LAZBOY CHR10084A-C User manual

Executive Chair
ASSEMBLY
Instructions
Model: CHR10084A-C

Should you prefer to
speak with a customer
service representative,
you may call toll free :
1-855-372-2315
0-800-051-6775
U.S. 6am - 5pm PST,
U.K. 2pm -1am
2

FAILURE TO FOLLOW THESE WARNINGS
WHEN IN USE COULD RESULT IN INJURY
• Do not stand on the item or use as a step ladder.
• The piece has been tested and approved for users
weighing up to 275 lbs (125kg) per seat.
• Do not use this item unless all bolts and screws are
firmly secured and fastened.
• Check all bolts and screws every 90 days. As
necessary tighten if any are loose.
• Lift up then move. Pushing over or dragging this
product can result in an injury or cause damage to
the floor and piece.
Guidelines
3

Please read through this instruction booklet before
beginning assembly of this item.
Two adults are recommended for assembly.
• Clear out the space for assembly and lay out all
parts on Parts List, extra room will allow you to
easily determine if all the pieces are present.
• Save all packing materials until assembly is
complete to avoid accidentally discarding smaller
parts or hardware.
• Keep small parts and pieces away from children
and pets until fully assembled.
• Please check for any loose screws and tighten them
before you use.
WARNING :DO NOT LET
CHILDREN PLAY IN OR
AROUND THE UNIT DUE
TO THE POSSIBLE RISK
OF INJURY.
Pre-Assembly Preparation:
4

Parts List
Casters Star BaseGas Lift Seat Plate
D EC
BA
1” Screws
SeatCushion Back Cushion
G
FI J
Quantity: 5Quantity:1Quantity: 1Quantity: 1
Arms
Quantity: 2
Quantity:1Quantity: 1
Plastic Shroud
H
Quantity: 1 Quantity: 2
1-1/4” Screws
Quantity: 6
Allen Key
Quantity: 1
5
D1
D2
K L
2” Screws with Spring
Washers
Quantity: 4
M
Plastic Caps
Quantity: 4

Step 1 Step 2
Place the Star Base (B) upside down and insert 5 Casters (A) into the holes
on the Star Base (B).
Turn the Star Base (B) over and insert the Gas Lift (C) through the
center hole on top of Star Base (B).
6
A
B
C
B

Step 3 Step 4
Attach Seat Plate (D) to the bottom of the Seat Cushion (F) (with the front
of the seat plate facing the front of seat cushion). Attach by using 1-1/4”
Screws (I) for the front holes of the Seat Plate (D) and 1” Screws (J) for the
rear holes of the Seat Plate (D) and tighten screws.
*Note: Tighten the screws completely.
Insert Levers (D1 & D2) of Seat Plate (D) to the pre-attached cable
lever receivers on the underside of Seat Cushion (F) (with the front
of the levers facing the front of seat cushion). Push down the key
on the receivers to pull out the levers.
*Note: Fix the cable for the seat plate into the plastic clips
attached to the bottom of the seat cushion.
7
Disassemble the lever
Assemble the lever
Insert Push
M
J
D
I
F
D
F
D2
D1

K
8
Step 5 Step 6
Attach the Back Cushion (G) to the Seat Cushion (F) by positioning the
back support plate over the Seat Plate (D) with 1-1/4” Screws (I).
*Note: Do not tighten the screws completely.
Insert 2” Screws with Spring Washers (K) into arm holes, attaching
Arms (E) (with the front of arms facing the front of seat cushion) to
sides of Seat Cushion (F) and Back Cushion (G).
*Note: Tighten all the screws completely. Remember to tighten the
back support plate screws.
E
M
I
G
D
F
M
K
F
G

9
Step 7 Step 8
Put the Plastic Shroud (H) over the Seat Plate (D) (with the front of plastic
shroud facing the front of seat cushion). Align shroud posts to holes on
bottom of Seat Cushion (F) and press into position.
Position the assembled chair upright with the seat plate facing down.
Insert the Gas Lift (C) into the center hole of the Seat Plate (D).
F
H
D
C
D
F

10
Step 9
Press the Plastic Caps (L) into armrest holes once all screws have been
tightened.
L
L

11
Operating Instructions
Function Instruction - 1
To Adjust Seat Height:
While seated, lean forward and reach under the right side of the chair to
find the lever. Lift the lever and raise your body up slightly to allow the
chair to rise to the desired height. Once desired height is reached,
release lever to lock chair at desired height. To lower the seat, lift the
lever while seated. The chair will descend until the lever is released or
the chair reaches the bottom position.

Function Instruction - 2
To Operate Tilt Lockout:
While seated, reach under the left side of the chair to find the lever.
Push down the lever and lean back to allow the chair to tilt
backwards. To lock the chair in the upright or vertical position, sit
upright and pull the lever to the up position.
12

Function Instruction - 3
To Adjust Tension On The Tilt:
Reach under the front center of the chair, grasp the
round knob (R) and turn it counter - clockwise to stiffen
the tilt mechanism for a heavier user. Turn the knob (R)
clockwise to loosen the tilt mechanism for a lighter user.
Rotate the knob (R) until the desired resistance is
reached.
13
R

14
Function Instruction - 4
360˚ Swivel:
360˚ seat swivel.

Limited Warranty
The product you have purchased is warranted against
defects in material and workmanship while owned by
the “Original Purchaser”. The term “Original Purchaser”
is defined as that party or entity which purchases these
products from an authorized dealer or retailer as shown
by the original sales receipt. This warranty does not
apply too “as is” or previously owned products.
The manufacturer warrants its products to be free from
defects in materials and workmanship (normal wear and
tear, fading and stretching excepted), for one year from
the date of purchase, except as provided below under
the limited warranty.
This warranty gives you specific rights, and you may also
have other rights, which vary from state to state (or
country to country). All warranties are limited to the
original purchaser for normal use by a maximum of two
users. Total weight capacity per chair is 275 pounds for
a single user.
The exceptions or exclusions to this warranty are:
•Upholstery material and foam cushion material is
warranted against defects in material and workmanship
for a period of one year, beginning on the date of
purchase as shown on the original sales receipt.
• Any warranty claim that is submitted after the limited
warranty period, or without proper proof of purchase
will not include the cost of parts, labor, or delivery on
the warranted parts within a reasonable amount of time.
We reserve the right to require damaged parts to be
returned to us upon request. Natural markings such as
scars, brands, grain variations, wrinkles, color variations,
etc. will be considered normal characteristics and not
construed as defects.
• For claims or questions concerning this warranty,
please contact the Customer Service Department
on the web at www.truecustomersupport.com.
Be prepared to provide your name, address,
daytime phone number, the model and purchase order
number of the product, date of purchase, and the store
where it was purchased. The manufacturer requires that
the original sales receipt be submitted with all requests
to confirm that you are the original purchaser according
to our written warranty.
