LDR Astro 250 Wi-fi RGBW User manual

01207190
01207390
Astro250Wi‐fiRGBW
DMX512+RDMLED
Astro250Wi‐fiRGBWHP
DMX512+RDMLED
istruzioniperl'uso
operatinginstructions
Bedienungsanleitung
instruccionesde
manejo
moded'emploi
gebruiksaanwijzing
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredomnItaly.tel+390376771777‐fax+390376772140‐email[email protected]

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
1
ENGLISH – TABLE OF CONTENTS
1.Important safety norms ………………………………………………………………………. page 3
2.Check packing content………………………………………………………………………… page 4
3.Mounting the spigot…………………………………………………..…….................... page 4
4.Mounting the iris diaphragm …………………………………………….………………. page 4
5.Black Shutter blades …………………………………………………………………………. page 5
6.Adjusting the yoke ……………………………………………………………………..…….. page 5
7.Wiring ………….…………………………………………………………………………………… page 5
8.Voltage ………………………………………..…….……………………………………………. page 6
9.Local Control panel and operation……………………………………….…………… page 6
10.Menu ………………………………………………………………………………………………... page 6
10.1 DMX or manual mode page 6
10.2 DMX address page 7
10.3 Dimmer Resolution page 7
10.4 Lost DMX Signal page 8
10.5 Strobe page 8
10.6 Strobe Speed page 8
10.7 Dimming curve page 9
10.8 Cut off dimming response page 9
10.9 Dimming behaviour page 9
10.10 Fan Setting page 10
10.11 LCD Screen Illumination page 10
10.12 Red colour intesity page 10
10.13 Green colour intensity page 11
10.14 Blue colour intensity page 11
10.15 White colour intensity page 11
10.16 Temperature control page 11
10.17 Software version page 11
10.18 Net page 11
10.19 Sub-Net page 12
10.20 Universe page 12
10.21.Manual dimmer Type page 12
10.22-a Pro or basic control page 12
10.23-b Factory setting page 12
10.24-c ID REMOTO page 13
10.25-d Calibration page 13
10.26-e IP address page 13
10.27-f Subnet Mask page 14
10.28-g Service set identifier( SSID) page 14
10.29-H Password page 14
10.30-i Exit Hidden menu page 14
11. App settings from LDR mobile controller………………………………………………..page 15
12. App settings and operations from user’s android mobile controller……….page 16
12.1 Settings page 19
12.2 Operationg the Astro Wi fi page 20
12.3 Creating, storing and deleting Colours page 21

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
2
13.App settings and operations from user’s IOs mobile controller………………………..page 23
13.1 Operating the Astro wi fi page 25
13.2 Creating, storing and deleting colours page 25
14. Universal 360° rotating mobile device holder supplier…………………………………….page 27
15. Positioning your device mobile………………………………………………………………………..page 27
16. Recharging your mobile battery……………..………………………………………………………..page 28
17. Clamp-on mobile digital dimmer………………………………………………………………………page 28
18. Focusing……………………………………………………………………………………………………………page 28
19. Cleaning and maintenance……………………………………………………………………………….page 28
20. Spare sparts……………………………………………………………………………………………………..page 29
21. Warranty………………………………………………………………………………………………………….page 29
22. Available accessories………………………………………………………………………………………. page 29
23. Summery of controls and functions………………………………………………………………….page 30
24. DMX charts……………………………………………………………………………………………………….page 31
24.1 DMX CHART 1 ( 16 bit dimmer and strobe disabled) page 31
24.2 DMX CHART 2( 16 bit dimmer inabled, strobe disabled)page 31
24.3 DMX CHART 3( strobe functions inabled, 8 bit dimmer) page 32
24.4 DIMX CHART 4 ( 16 bit dimmer and strobe inabled) page 33
LDR Conformity Certificate – Certificato di Conformità – Konformitätserklärung page 34
Complaint form – Modulo di reclamo – Reklamationsformular …………………………. page 35
WEEE Directive – Direttiva RAEE – WEEE Richtlinie …………………………………………… page 36

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
3
ENGLISH
Thank you for choosing a quality product from Luci della Ribalta srl. We trust our products and
services meet your requirements, but if not please contact us directly using the attached feedback
form to help us improve our service quality.
This product has been manufactured with great care and left our factory in perfect conditions,
but if it has been damaged in transport please contact your dealer in the first instance. A feedback
form is appended. Our warranty covers all manufacturing and component defects for one year from
the date you purchased the product.
Our products are designed for the use of professional technicians, and the instructions
provided here ensure safe and correct operation of this product. Luci della Ribalta srl will not accept
any responsibility where damage has been caused to the product or persons through improper use
of the product and/or non-compliance with the regulations described herein.
IMPORTANT: Read these user instructions before using the lighting unit
The instructions given here ensure a safe and correct usage of this product. A user’s failure to
comply with the installation, operating, maintenance and safety procedures mentioned in this
manual, as well as those generally applicable to this lighting equipment, may cause the unit not to
perform as expected.
Luci della Ribalta accepts no liability for direct, indirect, incidental, special, or consequential
damages resulting from the customer’s failure to follow the installation, operating, maintenance
and safety procedures in this manual or those generally applicable to lighting equipment.
The limitation extends to damages for personal injury, property damage, loss of operations,
loss of profits, loss of product or loss of time, whether incurred in by the customer, the customer’s
employees or a third party.
Apart from the instructions given on this manual, all relevant safety and health standards of
the appropriate EU Directives must be complied with.
1. IMPORTANT SAFETY NORMS
•Warning, high voltage ignition. Disconnect the unit from power before servicing
•Continuous mains power is required for this spotlight as an internal dimmer controls
the intensity via DMX or local rotary knob. An accessory moving manual dimmer is
furthermore available for positioning on the side grab handles.
•Use of a phase control dimmed mains supply may damage the internal electronics.
•This product features fan-assisted ventilation. Make sure you do not cover the fans
or obstruct the air flow at any one time.
•Make sure the fans are working correctly. Should you detect even the slightest
malfunction, switch the luminaire off and carry out the necessary servicing. Replace the fans
if necessary.
•This product is rated IP 20 and is therefore designed for interior use only. For details
on maximum ambient temperature, minimum distance from flammable objects and tilt
angle, please refer to what indicated on the product label.

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
4
•Repairing and replacement of any component of this product must be carried out
exclusively by professional personnel in conformity with the relevant safety and health
standards and only with original Luci della Ribalta srl components.
•Replacement of any part of the wiring system must be carried out exclusively by
professional personnel in compliance with the original wiring diagram and with components
identical to or compatible with those originally fitted.
•Installation of this product must be exclusively carried out by professional personnel
in compliance with the safety norms in force in the country where the product is used.
2. CHECK PACKING CONTENT
A. Standard followspot B. Kit followspot
Astro followspot in the chosen model Astro f.spot in the chosen model in flight case
Separate mains power cable with PowerCon Separate mains power cable with PowerCon
Ø28mm spigot for followspot Ø28mm spigot for followspot
Iris diaphragm Iris diaphragm
Clamp-on digital dimmer A20702071 Clamp-on digital dimmer A20702071
Universal mobile device holder A20702073 Universal mobile device holder A20702073
Black follow-spot tripod
3. MOUNTING THE SPIGOT
A spigot is supplied in standard delivery for you to tripod-mount your followspot.
•Make sure the tripod you are going to use can withstand the product load as
indicated on the product’s label
•Make sure the tripod you are going to use features a top aperture over 28mm dia.
•Remove the M12 nut and the washer from the spigot.
•Insert the spigot in the central hole of the yoke of the followspot from beneath the
yoke.
•Add the plain screw and the M12 self- locking nut and tighten the nut with a suitable
tool.
•Mount the followspot on the tripod.
4. MOUNTING THE IRIS DIAPHRAGM - supplied
The iris diaphragm supplied with the followspot has 20 leaves to size the beam from a
maximum aperture of 68mm to a minimum of 5mm. A black-out iris diaphragm is available to
special order.
•Using a Phillips screw-driver remove the two cross-head screws from the sides of the
iris plate.
•Slide the diaphragm in the gate area.

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
5
•Fix the iris in position by tightening the previously removed screws
Important notice: do not leave the iris closed for over 5 minutes while the LED is on
FAILURE TO COMPLY WITH THE ABOVE NOTICE MAY CAUSE THE IRIS AND THE FOLLOWSPOT
TO SUFFER MAJOR HEAT DAMAGES AND WILL INVALIDATE THE PRODUCT WARRANTY
5. BLACK SHUTTER BLADES (accessory, part nr. R80208019 x 4)
Black shutter blades are not supplied with the unit but are available as separate accessory.
They are sold as single items and relevant part number is R80208019, 4 are required.
6. ADJUSTING THE YOKE
This followspot is provided with a yoke balancing adjustment. The balancing point is
factory set for the standard product configuration supplied (without colour). However, should
you need to adjust the balancing, please follow the procedure here below:
•The followspot must be mounted on the tripod stand with all relevant accessories
attached.
•Using a Phillips screw driver, loosen the 2 M5 screws on each side of the yoke.
•Gently slide the followspot backwards or forwards to the required position.
•Make sure the yoke is correctly aligned horizontally.
•Tighten the 4 M5 screws
7. WIRING
Before being connected to the mains power, this unit may need to be wired with a suitable
plug if not already installed. Make sure the plug you are using is rated for the proper power load.
This fixture must be grounded
Ensure the plug conforms to the relevant EU/UL or local electrical standards
To perform a correct wiring, please note that the cores in this mains lead are colour-coded as
follows:
Ground: green+yellow –Neutral: blue -Phase: brown
In case the colours of the wires do not correspond to the colour of the connection points on
your plug, please proceed as follows:
•The green or green and yellow wire must be connected to the connection point
marked with the letter E or with the symbol or coloured in green or in green-yellow
•The blue wire must be connected to the connection point marked with the letter N
or coloured in black

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
6
•The brown wire must be connected to the connection point marked with the letter L
or coloured in red
Before you finally position this product for use, temporarily connect it to a properly fused
power supply to check the unit works correctly.
8. VOLTAGE
Before operating this unit please refer to the product label mounted at the back of the
luminaire to check you are operating with the correct voltage. The Astro 250 LED can be operated
between 100V and 260 VAC.
9. LOCAL CONTROL PANEL AND OPERATION
OPERATION: LCD display for DMX address, system setup and status details.
POWER: power LED status indicator , red colour. ON= power
DMX: DMX LED status indicator, green colour. LED OFF = DMX OFF and manual control
activated , LED ON = DMX MODE activated with no DMX signal, FLASHING LED = receiving
DMX
MENU: rotary switch selector to select and modify the operational modes.
Turn left or right to navigate through the menu and press to select or to confirm
DMX IN: input DMX signal (pin1=0 , pin2= DATA- , pin3=DATA+ ).
DMX OUT : Loop through DMX signal output
POWER IN: Mains power input
POWER OUT: Mains power output
10. MENU
There are twenty-one different menus to control the settings of ASTRO RGBW LED. The rotary
selector is used to adjust the settings and to navigate through the menu. Turn left or right to
select the menu and push to access or to confirm the selected data or functions. To exit the
selected menus without saving the data, press the rotary selector for at least 1 second.
10.1 Wi-Fi, DMX OR MANUAL (Mode) :
Colour control of the Astro is achieved through a totally innovative technology. The Astro Wi-Fi
generates a proprietary Wi-Fi access which will recognize one device only and whose range reaches
12m. Access is to the Wi-Fi access is protected by password. A universal mobile phone holder
(3.5/6.5in), rotatable over 360°, supplied with the Astro and clamped on the side bar, allows the
installation of a mobile device, either IOS or Android to take control of the followspot.
If the Astro was purchased complete with the LDR controller A20702074 Smartphone Honor 75
Black, pre-loaded with the Android Art-Net Controller app, relevant settings and libraries,
(available as an optional accessory), it is ready to be operated.

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
7
In case you are using your own mobile device, please refer to chapter 12 and 13 of this manual for
all the necessary steps needed to set up the control system
Select the LED control mode between Wi-Fi (factory setting – if you want to control the colour
mixing through a mobile device), DMX and manual. To change the control mode press once the
rotary selector until an arrow () appears on the menu. Turn the selector to the right or the left to
select the desired mode of operation and press to confirm your selection.
In order to work properly with an external mobile device the Astro must be set in Wi-Fi mode at the
default settings. If default settings have been changed, please refer to chapter 5.23-B to reset the
product to factory settings.
Tap the rotary selector and the LCD screen will display the mode status and the current value:
10.2 DMX ADDRESS (Addr) :
It allows to select the initial DMX starting address to remotely control the LED functions. To change
the initial DMX address press the rotary switch until an arrow appears, then turn to change to the
desired DMX starting address. Press to confirm your selection. Factory setting is 001.
10.3 DIMMER RESOLUTION (8/16b) :
The dimming resolution can be controlled at 8 bits from one DMX channel to 16 bits with 2 DMX
channels.
2 Addr
001
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
1 Mode
WIFI_D
1 Mode
WIFI_D ←
1 Mode
DMX ←
TURN TO SELECT
Wi-Fi, MANUAL OR
DMX AND PRESS TO
CONFIRM
2 Addr
001 ←
2 Addr
### ←
TURN TO ASSIGN THE
DMX ADDRESS AND
PRESS TO CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
M: DMX
XX %
M: WIFI_D
XX %
1 Mode
WIFI_D
1 Mode
DMX
TAP THE ROTARY
SELECTOR TO DISPLAY
THE VALUE
TAP THE ROTARY
SELECTOR TO DISPLAY
THE VALUE
00 % = LED OFF
100 % = LED FULL
00 % = LED OFF
100 % = LED FULL
M:Manual
XX % XXX
1 Mode
MANUAL
TAP THE ROTARY
SELECTOR TO DISPLAY
THE VALUE
00 % (000) = LED OFF
100% (FFF) = LED FULL

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
8
Factory setting is 8 Bit.
10.4 LOST DMX SIGNAL (DMXMem) :
In case of signal failure this function allows to store in memory the last DMX value. This function is
forced ON in Wi-Fi mode. Factory setting is ON.
Three options are available :
10.5 STROBE (Strobe) :
This function allows to activate the strobe function . Factory setting is DISABLE.
10.6 STROBE SPEED (SetStr) :
It allows to set the strobe speed. This menu is not active when the strobe function is disabled or
when it is remotely controlled through DMX. Factory setting is OPEN .
3 8/16b
8 BITS
PRESS THE ROTARY
SELECTOR TO
ACTIVATE
3 8/16b
8 BITS ←
3 8/16b
16 BITS ←
TURN TO SELECT 8
OR 16 BITS AND
PRESS TO CONFIRM
5 Strobe
DISABLE
5 Strobe
DISABLE ←
5 Strobe
ENABLE ←
TURN TO ENABLE OR
DISABLE STROBE AND
PRESS TO CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
6 SetStr
OPEN
WITH STROBE ENABLED
THE LIGHT IS SET TO ON
6 SetStr
OPEN ←
6 SetStr
SPEED # ←
CHOOSE STROBE’S
SPEED VALUE FROM
1(SLOW) TO 10 (FAST)
6 SetStr
CLOSED ←
WITH STROBE ENABLED
THE LIGHT IS SET TO
OFF
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
4 DMXMem
ON
LAST SCENE HOLD
4 DMXMem
ON ←
4 DMXMem
OFF=80% ←
DIM THE LED TO 80%
OF ITS MAXIMUM
POWER
4 DMXMem
OFF=00% ←
DIM THE LED TO 0%

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
9
10.7 DIMMING CURVE (Curves) :
This function allows to select a response curve for the Astro. A choice of two curves is available:
Square and Linear. Factory setting is SQUARE .
10.8 CUT OFF DIMMING RESPONSE (CutOff) :
This function allows to select a LED behaviour simulating a tungsten-halogen lamp during the
dimming cut off.
Factory setting is SLOW.
10.9 DIMMING BEHAVIOUR (Smooth) :
This function allows to set the LED dimming response. Factory setting is NORMAL .
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
7 Curves
SQUARE
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
8 CutOff
SLOW
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
9 Smooth
NORMAL
9 Smooth
FAST ←
IMMEDIATE DIMMING
RESPONSE
SQUARE TO INCREASE
VOLTAGE RESPONSE AT
LOWER VALUE
7 Curves
SQUARE ←
7 Curves
LINEAR ←
LINEAR DIMMING
CONTROL
SOFT LED DIMMING AT
SHUT DOWN
8 CutOff
SLOW ←
8 CutOff
FAST ←
DIRECT DIMMING
RESPONSE AT SHUT
DOWN
FAST DIMMING
RESPONSE = 150ms
9 Smooth
NORMAL ←
9 Smooth
SLOW ←
SLOW DIMMING
RESPONSE = 300ms

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
10
10.10 FAN SETTING (Fan) :
This function allows to set the fan’s response. A choice of three modes is available: Automatic,
Silent or Steady. When the fan is in Auto mode, the speed is regulated by the LED temperature. In
Silent mode the fan runs slowly to reduce the noise. In Steady mode the fan runs at constant speed,
halfway between the minimum and maximum speed. In all cases, if the LED temperature exceeds
the maximum admitted value, the LED is protected by a de-rating security system. Factory setting is
AUTO.
10.11 LCD SCREEN ILLUMINATION (BackL) :
This function allows to turn off the LCD backlight, the LED POWER and LED DMX after 1’30” from
last setting. Factory setting is AutoOFF.
10.12 RED COLOUR INTENSITY (Red) :
This function allows to set the intensity of red color for manual mode. Selecting the manual mode,
100% is automatically set.
11 BackL
AutoOFF
11 BackL
AutoOFF ←
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
LCD BACKLIGHT OFF
AFTER 1 MINUTE AND
30 SECONDS
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
10 Fan
AUTO
10 Fan
STEADY ←
CONSTANT FAN SPEED
FAN SPEED IS
REGULATED BY LED’S
TEMPERATURE
10 Fan
AUTO ←
10 Fan
SILENT ←
SLOW FAN SPEED TO
REDUCE THE NOISE
11 BackL
ON ←
LCD BACKLIGHT
ALWAYS ON
12 Red
###%
12 Red
###% ←
12 Red
###% ←
TURN TO SELECT THE
RED INTENSITY AND
PRESS TO CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
11
10.13 GREEN COLOUR INTENSITY (Green) :
This function allows to set the intensity of green color for manual mode. Selecting the manual
mode, 100% is automatically set.
10.14 BLUE COLOR INTENSITY (Blue) :
This function allows to set the intensity of blue color for manual mode. Selecting the manual mode,
100% is automatically set.
10.15 WHITE COLOR INTENSITY (White) :
This function allows to set the intensity of white color for manual mode. Selecting the manual
mode, 100% is automatically set.
10.16TEMPERATURE CONTROL (Tled) :
This function allows to visualize the LED temperature. Factory setting is °C.
10.17 SOFTWARE VERSION (SwVer) :
This function allows to visualize the software version.
10.18NET (Net) :
The apps used in Wi-Fi mode work with Art-Net 3 protocol. The Port-Address is composed of three
separate fields: NET, SUB-NET and UNIVERSE. This function allows to set the NET field, in a range
between 0 and 128. Factory setting is 000.
16 Tled
##°C
16 Tled
##°C ←
16 Tled
###°F ←
TURN TO SELECT °C
OR °F AND PRESS TO
CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
13 Green
###%
13 Green
###% ←
13 Green
###% ←
TURN TO SELECT
THE GREEN INTENSITY
AND PRESS TO
CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
14 Blue
###%
14 Blue ###%
←
14 Blue ###%
←
TURN TO SELECT THE
BLUE INTENSITY AND
PRESS TO CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
15 White
###%
15 White
###% ←
15 White
###% ←
TURN TO SELECT
THE WHITE INTENSITY
AND PRESS TO
CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
18 Net
000
18 Net
### ←
18 Net
### ←
TURN TO SELECT THE
NET NUMBER AND
PRESS TO CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
12
10.19SUB-NET (SubNet) :
This function allows to set the SUB-NET field of Art-Net 3 Port-Address, in a range between 0 and
15. Factory setting is 00.
10.20 UNIVERSE (Univ) :
This function allows to set the UNIVERSE field of Art-Net 3 Port-Address, in a range between 0 an
15. Factory setting is 00.
10.21 MANUAL DIMMER TYPE (Manu) :
This function allows to select the manual dimmer type, when Astro is set in Manual mode (see
chapter 5.1). When in Wi-Fi mode this setting is disregarded, as dimming on the Astro will be
achieved through the manually operated Digital Clamp-on Dimmer A20702071, supplied, or
through the eternal mobile device. For full details on the Digital Clamp-on Dimmer please refer to
chapter 12 of this manual
Factory setting is ENCODER.
There are also nine different hidden menus which allow to select the advanced settings of the
ASTRO WI-FI RGBW. To activate this function turn OFF and then ON again the Astro by pressing the
rotary switch at power on.
10.22-A PRO or BASIC CONTROL (ProBasic) :
The PRO-BASIC control is a special function which allows to limit the access to the control menu.
Select ProBasic with the rotary switch and press to access the menu. Select :
PRO, to enable access to all the functions
BASIC, to limit the access to functions 10.1 Wi-Fi, DMX or MANUAL MODE, 10.2 DMX ADDRESS,
10.12 - 10.13 - 10.14 - 10.15 RGBW Colour intensity in manual mode, 10.16 Temperature Control,
10.17 Software version and 10.18 - 10.19 - 10.20 Net, Sub-Net and Universe for Art-Net Port-
Address.
Factory setting is PRO.
Choose
ProBasic
MenuType
PRO ←
MenuType
BASIC ←
TURN TO SELECT PRO
OR BASIC MENU AND
PRESS TO CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
19 SubNet
00
19 SubNet
## ←
19 SubNet
## ←
TURN TO SELECT
THE SUBNET
NUMBER AND PRESS
TO CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
20 Univ
00
20 Univ
## ←
20 Univ
## ←
TURN TO SELECT
THE UNIVERSE
NUMBER AND PRESS
TO CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
14 Manu
ENCODER
14 Manu
ENCODER←
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
MANUAL DIMMING BY
ROTARY SWITCH
14 Manu
POTENT ←
MANUAL DIMMING BY
EXTERNAL SLIDER

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
13
10.23-B FACTORY SETTINGS (Reset) :
The RESET control is a special function which allows to RESET the product to factory settings.
10.24-C ID REMOTO (ID Rem) :
It allows to select the ID number to connect Astro to Remoto to upload and download firmware. To
change the initial ID press the rotary switch until an arrow appears, then turn again to change to
the desired ID number. Press to confirm your selection. It is possible to select an ID number’s value
between 0 an 250. If the ID number=0, remote control is not active. Factory setting is 000.
10.25-D CALIBRATION (Set Min):
It allows to calibrate the minimum output level of each colour.
NOTICE: Reset doesn’t restore the default settings of minimum levels.
IMPORTANT NOTICE
If the Astro is used in Wi-Fi mode, DO NOT CHANGE the default levels because the colours
generated by the controlling App depend on these.
10.26-E IP ADDRESS (IP Addr) :
It allows to view the Astro IP address when operating in Wi-Fi mode. The IP address cannot be
changed and it is necessary to correctly connect the external mobile controller to the ASTRO
Choose
Reset
Are You SURE
?
MenuType
BASIC ←
PRESS TO CONFIRM
THE RESET
PRESS TO ACTIVATE
THE MENU
Choose
ID Rem
ID Rem
000 ←
ID Rem
### ←
TURN TO ASSIGN THE
ID NUMBER AND
PRESS TO CONFIRM
PRESS TO ACTIVATE
THE MENU AN
ARROW SHOULD
APPEAR
Choose
IP Addr
2.xxx.xxx.
xxx
TAP THE ROTARY
SELECTOR TO DISPLAY
THE IP ADDRESS
Choose
Set Min
Min RED
#### ←
Min RED
#### ←
TURN TO ASSIGN
THE CALIBRATION
VALUE AND PRESS TO
CONFIRM
PRESS TO ACTIVATE
THE MENU. TURN
AND PRESS TO SELECT
THE COLOR TO SET
Min BLUE
#### ←
Min GREEN
#### ←
Min WHITE
#### ←
Min GREEN
#### ←
TURN TO ASSIGN
THE CALIBRATION
VALUE AND PRESS TO
CONFIRM
Min BLUE
#### ←
TURN TO ASSIGN
THE CALIBRATION
VALUE AND PRESS TO
CONFIRM
Min WHITE
#### ←
TURN TO ASSIGN
THE CALIBRATION
VALUE AND PRESS TO
CONFIRM

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
14
10.27-F SUBNET MASK (Net Mask) :
It allows to view the Astro Subnet Mask when operating in Wi-Fi mode. Subnet Mask can’t be
changed.
10.28-G SERVICE SET IDENTIFIER (SSID) :
It allows to set the name of the network generated by the Astro.
Default SSID is “Astro###”, where “###” is a value between “000” and “254”. Because the SSID is
assigned randomly, you might experience the unlikely case of receiving different fixtures with
identical SSID. In order to avoid conflicts, we strongly recommend you change the SSID name of
your Astro should you have purchased more than one unit. You will be allowed to create an 8 digit
SSID of your choice.
NOTICE: Reset (see chapter 10.23-B) doesn’t restore the default settings of SSID.
10.29-H PASSWORD (PassWord) :
It allows to set the password to connect the controller to the network generated by Astro. Default
password is “AstroNet”. We strongly recommend you change the SSID name of your Astro should
you have purchased more than one unit. You will be allowed to create an 8 digit SSID of your
choice.
NOTICE: Reset (see chapter 10.23-B) doesn’t restore the default settings of password.
10.30-I EXIT HIDDEN MENU (Exit) :
It allows to exit from hidden menus.
Choose
Net Mask
255.255.
255.0
TAP THE ROTARY
SELECTOR TO DISPLAY
THE SUBNET MASK
Choose
SSID
SSID
Astro###
SSID
########
TURN TO ASSIGN
THE LETTER, NUMBER
OR SYMBOL AND
PRESS TO CONFIRM
PRESS TO ACTIVATE
THE MENU
Choose
PassWord
PASSW
AstroNet
PASSW
########
TURN TO ASSIGN
THE LETTER, NUMBER
OR SYMBOL AND
PRESS TO CONFIRM
PRESS TO ACTIVATE
THE MENU

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
15
11. APP SETTINGS AND OPERATION FROM LDR MOBILE CONTROLLER
SMARTPHONE HONOR 7S BLACK – # A20702074 – optional accessory
If the Astro was purchased complete with the LDR controller A20702074 Smartphone Honor 75
Black , (available as an optional accessory), pre-loaded with the Android Art-Net Controller app,
relevant settings and libraries, it is ready to be operated.
In case you are using your own mobile device, please refer to chapter 12 and 13 of this manual for
all the necessary steps needed to set up the control system under either IOS or Android.
Set the Operation Mode of the ASTRO to WI-FI (refer to chapter 10.1)
Make sure the controller is connected to the network generated by Astro. From the home screen,
tap Settings Wi-Fi and check that the controller is connected to the Wi-Fi network “Astroxxx”.
Click on the Art-Net Controller icon: from the home screen, tap Pb 0v, which will bring you to the
existing library of colours, which also includes 3 whites (2700K, 3200K and 5600K) and a black-out
option. Click on the chosen colour to have it on. In order to change colour simply click on the
following one.
Should you need to create and store more cues, please refer to chapter 12.3 of this manual.
Art-Net
Controller

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
16
12. APP SETTINGS AND OPERATION FROM USER’S ANDROID MOBILE CONTROLLER
If you are planning to use an ANDROID mobile device of your own to control the ASTRO WI-FI,
please carefully follow the here-below described steps to ensure a correct configuration of your
mobile device.
12.1 SETTINGS
•From the Play Store, download and install Art-Net Controller and Art-Net Controller
Libraries Apps.
•On the Apps screen, tap Settings Flight mode. Drag the Flight mode switch to the
right.
Select Settings Wi-Fi. Drag the Wi-Fi mode switch to the right, select “Astroxxx” from the list of
detected Wi-Fi networks and tap CONNECT.

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
17
•Enter the password (default AstroNet) and press CONNECT. When the device is
connected to the network, exit from the Wi-Fi settings and tap on the Art-Net Controller
Libraries icon.
Please to chapter 10.28G and 10.29H to reset your SSID code and password.
•Tap Create/Update Fixtures Library and wait until loading is completed.

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
18
•Open the Art-Net Controller app: by default the app displays the Prog (Programmer)
window. Tap the three dots located on the upper left corner of the screen to open the
main menu and select Patch Lib.
•Scroll the fixtures library and select GENERIC_RGBW.D4. Insert “1” in the following
fields: Start DMX, n° Fixtures and Start ID. Tap Patch it and then exit the Patch menu.

Astro 250 Wi-Fi RGBW, DMX 512+ RDM LED followspot -User’s Manual – 1.0
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy
Tel. [phone] – fax [phone] – email [e-mail] – web www.ldr.it
19
•Open the main menu and select Options Play ‘Pb 0v’ by Fixture.
•Open the main menu and select Settings.
Enter your ASTRO’s IP address in the “Art-net broadcast/unicast to:”fields Please refer to chapter
10.26-E of this user guide to know the IP address to be used.
Scroll the Settings window downwards, enter “99” in the PlayBacks fields and confirm (Apply).
