LCG LCG-PL64Z User manual

- 1 -
LED PAR 64
ZOOM-RGBW
User Manual
LCG-PL64Z
Please read this manual carefully before use!

- 2 -
Thank you for purchasing our 120W COB RGBW LED PAR64. Please read user
guide for safety and operations before using. Keep this manual for future reference.
1. Safety Instructions
Please keep this User Manual for future consultation. If you sell the fixture to
another user, be sure that they also receive this intruction booklet.
Please unpack and check carefully there is no transportation damage before
using the fixture.
Please disconnect main power before servicing and mantenance.
The unit must be installed in a location with adequate ventilation, at least 50cm
from adjacent surfaces.Be sure that no ventilation slots are blocked.
The maximum ambient temperature is Ta:40°C. DO NOT operate it where the
temperature is higher than this.
DO NOT connect the device to any dimmer pack.
The housing must be replaced if they are visibly damaged.
Unit surface temperature may reach up to 85 °C. Don’t touch the housing
bare-hand during its operation. Turn off the power and allow about 15 minutes for
the unit to cool down before replacing or serving.
There are no user serviceable parts inside the fixture. Do not open the housing or
attempt any repairs by yourself. In the unlikely event your fixture may require
service, please contact your nearest dealer.
In the event of serious operating problem, stop using the fixture
Immediately. Never try to repair the fixture by yourself. Repairs carried out by
unskilled people can lead to damage or malfunction. Please contact the nearest
authorized technical assistance center. Always use the same type spare parts.
2. Product specification
2/3/4/5/6/10 6 Channel Mode;
Dimmer, Strobe;
Ideal for Professional stages, Concerts, Clubs, Discotheques, Mobile Djs, etc.
Input Voltage:
Total Power consumption:
Beam Angle:
AC100V~240V,50/60Hz
140W
Stepless manual zoom from 10°to 40°
IP rating: IP20
LED Sources: 120W RGBW COB LED
Product Dimension: 43.5x37.5x26cm

- 3 -
Weight(N.W)：3.3Kgs
3. Checking Parts
Please check if the following parts are included:
1pc x 120W COB RGBW LED PAR64)
1pc x Power cable
1pc x User manual
1pc x Gel frame
2pcs x Bracket
4. Installation and Connection
The unit should be mounted via its screw holes on the bracket. Always ensure that
the unit is firmly fixed to avoid vibration and slipping while operating. Always ensure
that the structure to which you are attaching the unit is secure and is able to support a
weight of 10 times of the unit’s weight. Also always use a safety cable that can hold
12 times of the weight of the unit when installing the fixture.
The equipment must be fixed by professionals. And it must be fixed at a place where
is out of the touch of people and has no one pass by or under it. The unit should be
mounted in the height of 0 to 30m.
5. How to set the unit
Rear Panel
1Display : Show the various menus and the selected functions;
2LED indicator:

- 4 -
POWER
On
Power On
DMX
On
DMX input present
3Button:
MENU
To select the programming functions
DOWN
To go forward in the selected functions
UP
To go backward in the selected functions
ENTER
To confirm the selected functions
4Main input/output: PowerCon: link 8 units at 230/240V &
4 units at 110/120V
5DMX input/output: For DMX512 link, use 3-pin XLR plug cable to input
DMX signal, and to link the next unit.
The beam angle can be adjusted manually, stepless manual zoom from 10°to 40°
6. Main Function
To select any functions, press MENU button until the required one is shown on the
display. Select the fuction by ENTER button. Use DOWN and UP button to change
the mode. Once the required mode has been selected, press ENTER button to setup
or it will return to the main functions without any change after idling 8 seconds
automatically. Back to the functions without any change press MENU button.

- 5 -
The main function are shown below:
MENU
(Nenu)
Addr(set address)
enter
+/-
set address（001-512）
Chnd
(channel option)
enter
+/-
2Ch
Press
ENTER
to
confirm
(save
and exit)
3Ch
4CH
5CH
6CH
10Ch
Dind
(Dimmer scene)
enter
+/-
stda (standard scene)
stge(stage scene)
tv (TV scene)
aral(building scene)
thal(theatre scene)
DinC( set dimmer curve)
enter
+/-
Linn(linner dimmer)
Inue(exponential dimmer
curve)
Suar(logarithmic dimmer
curve)
Scur(S curve)
Freq (dimmer frequency)
enter
+/-
900Hz
1000Hz
1100Hz
1200Hz
1300Hz
1400Hz
1500Hz
2500Hz
4000Hz
5000Hz
10K
15K
20K
25K
Shnd(shows)
enter
+/-
Sh_1
Sh_2
Sh_3
Slnd(set master/slave)
enter
+/-
SL 1(slave unit)
Mast (master unit)
Lost(function when DMX
enter
+/-
Blac(keep black)

- 6 -
is lost)
Hold(keep last scene)
Auto(run auto)
Soun (sound mode)
Sens(sound sensitivity)
enter
+/-
S000-S099
Manu
Color preset
enter
+/-
CCT (CCT marco,
CCT1-CCT9)
Clor
Tenp (TEMPERATURE)
enter
00C-90C
Led (set backlight）
enter
on
off
disp (display reverse)
enter
on
off
Fhrs (working hours)
enter
total working hour
Ver (software version)
enter
software version
defa (set default)
enter
default
7. DMX512 configuration
Channel Mode:
2 Channel Mode
Channel
Function
Value
Details
CH1
Color marco
000-005
No function
006-017
Red
018-029
Amber
030-041
Warm yellow
042-053
yellow
054-065
green
066-077
Turquoise
078-089
Cyan
090-101
Blue
102-113
Lavender
114-125
Violet
126-137
Magenta

- 7 -
138-149
Pink
150-161
Warm white
162-173
white
174-185
Cold white
186-220
Color jumping from slow to fast
221-255
Color fading from slow to fast
CH2
CCT Macro
000-035
No function
036-055
CCT: 2800K
056-075
CCT: 3000K
076-095
CCT:3200K
096-115
CCT:3500K
116-135
CCT:4000K
136-155
CCT:4500K
156-175
CCT:5000K
176-195
CCT:5500K
196-215
CCT:6000K
216-235
CCT:6500K
236-255
CCT:7200K
3 Channel Mode
Channel
Function
Value
Details
CH1
Red Dimmer
000-255
0-100% dimming
CH2
Green Dimmer
000-255
0-100% dimming
CH3
Blue Dimmer
000-255
0-100% dimming
4 Channel Mode
Channel
Function
Value
Details
CH1
Red Dimmer
000-255
0-100% dimming
CH2
Green Dimmer
000-255
0-100% dimming
CH3
Blue Dimmer
000-255
0-100% dimming
CH4
White Dimmer
000-255
0-100% dimming

- 8 -
5 Channel Mode
Channel
Function
Value
Details
CH1
Master dimmer
000-255
0-100% dimming
CH2
Red Dimmer
000-255
0-100% dimming
CH3
Green Dimmer
000-255
0-100% dimming
CH4
Blue Dimmer
000-255
0-100% dimming
CH5
White Dimmer
000-255
0-100% dimming
10 Channel Mode
Channel
Value
Function
CH1
master dimming
000-255
Master Dimming 0-100%
CH2
Strobe
000-015
No Function (open)
016-095
Strobe （1HZ-25HZ Slow-Fast）
096-175
Strobe （1HZ Slow-Fast）
176-255
Random Strobe
CH3
Red dimming
000-255
0-100% dimming
CH4
Green dimming
000-255
0-100% dimming
CH5
Blue dimming
000-255
0-100% dimming
CH6
White dimming
000-255
0-100% dimming
CH7
Color Macro
000-005
No Function
006-017
Red
018-029
Amber
030-041
Warm Yellow
042-053
Yellow
Channel
Value
Function
CH1
master dimming
000-255
Master Dimming 0-100%
CH2
Strobe
000-015
No Function (open)
016-095
Strobe （1HZ-25HZ Slow-Fast）
096-175
Strobe （1HZ Slow-Fast）
176-255
Random Strobe
CH3
Red dimming
000-255
0-100% dimming
CH4
Green dimming
000-255
0-100% dimming
CH5
Blue dimming
000-255
0-100% dimming
CH6
White dimming
000-255
0-100% dimming
6 Channel Mode

- 9 -
054-065
Green
066-077
Turquoise
078-089
Cyan
090-101
Blue
102-113
Lavender
114-125
Mauve
126-137
Magenta
138-149
Pink
150-161
Warm White
162-173
White
174-185
Cold White
186-220
Color Jumping Slow->Fast
221-255
Color Fading Slow->Fast
CH8
CCT Macro
000-035
No Function
036-055
CCT:2800K
056-075
CCT:3000K
076-095
CCT:3200K
096-115
CCT:3500K
116-135
CCT:4000K
136-155
CCT:4500K
156-175
CCT:5000K
176-195
CCT:5500K
196-215
CCT:6000K
216-235
CCT:6500K
236-255
CCT:7200K
CH9
Auto Program
000-015
No Function
016-095
Show1：LED color jumping change
096-175
Show2：LED color strobe
176-255
Show3：LED color fading
CH10
Auto
Speed/sound
000-250
Sound Off,AutoSpeed Slow->Fast
016-095
Sound ON
8. Troubleshooting
Following are a few common problems that may occur during operation. Here are
some suggestions for easy troubleshooting:
A. The fixture does not work, no light
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.

- 10 -
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if link
properly.
2. If the DMX LED is on and no response to the channel, check the address settings
and DMX polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on
PCB of the fixture or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or run alongside to high voltage cables that may
cause damage or interference to DMX interface circuit.
9. Fixture Cleaning
The cleaning of internal must be carried out periodically to optimize light output.
Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surrounding can cause greater accumulation of dirt on the
fixture’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 15 days. Clean the internal optics at least
every 30/60 days.
