ASC Breakout Board User Guide
EB92 Version 1.0, July 2015

2
ASC Breakout Board
Introduction
Thank you for choosing the Lattice Semiconductor ASC Breakout Board.
This guide describes how to begin using the L-ASC10 (ASC) Breakout Board, an easy-to-use platform for evaluat-
ing and designing with the ASC programmable hardware management expander. This board is designed for use
with a Lattice FPGA evaluation board such as the Platform Manager 2 evaluation board. The board cannot be used
stand-alone as the ASC works with an FPGA to function as a programmable hardware management controller.
The contents of this user guide include a description of the various portions of the evaluation board, the complete
set of schematics and the bill of material for the ASC Breakout Board. The ASC Breakout Board is also known as
the L-ASC10 Evaluation Board.
Features
The ASC Breakout Board features the following on-board components and circuits:
• L-ASC10 (ASC) Hardware Management Expander
• Two Potentiometers for Voltage Monitor Testing
• One Push-Button Switch as GPIO Input
• One 8-bit DIP Switch for I2C Address Selection
• Nine LEDs for GPIO Output
• Two PNP Transistors for Temperature Monitoring
• Jumpers for Reset and Voltage Configuration
• Header for Connection to FPGA Breakout Board
• Footprints for 4 x DC-DC Converters and Components for Trimming Evaluation
• Footprints for 5 V Hot Swap Circuit and 12 V Hot Swap Circuit
• Footprint for 12 V Input DC-DC Converter
The features are described in more detail in the Board Hardware Features.

3
ASC Breakout Board
ASC Breakout Board Photos
Photographs of the top and bottom of ASC Breakout Board are shown in Figure 1 and Figure 2 below. These pho-
tographs show the board with the Hot Swap and Trim circuits populated (which are not populated in the released
version of the breakout board). See Board Hardware Features for more detail on which circuits are populated on
the breakout board. Component location references are relative to the top of the board with the silk screen text in
the readable orientation (as shown in the photo).
Figure 1. ASC Breakout Board - Top View

4
ASC Breakout Board
Figure 2. ASC Breakout Board - Bottom View

5
ASC Breakout Board
Board Hardware Features
The ASC Breakout Board is provided with a limited set of circuits populated. The circuits populated on the breakout
board are described first. The breakout board also includes connections and footprints for evaluating the trimming
and Hot Swap functions of the ASC. These unpopulated circuits are described in the later part of this section.
L-ASC10 (ASC) Device
The L-ASC10 (Analog Sense and Control - 10 rail) is a Hardware Management (Power, Thermal, and Control
Plane Management) Expander designed to be used with Lattice FPGAs to implement the Hardware Management
Control function in a circuit board. The L-ASC10 (referred to as ASC) enables seamless scaling of power supply
voltage and current monitoring, temperature monitoring, sequence and margin control channels. The ASC includes
dedicated interfaces supporting the exchange of monitor signal status and output control signals with these central-
ized hardware management controllers. Up to eight ASC devices can be used to implement a hardware manage-
ment system.
The list below summarizes the hardware features of the ASC used on the breakout board. These features are also
shown in the block diagram in Figure 3. For detailed information on the operation of each feature, see DS1042, L-
ASC10 Data Sheet.
• Voltage Monitors (VMON) – Nine standard channels and one high voltage channel
• Current Monitors (IMON) – One standard voltage and one high voltage
• Temperature Monitors (TMON) – Two external and one internal
• Trim and Margin Circuits (TRIM) – Four channels
• General Purpose I/O (GPIO) – Nine channels
• High Voltage Outputs (HVOUT) – Four channels
• ASC Interface (ASC-I/F) – Connection to main FPGA
•I
2C Interface – A/D Converter measurement interface

6
ASC Breakout Board
Figure 3. ASC Block Diagram
Voltage Monitoring
There are 10 VMON inputs to the analog section of the device (including the HIMONN_HVMON pin). These are
routed to slide potentiometers, board power supplies (not populated), and the on-board Hot Swap circuits (not pop-
ulated).
Most of the voltage monitors on the breakout board have low value series resistors connected between the on-
board components and the voltage monitors. These series resistors are populated so that the on-board voltage
monitor test points can be driven by an off-board source without damaging the on-board components. These series
resistors are not required for a real-world application board.
All voltages can be read out from the A/D converter using I2C. The VMON signal connections and board compo-
nents are described in Table 1. The schematic sheet location for the given components and signals are also listed
(see the Appendix A. Schematics section).
Table 1. Voltage Monitor Components and Signals
Component / Signals Ref. Des. Schematic
Sheet Description
Components Populated on Breakout Board
Slider Potentiometers 
(POT1 and POT2)
R50, R52 5 1 kΩslider pot: provides a variable Voltage from zero
to 3.3 V. Connected to VMON7 and VMON8 of U1
with a 1k series resistor.
Series Resistors R51, R53 5 1 kΩresistor allows the user to safely drive VMON7
and VMON8 test points with an off-board Voltage
source.
Series Resistors R51, R612 270 Ωresistor allows the user to safely drive VMON5
and VMON6 test points with an off-board Voltage
source.
Output Control
Block
ASC
Interface
(ASC-I/F)
Non -
Volatile
Fault Log
Trim & Margin
Control
ADC
ADC
MOSFET &
Digital I/O Drive
Current
Sense
Voltage
Sense
Temperature
Sense
I
2
C
Interface
A
D
C
A
D
C

7
ASC Breakout Board
Components Not Populated on Breakout Board
Series Resistors R231, R3213 270 Ωresistor allows the user to safely drive VMON1
and VMON2 test points with an off-board voltage
source. (Only needed when DCDC1 and DCDC2 are
populated.)
Ground Sense Resistors R241, R3313 100 Ωresistor allows the user to safely drive the
VMON1_GS and VMON2_GS test points with an off-
board voltage source (such as remote load sensing)
without adding or removing components. (Only
needed when DCDC1 and DCDC2 are populated.)
Series Resistors R401, R4814 270 Ωresistor allows the user to safely drive VMON3
and VMON4 test points with an off-board voltage
source. (Only needed when DCDC3 and DCDC4 are
populated.)
Ground Sense Resistors R411, R4914 100 Ωresistor allows the user to safely drive the
VMON3_GS and VMON4_GS test points with an off-
board voltage source (such as remote load sensing)
without adding or removing components. (Only
needed when DCDC3 and DCDC4 are populated.)
Signals
VMON1 / GS_VMON1 2, 3 Connected to DCDC1 output – 5 V – via R23 series
resistor. Also connected to J4 terminal. See the
Closed Loop Trimming (Not Populated) section for
more details.
VMON2 / GS_VMON2 2, 3 Connected to DCDC2 output – 3.3 V – via R32 series
resistor. Also connected to J5 terminal. See the
Closed Loop Trimming (Not Populated) section for
more details.
VMON3 / GS_VMON3 2, 4 Connected to DCDC3 output – 2.5 V – via R40 series
resistor. Also connected to J4 terminal. See the
Closed Loop Trimming (Not Populated) section for
more details.
VMON4 / GS_VMON4 2, 4 Connected to DCDC4 output – 1.2 V – via R48 series
resistor. Also connected to J4 terminal. See the
Closed Loop Trimming (Not Populated) section for
more details.
VMON5 2, (6), 9 5 V switched input supply to 5 V Hot Swap circuit via
R5 series resistor. Connected to SW1 in Board Power
circuit. See the 5 V Hot Swap (Not Populated) section
for more details.
VMON6 2, (6) 5 V rail supply from either main FPGA board or Hot
Swap output via R6 series resistor. See the 5 V Hot
Swap (Not Populated) section for more details.
VMON7 2, 5 Potentiometer 1 (R50) via R51 series resistor
VMON8 2, 5 Potentiometer 2 (R52) via R53 series resistor
VMON9 2, (7), 9 12 V switched input supply to 12 V Hot Swap circuit
via R65 (part of resistor divider). Connected to SW1
in Board Power circuit. See the 12 V Hot Swap (Not
Populated) section for more details.
HVMON (HIMONN_HVMON) 2, 7 12 V rail supply from either main FPGA board or Hot
Swap output. See the 12 V Hot Swap (Not Populated)
section for more details.
1. Not required for customer designs; this is only needed to support demonstrations on the breakout board.
Component / Signals Ref. Des. Schematic
Sheet Description

8
ASC Breakout Board
The two potentiometers (R50 and R52) are tied to VMON7 and VMON8 these can be used to simulate a fault or trip
a comparator (see Figure 4). The slide potentiometers provide a voltage in the range of 0 V to 3.3 V depending on
their position. R51 and R53 are 1 kΩseries resistors which allow for the connection of an off-board source directly
to the VMON7 and VMON8 test points. The voltage on either potentiometer can be read out from the A/D converter
using the I2C port.
Figure 4. Voltage Monitor Potentiometer Circuits
Temperature Monitoring
The board has PNP transistors mounted in the two corners opposite the main D-SUB connector. The PNP transis-
tors are connected in the beta-compensated PNP temperature monitor configuration (preferred configuration for
temperature monitors), as shown in Figure 5.
Provided the temperature monitors are enabled in the design, the temperature of each sensor can be read out
using I2C. The sensors can also be used to simulate over or under-temperature faults.
Figure 5. Temperature Monitor Circuits
The temperature sensors have 150 pF filter capacitors (C3 and C4) connected across the differential signals to
improve noise-immunity that are located close to the ASC device, as shown in Figure 6.
VMON7
VMON8
+3.3V
+3.3V
POT1 Sheet [2]
POT2 Sheet [2]
+3.3V
R51
1k
R50
1k
1
3
2
R53
1k
R52
1k
1
3
2
Temperature Sensor 1
Temperature Sensor 2
TEMP_SENSE1P
TEMP_SENSE1N
TEMP_SENSE2P
TEMP_SENSE2N
Q4
2N3906
Q3
2N3906

9
ASC Breakout Board
Figure 6. Temperature Monitor Connections
The temperature monitor components and signals are summarized in Table 2 below.
Table 2. Temperature Monitor Components and Signals
LED Outputs
The ASC Breakout Board has 9 LEDs tied to the ASC open-drain outputs. The LEDs are pulled up to 3.3 V and are
lit when GPIO1-GPIO10 are driven to a logic low (GPIO7 is not bonded out of the ASC). The LED circuit is shown
in Figure 7 below (taken from Sheet 8 of the schematic).
Figure 7. ASC GPIO LEDs
Push Button
The breakout board has one push-button (SW2), shown in Figure 8 (taken from Sheet 5 of the schematic). This sig-
nal is routed to GPIO10 of the ASC. This GPIO must be configured as an input in Platform Designer in order to use
the push-button. When the button is pressed, GPIO10 is set to 0. When the button is released, GPIO10 is pulled to
1 by R82 (see the LED outputs section). The input signal can be used in the logic design of the main board FPGA.
GPIO10 is shared with LED10, pressing the push-button (SW2) will cause LED10 to illuminate.
Component / Signals Ref. Des. Schematic
Sheet Description
Components Populated on Breakout Board
Temperature Sensor Q3, Q4 5 2N3906 PNP Transistor connected in Beta-Compen-
sated PNP configuration.
Series Resistors C3, C4 2 150 pF input filter capacitors for temperature monitor-
ing signals to reject noise.
Signals
TEMP_SENSE1P /
TEMP_SENSE1N
2, 5 Input from temperature sensor to TMON1 (tempera-
ture monitor input) of L-ASC10
TEMP_SENSE2P /
TEMP_SENSE2N
2, 5 Input from temperature sensor to TMON2 (tempera-
ture monitor input) of L-ASC10
TEMP_SENSE1P
TEMP_SENSE1N
TEMP_SENSE2P
TEMP_SENSE2N
C3
150pF
C4
150pF
TMON1P
21
TMON1N
22
TMON2P
23
TMON2N
24
LED2 LED3 LED4 LED5 LED6 LED8LED9 LED10
LED1
LED[1:10]
+3.3V
D1
Red
RN1A
2.2k
10
1
RN2B
2.2k
2
RN1C
2.2k
3
D4
Red
R82
2.2k
RN1G
2.2k
8
RN1F
2.2k
7
RN1E
2.2k
5
6
RN1H
2.2k
9
D2
Red
D6
Red
RN2A
2.2k
10
1
RN2D
2.2k
4
D7
Red
RN1B
2.2k
2
RN2E
2.2k
5
6
RN2F
2.2k
7
RN2C
2.2k
3
D8
Red
R81
2.2k
RN1D
2.2k
4
D3
Red
D5
Red
RN2H
2.2k
9
RN2G
2.2k
8
D9
Red

10
ASC Breakout Board
Figure 8. Push-Button Circuit
I2C Address Selection DIP Switch
The ASC Breakout Board provides an 8-position DIP switch for I2C address selection of the ASC device. The switch
combines with a set of on-board resistors (R9 – R15) to connect to the I2C_ADDR pin of the device (shown in
Figure 9, taken from Sheet 2 of the schematic). Each switch corresponds to a different resistor setting and address
selection (see the ASC Datasheet for more details). The ASC device only checks the resistor setting at power-on-
reset, updating the switches while the board is powered will have no effect. Only one switch should be closed at a
time.
Figure 9. I2C Address Selection DIP Switch
Reset Configuration Jumper
The ASC on the breakout board can be configured as a Mandatory ASC or Optional ASC. This setting is configured
in the Platform Designer software and described in the System Connections section of the ASC datasheet. The
position of jumper J12 (shown in Figure 10, from Sheet 2 of the schematic) should match the setting in the soft-
ware. This jumper routes the ASC RESETb signal to either the Mandatory Reset signal or to the Optional Reset
signal on the ASC Interface Connector.
Figure 10. Reset Configuration Jumper
LED10
SW2
GPIO10
14
23
ASC I2C Address Select
1
3
2
4
5
7
6
0
I2C_ADDR
+3.3V
SW3E
512
SW3D 413
R9 1K
SW3F
611
SW3H
89
SW3G
710
R10 18.0K
R11 14.0K
R12 10.0K
SW3A
116
R13 7.00K
SW3C
314
R14 4.40K
SW3B
215
R15 2.20K
Mandatory ASC Jumper 2 to 3
Optional ASC Jumper 1 to 2
ASC_RESET
MANDATORY_RESET
ASC_RESETbJ12
HEADER 3
1
2
3

11
ASC Breakout Board
ASC Interface Connector
The ASC Interface Connector (shown in Figure 11 from Schematic Sheet 2) is used to connect the ASC Breakout
Board to the main FPGA Board. The connector has been designed to pair with other available Lattice Evaluation
Boards, including the Platform Manager 2 Evaluation Board (see the related literature section for more details).
The connector includes all the mandatory signals for connecting the ASC device to the hardware management
controller as described in the system connections section of the ASC datasheet. This includes the ASC-Interface
Signals, the I2C signals, and the Clock and Reset signals. The connector also includes a set of power rails as
described in Table 3. Additionally, the connector provides the 5 V and 12 V Hot Swap signals.
Figure 11. ASC Interface Connector
Table 3. ASC Interface Connector Pin Description
Pin # Signal Name Description
1 GND Shared ground signal with main FPGA Board
2 ASC_WDAT ASC-Interface Signal – must be connected to FPGA PIO and assigned
in Diamond
3 ASC_RDAT ASC-Interface Signal – must be connected to FPGA PIO and assigned
in Diamond
4 ASC_WRCLK ASC-Interface Signal – must be connected to FPGA PIO and assigned
in Diamond
5 MANDATORY_RESET RESETb signal if ASC device is declared as mandatory in Platform
Designer. Must match J12 setting (Reset Configuration). Must be con-
nected to FPGA PIO and assigned in Diamond.
6 GND Shared ground signal with main FPGA Board
7 I2C_WRITE_EN Connected to GPIO1 through R4. Used with optional ASC Write Protect
feature. Connect to FPGA PIO and assign in Diamond if this feature is
used.
8 ASC_CLK 8-MHz Clock Output by ASC0 in ASC hardware management controller
systems. This signal is NC for all non-ASC0 ASC devices. ASC0
devices should connect to FPGA PCLK input and assign to ASCCLK
signal in Diamond
ASC Interface Connector
ASC_WDAT
ASC_RDAT
ASC_WRCLK
MANDATORY_RESET
ASC_RESET
I2C_WRITE_EN
+5V_HS
+12V_HS
I2C_SCL
I2C_SDA
5V_OC_SENSE
12V_OC_SENSE
LED2
LED3
ASC_CLK
+3.3V
ASC_12V_OC_SHUTDOWN
+5V_HS
+12V_HS
+3.3V
+11.3V
ASC_5V_OC_SHUTDOWN
J10
CONN DSUB 25-P
1
14
2
15
3
16
4
17
5
18
6
19
7
20
8
21
9
22
10
23
11
24
12
25
13
R7 0
R80

12
ASC Breakout Board
9 +3.3V ASC Supply Voltage. Provided by FPGA board or 12 V power supply
(power supply not populated on Breakout Board).
10 +11.3V Voltage rail generated from diode OR of +12V_SW and +5_SW input
supplies. FPGA main board may use as input to 12 V DC-DC convert-
ers.
11 +12V_HS 12 V supply rail. Output from either 12 V Hot Swap circuit or main FPGA
board. This rail is the input for DCDC1 and DCDC2.
12 +5V_HS 5 V supply rail. Output from either 5 V Hot Swap circuit or main FPGA
board. This rail is the input for DCDC3 and DCDC4.
13 GND Shared ground signal with main FPGA Board
14 ASC_12V_OC_SHUTDOWN Output from main FPGA board, connected to fast shutoff transistor
(Q12) of 12 V Hot Swap circuit. Assign to FPGA PIO in Platform
Designer and Diamond when using 12 V Hot Swap.
15 12V_OC_SENSE Output from ASC device (connected to GPIO3 through R8). Used as
fast shutdown alarm to main FPGA board. Assign to FPGA PIO in Plat-
form Designer and Diamond when using 12 V hot swap.
16 GND Shared ground signal with main FPGA Board
17 ASC_RESET RESETb signal if ASC device is declared as optional in Platform
Designer. Must match J12 setting (Reset Configuration). Must be con-
nected to FPGA PIO and assigned in Diamond.
18 I2C_SCL I2C Clock Signal. Should be connected to FPGA SCL pin. Main FPGA
board should include pull-up resistors. Used for programming the ASC
device.
19 I2C_SDA I2C Data Signal. Should be connected to FPGA SDA pin. Main FPGA
board should include pull-up resistors. Used for programming the ASC
device.
20 ASC_5V_OC_SHUTDOWN Output from main FPGA board, connected to fast shutoff transistor (Q7)
of 5 V Hot Swap circuit. Assign to FPGA PIO in Platform Designer and
Diamond when using 5 V Hot Swap.
21 5V_OC_SENSE Output from ASC device (connected to GPIO2 through R7). Used as
fast shutdown alarm to main FPGA board. Assign to FPGA PIO in Plat-
form Designer and Diamond when using 5 V Hot Swap.
22 GND Shared ground signal with main FPGA Board
23 +12V_HS 12 V supply rail. Output from either 12 V Hot Swap circuit or main FPGA
board. This rail is the input for DCDC1 and DCDC2.
24 +5V_HS 5 V supply rail. Output from either 5 V Hot Swap circuit or main FPGA
board. This rail is the input for DCDC3 and DCDC4.
25 +5V_HS 5 V supply rail. Output from either 5 V Hot Swap circuit or main FPGA
board. This rail is the input for DCDC3 and DCDC4.
Pin # Signal Name Description

13
ASC Breakout Board
Closed Loop Trimming (Not Populated)
The ASC provides four Closed Loop Trim (CLT) cells which are used to accurately trim and margin power supplies.
The ASC Breakout Board provides four DC-DC converter and trimming circuit footprints on the breakout board.
Table 4 lists the components and signal associated with CLT operation on the ASC Breakout Board.
Table 4. Closed Loop Trim Components & Signals
Component / Signals Ref. Des. Schematic-
Sheet Description
Components Not Populated on Breakout Board
DC-DC Converter DCDC1_A /
DCDC1_B
3 Dual-footprint +12 V input adjustable output power
supply. Trim circuit shown in schematic for DCDC1_A
(NQR002A0X4Z) at 5 V output.
DC-DC Converter DCDC2_A /
DCDC2_B
3 Dual-footprint +12 V input adjustable output power
supply. Trim circuit shown in schematic for DCDC2_A
(NQR002A0X4Z) at 3.3 V output.
DC-DC Converter DCDC3_A /
DCDC3_B
4 Dual-footprint +5 V input adjustable output power
supply. Trim circuit shown in schematic for DCDC3_A
(NQR002A0X4Z) at 2.5 V output.
DC-DC Converter DCDC4_A /
DCDC4_B
4 Dual-footprint +5 V input adjustable output power
supply. Trim circuit shown in schematic for DCDC4_A
(NQR002A0X4Z) at 1.2 V output.
N-Channel MOSFET – SOT-23 Q1, Q2 3 FDV301N N-Channel MOSFET. Inverts the DC-DC
enable signal from ASC GPIO8 / GPIO9 and shifts
the level up to +12 V.
Green Indicator LED D19, D20, D21,
D22
3, 4 LED indicates output of DC-DC is active.
LED Bias Resistor R86, R88, R90,
R92
3, 4 470 Ωresistor limits the LED current.
NPN Transistor – SOT-23 Q13, Q14, Q15,
Q16
3, 4 2N3904 NPN Transistor drives LED on when DC-DC
output is active.
NPN Bias Resistor R85, R87, R89,
R91
3, 4 4.7 kΩresistor limits the base current of NPN transis-
tor.
Tantalum Cap C5, C7, C9, C11 3, 4 6.8 µF, 20 V capacitor DC-DC input filter.
Tantalum Cap C6, C8, C10,
C12
3, 4 10 µF, 6.8 V capacitor DC-DC output filter.
DC-DC Output Load Resistor R22,R31, R39,
R47
3, 4 1k, 680, 470 and 330 Ωresistors pull DC-DC outputs
down to zero when disabled.
DCDC1 Trim Resistors R17 – R21 3 Resistor values based on Platform Designer Trim Cal-
culator for DCDC1_A at 5 V.
DCDC2 Trim Resistors R26 – R30 3 Resistor values based on Platform Designer Trim Cal-
culator for DCDC2_A at 3.3 V.
DCDC3 Trim Resistors R34 – R38 4 Resistor values based on Platform Designer Trim Cal-
culator for DCDC3_A at 2.5 V.
DCDC4 Trim Resistors R42 – R46 4 Resistor values based on Platform Designer Trim Cal-
culator for DCDC4_A at 1.2 V.
Phoenix 4-Terminal Connector
DCDC1-4
J4, J5, J7, J9 3, 4 Wire to board connectors to apply off-board loads to
DC-DC with remote sensing.
Signals
LED8 2, 3 DCDC1 control signal from GPIO8. Safe state is high.
Inverted via Q1.
LED9 2, 3 DCDC2 control signal from GPIO9. Safe state is high.
Inverted via Q1.
LED4 2, 4 DCDC3 control signal from GPIO4. Safe state is low.

14
ASC Breakout Board
Overview of Trim and Margin
The board provides footprints for four DC-DC modules. Since all four are similarly designed and laid out, this sec-
tion will provide an overview of the DC-DC circuit rather than provide a separate section for each DC-DC. Foot-
prints are provided for both 5-pin SIP modules and DOSA power converters. The circuits shown in the schematic
appendix support the NQR002A0X4 SIP from GE Industrial and the OKY-T/3-D12 DOSA converter from Murata.
None of the components associated with the DC-DC operation (shown in Table 4) are populated on the breakout
board.
The ASC Breakout board provides footprints and circuit connections for five trimming resistors for each DC-DC.
These five resistors are shared by both the SIP and DOSA footprints because only one supply can be populated at
a time. The resistors are organized in an “H” pattern both in the schematic and on the board layout. The resistors
are named in the schematic to match the names used in the Platform Designer Trim-view calculator. The names
are listed and described in Table 5 below. Typically only three resistors are suggested by the calculator; a pull-up, a
pull-down, and a series resistor. The exact population of the “H” pattern depends on many factors that the calcula-
tor takes into account such as type of DC-DC, output voltage, and range of trim. The ASC Breakout board provides
pads and connections to support any result from the Trim Calculator. However, with certain supplies and option set-
tings, the calculator can produce a result that only uses two resistors: a pull-down and series resistor. The DC-DCs
on the ASC Breakout board are populated with the two resistor solution. A key requirement for the calculator to pro-
duce a two-resistor solution is the Bi-Polar Zero (BPZ) voltage of the Trim Cell has to match the DC-DC internal ref-
erence voltage. Otherwise the calculator will add a pull-up or pull-down resistor in attempt to offset the imbalance
between the BPZ voltage setting and DC-DC reference voltage. The values shown in the schematic have been cal-
culated for the NQR002A0X4 SIP from GE Industrial. For more information on the Trim interface and Calculator
please see AN6074, Interfacing the Trim Output of Power Manager II Devices to DC-DC Converters and the Plat-
form Designer 3.1 User Guide.
Table 5. Trim Resistor "H-Network" Names.
In order for the CLT circuits within the ASC to operate properly the output of the supply needs to be monitored by
the correct VMON input. The ASC Breakout board illustrates the correct connections by using TRIM1 with VMON1
for DCDC1, TRIM2 with VMON2 for DCDC2, all the way to TRIM4 with VMON4 for DCDC4. As discussed in the
Voltage Monitor Operation section, the DC-DC outputs are connected to the VMON inputs using a series resistor
with a value of 270 Ω. The series resistor is not required in customer designs; its only function on the breakout
board is to isolate the DC-DC outputs from the VMON test point. The VMON series resistor allows another voltage
LED5 2, 4 DCDC4 control signal from GPIO5. Safe state is low.
OUT_DCDC1 2, 3 DCDC1 Output connected to VMON1 via R23.
OUT_DCDC2 2, 3 DCDC2 Output connected to VMON2 via R32.
OUT_DCDC3 2, 4 DCDC3 Output connected to VMON3 via R40.
OUT_DCDC4 2, 4 DCDC4 Output connected to VMON4 via R48.
TRIM_DCDC1 2, 3 DCDC1 Trim signal from TRIM1.
TRIM_DCDC2 2, 3 DCDC2 Trim signal from TRIM2.
TRIM_DCDC3 2, 4 DCDC3 Trim signal from TRIM3.
TRIM_DCDC4 2, 4 DCDC4 Trim signal from TRIM4.
Schematic Name Calculator Name Description
RpupS RpupSupply Pull Up Resistor at DC-DC Supply Trim input
RpdnS RpdnSupply Pull Down Resistor at DC-DC Supply Trim input
Rs Rseries Series Resistor between Trim DAC output and DC-DC Supply Trim input
RpupD RpupDAC Pull Up Resistor at Trim DAC output
RpdnD RpupDAC Pull Down Resistor at Trim DAC output
Component / Signals Ref. Des. Schematic-
Sheet Description

15
ASC Breakout Board
source to be applied to the VMON test point directly. If the voltage source is fairly weak, the VMON series resistor
can be removed.
Each of the DC-DC supplies has a load resistor connected to the output. The load resistor is not required in cus-
tomer designs as the supply is typically connected to a real load. The load resistor is only used on the breakout
board to prevent the output of the supply from “creeping up” when the supply is disabled. Without the load resistor
some disabled supplies may output around 1 Volt that can be read by either the VMON or a Digital Volt Meter
(DVM). The load resistors are sized based on the target DC-DC supply output voltage; lower values for lower volt-
ages and higher values for higher voltages. In all cases they are 1/10 watt packages so there is minimal heat gen-
erated.
DCDC1 – Enable and Trim
This section discusses the specific circuits that support DCDC1. In Figure 12 the control signal LED8, which comes
from GPIO8, is inverted and level shifted by a small signal N-channel MOSFET (Q1 FDV301N). For +12 V supplies
a buffer or inverter is needed because the ASC GPIOs can only be pulled up to +5.5 V. All GPIOs of the ASC have
a “safe state” which defines the behavior independent of configuration during Power-On-Reset (POR) or during
programming; the safe sate of GPIO8 is high. Both the DOSA and SIP supplies are enabled when the On-Off pin is
high (positive enable logic). Since the enable signal is inverted by Q1, the supplies will be off during “safe state”. A
10 kΩpull-up resistor (R16) to 12 V is used to insure a full logic swing at the enable input of the supplies. (Note that
DCDC3 and DCDC4 do not require the MOSFET circuit, this is because there input supply is +5 V. See Table 6 for
more details).
Figure 12. DCDC1 Trim and Control Circuit
The control signal LED8 is also used to turn on a red LED (D7) when it is low and pulled up to +3.3 V by a 2.2 kΩ
resistor (RN2G – Sheet 8). Depending on the enable logic (positive or negative) of the installed supply, the illumina-
tion of LED D7 may not indicate that DCDC1 is enabled. (When the DC-DC converters from the schematic are
used, DCDC1 and DCDC2 will be enabled when their control LED is illuminated. DCDC3 and DCDC4 will not be
enabled when their control LED is illuminated. This is due to the inverting MOSFET used with DCDC1 and
DCDC2). A separate green LED (D49) is used to indicate when the supply is enabled. An NPN transistor (Q15) is
used to turn the green LED on when the supply has enough voltage to bias the emitter-base junction (slightly more
than 0.7 V).
Supply filtering is provided by a 6.8 µF capacitor (C5) on the input and a 10 µF capacitor on the output (C6). These
are located close to the DC-DC footprints to ensure their effectiveness. Note that these values may not be optimal
for all supplies and loading conditions, specific filtering requirements should be followed from the DC-DC data
sheet.
5V @ 3A
GPIO8
TRIM1
VMON1
5V @ 2A
SIP
OUT_DCDC1
+12V_HS
+3.3V
LED8
Sheet [2,8]
TRIM_DCDC1
Sheet [2]
VMON1Sheet[2]
GS_VMON1 Sheet [2]
+12V_HS
Sheet [2,7]
+3.3V
Sheet [2,4,5,6,7,8,9,10]
J4
DCDC1
A
B
C
D
R22
1K
R23
270
R90
470
NQR002A0X4Z
DCDC1_A
DI
GND
3
Vin
2
On-Off Control
1Trim 5
Vout4
C6
10uF
6.8V
R24
100
D21
Green
SM_LED_0603
Q1
FDV301N
R18
2.74k
RpdnS
R21
open
RpdnD
OKY-T/3-D12P-C
DCDC1_B
DNI
GND
3
Vin
2
On-Off Control
1Trim 4
Vout5
R89
4.7k
R16
10K
R20
open
RpupD
C5
6.8uF
20V
R17
open
RpupS
R19
11.0k
Rs
Q15
2N3904

16
ASC Breakout Board
Table 6 shows a summary of the input voltage, output voltage, and control signal behavior for each of the four DC-
DC converters. The +12V_HS and +5V_HS rails which are used to power the DC-DC converters can be provided
by either the Hot Swap circuits or the ASC Interface Board connector. See the connector section for more details.
Table 6. Summary of DCDC Trim Circuits
Board Power Supplies (Not Populated)
The breakout board is supplied by the +3.3 V rail from the ASC Interface connector. The breakout board also pro-
vides the footprint for the power supply circuit shown in Figure 13. Table 7 lists the power supply components on
the ASC Breakout Board.
Table 7. Power Supply Components
The terminal connector J1 connects the +5 V supply to the SW1 power switch. Either the J2 power supply jack or J3
terminal connect the +12 V supply to SW1. Switching SW1 to the on position will connect the terminals to the
+12V_SW supply rail and the +5V_SW supply rail. The +12V_SW supply rail is connected to the D17 TRANZORB to
protect the board from voltage transients. These voltage rails are the input supplies to the 12 V Hot Swap and 5 V Hot
Swap circuits.
DC-DC Vin Vout VMON /
Trim Channel
GPIO Enable
Control
ON Logic
Level RpdnS Rseries
1 +12V_HS 5 V VMON1/TRIM1 GPIO8 0 2.74 kΩ11.0 kΩ
2 +12V_HS 3.3 V VMON2/TRIM2 GPIO9 0 4.42 kΩ16.0 kΩ
3 +5V_HS 2.5 V VMON3/TRIM3 GPIO4 1 6.34 kΩ22.0 kΩ
4 +5V_HS 1.2 V VMON4/TRIM4 GPIO5 1 20.0 kΩ39.0 kΩ
Component Ref. Des.
Schematic
Sheet Description
Components Not Populated on Breakout Board
DC-DC Converter DCDC5 9 SIP +12 V input power supply (NQR002A0X4Z)
trimmed for 3.3 V output. Provides board power sup-
ply from +12 V or +5 V rails.
Power Jack J2 9 +12 V AC Adapter connector.
Phoenix 2-Terminal Connector J1, J3 9 Input terminal for +5 V supply voltage (J1) and +12 V
supply voltage (J3)
Tranzorb TVS Diode D17 9 Transient voltage suppressor diode – protects +12 V
input from external voltage.
Schottky Diode D16, D18 9 Schottky diodes for diode ORing for +11.3 V rail
Tantalum Capacitor C29 9 22 µF, 25 V capacitor +12 V DC-DC input filter.
Ceramic Bypass Capacitors C31, C32 9 100 nF 25 V capacitor +12 V DC-DC input and output
filter.
Tantalum Capacitor C30 9 22 µF, 25 V capacitor +12 V DC-DC output filter.
Trim Resistor R96 9 4.53 kΩtrim resistor, sets DCDC5 output voltage at
+3.3 V
2-pin Header J14 9 Selects +3.3 V sources – populating with jumper
sources +3.3 V from +11.3 V rail, unpopulated
sources +3.3 V from ASC Interface Board connector

17
ASC Breakout Board
Figure 13. Board Power Supply Circuit
The +12 V connects through schottky diode D16 to the +11.3 V rail, while the +5 V connects through schottky
diode D18 to the +11.3 V rail. Through this configuration, the +11.3 V rail will be sourced by either the +12V_SW
rail (if present) or the +5V_SW rail (if present and +12V_SW rail not present). The +11.3 V rail is connected to the
ASC Interface connector. This rail may be used as an input to a 12 V DC-DC converter on the main FPGA board.
The +11.3 V rail is also used as the input voltage to DCDC5. DCDC5 steps down the +11.3 V input to a +3.3 V out-
put voltage. The +11.3 V is buffered and filtered by C29 and C31. The +3.3 V output is buffered and filtered by C30
and C32. The +3.3 V output voltage is set by the 4.53 kΩresistor (R96) connected to the DCDC5 Trim pin.
The header J14 is used to connect the DCDC5 output to the +3.3 V rail using a 2-pin jumper. Placing a jumper on
J14 will supply the ASC Breakout Board +3.3 V from DCDC5. It will also provide +3.3 V to the ASC Interface Con-
nector – this will power the FPGA main board from only the +12V_SW input on the ASC Breakout Board. No other
input supply is required.
5 V Hot Swap (Not Populated)
The ASC Breakout Board provides a set of footprints and connections for implementing a 5 V Hot Swap circuit
using the ASC’s built in hardware. Table 8 lists the components and signals associated with 5 V Hot Swap opera-
tion on the ASC Breakout Board.
Table 8. 5 V Hot Swap Components and Signals
Component / Signals Ref. Des. Schematic
Sheet Description
Components Not Populated on Breakout Board
Current sense resistor R60265mΩ2 W resistor for supply side current monitoring with
IMON1 input of ASC
IMON1 Isolation Resistor R582, R5926 Zero Ωresistors – support population option for standard
MOSFET versus MOSFET with Sense output
MOSFET Switch Q626 N-Channel MOSFET load-side Hot Swap switch supplies
power to +5V_HS and load capacitor C13.
Gate Drive Resistor R6126 2.2 kΩresistor, located close to MOSFET Q6, limits parasitic
oscillations at the gate of Q6. Works with C22 to slow switching
at Q6, limiting current ripple during hysteretic switching.
Gate-Source Capacitor C2226 100 nF capacitor, works with R61 to slow switching at Q6, lim-
iting current ripple during hysteretic switching.
Populate jumper to provide
3.3V power from ASC Eval
Board
3.3V
1A
12V to 4.8V input range
+11.3V
+3.3V
+12V
+5V
+11.3V
+11.3V
+3.3VSheet [2,3,4,5,6,7,8,10]
+5V_SWSheet [2,6,10]
+12V_SWSheet [7,10]
+11.3VSheet [2]
J14
HEADER 2
1
2
C31
100nF
25V
SW1
SWDPDT
2
3
5
6
1
4
J1
2 Position Terminal Block
A
B
J2
PWR JACK
3
2
1
J3
2 Position Terminal Block
A
B
R96
4.53K
C30
22uF
25V
D17
TRANZORB
C32
100nF
C29
22uF
25V
NQR002A0X4Z
DCDC5
GND
3
Vin
2
On-Off Control
1Trim 5
Vout4
D16
NSR0530P2T5G
D18
NSR0530P2T5G

18
ASC Breakout Board
The 5 V Hot Swap circuit is designed to support two separate implementations. The Standard MOSFET implemen-
tation uses a standard power MOSFET (Q6) and a 5 mΩsense resistor (R60). The MOSFET with Sense output
implementation uses a power MOSFET with current sense output (Q5) and a 3.30 Ωsense resistor. The Standard
MOSFET implementation is a Load-based Hot Swap implementation with the MOSFET connected between the
current sensing resistor and the load capacitor. The MOSFET with Sense output implementation is a Supply-based
Hot Swap implementation with the MOSFET connected between the supply and the current sensing resistor. The
full 5 V Hot Swap circuit is shown in Figure 14 below.
MOSFET with Sense Output Q536 N-Channel MOSFET supply-side Hot Swap switch supplies
power to +5V_HS and load capacitor C13. Sense output pro-
vides proportional current to drain current.
Gate Drive Resistor R5436 2.2 kΩresistor, located close to MOSFET Q5, limits parasitic
oscillations at the gate of Q5. Works with C23 to slow switching
at Q5, limiting current ripple during hysteretic switching.
Current sense resistor R57363.30Ωsense resistor for supply-side current monitoring with
IMON1 input of ASC, connected to Sense output of MOSFET
(Q5)
IMON1 Isolation Resistor R553, R5636 Zero Ωresistors – support population option for MOSFET with
Sense output versus standard MOSFET
Gate-Source Capacitor C2336 100 nF capacitor, works with R54 to slow switching at Q5, lim-
iting current ripple during hysteretic switching.
Load Capacitors C1316 680 µF 10 V Bulk capacitance emulates a Hot Swap load.
Discharge Resistors R6216 4.7 kΩResistor discharges load capacitor between Hot
Swaps.
LED Bias Resistor R63 6 3.3 kΩresistor limits the LED current for D10.
Red Indicator LED D10 6 LED to indicate Hot Swap has completed successfully.
Phoenix 2-Terminal Connector J6 6 +5V_HS terminal block connector
Current Sense Amplifier U216 ZXCT1009 current sense amplifier – provides output current
proportional to voltage across Vsense+ and Vsense-. Used for
demonstration purpose only, not required in application.
Current Sense Output Resistor R941620kΩresistor, sets output voltage at I_5V_HS test point to 1 V
/ 1A drain current of MOSFET.
NPN Fast Shutoff Transistor Q7 6 NPN transistor, provides fast pull-down of Q5/Q6 gate voltage,
enables fast shutdown from FPGA via ASC Interface connec-
tor during Hot Swap faults
Shutoff Transistor Pull-up Resistor R64 6 1 kΩpull-up resistor – biases Q7 ON by default (shutting off
Q5/Q6).
Signals
+5V_SW 2, 6 5 V input voltage, from Power Supply circuit and J1
5V_HS_DRIVE 2, 6 HVOUT2 signal from ASC
ASC_5V_OC_SHUTDOWN 2, 6 FPGA PIO signal, from ASC Interface Connector
5V_HS_CURRENT_P 2, 6 Connected to IMON1A_P, positive current monitor terminal
5V_HS_CURRENT_N 2, 6 Connected to IMON1A_N, negative current monitor terminal
+5V_HS 2, 4, 6 5 V Hot Swap output voltage, provided to J6 terminal block,
ASC Interface Connector, and DCDC1 and 2 input voltage
Additional Test Points
I_5V_HS Current Sense Amplifier Output Voltage – 1 V per 1A
1.Not required for customer designs; this is only needed to support ASC device evaluation.
2.Only populate for 5 V Standard MOSFET Hot Swap. Populate only from either Note 2 or Note 3, never both.
3.Only populate for 5 V MOSFET with Sense output Hot Swap. Populate only from either Note 3 or Note 3, never both.
Component / Signals Ref. Des. Schematic
Sheet Description

19
ASC Breakout Board
Figure 14. 5 V Hot Swap Circuit
The Hot Swap circuit is designed to work with the Hot Swap component in the Platform Designer software. Platform
Designer will automatically generate the Hot Swap algorithm and device configuration based on user defined set-
tings for input voltage, MOSFET characteristics, load capacitance, and other parameters. For more detail on the
Hot Swap algorithm and working with Hot Swap in Platform Designer, see the References section.
The Hot Swap circuit can be broken into three sections in order to understand the operation of the overall circuit:
• Hot Swap
– Load-Based Using Standard MOSFET
– Supply-Based Using MOSFET with Sense Output
• Fast Shutdown Circuit
• Current Sensing Test Circuit
Load-Based Hot Swap (Standard MOSFET)
The circuit in Figure 15 illustrates the Load-based Hot Swap using Standard MOSFET. The Load-based Hot Swap
circuit has Q6 connected between the current sensing resistor R60 and the load capacitor. The N type MOSFET
Q6 is controlled by the high voltage output (HVOUT2) from the ASC. The gate resistor (R61) and gate-source
capacitor (C22) are used to maintain a soft turn on of Q6. The increased gate capacitance smooths out the current
during the hysteretic control stage (see the References section for more details on the Hot Swap behavior).
IMON
VMON6
HVOUT2
Population Options:
Standard MOSFET (Option A):
Q6, C22, R61,
R60, R58, R59
MOSFET w/ Sense (Option B):
Q5, R57, R55,
C23, R54, R56
sense X 600
ASC INT
Connector
Fast
Shutdown
VMON5
I_5V_HS - 1V per 1A sensed
Demonstration Circuit to Output
Monitored Current to Test Point
(Not required for Hot Swap Operation)
MOSFET w/ Sense (Option B)
+5V_HS
+3.3V
5V_HS_DRIVE
Sheet [2]
+5V_HS Sheet [2,4]
5V_HS_CURRENT_P
Sheet [2]
5V_HS_CURRENT_NSheet [2]
ASC_5V_OC_SHUTDOWN
Sheet [2]
+5V_SWSheet [2,9,10]
kelvin
sense
Q5
BUK7C06-40AITE
R58
0
TP7
5V_IN
1
R54
2.2k R60
0.005
2W, 1%
TP17
I_5V_HS
1
TP16
5V_SDN
1
R59
0
C22
100nF
R62
4.7k
R61
2.2k
R57
3.30
1%
R55
0
R64
1k
C23
100nF
D10
Red
SM_LED_0603
R94
20k
1%
TP12
5V_HS
1
Q6
IRF7832
J6
2 Position Terminal Block
A
B
Q7
2N3904
R63
3.3k
R56
0
C13
680uF
10V
U2
ZXCT1009
Vsense+
2
Vsense-
3
Iout
1

20
ASC Breakout Board
Figure 15. 5 V Hot Swap - Load-Based, Standard MOSFET
The signals 5V_HS_CURRENT_P and 5V_HS_CURRENT_N are connected to the IMON1P and IMON1N signals
of the ASC. The sensing resistor R60 is connected through the zero Ωisolation resistors (R58, 59) to the ASC
using Kelvin connections and differential layout techniques to maximize the current sensing accuracy at the IMON1
inputs.
The +5V_HS signal is used by the Hot Swap function to monitor the load capacitor C13 voltage using VMON6 of
the ASC. The Hot Swap function monitors the load capacitor C13 voltage for the following reasons:
• to see that C13 is charging up and there is not a short or open in the circuit
• to see that C13 has reached a voltage where a higher current limit can be used
• to know when C13 is close to the 5 V supply voltage – Hot Swap is complete.
When Hot Swap is disabled R62 provides a discharge path for C13 to prepare the circuit for subsequent Hot
Swaps. LED D10 and bias resistor R63 give a visual indication that the Hot Swap process is complete.
Supply-Based Hot Swap (MOSFET with Sense Output)
The circuit in Figure 16 illustrates the Supply-based Hot Swap using a MOSFET with Sense output. (Components
from the Standard MOSFET Hot Swap are shown to illustrate the shared connections between the two circuits. Q6,
R58, R59, R60, R61, C22 should not be populated when the MOSFET with Sense output is used.) The MOSFET
with Sense output variation has Q5 connected to the supply side of R57. The SENSE output of Q5 provides a cur-
rent proportional to the current flowing through the MOSFET drain (the BUK7C06 shown in the schematic has a
typical drain current to sense current ratio of 615). The N type MOSFET Q5 is controlled by the HVOUT2 output
from the ASC. The gate resistor (R54) and gate-source capacitor (C23) are used to maintain a soft turn on of Q5.
The increased gate capacitance smooths out the current during the hysteretic control stage (see the References
section for more details on the Hot Swap behavior).
Shared
Connection with
MOSFET with Sense
Hot Swap
VMON6
+5V_HS
R58
0
R60
0.005
2W, 1%
R59
0
C22
100nF
R62
4.7k
R61
2.2k
D10
Red
SM_LED_0603
TP12
5V_HS
1
Q6
IRF7832
J6
2 Position Terminal Block
A
B
R63
3.3k
C13
680uF
10V
From 5V_SW
Supply Voltage
To ASC IMON 1P
Current Monitor
To ASC IMON 1N
Current Monitor
To Current Sense
Amplifier
From ASC
HVOUT2
