LEDJ Event Panel
(Order code: LEDJ68)
User Manual

LEDJ Event Panel Safety
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
Keep this equipment away from rain,
moisture and liquids.
SAFETY INSTRUCTIONS
Every person involved with the installation, operation & maintenance of this
equipment should:
- Be competent
- Follow the instructions of this manual
CAUTION! TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the
equipment.
To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
Please note that damages caused by user modications to this equipment are not
subject to warranty.
1

LEDJ Event Panel Safety
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused
by the non-observance of this manual or any unauthorised modication to the
equipment.
• Never let the power-cable come into contact with other cables. Handle the power-cable
and all mains voltage connections with particular caution!
• Never remove warning or informative labels from the equipment.
• Do not open the equipment and do not modify the equipment.
• Do not connect this equipment to a dimmer-pack.
• Do not switch the equipment on and off in short intervals, as this will reduce the
system’s life.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when equipment is fully charged
Only handle the power-cable by the plug. Never pull out the plug by pulling the
power-cable.
• Make sure that the available voltage is between 220v/240v. (for charging only)
• Make sure that the power-cable is never crimped or damaged. Check the equipment and
the power-cable periodically.
• If the equipment is dropped or damaged, disconnect the power supply immediately.
Have a qualied engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic temperature uctuation (e.g. after
transportation), do not switch it on immediately. The arising condensation might damage
the equipment. Leave the equipment switched off until it has reached room temperature.
• If your product fails to function correctly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Prolight dealer
for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be carried out by a qualied
technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
• WARRANTY; One year from date of purchase.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual,
the product may suffer damage and the warranty becomes void.
Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,
lamp failure etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property.
2

LEDJ Event Panel Over view
Over view:
Operation:
After the unit is powered up, Press the “MODE” button to activate the main menu:
Built-in programmes, Auto run, DMX, Slave or Sound active mode.
“SETUP” button is to change the current mode.
“UP” button is to increase the value of the current setting.
“DOWN” button is to decrease the value of the current setting.
Built-in programmes: Runs one of the 12 built-in programmes.
Auto run: Runs the built-in programmes in a continuous loop.
DMX mode: The unit can be controlled by any universal DMX controller.
Slave mode: The units in this mode can be synchronously run with a Event Panel
set to master mode.
Sound activated mode: Runs via sound activation using the built-in microphone
Built-in programmes mode:
With the LEDJ Event Panel, you can select 12 different Programmes. Press the “SETUP” and
“UP” and “DOWN” buttons to select the programmes (from PG01 to PG12) and select the desired
programme value. When the LED display shows PG.01, press the “SETUP” button for the
rst time, and it will show CL0.0 you can now select one of the 7 static colours by using the
“UP” and “DOWN” buttons; then press the “SETUP” button for the second time, and it will show
FS.00, you can now select your desired ash frequency by using the “UP” and “DOWN”
buttons. When in PG.11 and PG.12, press the “SETUP” button for a third and fourth time, and
it will show C1.-1, or C2.-2 and now you can choose two colours for the programmes to work
in, using the “UP” and “DOWN” buttons.
When in programmes PG.02 - PG.10 , press the “SETUP” button for the rst time, and it will
show SP.99, you can now set the running speed for this programme. Then press the “SETUP”
button for a second time, and it will show FS.00, you can now select the ash frequency for it
using the “UP” and “DOWN” buttons.
SP: Speed 00-99 (00 = slow, 99 = fast)
FS: Flash frequency from 00-99 (00 = slow, 99 = fast)
3

LEDJ Event Panel Over view
Auto Run mode:
To access the Auto run mode, Press the “MODE” button until the LED display shows AU70.,
then press the “SETUP” button and it will show N.OO1, you can now select the programme
running times by using the “UP” and “DOWN” buttons. Programme Running times N.001 - N.100
Note: The Programme running time indicates how many times the running programme is repeated
before moving on to the next one.
DMX Mode
To control the Event Panel individually via your DMX controller, press the “MODE” button untill
is shown on the LED display, it is now in DMX mode. Now press the “SETUP” button so
the LED display shows .001, this now means that the DMX address is set at 001. You can
select your DMX address by using the “UP” and “DOWN” buttons. If you press the “SETUP”
button the LED display will show: 03.Ch., 06C.h.,12.ch., 24.ch., or p4.ch.
this selects which DMX mode the Event Panel is being run in. You can select any of these 5 DMX
modes by using the “UP” and “DOWN” buttons.
DMX Values
03CH
06CH
12CH
4

DMX Values (cont..)
24CH
P4CH
Slave Mode:
To activate the Slave Mode, press the “MODE” button to show SlA-, this will now run
the Event Panel in slave mode.
Sound Mode:
To activate the Sound Mode, press the “MODE” button to select SO.31, now the sound mode is
activated it will run one step at a time, you can adjust the sensitivity by using the “UP” and “DOWN”
buttons. (Sensitivity: SO01 - SO31, 01 = low, 31 = high). Press the “SETUP” button and it will
show Nn-1, this is sound mode 1 (running static colour 1 step, 1 time) use the “UP” and “DOWN”
buttons to select sound mode 2 Nn-2, (running dimming colours 1 step, 1 time)
CH3
0 - 255: G
LEDJ Event Panel Over view
CH1
0 - 255
RED 1
CH2
0 - 255
GREEN 1
CH3
0 - 255
BLUE 1
CH22
0 - 255
RED 8
CH23
0 - 255
GREEN 8
CH24
0 - 255
BLUE 8
CH1
0 - 18:
19-37
38-56
57-75
76-94
95-113
114-132
133-151
152-170
171-189
190-208
209-227
228-246
247-255
CH2
0 - 255: R
CH4
0 - 255: B
Functions
RGB Dimmer
PG02 - Colour dream
PG03 - Colour fade
PG04 - Colour change
PG05 - Colour jump
PG06 - Flow 1
PG07 - Flow 2
PG08 - Chase 1
PG09 - Chase 2
PG10 - Multi-colour
PG11 - Chase 3
PG12 - Chase 4
Sound active0-255 Sensitivity Not used Not used
0-255 select colour
0-255 select colour
Not
Used
0-255
Flash
Speed
0-255
Running
Speed
5
PG01 - Static colour

Operation For Battery Pack
1, Press the Transmitting mode button for more than 3 seconds, until the transmitting signal light is
“ON”, then it means this unit is transmitting. If you want this unit to be the receiver, then you can
press the Receiving mode button for more than 3 seconds until the receiving signal light is “ON”.
2, The UP and DOWN buttons are for selecting different channel frequencies of the
battery pack.
For example, if you have 10 transmitters and 10 receivers, you can press the UP and DOWN
buttons to set their channel frequency accordingly. There are 125 to choose from.
3, When you are charging the battery pack the “Charging LED” will illuminate Red and once
the battery pack is fully charged, the “Charging signal light” will turn Green and the LED Event
Panel is now ready for use.
Note:
1, When using the battery to power the event panel, do not connect the 110V-240V power cable
2, When the battery is fully charged, it can supply a single colour on full output on the
LED Event Panel for about eight hours.
3, Please make sure you connect all necessary cables before operation.
4, Please recharge it immediately after discharge.
LEDJ Event Panel Operation For Battery Pack
6

DMX-512:
• DMX (Digital Multiplex) is a universal protocol used as a form of communication between
intelligent xtures and controllers. A DMX controller sends DMX data instructions form the
controller to the xture. DMX data is sent as serial data that travels from xture to xture via the
DATA “IN” and DATA “OUT” XLR terminals located on all DMX xtures (most controllers only have
a data “out” terminal).
DMX Linking:
• DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all xtures and the controller are DMX compliant.
To ensure proper DMX data transmission, when using several DMX xtures try to use the
shortest cable path possible. The order in which xtures are connected in a DMX line does not
inuence the DMX addressing. For example; a xture assigned to a DMX address of 1 may be
placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a
xture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to
address 1 to that unit, no matter where it is located in the DMX chain.
DATA Cable (DMX cable) requirements (for DMX operation):
• The LEDJ Event Panel can be controlled via DMX-512 protocol. The DMX address is set on the
back of the unit. Your unit and your DMX controller require a standard 3-pin XLR connector for
data input/output (gure 1).
Figure 1
Also remember that DMX cable must be daisy chained and cannot be split.
Equinox Event Panel DMX set up
Further DMX cables can be purchased from all
good sound and lighting suppliers or Prolight
dealers.
Please quote:
CABL10 – 2M
CABL11 – 5M
CABL12 – 10M
7

Notice:
• Be sure to follow gures 2 & 3 when making your own cables. Do not connect the cable’s shield
conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer
casing. Grounding the shield could cause a short circuit and erratic behaviour.
Special Note: Line termination:
• When longer runs of cable are used, you may need to use a terminator on the last unit to
avoid erratic behaviour.
Using a cable terminator (part number CABL90) will decrease the possibilities of erratic
behaviour.
5-Pin XLR DMX Connectors:
• Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-Pin
XLR xtures may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin
XLR connectors in to a 3-pin line a cable adaptor must be used. The Chart below details the
correct cable conversion.
Termination reduces signal transmission problems
and interferance. it is always advisable to connect a
DMX terminal, (resistance 120 Ohm 1/4 W) between
pin 2 (DMX-) and pin 3 (DMX+) of the last fixture.
LEDJ Event Panel DMX Set Up
8

9
Features:
DMX Channels: ....................................................................................... 3/4/6/12 or 24 selectable
Display: ................................................................................................4 Push button LED display
Connections: .........................................................................................3-Pin XLR In/Out for DMX
Operations: ...............................Built-in programmes, Auto run, Sound active, Slave and DMX
LEDs: ...........................................................288 Ultra Bright 10mm LEDs (R: 48, G: 120, B: 120)
Beam angle: ...................................................................................................................40 degrees
Wireless DMX: .......................................................................................................On battery pack
Panel specications:
Power consumption: .................................................................................................................36W
Power supply: ...........................................................................................110V - 240V 50Hz/60Hz
Dimensions: ........................................................................................................420 x 265 x 65mm
Weight: ...................................................................................................................................3.0Kgs
Battery pack specications:
Power supply: ...........................................................................................................................240V
Dimensions: ......................................................................................................325 x 240 x 120mm
Weight: ...................................................................................................................................8.0Kgs
LEDJ Event Panel Features

10
Notes:
LEDJ Event Panel Notes
