LEGRAND HPM EFD01RDWE User manual

Ceiling Exhaust Fan - Ducted
Cat. No: EFD01RDWE, EFD01RDMS,
EFD01SQWE,EFD01RDWEKIT
Instruction Manual
Specifications
Cat. No.EFD01RDWE/EFD01RDWEKIT EFD01RDMS EFD01SQWE
Colour White Matt Silver White
Supply Voltage 230-240V AC 50Hz
Power Rating 40W max.
Max Airflow Rate (Non-ducted) 330m3/hr
Max Airflow Rate(Ducted –Ø150mm x 3m) 250m3/hr
Protection Class Class II
IP Rating IPX4
Duct Requirement Ø150mm
Ceiling Cut-out Size (Ceiling fan) Ø298mm
External grille cut-out size 160mm (EFD01RDWEKIT only)
Projection into Ceiling 190mm
Protrusion from Ceiling 26mm
Grille Size (Ceiling fan) Ø372mm 350 x 350 mm
Sound Pressure level at 3m 36 dBA (Tested in accordance with AS1217.5)
EFD01RDWE/EFD01RDMS/EFD01RDWEKIT EFD01SQWE
EFD01RDWEKIT includes : 1) External Grill
2) Ø150mm X 3m Duct
3) Cable ties
4) Duct tape
5) Mounting screws
Also available
External wall kit accessory: R621/6D
Please read carefully: Read through these instructions completely before commencing installation. Retain for future use.
This product should be installed by a licensed electrical contractor or similarly qualified person.

Please read carefully
Read through these instructions completely before commencing installation. Retain for futureuse.
1. This product shall be installed in accordance to AS/NZS 3000 WiringRules.
2. Regulations concerning the discharge of air must be fulfilled. Local building codes may require venting to theoutside.
3. This product must be installed at least 2.2m above floorlevel.
4. Do not install within 120cm of a stove or inside a shower recess.
5. Cross Ventilation:
Ventilation products must have an adequate source of external air to ensure ratedperformance.
Steam and air will only be exhaustedthrough the fan if there is sufficient flow of air through the room. Ensure adequate inlets exist through windows,
vents or under the door. Airflow path from the inlet to the fan should ideally pass over the source of steam or air to be removed from the room.
Restrictions on replacement air entering the room to be ventilated, or pressure-differentials between the room and outside air will significantly reduce
the exhaust fan’s performance.
6. Compliance with Section 6 Damp Situation of AS/NZS 3000 WiringRules:
No part of the unit may be located directly above any part of the bath or shower recess or enclosure.
The unit must be installed within zones 2 and 3 only. For further information, refer to AS/NZS 3000.
7. Unit Orientation:
The unit must be installed to ensure the housing outlet and ducting is oriented in parallel to any roofing structures or supports. Refer to image below
for correct installation orientation. Orientation which forces the unit to be ducted into a 90°bend immediately after the fan outlet will cause a significant
performance reduction.
120
100
80
60
40
20
0
-20
050 100 150 200 250 300
Back Pressure(PA)
Air Flow(m3/H)
8. Duct Size and Length:
The unit must be installed with Ø150mm duct using the adaptor supplied to ensure optimum extraction and performance. The maximum recommended
duct length is 3m. The graph below shows the unit’s performance with 3m of duct. Longer ducts will reduce the unit’sperformance.
9. Duct Routing:
As the back pressure increases the unit’s performance is reduced. Airflow will be reduced with bends in duct or squashing of duct. Every 90°bend/
elbow results in approx 20% reduction in the unit’sperformance.
Please refer to the graph below, an almost linear relationship between back pressure and fan performance proves just how critical correct installation
of the exhaust fan is in relation to performance.
EFD01 series
(Ducted- Ø150mm x3m)

The unit shall be installed horizontally in the ceiling in accordance with example images shown below to ensure intended operation and rated performance.
When fitted, the duct outlet must be the same height or lower than the exhaust fan.
The duct must not be installed vertically into a roof vent cap - the product is not designed or intended for this type of installation.
Installation (CEILING FAN)
1. Determineposition in ceilingwherethe exhaust fan is required to be installed(figure1).
2. Use the template provided to draw a circle. To do this, insert a thumb tack at one end and insert a pencilat the other end and scribe a circle (figure 2).
3. Cut out around this line (figure 3).
4. Remove grille from the exhaust fan.
5. Attach duct adaptor to duct with duct tape (figure 4).
6. Ensurethat a power outlet is installedin the ceilingnear the intended position of the exhaust fan. Ensure that power to the outlet is off. Plug the exhaust fan
into this outlet (figure5).
7. Attach duct adaptor to the exhaust fan outlet (figure6).
8. Insert the unit into the cavity (figure 7).
9. With the unit in place,turn the toggles (4x) clockwise and tighten the screws until the clampssecurelygrip the ceiling(figure8).
10. Push grille onto unit and click into position (figure9).
figure 1 figure 2 figure 3 figure 4
figure6 figure7figure5
ROOFING
ROOF VENT CAP

AFTERBEFORE
figure8 figure9
Installation for External Grille (EFD01RDWEKIT ONLY)
A suitable position must be found that will suit:
1. The position of the vent on the outside wall.
2. The location of studs, pipes, wires inside the cavity. Make a circular hole
in the outside wall.
From the outside:
1. From the outside, pull the ducting through the outside hole.
2. Remove the inner louvred grille section by gently prying open with a
screw driver.
3. Attach the vent frame to the ductwith the cable tie firmly.
4. Push the vent frame back into the hole and attach with the appropriate
screws for the wall material.
5. Snap in the louvredgrille from the outside with the louvres pointing
downwards.
Note: It is desirable to have the ducting as taut as possible as any
slackness may restrict the air-flow through the ducting.

External Grille
Louvered Grille
189mm
18mm
Ø150mm
(R621/6D- Grille only)

Disclaimers
1. This productmust be installed and used as per these instructions.
2. This productshould be cleaned periodicallyonly with a damp cloth.Cleaning agents and solventsshouldnot be used.
3. This product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervisedto ensure that they do not play with the appliance.
4. This product is intendedfor household use and similar purposes. It is not suitable for use in and environment heavily laden with dust. Under these conditions
the life of the fan motor can be significantlyreduced.
5. This productshouldnot be enclosed in thermal insulationas it may cause the unit to overheat.
6. This producthas been designed to operatein ambienttemperatures -10Cto 40C.
7. This productcontains no serviceable parts and no attempt should be madeto repair it. If the productis faulty it shouldbe discarded.
8. Airflows listed in this productindicate the product performance. Referto the BCA (Building Codeof Australia), or similar, for the appropriate airflow
required for a particular installation.
9. Ventilationproducts must have an adequate sourceof external air to ensure correct performance.
10. Considerationmust be taken in the installation of ductsto ensure that condensationthat will form in the ductwill not run back into the fan housing.
11. Precautionsmust be taken to avoidthe back-flowof gases into the room from the open flue of gas or other fuel-burning appliances.
12. This producthas been designed for domestic or similar uses and is not suitable for a commercial installation.
13. This productis not suitable for installation in hazardous and/or corrosiveareas.
14. The materialin this productmay vary in colourfrom batch to batch. Colour matching from one batch to anothercannotbe guaranteed.
15. This productutilises intellectual property in the form of registered designs, trademarks, and/or patents. Such intellectual property remains the property
of Legrand in all cases.
16. Legrand reserves the right to modify the specification of this product at any time.
LE09237AAB
04_2019
Warranty
Legrand warrants this product for a period of 3 years from the date of purchase.
These goods come with guarantees that cannot be excluded under the Australian
and New Zealand Consumer Laws. You are entitled to a replacement or a refund
for a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired ifthe goods fail
to be acceptable quality and the failure does not amount to a major failure.
See the Warranty card enclosed with this product forfurther details.
Customer Service
For all Customer Service and Technical Support
please call Monday to Friday during businesshours.
Legrand Australia
1300 369 777
www.hpm.com.au
Legrand NewZealand
0800 476 009
www.hpm.co.nz
ABN: 31 000 102 661
