LDR Samba A100 CM User manual

01106250 SambaA100CM
180WRGBWLED
100/260V,DMX512
istruzioniperl'uso
operatinginstructions
Bedienungsanleitung
instruccionesdemanejo
moded'emploi
gebruiksaanwijzing
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredomnItaly.tel+390376771777‐fax+390376772140‐email[email protected]

SAMBAA100RGBW180WLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
1
ENGLISH–TABLEOFCONTENTS

1.Importantsafetynorms...............................................................2
2.Checkpackingcontents……………………………………………………..………3
3.Weightanddimensions................................................................4
4.Importantnoticebeforetheinstallation/installation...................4
5.Wiring.........................................................................................4
6.Voltage..........................................................................................5
7.Frequency.....................................................................................5
8.Connecttothepowersupply……………………………………………………..5
9.Controlfunctionsandoperation...................................................5
9.1DMXormanualmode.................................................5
9.2DMXaddress...............................................................6
9.3DimmerResolution(8/16bit).....................................6
9.4LostDMXsignal...........................................................6
9.5Strobe.........................................................................6
9.6StrobeSpeed...............................................................6
9.7DimmingCurve...........................................................7
9.8Cut‐offDimmingResponse.........................................7
9.9DimmingBehaviour....................................................7
9.10FanSetting................................................................8
9.11LCDScreenIllumination............................................8
9.12RedColourIntensity..................................................8
9.13GreenColourIntensity..............................................8
9.14BlueColourIntensity.................................................8
9.15WhiteColourIntensity..............................................9
9.16TemperatureControl................................................9
9.17SoftwareVersion.......................................................9
9.18ProorBasicControl..................................................9
9.19FactorySettings........................................................9
9.20IDREMOTO..............................................................9
9.21Calibration...............................................................10
9.22ExitHiddenMenu...................................................10
10.SoftwareUpgrade–REMOTOControlDevice...........................10
11.CleaningandMaintenance.......................................................10
12.SpareParts................................................................................10
13.Warranty...................................................................................10
SUMMARYOFCONTROLSANDFUNCTIONS
14.SummaryofControlsandFunctions.........................................11
15.DMXCharts...............................................................................12
15.1DMXChart1............................................................12
15.2DMXChart2............................................................12
15.3DMXChart3............................................................12
15.4DMXChart4............................................................13

LDRConformityCertificate–CertificatodiConformità–Konformitätserklärung14
Complaintform–Modulodireclamo–Reklamationsformular………………………….15
WEEEDirective–DirettivaRAEE–WEEERichtlinie……………………………………………16

SAMBAA100RGBW180WLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
2
ENGLISH
ThankyouforchoosingaqualityproductfromLucidellaRibaltasrl.Wetrustourproductsandservices
meetyourrequirements,butifnotpleasecontactusdirectlyusingtheattachedfeedbackformtohelp
usimproveourservicequality.
Thisproducthasbeenmanufacturedwithgreatcareandleftourfactoryinperfectconditions,butifit
hasbeendamagedintransportpleasecontactyourdealerinthefirstinstance.Afeedbackformis
appended.Ourwarrantycoversallmanufacturingandcomponentdefectsforoneyearfromthedate
youpurchasedtheproduct.
Ourproductsaredesignedfortheuseofprofessionaltechniciansandoperatorsonly,andthe
instructionsprovidedhereensureasafeandcorrectoperationofthisproduct.LucidellaRibaltasrlwill
notacceptanyresponsibilitywheredamagehasbeencausedtotheproductorpersonsthrough
improperuseoftheproductand/ornon‐compliancewiththeregulationsdescribedherein.

IMPORTANT:Readtheseuserinstructionsbeforeusingthislightingunit

Theinstructionsgivenhereensureasafeandcorrectusageofthisproduct.Auser’sfailuretocomply
withtheinstallation,operating,maintenanceandsafetyproceduresmentionedinthismanual,aswell
asthosegenerallyapplicabletothislightingequipment,maycausetheunitnottoperformasexpected.
LucidellaRibaltaacceptsnoliabilityfordirect,indirect,incidental,special,orconsequentialdamages
resultingfromthecustomer’sfailuretofollowtheinstallation,operating,maintenanceandsafety
proceduresinthismanualorthosegenerallyapplicabletolightingequipment.
Thelimitationextendstodamagesforpersonalinjury,propertydamage,lossofoperations,lossof
profits,lossofproductorlossoftime,whetherincurredinbythecustomer,thecustomer’semployees
orathirdparty.
Apartfromtheinstructionsgivenonthismanual,allrelevantsafetyandhealthstandardsofthe
appropriateDirectivesofthecountrywheretheunitwillbeinstalledmustbecompliedwith.


1.IMPORTANTSAFETYNORMS
Thisproductisaprofessionallightingfixture,namelyafloodlight/cyclorama,fittedwithaLED
lightsource,whichcanonlybeoperatedbyprofessionalstaff
Thisproductmustbefittedwithasecondaryfixingsystemsuchasasafetychainorbond.Should
thisnotbesuppliedasastandardaccessory,pleasemakesureyoubuyitseparatelyandinstallit
beforeusingtheproduct
Warning,highvoltageignition.Disconnecttheunitfrompowerbeforeservicing
Continuousmainspowerisrequiredforthisspotlightasaninternaldimmercontrolsthe
intensityviaDMXorlocalrotaryknob.
Useofaphasecontroldimmedmainssupplymaydamagetheinternalelectronics
Thisproductfeaturesfan‐assistedventilation.Makesureyoudonotcoverthefansorobstruct
theairflowatanytime
Makesureallfansareworkingcorrectlyatanyonetime.Shouldyoudetecteventheslightest
malfunction,switchtheluminaireoffandcarryoutthenecessaryservicing.Replacethefansif
necessary
ThisproductisratedIP20andisthereforedesignedforinterioruseonly.Fordetailson
maximumambienttemperatureandtiltanglepleaserefertowhatindicatedontheproduct
labelorscreen‐printingontherearoftheunit
Repairingandreplacementofanycomponentofthisproductmustbecarriedoutexclusivelyby
professionalpersonnelinconformitywiththerelevantsafetyandhealthstandardsandonlywith
originalLucidellaRibaltasrlcomponents

SAMBAA100RGBW180WLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
3
Replacementofanypartofthewiringsystemmustbecarriedoutexclusivelybyprofessional
personnelincompliancewiththeoriginalwiringdiagramandwithcomponentsidenticaltoor
compatiblewiththoseoriginallyfitted
Installationofthisproductmustbeexclusivelycarriedoutbyprofessionalpersonnelin
compliancewiththesafetynormsinforceinthecountrywheretheproductisused




WARNING:DANGEROFELECTRICALSHOCK
DONOTOPERATEONLIVEEQUIPMENT
Disconnectpowerbeforeopeningthisfixturetoaccessitslightsourceorelectronics.
ThereplacementoftheLEDsourceoranyofitselectroniccomponentscanbecarriedout
exclusivelybyprofessionalpersonneluponLDR’swrittenauthorizationandonlywithoriginal
LucidellaRibaltasrlcomponents.Failuretoobtainthemanufacturer’sauthorizationtocarryout
thereplacement/repair,willimmediatelyinvalidatetheproduct’swarranty




WARNING:EYEDAMAGEHAZARD
Makesurethisfixtureisinstalledsoastoavoidprolongeddirectstaringatitsoperatinglightsource
(LED)fromadistanceoflessthan7m/23ft.




WARNING:FIREHAZARD
Neverlocatethisfixtureonanyflammablesurface.
Minimumdistanceofanypartofthebodyoftheluminairefromanyflammablesurfaceor
object:0,5m/20in
Minimumdistancefromlitsurface,pleaserefertoproductlabel
Makesurethemainspowersupplythefixturewillbeconnectedtoisprotectedbyasuitable
thermalmagneticcircuitbreaker


2. CHECKPACKINGCONTENTS
Uponopeningthepackaging,pleasemakesureitcontainsthefollowing:
lightingunitinthechosenmodel
160cmmainspowercablewithfittedNeutrikPowerConblueconnector

Shouldoneormoreitemsmiss,wekindlyaskyoutocontactyourdealerimmediately.


SAMBAA100RGBW180WLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
4

3.WEIGHTANDDIMENSIONS

SAMBAA100CMRGBW 
netweight:5,5kg
grossweight:7,9kg
packingdim.:48x45x30hcm


4. IMPORTANTNOTICEBEFORETHEINSTALLATION/INSTALLATION
Beforeinstallingthisfixturecheckitsweightontheproductlabelandtheweightofeachaccessoryyou
areaddingandmakesurethestructureyouareinstallingittowithstandsthetotalweight.

ThemountingstirrupisdesignedtoallowthecycloramatobesuspendedfromaboveusingaC‐
clamporsimilar,laidonthegroundatanangleorsupportedonastandorbracketfrombelow.
Note:thecyclorama’slocationmustprovidesuitableventilationfortheLEDmodule.
Thebeamdistribution(peak/flat)isfixedandbeamshapingisalsonotavailableonthisfixture.
Ifnotsuppliedchooseasuitableclamporspigotandmakesureitiscorrectlyfixedandstrongly
tightenedtothestirrupaccordingtotheclamp’s/spigotmanufacturer’sinstructions
Ifnotsuppliedchooseasuitablesafetycableorbond.Clampittotheeyeletprovidedontheupper
rearpartoftheluminaire,runittwicearoundthestirrupandthestructuretheluminaireishungto
soastobondthemtogetherandclosetheloop.
Whentiltingtheunitmakesuretheknobblockingthestirrupisstronglytightenedatanytimeand
thattheluminairecanholdthedesiredtiltangle


5. WIRING
Beforebeingconnectedtothemainspower,thisunitmayneedtobewiredwithasuitableplugifnot
alreadyinstalled.Makesuretheplugyouareusingisratedfortheproduct’spowerloadandit
conformstotherelevantEU/ULelectricalstandards.

MakesuretheplugyouarefittingwithstandstheLEDpowerload.
Thisfixturemustbegrounded
Toperformacorrectwiring,pleasenotethatthecoresinthismainsleadarecolour‐codedas
follows:
Ground:green+yellow–Neutral:blue‐Phase:brown

Incasethecoloursofthewiresdonotcorrespondtothecolouroftheconnectionpointsonyourplug,
pleaseproceedasfollows:
Thegreenorgreenandyellowwiremustbeconnectedtotheconnectionpointmarkedwiththe
letterEorwiththesymbol orcolouredingreenoringreen‐yellow
ThebluewiremustbeconnectedtotheconnectionpointmarkedwiththeletterNorcoloured
inblack
ThebrownwiremustbeconnectedtotheconnectionpointmarkedwiththeletterLorcoloured
inred

Beforeyoufinallypositionthisproductforuse,temporarilyconnectittoaproperlyfused
powersupplytochecktheLEDworkscorrectly

SAMBAA100RGBW180WLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
5
6. VOLTAGE
Beforeoperatingthisunitpleaserefertotheproductlabelmountedatthebackoftheluminaireto
checkyouareoperatingwiththecorrectvoltage.
TheSAMBAA100CMcanbeoperatedbetween90Vand260VandtheelectronicPSUinsidethefixture
willautomaticallyswitchtotheavailablevoltage.


7. FREQUENCY
FrequencyonthisproductisautomaticallyselectedbytheelectronicPSU(50/60Hz)

8.CONNECTTOTHEPOWERSUPPLY
Connecttheunittoacontinuousmainspowersource
Makesurethepowersupplyisprotectedbyasuitablethermalmagneticcircuitbreaker
Thisfixturemustbegrounded


9.CONTROLFUNCTIONSANDOPERATION
OPERATION:LCDdisplayforDMXaddress,systemsetupandstatusdetails.
POWER:powerLEDstatusindicator,redcolour.ON=power
DMX:DMXLEDstatusindicator,greencolour.LEDOFF=DMXOFFandmanualcontrolactivated,LED
ON=DMXMODEactivatedwithnoDMXsignal,FLASHINGLED=receivingDMX
MENU:rotaryswitchselectortoselectandmodifytheoperationalmodes.Turnleftorrighttonavigate
throughthemenuandpresstoselectortoconfirm
DMXIN:inputDMXsignal(pin1=0,pin2=DATA‐,pin3=DATA+).
DMXOUT:LoopthroughDMXsignaloutput
POWERIN:Mainspowerinput
POWEROUT:Mainspoweroutput

ThereareseventeendifferentmenustocontrolthesettingsoftheSAMBARGBWLED.Therotary
selectorisusedtoadjustthesettingsandtonavigatethroughthemenu.Turnleftorrighttoselectthe
menuandpushtoaccessortoconfirmtheselecteddataorfunctions.Toexittheselectedmenus
withoutsavingthedata,presstherotaryselectorforatleast1second.

9.1DMXORMANUAL(Mode)
SelecttheLEDcontrolmodebetweenDMX(factorysetting)andmanual.Tochangethecontrolmode
pressoncetherotaryselectoruntilanarrow()appearsonthemenu.Turntheselectortotherightor
thelefttoselectthedesiredmodeofoperationandpresstoconfirmyourselection.




TaptherotaryselectorandtheLCDscreenwilldisplaythemodestatusandthecurrentvalue:








M: Manual
XX % XXX
M: DMX
XX %
1 Mode
DMX
1 Mode
MANUAL
TAPTHEROTARY
SELECTORTODISPLAY
THEVALUE
TAPTHEROTARY
SELECTORTODISPLAY
THEVALUE
00%=LEDOFF
100%=LEDFULL
00%(000)=LEDOFF
100%(FFF)=LEDFULL
PRESSTOACTIVATE
THEMENU
ANARROWSHOULD
APPEAR
1 Mode
DMX
1 Mode
DMX 
1 Mode
MANUAL 
TURNTOSELECT
MANUALORDMX
ANDPRESSTO
CONFIRM

SAMBAA100RGBW180WLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
6
9.2 DMXADDRESS(Addr)
ItallowstoselecttheinitialDMXstartingaddresstoremotelycontroltheLEDfunctions.Tochangethe
initialDMXaddresspresstherotaryswitchuntilanarrowappears,thenturntochangetothedesired
DMXstartingaddress.Presstoconfirmyourselection.Factorysettingis001.





9.3DIMMERRESOLUTION(8/16b)
Thedimmingresolutioncanbecontrolledat8bitsfromoneDMXchannelto16bitswith2DMX
channels.
Factorysettingis8Bit.





9.4 LOSTDMXSIGNAL(DMXMem)
IncaseofsignalfailurethisfunctionallowstostoreinmemorythelastDMXvalue.FactorysettingisON
Threeoptionsareavailable:












9.5STROBE(Strobe)
Thisfunctionenablestheactivationofthestrobefunction.FactorysettingisDISABLE.





9.6 STROBESPEED(SetStr)
Itallowstosetthestrobespeed.Thismenuisnotactivewhenthestrobefunctionisdisabledorwhenit
isremotelycontrolledthroughDMX.FactorysettingisOPEN.







2 Addr
001
2 Addr
001 
2 Addr
### 
TURNTOASSIGNTHE
DMXADDRESSAND
PRESSTOCONFIRM
3 8/16b
8 BITS
PRESSTHEROTARY
SELECTORTO
ACTIVATE
3 8/16b
8 BITS 
3 8/16b
16 BITS 
TURNTOSELECT8OR
16BITSANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
4 DMXMem
ON
5 Strobe
DISABLE
5 Strobe
DISABLE 
5 Strobe
ENABLE 
TURNTOENABLEOR
DISABLESTROBEAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU
ANARROWSHOULD
APPEAR
LASTSCENEHOLD
4 DMXMem
ON 
4 DMXMem
OFF=80% 
DIMTHELEDTO80%OF
ITSMAXIMUMPOWER
4 DMXMem
OFF=00% 
DIMTHELEDTO0%

SAMBAA100RGBW180WLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
7












9.7 DIMMINGCURVE(Curves)
ThisfunctionallowstoselectaresponsecurvefortheSambaLED.Achoiceoftwocurvesisavailable:
SquareandLinear.FactoringsettingisSQUARE.









9.8 CUTOFFDIMMINGRESPONSE(CutOff)
ThisfunctionallowstoselecttheLEDbehavioursimulatingatungstenorhalogenlampduringthe
dimmingcutoff.
FactorysettingisSLOW.









9.9DIMMINGBEHAVIOUR(Smooth)
ThisfunctionallowstosettheLEDdimmingresponse.FactorysettingisNORMAL.











PRESSTOACTIVATE
THEMENU
ANARROWSHOULD
APPEAR
6 SetStr
OPEN
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
7 Curves
SQUARE
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
8 CutOff
SLOW
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
9 Smooth
NORMAL
9 Smooth
FAST 
IMMEDIATEDIMMING
RESPONSE
WITHSTROBEENABLE
THELIGHTISSETTOON
6 SetStr
OPEN 
6 SetStr
SPEED # 
CHOOSETHESTROBE
SPEEDVALUEFROM
1(SLOW)TO10(FAST)
6 SetStr
CLOSED 
WITHSTROBEENABLE
THELIGHTISSETTO
OFF
SQUARETOINCREASE
VOLTAGERESPONSEAT
LOWERVALUE
7 Curves
SQUARE 
7 Curves
LINEAR 
LINEARDIMMING
CONTROL
SOFTLEDDIMMINGAT
SHUTDOWN
8 CutOff
SLOW 
8 CutOff
FAST 
DIRECTDIMMING
RESPONSEATSHUT
DOWN
FASTDIMMING
RESPONSE=150ms
9 Smooth
NORMAL 
9 Smooth
SLOW 
SLOWDIMMING
RESPONSE=300ms

SAMBAA100RGBW180WLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
8
9.10FANSETTING(Fan)
Thisfunctionallowstosetthefanresponse.Achoiceofthreemodesisavailable:Automatic,Silentor
Steady.WhenfanisinAutomode,thespeedisregulatedbytheLEDtemperature.WheninSilentmode
thefanrunsslowlytoreducethenoise;wheninSteadymodethefanrunsatconstantspeed,halfway
betweentheminimumandmaximumspeed.Inallcases,iftheLEDtemperatureexceedsthemaximum
admittedvalue,theLEDisprotectedbyade‐ratingsecuritysystem.FactorysettingisAUTO.












9.11LCDSCREENILLUMINATION(BackL)
ThisfunctionallowstoturnofftheLCDbacklight,theLEDPOWERandLEDDMXafter1’30”fromlast
setting.FactorysettingisAutoOFF.








9.12REDCOLOURINTENSITY(Red)
Thisfunctionallowstosettheintensityoftheredcolourformanualmode.Selectingthemanualmode,
100%isautomaticallyset.




9.13GREENCOLOURINTENSITY(Green)
Thisfunctionallowstosettheintensityofthegreencolourformanualmode.Selectingthemanual
mode,100%isautomaticallyset.




9.14BLUECOLOURINTENSITY(Blue)
Thisfunctionallowstosettheintensityofthebluecolourformanualmode.Selectingthemanualmode,
100%isautomaticallyset.




11 BackL
AutoOFF
11 BackL
AutoOFF 
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
LCDBACKLIGHTOFF
AFTER1MINUTEAND
30SECONDS
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
10 Fan
AUTO
10 Fan
STEADY 
CONSTANTFANSPEED
FANSPEEDIS
REGULATEDBYLED
TEMPERATURE
10 Fan
AUTO 
10 Fan
SILENT 
SLOWFANSPEEDTO
REDUCETHENOISE
11 BackL
ON 
LCDBACKLIGHT
ALWAYSON
12 Red
###%
12 Red
###% 
12 Red
###% 
TURNTOSELECTTHE
REDINTENSITYAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
13 Green
###%
13 Green
###% 
13 Green
###% 
TURNTOSELECTTHE
GREENINTENSITY
ANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
14 Blue
###%
14 Blue
###% 
14 Blue
###% 
TURNTOSELECTTHE
BLUEINTENSITYAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR

SAMBAA100RGBW180WLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
9
9.15 WHITECOLOURINTENSITY(White)
Thisfunctionallowstosettheintensityofthewhitecolourformanualmode.Selectingthemanual
mode,100%isautomaticallyset.





9.16TEMPERATURECONTROL(Tled)
ThisfunctionallowstovisualizetheLEDtemperature.Factorysettingis°C.





9.17SOFTWAREVERSION(SwVer)
Thisfunctionallowstovisualizethesoftwareversion.

TherearealsofourdifferenthiddenmenuswhichallowtoselecttheadvancedsettingsoftheSAMBA
LED.ToactivatethisfunctionturnOFFandONtheSambabypressingtherotaryswitchatpoweron.

9.18PROorBASICCONTROL(ProBasic)
ThePRO‐BASICcontrolisaspecialfunctionwhichallowstolimittheaccesstothecontrolmenu.Select
ProBasicwiththerotaryswitchandpresstoaccessthemenu.
Select:
PRO,toenableaccesstoallthefunctions
BASIC,tolimitaccesstofunctions9.1DMXorManualMode,9.2DMXaddress,9.12‐9.13‐9.14‐9.15
RGBWColourintensityinmanualmode,9.16TemperatureControland9.17Softwareversion.
FactorysettingisPRO.




9.19FACTORYSETTINGS(Reset)
TheRESETcontrolisaspecialfunctionwhichallowstoRESETtheproducttofactorysettings.




9.20IDREMOTO(IDRem)
ItallowstoselecttheIDnumbertoconnecttheSambatoRemototouploadanddownloadfirmware.To
changetheinitialIDpresstherotaryswitchuntilanarrowappears,thenturntochangetothedesired
IDnumber.Presstoconfirmyourselection.ItispossibletoselectanIDnumberfrom0to250.IfID
number=0remotecontrolisnotactive.Factorysettingis000.






16 Tled
##°C
16 Tled
##°C 
16 Tled
###°F 
TURNTOSELECT°C
OR°FANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
Choose
ProBasic
MenuType
PRO 
MenuType
BASIC 
TURNTOSELECTPRO
ORBASICMENUAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
Choose
Reset
Are You
SURE?
MenuType
BASIC 
PRESSTOCONFIRM
THERESET
PRESSTOACTIVATE
THEMENU
Choose
ID Rem
ID Rem
000 
ID Rem
### 
TURNTOASSIGNTHE
IDNUMBERAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
15 White
###%
15 White
###% 
15 White
###% 
TURNTOSELECTTHE
WHITEINTENSITY
ANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU,
ANARROWSHOULD
APPEAR
