Lattice LCMXO3L-DSI-EVN User manual

QuickSTART
MachXO3L SMA/DSI
Breakout Board
This document provides a brief introduction and instructions to install and run the
Lattice MachXO3L SMA/DSI Breakout Board Evaluation Kit on Windows 7/Vista/
XP. For full documentation, schematics, demonstration programs and more go
to www.latticesemi.com/breakoutboards and look for the MachXO3L SMA/DSI
Breakout Board.
Two versions of the Lattice MachXO3L Breakout Board are available:
MachXO3L DSI Breakout Board (LCMXO3L-DSI-EVN)
MIPI D-PHY Input and Output connectors are installed
MachXO3L SMA Breakout Board (LCMXO3L-SMA-EVN)
SMA breakout connectors are installed
This document describes either/both boards.
Check Kit Contents
The following items are included in this kit:
MachXO3L SMA/DSI Breakout Board
USB cable
QuickSTART Guide
Install USB driver & Connect the Board
1. A driver to enable the USB programming interface is included with Lattice Diamond
Programmer software. Go to www.latticesemi.com/software and download/install
the Programmer and Deployment Tool. Be sure to include the USB driver during
installation.
2. Connect the USB cable provided between the Breakout board and your PC’s USB
port. LEDs will light and start to ash according to the preprogrammed design.
Note: Power can be supplied to the board via mini USB port, 12 V power supply,
from a separate board through the J48 DSI input connector or any combination of
the three.
Doing More
The source code for the demonstration program is available on the Lattice website (link
above). Lattice Diamond software can be used to make modications to this program,
or develop your own designs.
For further questions contact Lattice Technical Support at:
email: [email protected].

MachXO3L SMA/DSI
Breakout Board
Programming Selection Reference
The Lattice MachXO3L Breakout Board features two MachXO3L devices:
MachXO3L-2100E in 49-ball WLCSP. This device is in a circuit optimized for MIPI D-PHY
transmit and receive interfaces
MachXO3L-6900C in 256-ball caBGA. This device is in a exible IO evaluation
environment.
The diagram below shows how to populate the JTAG Control Field header J50 for different
programming congurations:
Board reference
Note: This image shows components that may not be included on the version of the board you’ve
purchased. See the notes for more details.
2100E + 6900C
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
2100E+6900C 2100Eonly 6900Conly
2100E
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
2100E+6900C 2100Eonly 6900Conly
6900C
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
2100E+6900C 2100Eonly 6900Conly
