLAG_B
FX3_PCKTEND_N
FX3_A1
FX3_A0
FX3_SPI_SCK
FX3_SPI_CS_N
FX3_SPI_MISO
FX3_SPI_MOSI
FX3_FPGA_DONE
FX3_FPGA_INIT_N
IN/OUT1 1
IN/OUT2 2
GND 3
IN/OUT3 4
IN/OUT4 5 IN/OUT5
6IN/OUT6
7
IN/OUT7
9IN/OUT8
10
GND
8
U10
SP3010-04UTG
GND
GND
USB_D_N
USB_D_P
USB_OTG
VBUS3
USB_SSTX_N
USB_SSTX_P
USB_SSRX_P
USB_SSRX_N
100nF
C72
L10
MPZ2012S601A
JTAG FOR FX3 VIA USB2
VIO
560 Ohm
R21
FX3 user LED
12
D7
LED B
1 2
3 4
SW1
FX3 user switch 10K Ohm
R22
VIO
FX3_SYNC
IN/OUT1 1
IN/OUT2 2
GND 3
IN/OUT3 4
IN/OUT4 5 IN/OUT5
6IN/OUT6
7
IN/OUT7
9IN/OUT8
10
GND
8
U8
SP3010-04UTG
1
2
3
P3
Header 3 10K Ohm
R31
PMODE0
PMODE1
PMODE2
GND
VIO
PMODE0
1
2
3
P4
Header 3 10K Ohm
R32
GND
VIO
PMODE1
1
2
3
P5
Header 3 10K Ohm
R35
GND
VIO
PMODE2
DU
1
SDA 5
E2
3DU
2WC 7
VSS 4
SCL 6 VCC
8
U11
M24M02
I2C_SCL
I2C_SCL
I2C_SDA
I2C_SDA
4.7K Ohm
R29
4.7K Ohm
R30
GND
VIO
VIO
GND
100nF
C81
VIO VIO
(VIO interface voltage)
USB3 GbE => FPGA VCCIO
VIO
GND
100nF
C73
1 2 3
P2
Header 3
VIO
V2R5V3R3
10uF
C62
VIO
100nF
C65
4.7K Ohm
R24
VIO
IN/OUT1 1
IN/OUT2 2
GND 3
IN/OUT3 4
IN/OUT4 5 IN/OUT5
6IN/OUT6
7
IN/OUT7
9IN/OUT8
10
GND
8
U12
SP3010-04UTG
GND
USB2_DP
USB2_DP
USB2_DM
USB2_DM
+5V
1
D-
2
D+
3
OTG
4
GND1
5
SSTX-
6
SSTX+
7
GND2
8
SSRX-
9
SSRX+
10
SHLD
0
J4
USB3
0 Ohm
R39
0 Ohm
R38
0 Ohm
R37
0 Ohm
R36
UART_TX
UART_RX
I2C_SCL
I2C_SDA
UART_TX
UART_RX
FX3_D24
FX3_D25
FX3_D26
FX3_D27
FX3_D28
FX3_D29
FX3_D30
FX3_D31
I2C address 0xA0/0xA1 and 0xB0/0xB1
4.7K Ohm
R45
0 Ohm
R46
GND
USB_D_N
USB_D_P
USB_OTG
GND
USB_SSTX_N
USB_SSTX_P
USB_SSRX_P
USB_SSRX_N
GND
GND
USB2_DP
USB2_DM
PIC3701
PIC3702
COC37
PIC3801
PIC3802
COC38
PIC3901
PIC3902
COC39
PIC4001
PIC4002
COC40
PIC4101
PIC4102
COC41
PIC4201
PIC4202
COC42
PIC4301
PIC4302
COC43
PIC4401
PIC4402
COC44
PIC4501
PIC4502
COC45
PIC4601
PIC4602
COC46
PIC4701
PIC4702
COC47
PIC4801
PIC4802
COC48
PIC4901
PIC4902
COC49
PIC5001
PIC5002
COC50
PIC5101
PIC5102
COC51
PIC5201
PIC5202
COC52
PIC5301
PIC5302
COC53
PIC5401
PIC5402
COC54
PIC5501
PIC5502
COC55
PIC5601
PIC5602
COC56
PIC5701
PIC5702
COC57
PIC5801
PIC5802
COC58
PIC5901
PIC5902
COC59
PIC6001
PIC6002
COC60
PIC6201
PIC6202
COC62
PIC6301
PIC6302
COC63
PIC6401
PIC6402
COC64
PIC6501
PIC6502
COC65
PIC6601
PIC6602
COC66
PIC6701
PIC6702
COC67
PIC6801
PIC6802
COC68
PIC6901
PIC6902
COC69
PIC7001
PIC7002
COC70
PIC7101
PIC7102
COC71
PIC7201
PIC7202
COC72
PIC7301
PIC7302
COC73
PIC7401 PIC7402
COC74
PIC7501 PIC7502
COC75
PIC7601
PIC7602
COC76
PIC7701
PIC7702
COC77
PIC7801
PIC7802
COC78
PIC7901
PIC7902
COC79
PIC8001
PIC8002
COC80
PIC8101
PIC8102
COC81
PID701
PID702
COD7
PIJ400
PIJ401
PIJ402
PIJ403
PIJ404
PIJ405
PIJ406
PIJ407
PIJ408
PIJ409
PIJ4010
COJ4
PIJ501
PIJ502
PIJ503
PIJ504
PIJ505
PIJ506
PIJ507
PIJ508
PIJ509
COJ5
PIL701 PIL702
COL7
PIL801 PIL802
COL8
PIL901 PIL902
COL9
PIL1001
PIL1002
COL10
PIL1101
PIL1102
COL11
PIP201PIP202PIP203
COP2
PIP301
PIP302
PIP303
COP3
PIP401
PIP402
PIP403
COP4
PIP501
PIP502
PIP503
COP5
PIR2001PIR2002
COR20
PIR2101
PIR2102
COR21
PIR2201 PIR2202
COR22
PIR2301 PIR2302
COR23
PIR2401
PIR2402
COR24
PIR2501
PIR2502
COR25
PIR2701
PIR2702
COR27
PIR2801 PIR2802
COR28
PIR2901
PIR2902
COR29
PIR3001
PIR3002
COR30
PIR3101 PIR3102
COR31
PIR3201 PIR3202
COR32
PIR3301
PIR3302
COR33
PIR3401
PIR3402
COR34
PIR3501 PIR3502
COR35
PIR3601PIR3602
COR36
PIR3701PIR3702
COR37
PIR3801PIR3802
COR38
PIR3901PIR3902
COR39
PIR4501
PIR4502
COR45
PIR4601
PIR4602
COR46
PISW101 PISW102
PISW103 PISW104
COSW1
PIU50C1
PIU50C2
PIU50C4
PIU50C5
PIU50D1
PIU50D2
PIU50D3
PIU50D4
PIU50D5
PIU50D9
PIU50D10
PIU50E1
PIU50E4
PIU50E5
PIU50F2
PIU50F3
PIU50F4
PIU50F5
PIU50F7
PIU50F8
PIU50F9
PIU50F10
PIU50G2
PIU50G3
PIU50G5
PIU50G6
PIU50G7
PIU50G8
PIU50G9
PIU50G10
PIU50H2
PIU50H3
PIU50H5
PIU50H6
PIU50H7
PIU50H8
PIU50H9
PIU50H10
PIU50J1
PIU50J2
PIU50J3
PIU50J4
PIU50J5
PIU50J6
PIU50J7
PIU50J8
PIU50J9
PIU50J10
PIU50K1
PIU50K2
PIU50K5
PIU50K6
PIU50K7
PIU50K8
PIU50K9
PIU50K10
PIU50K11
PIU50L8
PIU50L10
COU5A
PIU50A1
PIU50A2 PIU50A3
PIU50A4
PIU50A5
PIU50A6
PIU50A7
PIU50A8
PIU50A9
PIU50A10
PIU50A11
PIU50B1
PIU50B2
PIU50B3
PIU50B4
PIU50B5
PIU50B6
PIU50B7
PIU50B8
PIU50B9
PIU50B10
PIU50B11
PIU50C3
PIU50C6
PIU50C7
PIU50C8
PIU50C9
PIU50C10
PIU50C11
PIU50D6
PIU50D7
PIU50D8
PIU50D11 PIU50E2
PIU50E3
PIU50E6
PIU50E7
PIU50E8
PIU50E9
PIU50E10
PIU50E11
PIU50F1
PIU50F6
PIU50F11
PIU50G1
PIU50G4
PIU50G11
PIU50H1
PIU50H4
PIU50H11
PIU50J11
PIU50K3
PIU50K4
PIU50L1
PIU50L2
PIU50L3
PIU50L4
PIU50L5
PIU50L6
PIU50L7
PIU50L9
PIU50L11
COU5B
PIU601
PIU602 PIU603
PIU604
COU6
PIU701
PIU702 PIU703
PIU704
COU7
PIU801
PIU802
PIU803
PIU804
PIU805PIU806
PIU807
PIU808
PIU809
PIU8010
COU8
PIU901
PIU902
PIU903
PIU904
PIU905
PIU906
PIU907
PIU908
PIU909
PIU9010
PIU9011
PIU9012
PIU9013
PIU9014
PIU9015
PIU9016 PIU9017
PIU9018
PIU9019 PIU9020
PIU9021
PIU9022
PIU9023
PIU9024
PIU9025
PIU9026
PIU9027
PIU9028
PIU9029
PIU9030
PIU9031
PIU9032
PIU9033
COU9
PIU1001
PIU1002
PIU1003
PIU1004
PIU1005PIU1006
PIU1007
PIU1008
PIU1009
PIU10010
COU10
PIU1101
PIU1102
PIU1103 PIU1104
PIU1105
PIU1106
PIU1107
PIU1108
COU11
PIU1201
PIU1202
PIU1203
PIU1204
PIU1205PIU1206
PIU1207
PIU1208
PIU1209
PIU12010
COU12
PIC4201 PIC4301
PIL702
PIU50A7
PIU50D6
PIU703
NLCLK032768
PIU50H5
PIU50J5
PIU50F10
PIU50F9
PIU50F7
PIU50G10
PIU50G9
PIU50F8
PIU50H10
PIU50H9
PIU50J10
PIU50J9
PIU50K11
PIU50L10
PIU50K10
PIU50K9
PIU50J8
PIU50G8
PIU50K2
PIU50J4
PIU50K1
PIU50J2
PIU50J3
PIU50J1
PIU50H2
PIU50H3
PIU50F4
PIU50G2
PIU50G3
PIU50F3
PIU50F5
PIU50E1
PIU50E5
PIU50E4
PIU50G7
PIU50G6
PIU50D1
PIU50D2
PIU50H8
PIR2001
PIU50J6
PIU50K8
PIU50J7
PIU50H7
PIU50K7
PIU50C1
PIU50C4
PIU50D3
PIU50D4
PIU50G5
PIR2802 PIU50F6
PIU908
NLFX30TCK
PIU50E7
PIU906
NLFX30TDI
PIU50C10
PIU905
NLFX30TDO
PIU50E8
PIU907
NLFX30TMS
PIU50B11
PIU909
NLFX30TRST0N
PIC3702 PIC3802 PIC3902 PIC4002
PIC4102
PIC4202 PIC4302
PIC4402 PIC4501 PIC4602
PIC4701
PIC4801 PIC4902 PIC5002
PIC5101 PIC5202 PIC5302 PIC5402 PIC5501 PIC5602 PIC5701 PIC5802 PIC5901 PIC6002
PIC6201 PIC6302 PIC6401 PIC6502 PIC6601 PIC6702 PIC6802 PIC6901 PIC7002 PIC7102
PIC7202 PIC7302
PIC7602
PIC7701 PIC7802 PIC7901 PIC8002
PIC8102
PIJ405
PIJ408
PIJ505
PIL1001
PIL1101
PIP303
PIP403
PIP503
PIR2002
PIR2701
PIR2801
PIR3302 PIR3402PIR4601
PISW101
PISW103
PIU50A1
PIU50A8
PIU50B2
PIU50B4
PIU50B7
PIU50B8
PIU50B9
PIU50D8
PIU50E2
PIU50G1
PIU50G11
PIU50K3
PIU50K4
PIU50L1
PIU50L2
PIU50L3
PIU50L6
PIU50L11
PIU602
PIU702
PIU803PIU808
PIU904
PIU9017
PIU9020
PIU9024
PIU9033
PIU1003PIU1008
PIU1104
PIU1107
PIU1203PIU1208
PIR2901
PIR3702
PIU50D9
PIU1106
NLI2C0SCL
PIR3002
PIR3602
PIU50D10
PIU1105
NLI2C0SDA
PIU50D7
PIU603
NLMSTCLK0FX3
PIC7201
PIJ400
PIL1002
PIC7402
PIU50A6
PIC7502
PIU50A5
PIC7601
PIU9016
PID701
PIR2102
PID702
PIU50K6
PIJ504
PIJ506
PIJ507
PIJ508
PIJ509
PIL1102
PIP301 PIR3101
PIP401 PIR3201
PIP501 PIR3501
PIR2201
PISW102
PISW104
PIU50K5
PIR2302 PIU50E6
PIR2401
PIU9012
PIR2501
PIR2702
PIU9018
PIR3301
PIU50C8
PIR3401
PIU50B3
PIR3601 PIU9029
PIR3701 PIU9028
PIR3801 PIU9030
PIR3901 PIU902
PIR4501
PIR4602
PIU1103 PIU50A11
PIU50C6
PIU50C7
PIU50D11
PIU50F2
PIU50H6
PIU50L8
PIU804PIU807
PIU903
PIU9010
PIU9011
PIU9013
PIU9021
PIU9022
PIU9025
PIU9026
PIU9027
PIU9031
PIU9032
PIU1101
PIU1102
PIU1204
PIU1205PIU1206
PIU1207
PIP302
PIU50G4
NLPMODE0
PIP402
PIU50H4
NLPMODE1
PIP502
PIU50L4
NLPMODE2
PIU50C5
PIC4802 PIC4901 PIC5001
PIL902
PIU50A2
PIC4401 PIC4502 PIC4601
PIL802
PIU50B5
PIR3802
PIU50D5
NLUART0RX
PIR3902
PIU50C2
NLUART0TX
PIJ502 PIU9015
PIU1202PIU1209
NLUSB20DM
PIJ503 PIU9014
PIU1201 PIU12010
NLUSB20DP
PIJ402
PIU50A10
PIU801 PIU8010
NLUSB0D0N
PIJ403
PIU50A9
PIU802PIU809
NLUSB0D0P
PIJ404
PIU50C9
PIU805PIU806
NLUSB0OTG
PIJ409
PIU50A3
PIU1004PIU1007
NLUSB0SSRX0N
PIJ4010
PIU50A4
PIU1005PIU1006
NLUSB0SSRX0P
PIC7401
PIJ406 PIU1001 PIU10010
NLUSB0SSTX0N
PIC7501
PIJ407 PIU1002PIU1009
NLUSB0SSTX0P
PIC5102 PIC5201 PIC5301 PIC5401 PIC5502 PIC5601 PIC5702 PIC5801 PIC5902 PIC6001
PIL701
PIL801
PIL901
PIU50B10
PIU50C3
PIU50E9
PIU50F11
PIU50H1
PIU50J11
PIU50L5
PIU50L7
PIP201PIP203
PIC3901 PIC4001
PIU50E10
PIC7702 PIC7801
PIJ501
PIR2502
PIU9019
PIC3701 PIC3801
PIJ401
PIU50E11
PIC4101
PIC4702
PIC6202 PIC6301 PIC6402 PIC6501 PIC6602 PIC6701 PIC6801 PIC6902 PIC7001 PIC7101
PIC7301
PIC7902 PIC8001
PIC8101
PIP202
PIR2101
PIR2202
PIR2301
PIR2402
PIR2902 PIR3001
PIR3102
PIR3202
PIR3502
PIR4502
PIU50B1
PIU50B6
PIU50C11
PIU50E3
PIU50F1
PIU50H11
PIU50L9
PIU601 PIU604
PIU701 PIU704
PIU901
PIU9023
PIU1108
USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02016-1.0 15
Figure A.3. VIP GbE USB3 Interface

1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
4 4
VIP GbE_USB3, VIP connectors
*. *
4/11/2018 11:36:16 PM
D:\Backup\VINOD\JOBS\JOBS_2018\LATTICE_SEMICONDUCTOR\USB3-GbE VIP IO Board\OUTPUTS\041218\GbE_USB3 (4-11-2018 11-31-10 PM)\Connectors.SchDoc
Title
Size: Number:
Date:
File:
Revision:
Sheet of
Time:
A3
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
J1
ERM5-030-05.0-L-DV-K-TR
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
J2
ERM5-030-05.0-L-DV-K-TR
EXT_3V3
EXT_3V3
EXT_2V5
V2R5
V3R3
EXT_2V5
P12
OUT_1 1
OUT_2 2
SET 3
IN_7
5IN_8
6
VCtrl
4
Pad 7
U1
LT3085
GND
GND
V3R3
10uF
C2
100nF
C5
1uF
C1
OUT_1 1
OUT_2 2
SET 3
IN_7
5IN_8
6
VCtrl
4
Pad 7
U2
LT3085
GND
GND
P12
10uF
C4
100nF
C6
1uF
C3
L2
MPZ2012S601A
L1
MPZ2012S601A
120K Ohm
R4
499K Ohm
R5
RGMII_TXCLK
RGMII_TXCTRL
RGMII_TXD0
RGMII_TXD1
RGMII_TXD2
RGMII_TXD3
RGMII_RXD0
RGMII_RXD1
RGMII_RXD2
RGMII_RXD3
RGMII_RXCLK
RGMII_RXCTRL
MDIO_CLK
MDIO_DATA
CLK_OUT
FX3_PCLK
SYS_RST_N
FX3_SLCS_N
FX3_SLWR_N
FX3_SLOE_N
FX3_SLRD_N
FX3_I2C_SCL
FX3_I2C_SDA
FX3_FLAG_A
FX3_FLAG_B
FX3_PCKTEND_N
FX3_A1
FX3_A0
FX3_SPI_SCK
FX3_SPI_CS_N
FX3_SPI_MISO
FX3_SPI_MOSI
FX3_FPGA_DONE
FX3_FPGA_INIT_N
FX3_D0
FX3_D1
FX3_D2
FX3_D3
FX3_D4
FX3_D5
FX3_D6
FX3_D7
FX3_D8
FX3_D9
FX3_D10
FX3_D11
FX3_D12
FX3_D13FX3_D14
FX3_D15
FX3_D16
FX3_D17
FX3_D18
FX3_D19
FX3_D20
FX3_D21
FX3_D22
FX3_D23
3
1
2
Q1
MMBT2222LT1G
V5P12
12
D3
LED G
GND
1k Ohm
R2
GND
12
D2
LED G
12
D1
LED G
2K Ohm
R1
GND
10K Ohm
R3
V1R2
TP5
TP
TP23
TP
TP4
TP
TP22
TP
TP21
TP
FX3_SYNC
H4
Mounting hole
H2
Mounting hole
H3
Mounting hole
H1
Mounting hole
M2
Assembly target
M4
Assembly target
M3
Assembly target
M1
Assembly target
FX3_D24
FX3_D25
FX3_D26
FX3_D27
FX3_D28
FX3_D29
FX3_D30
FX3_D31
TP13
TP
TP12
TP GND
TP1
TP
TP2
TP
TP3
TP
470
R47
V3R3
12
34
SW2
GND 1uF
C82
4.7K Ohm
R48
100
R49
GND
SYS_RST_N
V1R2 V5
VIO
PIC101
PIC102
COC1
PIC201
PIC202
COC2
PIC301
PIC302
COC3
PIC401
PIC402
COC4
PIC501
PIC502
COC5
PIC601
PIC602
COC6
PIC8201
PIC8202
COC82
PID101
PID102
COD1
PID201
PID202
COD2
PID301
PID302
COD3
COH1 COH2
COH3 COH4
PIJ101 PIJ102
PIJ103 PIJ104
PIJ105 PIJ106
PIJ107 PIJ108
PIJ109 PIJ1010
PIJ1011 PIJ1012
PIJ1013 PIJ1014
PIJ1015 PIJ1016
PIJ1017 PIJ1018
PIJ1019 PIJ1020
PIJ1021 PIJ1022
PIJ1023 PIJ1024
PIJ1025 PIJ1026
PIJ1027 PIJ1028
PIJ1029 PIJ1030
PIJ1031 PIJ1032
PIJ1033 PIJ1034
PIJ1035 PIJ1036
PIJ1037 PIJ1038
PIJ1039 PIJ1040
PIJ1041 PIJ1042
PIJ1043 PIJ1044
PIJ1045 PIJ1046
PIJ1047 PIJ1048
PIJ1049 PIJ1050
PIJ1051 PIJ1052
PIJ1053 PIJ1054
PIJ1055 PIJ1056
PIJ1057 PIJ1058
PIJ1059 PIJ1060
COJ1
PIJ201 PIJ202
PIJ203 PIJ204
PIJ205 PIJ206
PIJ207 PIJ208
PIJ209 PIJ2010
PIJ2011 PIJ2012
PIJ2013 PIJ2014
PIJ2015 PIJ2016
PIJ2017 PIJ2018
PIJ2019 PIJ2020
PIJ2021 PIJ2022
PIJ2023 PIJ2024
PIJ2025 PIJ2026
PIJ2027 PIJ2028
PIJ2029 PIJ2030
PIJ2031 PIJ2032
PIJ2033 PIJ2034
PIJ2035 PIJ2036
PIJ2037 PIJ2038
PIJ2039 PIJ2040
PIJ2041 PIJ2042
PIJ2043 PIJ2044
PIJ2045 PIJ2046
PIJ2047 PIJ2048
PIJ2049 PIJ2050
PIJ2051 PIJ2052
PIJ2053 PIJ2054
PIJ2055 PIJ2056
PIJ2057 PIJ2058
PIJ2059 PIJ2060
COJ2
PIL101 PIL102
COL1
PIL201 PIL202
COL2
COM1 COM2
COM3 COM4
PIQ101
PIQ102
PIQ103
COQ1
PIR101
PIR102
COR1
PIR201
PIR202
COR2
PIR301 PIR302
COR3
PIR401
PIR402
COR4
PIR501
PIR502
COR5
PIR4701
PIR4702
COR47
PIR4801
PIR4802
COR48
PIR4901 PIR4902
COR49
PISW201PISW202
PISW203PISW204
COSW2
PITP101
COTP1
PITP201
COTP2
PITP301
COTP3
PITP401
COTP4
PITP501
COTP5
PITP1201
COTP12
PITP1301
COTP13
PITP2101
COTP21
PITP2201
COTP22
PITP2301
COTP23
PIU101
PIU102
PIU103PIU104
PIU105
PIU106
PIU107
COU1
PIU201
PIU202
PIU203PIU204
PIU205
PIU206
PIU207
COU2
PIJ103
PIJ2057 PIJ2058
PIJ2059 PIJ2060
PIL201
PIJ201 PIJ202
PIJ203 PIJ204
PIL101
PIJ2025
PIJ2023
PIJ205
PIJ2035
PIJ2037
PIJ206
PIJ207
PIJ2033
PIJ208
PIJ2011
PIJ2010
PIJ2022
PIJ2012
PIJ2016
PIJ2014
PIJ2018 PIJ2017
PIJ209
PIJ1022
PIJ2027
PIJ1023
PIJ1021
PIJ2029
PIJ1017
PIJ1015
PIJ2031
PIJ105
PIJ1011
PIJ1018
PIJ109
PIJ1012
PIJ1032
PIJ2047
PIJ1010
PIJ2041
PIJ2045
PIJ1035
PIJ1037
PIJ1041
PIJ1043
PIJ2013
PIJ2019
PIJ2024
PIJ2043
PIJ2015
PIJ2026
PIJ1033
PIJ1031
PIJ1029
PIJ1027
PIJ1016
PIC102 PIC202 PIC302 PIC402
PIC501 PIC601
PIC8201
PID202 PID302
PIJ101
PIJ107
PIJ1013 PIJ1014
PIJ1019 PIJ1020
PIJ1026
PIJ1034
PIJ1040
PIJ1046
PIJ1052
PIJ1055
PIJ1058
PIJ2020
PIJ2021
PIJ2039 PIJ2040
PIJ2053
PIJ2055 PIJ2056
PIQ102
PIR402 PIR502
PISW202
PISW204
PITP1201 PITP1301
PIJ1030
PIJ1024
PIC502 PIR401
PIU103
PIC602 PIR501
PIU203
PID101
PIR4701
PID102
PIQ103
PID201
PIR102
PID301
PIR202
PIJ1025
PIJ1036
PIJ1038
PIJ1039
PIJ1042
PIJ1044
PIJ1045
PIJ1047 PIJ1048
PIJ1049 PIJ1050
PIJ1051
PIJ1053 PIJ1054
PIJ1056
PIJ1057
PIJ1059 PIJ1060
PIJ2049
PITP101
PIJ2051
PITP201
PIJ2054
PITP301
PIQ101 PIR301
PIR4901 PISW201
PISW203
PIC301
PIJ102
PIJ104
PIJ106
PIJ108
PIR101
PIU204
PIU205
PIU206
PIJ2052
PIJ2028
PIJ2038
PIJ2036
PIJ2034
PIJ2032
PIJ2042
PIJ2030
PIJ2044
PIJ2046
PIJ2048
PIJ2050
PIC8202
PIJ1028
PIR4801
PIR4902
PIC201
PIR302
PITP2301
PIU101
PIU102
PIU107
PIL202
PITP2201
PIC101
PIL102
PIR4702
PITP501
PITP2101
PIU104
PIU105
PIU106
PIC401
PIR201
PITP401
PIU201
PIU202
PIU207
PIR4802
USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
16 FPGA-EB-02016-1.0
Figure A.4. VIP GbE USB3 VIP Connector

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02016-1.0 17
Appendix B. USB3-GbE VIP IO Board Bill of Materials
Item
Reference
Qty
Value
Comments
Part Number
Manufacturer
Description
1
C1,C3,C34
3
1uF
—
CGA3E3X5R1E105M080
AB
TDK Corporation
Cap 1uF 25V ±20% 0603 (1608 Metric)
Thickness 1mm SMD
2
C2,C4,C10,C16,C24,C35,C4
4,C45,C48,C49,C51,C52,C6
2,C64,C68
15
10uF
—
GRJ155R60J106ME11D
Murata
Cap 10uF 6.3V ±20% 0402 (1005
Metric) Thickness 0.6mm SMD
3
C5,C6,C14,C15,C21,C22,C2
3,C30,C31,C32,C33,C36,C3
8,C40,C41,C43,C46,C47,C5
0,C53,C54,C55,C56,C61,C6
3,C65,C69,C71,C72,C73,C7
4,C75,C78,C80,C81
35
100nF
—
C0402C104M9PACTU
Kemet
Cap 100nF 6.3V ±20% 0402 (1005
Metric) Thickness 0.6mm SMD
4
C7,C12,C13,C18,C19,C20,C
26,C27,C28,C29,C76,C82
12
1uF
—
GRM152R60J105ME15
D
Murata
CAP 1uF 6.3V ±20% 0402 (1005 Metric)
Thickness 0.6mm SMD
5
C8,C9
2
27pF
—
GRM1555C1H270GA01
D
Murata
Cap 27pF 10V ±2% 0402 (1005 Metric)
Thickness 0.6mm SMD
6
C11,C17,C25,C57,C58,C59,
C60,C66,C67,C70
10
10nF
—
GRM155R60J103KA01D
Murata
Cap 10nF 6.3V ±10% 0402 (1005
Metric) Thickness 0.6mm SMD
7
C37,C39,C42,C77,C79
5
4.7uF
—
GRM153R60J475ME15
D
Murata
Cap 4.7uF 6.3V ±20% 0402 (1005
Metric) Thickness 0.6mm SMD
8
D1,D2,D3,D5,D8
5
APG1005CGC-T
—
APG1005CGC-T
Kingbright
LED GREEN CLEAR 0402 SMD
9
D4
1
APHHS1005SYCK
—
APHHS1005SYCK
Kingbright
LED YELLOW CLEAR 0402 SMD
10
D6,D7
2
APHHS1005LQBC/
D-V
—
APHHS1005LQBC/D-V
Kingbright
LED BLUE CLEAR SMD
11
H1,H2,H3,H4
4
M HOLE
DNL
—
—
Hole M3 -No component mounted
12
J1,J2
2
ERM5-030-050-L-
DV-K-TR
—
ERM5-030-05.0-L-DV-K-
TR
Samtec Inc
Conn High Speed Edge Rate Terminal
Strip HDR 60 POS 0.5mm Solder ST SMD
T/R -
13
J3
1
7498111001
—
7498111001
Wurth
CONN MAGJACK 1PORT 1000 BASE-T
14
J4
1
GSB443133HR
—
GSB443133HR
Amphenol
USB3.1 MICRO B R/A SMT 30U

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
18 FPGA-EB-02016-1.0
Item
Reference
Qty
Value
Comments
Part Number
Manufacturer
Description
15
J5
1
67503-1020
—
67503-1020
Molex
CONN RECEPT MINIUSB R/A 5POS SMD
16
L1,L2,L3,L4,L5,L6,L7,L8,L9,L
10,L11
11
MPZ2012S601AT0
00
—
MPZ2012S601AT000
TDK
FERRITE BEAD 600 OHM 0805 1LN
17
M1,M2,M3,M4
4
MIRE
DNL
—
—
Assembly target -No component
mounted
18
P2,P3,P4,P5
4
HDR1X3
Regular
100 Mil
Header
—
—
Header, 3-Pin
19
Q1,Q2
2
MMBT2222LT1G
—
MMBT2222LT1G
ON Semiconductor
TRANS NPN 30V 0.6A SOT23
20
R1
1
2K Ohm
—
RC0402FR-072KL
Yageo
2K 0.063W 1% 0402 (1005 Metric) SMD
21
R2
1
1k Ohm
—
RC0402FR-071KL
Yageo
1K 0.063W 1% 0402 (1005 Metric) SMD
22
R3,R22,R31,R32,R35,R51
6
10K Ohm
—
RC0402JR-0710KL
Yageo
10K 0.063W 5% 0402 (1005 Metric)
SMD
23
R4
1
120K Ohm
—
RC0402FR-07120KL
Yageo
120K 0.063W 1% 0402 (1005 Metric)
SMD
24
R5
1
499K Ohm
—
RC0402FR-07499KL
Yageo
499K 0.063W 1% 0402 (1005 Metric)
SMD
25
R6,R15,R20,R28
4
402 Ohm
—
RC0402FR-07402RL
Yageo
402R 0.063W 1% 0402 (1005 Metric)
SMD
26
R7
1
11K Ohm
—
RC0402FR-0711KL
Yageo
11K 0.063W 1% 0402 (1005 Metric)
SMD
27
R8
1
5.76K Ohm
—
RC0402FR-075K76L
Yageo
5.76K 0.063W 1% 0402 (1005 Metric)
SMD
28
R9
1
2.49K Ohm
—
RC0402FR-072K49L
Yageo
2.49K 0.063W 1% 0402 (1005 Metric)
SMD
29
R10,R52
2
22 Ohm
—
RC0402FR-0722RL
Yageo
22R 0.063W 1% 0402 (1005 Metric)
SMD
30
R11,R16,R23,R24,R26,R29,
R30,R40,R41,R45,R48
11
4.7K Ohm
—
RC0402FR-074K7L
Yageo
4K7 0.063W 1% 0402 (1005 Metric)
SMD
31
R12,R13,R14,R21
4
560 Ohm
—
RC0402FR-07560RL
Yageo
560R 0.063W 1% 0402 (1005 Metric)
SMD

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02016-1.0 19
Item
Reference
Qty
Value
Comments
Part Number
Manufacturer
Description
32
R17
1
1M Ohm
—
RC0402FR-071ML
Yageo
1M 0.063W 1% 0402 (1005 Metric)
SMD
33
R18
1
2.2K Ohm
—
RC0402FR-072K2L
Yageo
2.2K 0.063W 1% 0402 (1005 Metric)
SMD
34
R19
1
110K Ohm
—
RC0402FR-07110KL
Yageo
110K 0.063W 1% 0402 (1005 Metric)
SMD
35
R25
1
4.7K Ohm
DNL
RC0402FR-074K7L
Yageo
4K7 0.063W 1% 0402 (1005 Metric)
SMD
36
R27
1
10K Ohm
DNL
RC0402JR-0710KL
Yageo
10K 0.063W 5% 0402 (1005 Metric)
SMD
37
R33
1
6.04K Ohm
—
RC0402FR-076K04L
Yageo
6.04K 0.063W 1% 0402 (1005 Metric)
SMD
38
R34
1
200 Ohm
—
RC0402JR-07200RL
Yageo
200R 0.063W 5% 0402 (1005 Metric)
SMD
39
R36,R37,R38,R39,R42,R43,
R44
7
0 Ohm
DNL
RC0402JR-070RP
Yageo
0 0.063W 1% 0402 (1005 Metric) SMD
40
R46
1
0 Ohm
—
RC0402JR-070RP
Yageo
0 0.063W 1% 0402 (1005 Metric) SMD
41
R47,R50
2
470
—
ERJ-2RKF4700X
Panasonic
RES SMD 470 OHM 1% 1/10W 0402
42
R49
1
100
—
CRCW0402100RFKED
Vishay-Dale
RES, 100, 1%, 0.063 W, 0402
43
SW1,SW2
2
SWPB
—
434153017835
Wurth
Switch PB SPST-NO 0.05A 12V
44
TP1,TP2,TP3,TP4,TP5,TP6,T
P7,TP8,TP12,TP13,TP21,TP
22,TP23
13
TP
DNL
5003
Keystone
Test Point, Orange, 1-Pin THD, RoHS
45
U1,U2,U4
3
LT3085
—
LT3085EDCB#TRMPBF
Linear Technology
IC REG LDO ADJ 0.5A 6DFN
46
U3
1
DP83867
—
DP83867IRPAPR
Texas Instruments
IC ETHERNET PHY 64HTQFP
47
U5
1
CYUSB3014
—
CYUSB3014-BZXI
Cypress
IC ARM9 USB CONTROLLER 121FBGA
48
U6
1
OSC_19M2
—
KC5032A19.2000CM0E
00
Kyocera
Oscillator 19.2MHz - 5x3.2mm package
49
U7
1
OSC_32768
—
ECS-327KE-TR
ECS
Oscillator 32.768KHz - 3.2x2.5mm
package

USB3-GbE VIP I/O Board
Evaluation Board User Guide
© 2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
20 FPGA-EB-02016-1.0
Item
Reference
Qty
Value
Comments
Part Number
Manufacturer
Description
50
U8,U10,U12
3
SP3010-04UTG
—
SP3010-04UTG
Littelfuse
TVS DIODE 6V 12.3V 10UDFN
51
U9
1
CY7C65215
—
CY7C65215-32LTXI
Cypress
IC USB TO SERIAL BRIDGE 32QFN
52
U11
1
M24M02
—
M24M02-DRMN6TP
STMicroelectronics
IC EEPROM 2MBIT 1MHZ 8SO
53
U13
1
AT24MAC402
—
AT24MAC402-SSHM
Microchip
IC EEPROM 2KBIT 1MHZ 8SOIC
54
Y1
1
ABM3-25
—
ABM3-25.000MHZ-D2Y-
T
Abracon
CRYSTAL 25.0000MHZ 18PF SMD
55
USB3-GbE VIP IO BOARD
REVB PCB
1
—
—
305-PD-18-0242
PACTRON
—
