MachXO2-1200ZE Breakout Board Evaluation Kit

User’s Guide

2
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Introduction
Thank you for choosing the Lattice Semiconductor MachXO2™-1200ZE Breakout Board Evaluation Kit!
This user’s guide describes how to start using the MachXO2-1200ZE Breakout Board, an easy-to-use platform for
evaluating and designing with the MachXO2-1200ZE PLD. Along with the board and accessories, this kit includes a
pre-loaded demonstration design. You may also reprogram the on-board MachXO2-1200ZE device to review your
own custom designs.
Note: Static electricity can severely shorten the lifespan of electronic components. See the Storage and Handling
section of this document for handling and storage tips.
Features
The MachXO2-1200ZE Breakout Board Evaluation Kit includes:
•MachXO2-1200ZE Breakout Board – The board is a 3” x 3” form factor that features the following on-board
components and circuits:
– MachXO2-1200ZE PLD (LCMXO2-1200ZE-1TG144C)
– USB mini-B connector for power and programming
– Eight LEDs
– 60-hole prototype area
– Four 2x20 expansion header landings for general I/O, JTAG, and external power
– 1x8 expansion header landing for JTAG
– 3.3V and 1.2V supply rails
•Pre-loaded Demo – The kit includes a pre-loaded counter design that highlights use of the embedded
MachXO2-1200ZE oscillator and programmable I/Os configured for LED drive.
•USB Connector Cable – The board is powered from the USB mini-B socket when connected to a host PC. The
USB channel also provides a programming interface to the LCMXO2-1200ZE JTAG port.
•Lattice Breakout Board Evaluation Kits Web Page – Visit www.latticesemi.com/breakoutboards for the latest
documentation (including this guide) and drivers for the kit.
The content of this user’s guide includes demo operation, programming instructions, top-level functional descrip-
tions of the Breakout Board, descriptions of the on-board connectors, and a complete set of schematics.

3
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Figure 1. MachXO2-1200ZE Breakout Board, Top Side
Two 2x20
Header Landings
(J3, J5)
Two 2x20
Header Landings
(J2, J4)
MachXO2-1200ZE
PLD (U3)
FTDI
USB to UART/FIFO
IC (U1)
JTAG Header
Landing (J1)
USB Mini-B
Socket (J7)
Power LED
(PWR_ON)
Power/GND
Test Points
(TP1, TP2, TP3)
4x15 60-Hole
Prototype Array (J6)LED Array (J4)
Storage and Handling
Static electricity can shorten the lifespan of electronic components. Please observe these tips to prevent damage
that could occur from electro-static discharge:
• Use anti-static precautions such as operating on an anti-static mat and wearing an anti-static wrist-band.
• Store the evaluation board in the packaging provided.
• Touch a metal USB housing to equalize voltage potential between you and the board.
Software Requirements
You should install the following software before you begin developing new designs for the Breakout board:
• Lattice Diamond®design software
• FTDI Chip USB hardware drivers (installed as an option within the Diamond installation program)
MachXO2-1200ZE Device
This board features the MachXO2-1200ZE PLD which offers embedded Flash technology for instant-on, non-vola-
tile operation in a single chip. Numerous system functions are included, such as a PLL and 64Kbits of embedded
RAM plus hardened implementations of I2C, SPI, timer/counter, and user Flash memory. Flexible, high perfor-
mance I/Os support numerous single-ended and differential standards including LVDS, and also source synchro-

4
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
nous interfaces to DDR/DDR2/LPDDR DRAM memory. The 144-pin TQFP package provides 108 user I/Os in a
20mm x 20mm form factor. A complete description of this device can be found in the MachXO2 Family Data Sheet.
Demonstration Design
Lattice provides a simple, pre-programmed demo to illustrate basic operation of the MachXO2-1200ZE device. The
design integrates an up-counter with the on-chip oscillator.
Note: You may obtain your Breakout Board after it has been reprogrammed. To restore the factory default demo
and program it with other Lattice-supplied examples see the Download Demo Designs section of this document.
Run the Demonstration Design
Upon power-up, the preprogrammed demonstration design automatically loads and drives the LED array in an
alternating pattern. The program shows a clock generator based on the MachXO2-1200ZE on-chip oscillator. The
counter module is clocked at the oscillator default frequency of 2.08MHz to illustrate how low speed timer functions
can be implemented with a PLD. The 22-bit up-counter further divides the clock to advance the LED display
approximately every 500ms. The resulting light pattern will appear as an alternating pair of lit LEDs per row.
Figure 2. Demonstration Design Block Diagram
1x8 LED
Array
MachXO2-1200ZE
22-bit
Up-Counter
Clock
Generator 2.08 MHz
c_delay[21:0]
c_delay[20]
(~2 Hz)
WARNING: Do not connect the Breakout Board to your PC before you follow the driver installation procedure of
this section.
Communication with the Breakout Board with a PC via the USB connection cable requires installation of the FTDI
chip USB hardware drivers. Loading these drivers enables the computer to recognize and program the Breakout
Board. Drivers can be loaded as part of the installation of Lattice Diamond design software or Diamond Program-
mer, or as a stand-alone package.
To load the FTDI Chip USB hardware drivers as part of the Lattice Diamond installation:
1. Select Programmer Drivers in the Product Options of Lattice Diamond Setup.
2. Select FTDI Windows USB Driver or All Drivers in the LSC Drivers Install/Uninstall dialog box.
3. Click Finish to install the USB driver.
4. After the driver installation is complete, connect the USB cable from a USB port on your PC to the board’s USB
mini-B socket (J2). After the connection is made, a green Power LED (D9) will light indicating the board is pow-
ered on.
5. The demonstration design will automatically load and drive the LED array in an alternating pattern.

5
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
To load the FTDI chip USB hardware drivers via the stand-alone package:
1. Browse to www.latticesemi.com/breakoutboards and download the FTDI Chip USB Hardware Drivers package.
2. Extract the FTDI chip USB Hardware driver package to your PC hard drive.
3. Connect the USB cable from a USB port on your PC to the board’s USB mini-B socket (J7). After the connec-
tion is made, a green Power LED (D9) will light indicating the board is powered on.
4. If you are prompted, “Windows may connect to Windows Update” select No, not this time from available
options and click Next to proceed with the installation. Choose the Install from specific location (Advanced)
option and click Next.
5. Search for the best driver in these locations and click the Browse button to browse to the Windows driver folder
created in the Download Windows USB Hardware Drivers section. Select the CDM 2.04.06 WHQL Certified
folder and click OK.
6. Click Next. A screen will display as Windows copies the required driver files. Windows will display a message
indicating that the installation was successful.
7. Click Finish to install the USB driver.
8. The demonstration design will automatically load and drive the LED array in an alternating pattern.
See the Troubleshooting section of this guide if the board does not function as expected.
Download Demo Designs
The counter demo is preprogrammed into the Breakout Board, however over time it is likely your board will be mod-
ified. Lattice distributes source and programming files for demonstration designs compatible with the Breakout
Board.
To download demo designs:
1. Browse to the Lattice Breakout Board Evaluation Kits web page (www.latticesemi.com/breakoutboards) of the
Lattice web site. Select MachXO2 Breakout Board Demo Source and save the file.
2. Extract the contents of MachXO2_1200ZE_BB_Eval_Kit_v01.0.zip to an accessible location on your hard
drive.
The demo design directory Demo_LED is unpacked with all design files needed for the demo, including the JEDEC
programming data file.
Continue to Programming a Demo Design with Lattice Diamond Design Software.
Programming a Demo Design with the Lattice Diamond Programmer
The demonstration design is pre-programmed into the MachXO2-1200ZE Breakout Board by Lattice. If you have
changed the design but now want to restore the Breakout Board to factory settings, use the procedure described
below.
To program the MachXO2-1200ZE device:
1. Install, license and run Lattice Diamond software. See www.latticesemi.com/latticediamond for download and
licensing information.
2. Connect the USB cable to the host PC and the MachXO2-1200ZE Breakout Board.
3. From Diamond, open the Demo_LED_OSC.ldf project file.

6
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
4. Click the Programmer icon.
5. Click Detect Cable. The Programmer will detect the cable (Cable: USB2, Port: FTUSB-0).
6. Click the Program icon. When complete, PASS is displayed in the Status column.
MachXO2-1200ZE Breakout Board
This section describes the features of the MachXO2-1200ZE Breakout Board in detail.
Overview
The Breakout Board is a complete development platform for the MachXO2-1200ZE PLD. The board includes a pro-
totyping area, a USB program/power port, an LED array, and header landings with electrical connections to most of
the PLD’s programmable I/O, power, and JTAG pins. The board is powered by the PC’s USB port or optionally with
external power. You may create or modify the program files and reprogram the board using Lattice Diamond soft-
ware.
Figure 3. MachXO2-1200ZE Breakout Board Block Diagram
LCMXO2-1200ZE-
1TG144C
2x20 Header
Landing (J5)
LED
Array
GPIO
8
2x20 Header
Landing (J2)
GPIO
2x20 Header
Landing (J3)
Bank 1
Bank 2
Bank 0
2x20 Header
Landing (J4)
Bank 3
GPIO
GPIO
USB
Controller
USB Mini B
Socket
1x8 Header
Landing (J1,
Optional JTAG
Interface)
A/Mini-B
USB Cable
JTAG
Programming

7
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Table 1 describes the components on the board and the interfaces it supports.
Table 1. Breakout Board Components and Interfaces
Component/Interface Type
Schematic
Reference Description
Circuits
USB Controller Circuit U2: FT2232H USB-to-JTAG interface and dual USB UART/FIFO IC
USB Mini-B Socket I/O J7:USB_MINI_B Programming and debug interface
Components
LCMXO2-1200ZE PLD U3: LCMXO2-
1200ZE-1TG144C 1200-LUT device packaged in a 20 x 20mm, 144-pin TQFP
Interfaces
LED Array Output D8-D1 Red LEDs
Four 2x20 Header
Landings I/O
J2: header_2x20
J3: header_2x20
J4: header_2x20
J5: header_2x20
User-definable I/O
1x8 Header Landing I/O J1: header_1x8 Optional JTAG interface
4x15 60-Hole Prototype
Area Prototype area 100mil centered holes.
Test points Power
TP1: +3.3V
TP2: +1.2V
TP3: GND
Power and ground reference points
Subsystems
This section describes the principle sub systems for the Breakout Board in alphabetical order.
Clock Sources
All clocks for the counter demonstration designs originate from the MachXO2-1200ZE PLD on-chip oscillator. You
may use an expansion header landing to drive a PLD input with an external clock source.
Expansion Header Landings
The expansion header landings provide access to user GPIOs, primary inputs, clocks, and VCCO pins of the
MachXO2-1200ZE. The remaining pins serve as power supplies for external connections. Each landing is config-
ured as one 2x20 100 mil.
Table 2. Expansion Connector Reference
Item Description
Reference Designators J2, J3, J4, J5
Part Number header_2x20

8
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Table 3. Expansion Header Pin Information (J2)
Pin Number Function MachXO2-1200ZE Pin
1NC N/A
2VCCIO0 118, 123, 135
3PT17D/DONE 109
4PT17C/INITn 110
5PT17B 111
6PT17A 112
7GND N/A
8GND N/A
9PT16D 113
10 PT16C 114
11 PT16B 115
12 PT16A 117
13 PT15D/PROGn 119
14 PT15C/JTAGen 120
15 GND N/A
16 GND N/A
17 PT15B 121
18 PT15A 122
19 PT12D/SDA/PCLKC0_0 125
20 PT12C/SCL/PCLKT0_0 126
21 PT12B/PCLKC0_1 127
22 PT12A/PCLKT0_1 128
23 GND N/A
24 GND N/A
25 PT11D/TMS 130
26 PT11C/TCK/TEST_CLK 131
27 PT11B 132
28 PT11A 133
29 PT10D/TDI 136
30 PT10C/TDO 137
31 GND N/A
32 GND N/A
33 PT10B 138
34 PT10A 139
35 PT9D 140
36 PT9C 141
37 PT9B 142
38 PT9A 143
39 GND N/A
40 GND N/A

9
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Table 4. Expansion Header Pin Information (J3)
Pin Number Function MachXO2-1200ZE Pin
1VCC_1.2V 36, 72, 108, 144
2VCCIO1 79, 88, 102
3VCC_1.2V 36, 72, 108, 144
4NC N/A
5PR10C 74
6PR10D 73
7PR10A 76
8PR10B 75
9GND N/A
10 GND N/A
11 PR9C 78
12 PR9D 77
13 PR9A 82
14 PR9B 81
15 GND N/A
16 GND N/A
17 PR8C 84
18 PR8D 83
19 PR8A 86
20 PR8B 85
21 GND N/A
22 GND N/A
23 PCLKT1_0/PR5C 92
24 PCLKC1_0/PR5D 91
25 PR5A 94
26 PR5B 93
27 GND N/A
28 GND N/A
29 PR4C 96
30 PR4D 95
31 PR4A 98
32 PR4B 97
33 GND N/A
34 GND N/A
35 PR3A 100
36 PR3B 99
37 PR2C 105
38 PR2D 104
39 PR2A 107
40 PR2B 106

10
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Table 5. Expansion Header Pin Information (J4)
Pin Number Function MachXO2-1200ZE Pin
1VCC_3.3V N/A
2VCCIO3 7, 16, 30
3VCC_3.3V N/A
4NC N/A
5PL2A/L_GPLLT_FB 1
6PL2B/L_GPPLC_FB 2
7PL2C/L_GPLLT_IN 3
8PL2D/L_GPLLC_IN 4
9PL3A/PCLKT3_2 5
10 PL3B/PCLKC3_2 6
11 PL3C 9
12 PL3D 10
13 GND N/A
14 GND N/A
15 PL4A 11
16 PL4B 12
17 PL4C 13
18 PL4D 14
19 GND N/A
20 GND N/A
21 PL5A/PCLKT3_1 19
22 PL5B/PCLKC3_1 20
23 PL5C 21
24 PL5D 22
25 GND N/A
26 GND N/A
27 PL8A 23
28 PL8B 24
29 PL8C 25
30 PL8D 26
31 GND N/A
32 GND N/A
33 PL9A/PCLKT3_0 27
34 PL9B/PCLKC3_0 28
35 GND N/A
36 GND N/A
37 PL10A 32
38 PL10B 33
39 PL10C 34
40 PL10D 35

11
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Table 6. Expansion Header Pin Information (J5)
Pin Number Function MachXO2-1200ZE Pin
1NC N/A
2VCCIO2 37, 51, 66
3SI/SISPI/PB20D 71
4PB20B 69
5 SN/PB20C 70
6PB20A 68
7PB18D 67
8PB18B 62
9PB18C 65
10 PB18A 61
11 GND N/A
12 GND N/A
13 PB15D 60
14 PB15B 58
15 PB15C 59
16 PB15A 57
17 GND N/A
18 GND N/A
19 PCLKC2_1/PB11B 56
20 PB11D 54
21 PCLKT2_1/PB11A 55
22 PB11C 52
23 GND N/A
24 GND N/A
25 PCLKC2_0/PB9B 50
26 PB9D 48
27 PCLKT2_0/PB9A 49
28 PB9C 47
29 GND N/A
30 GND N/A
31 S0/SPISO/PB6D 45
32 PB6B 43
33 MCLK/CLK/PB6C 44
34 PB6A 42
35 GND N/A
36 GND N/A
37 PB4D 41
38 PB4B 39
39 CSSPIN/PB4C 40
40 PB4A 38

12
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Figure 4. J2/J4 Header Landing Callout
NC IO0
109 110
111 112
GND GND
113 114
115 117
119 120
GND GND
121 122
125 126
127 128
GND GND
130 131
132 133
136 137
GND GND
138 139
140 141
142 143
GND GND
12
J2
3.3 IO3
3.3 NC
12
34
56
910
GND GND
11 12
13 14
GND GND
19 20
21 22
GND GND
23 24
25 26
GND GND
27 28
GND GND
32 33
34 35
12
J4
Top Side
J2 J4
Figure 5. J3/J5 Header Landing Callout
1.2 IO1
1.2 NC
74 73
76 75
GND GND
78 77
82 81
GND GND
84 83
86 85
GND GND
92 91
94 93
GND GND
96 95
98 97
GND GND
100 99
105 104
107 106
12
J3
NC IO2
71 69
70 68
67 62
65 61
GND GND
60 58
59 57
GND GND
56 54
55 52
GND GND
50 48
49 47
GND GND
45 43
44 42
GND GND
41 39
40 38
12
J5
J3 J5
Top Side

13
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Figure 6. J1 Header Landing and LED Array Callout
D8 LED7
D7 LED6
D6 LED5
D5 LED4
D4 LED3
D3 LED2
D2 LED1
D1 LED0
107
LED Function
LED Array
MachXO2-
1200ZE
Pin
106
105
104
100
99
98
97
Top Side
D8
D1
J1
3.3
TDO
TDI
NC
NC
TMS
GND
TCK
1
8
J1
MachXO2-1200ZE PLD
The MachXO2-1200ZE-1TG144C is a 144-pin TQFP package PLD device which provides 108 I/Os in a 20 x 20mm
package.
Table 7. MachXO PLD Interface Reference
Item Description
Reference Designators U3
Part Number LCMXO2-1200ZE-1TG144C
Manufacturer Lattice Semiconductor
Web Site www.latticesemi.com
JTAG Interface Circuits
For power and programming an FTDI USB UART/FIFO IC converter provides a communication interface between a
PC host and the JTAG programming chain of the Breakout Board. The USB 5V supply is also used as a source for
the 3.3V supply rail. A USB mini-B socket is provided for the USB connector cable.
Table 8. JTAG Interface Reference
Item Description
Reference Designators U1
Part Number FT2232HL
Manufacturer Future Technology Devices International (FTDI)
Web Site www.ftdichip.com

14
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Table 9. JTAG Programming Pin Information
Description MachXO2-1200ZE Pin
Test Data Output 137:TDO
Test Data Input 136:TDI
Test Mode Select 130:TMS
Test Clock 131:TCK
LEDs
A green LED (D9) is used to indicate USB 5V power. Eight red LEDs are driven by I/O pins of the MachXO2-
1200ZE device.
Table 10. Power and User LEDs Reference
Item Description
Reference Designators D1, D2, D3, D4, D5, D6, D7, D8, D9
Part Number LTST-C190KRKT (D1-D8)
LTST-C190KGKT (D9)
Manufacturer Lite-On It Corporation
Web Site www.liteonit.com
Power Supply
3.3V and 1.2V power supply rails are converted from the USB 5V interface when the board is connected to a host
PC.
Test Points
In order to check the various voltage levels used, test points are provided:
•TP1:+3.3V
•T
P2:+1.2V
• TP3: GND
USB Programming and Debug Interface
The USB mini-B socket of the Breakout Board serves as the programming and debug interface.
JTAG Programming: For JTAG programming, a preprogrammed USB PHY peripheral controller is provided on the
Breakout Board to serve as the programming interface to the MachXO2-1200ZE PLD.
Programming requires the Lattice Diamond or ispVM System software.
Table 11. USB Interface Reference
Item Description
Reference Designators U1
Part Number FT2232HL
Manufacturer Future Technology Devices International (FTDI)
Web Site www.ftdichip.com

15
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
Board Modifications
This section describes modifications to the board to change or add functionality.
Bypassing the USB Programming Interface
The USB programming interface circuit (USB Programming and Debug Interface section) may be optionally
bypassed by removing the 0 ohm resistors: R5, R6, R7, R8 (See Appendix A. Schematics, Sheet 2 of 5). Header
landing J1 provides JTAG signal access for jumper wires or a 1x8 pin header.
Applying External Power
The Breakout Board is powered by the circuit of Schematic Sheet 5 of 5 based on the 5V USB power source. You
may disconnect this power source by removing the 0 ohm resistors: R42 (VCC_1.2V) and R44 (VCC_3.3V). Power
connections are available from the expansion header landings, J3 (+1.2V, pins 1 and 3, schematic sheet 3 of 5) and
J4 (+3.3V, pins 1 and 3, schematic sheet 4 of 5).
Measuring Bank and Core Power
In addition to the expansion headers, test points (TP1, TP2) provide access to power supplies of the MachXO2-
1200ZE PLD. Inline 1 ohm resistors: R24 (VCCIO0, +3.3V, Bank 0), R25 (VCCIO1, +3.3V, Bank 1), R26 (VCCIO2,
+3.3V, Bank 2), R27 (VCCIO3, +3.3V, Bank 3), R56 (VCC core, +1.2V) can be used to measure current for the
power supplies.
Mechanical Specifications
Dimensions: 3 in. [L] x 3 in. [W] x 1/2 in. [H]
Environmental Requirements
The evaluation board must be stored between -40° C and 100° C. The recommended operating temperature is
between 0° C and 90° C.
The board can be damaged without proper anti-static handling.
Glossary
PLD: Programmable Logic Device
DIP: Dual in-line package
LED: Light Emitting Diode.
LUT: Look Up Table
PCB: Printed Circuit Board
RoHS: Restriction of Hazardous Substances Directive
USB: Universal Serial Bus
WDT: Watchdog Timer
Troubleshooting
Use the tips in this section to diagnose problems with the Breakout Board.
LEDs Do Not Flash
If power is applied but the board does not flash according to the preprogrammed counter demonstration then it is
likely the board has been reprogrammed with a new design. Follow the directions in the Demonstration Design sec-
tion to restore the factory default.

16
MachXO2-1200ZE Breakout Board
Lattice Semiconductor Evaluation Kit User’s Guide
USB Cable Not Detected
If Lattice Diamond Programmer or ispVM System does not recognize the USB cable after installing the Lattice USB
port drivers and rebooting, the incorrect USB driver may have been installed. This usually occurs if you attach the
board to your PC prior to installing the Lattice-supplied USB driver.
To access the Troubleshooting the USB Driver Installation Guide:
For Diamond software and standalone Diamond Programmer:
1. Start Diamond or Diamond Programmer and choose Help.
2. Search for USB driver or Troubleshooting, then select the Troubleshooting the USB Driver topic.
3. Follow the directions to install the Lattice USB driver.
For ispVM:
1. Start ispVM System and choose Options > Cable and I/O Port Setup.
The Cable and I/O Port Setup Dialog appears.
2. Click the Troubleshooting the USB Driver Installation Guide link.
The Troubleshooting the USB Driver Installation Guide document appears in your system’s PDF file reader.
3. Follow the directions to install the Lattice USB driver.
Determine the Source of a Pre-Programmed Device
If the Breakout Board has been reprogrammed, the original demo design can be restored. To restore the board to
the factory default, see the Download Demo Designs section for details on downloading and reprogramming the
device.
Ordering Information
Description Ordering Part Number
China RoHS Environment-Friendly
Use Period (EFUP)
MachXO2-1200ZE Breakout Board Evaluation Kit LCMXO2-1200ZE-B-EVN
Technical Support Assistance
Hotline: 1-800-LATTICE (North America)
[phone] (Outside North America)
e-mail: techsuppor[email protected]m
Internet: www.latticesemi.com
Revision History
Date Version Change Summary
December 2011 01.0 Initial release.
January 2012 01.1 Figure “MachXO2-1200ZE Breakout Board, Top Side” updated with revi-
sion B board photo.
© 2012 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as
listed at www.latticesemi.com/legal. All other brand or product names are trademarks or registered trademarks of
their respective holders. The specifications and information herein are subject to change without notice.
