LEGRAND HPM RCF12H4WE User manual

Warranty
Legrand warrants this product for a period of 3 years from the date of purchase.
These goods come with guarantees that cannot be excluded under the Australian and New
Zealand Consumer Laws. You are entitled to a replacement or a refund for a major failure and
for compensation for any other reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired if the goods fail to be acceptable quality and the failure does not
amount to a major failure.
See the Warranty card enclosed with this product for further details.
Customer Service
For all Customer Service and Technical Support
please call Monday to Friday during business hours.
LE11531AAE
Product Notes
1. This product must be installed by a licensed electrician and used as per
these instructions.
2. This product contains no serviceable parts and no attempt should be
made to repair this product. If the product is faulty it should be discarded.
3. This product must be cleaned periodically with a damp cloth. Cleaning
agents and solvents should never be used.
4. This product has been designed to operate in ambient temperatures
between 5°C to 40°C.
5. This product must be securely attached to a structural member for
support. Fixing means (hooks & brackets) must be xed to the structural
member with sucient strength to withstand 4 times the weight of the
ceiling fan.
6. During installation the mains supply wiring terminals should be tightened
between 0.4Nm and 0.6Nm. Over-tightening may damage the terminal.
Under-tightening may result in hot joints.
7. This product is for Indoor use only.This product is not intended to
be exposed to direct weathering. It is not suitable for installation
in hazardous and/or corrosive areas. It is not suitable for marine
environments such as areas subjected to salt spray and/or mist.
8. This product is not intended for use by young children or inrm persons
without supervision. Young children should be supervised to ensure that
they do not play with the appliance.
9. Extended exposure to UV rays (such as exposure to direct sunlight) may
cause discolouration of this product.
10. The material in this product may vary in colour from batch to batch.
Colour matching from one batch to another cannot be guaranteed.
11. This product has been designed to operate on a nominal supply voltage
of 230V - 240Va.c. 50Hz.
12. After installation this product must be tested as required by the
appropriate government and/or statutory regulations.
13. This product utilises intellectual property in the form of registered
designs, trademarks, and/or patents. Such intellectual property remains
the property of Legrand in all cases.
14. Legrand reserves the right to modify the specication of this product at
any time.
Legrand Australia
1300 369 777
www.hpm.com.au
Legrand New Zealand
0800 476 009
www.hpm.co.nz
ABN: 31 000 102 661
Inspire Sweep Fans Weight
RCF12H4WE Inspire Residential sweep fan, 4 blades, Wall Switch,1200mm, White 5.8 kg
RCF12H4BL Inspire Residential sweep fan, 4 blades, Wall Switch,1200mm, Black 5.8 kg
RCF12H4BS Inspire Residential sweep fan, 4 blades, Wall Switch,1200mm, Brushed Stainless Steel 5.8 kg
RCFL12H4WE Inspire Residential sweep fan with lamp, 4 blades, Wall Switch, Diuser,1200mm, White 5.9 kg
Inspire Sweep Fans
Cat. No: RCF12H4WE, RCF12H4BL, RCF12H4BS, RCFL12H4WE
Instruction Sheet
4-Blade Models
PLEASE READ ALL INSTRUCTIONS CAREFULLY. RETAIN FOR FUTURE REFERENCE. INSTALLATION MUST BE CARRIED OUT BY A LICENSED
ELECTRICAL CONTRACTOR.
1 Fix fan blades to motor assembly
x2
x3
Max torque 0.5Nm
Magnetic Screw driver should be used
x4
x3
x 2
A. Remove the cover plate on the
motor by removing the screws.
B. Remove the screws connecting
the fan blades.
C. Assemble the blade to the motor
with the screws.
1. The Hang-sure style is suitable for both at and inclined ceilings (up to maximum angle of 20°).
2. This fan has been supplied with a 3 speed fan controller. It is designed to operate a single fan only.
3. The fan is to be installed so that the fan blades are more than 2.1m above oor level. Fan blades should have clearances >300mm from any
obstacles.
4. The lamp in the fan is built-in and is non-replaceable.
5. During installation a switch disconnection should be incorporated in the supply circuit.
6. Blades provided are paired for individual fan and must not be mixed with blades from other fans. This may aect performance and cause
vibration/wobble. If unusual oscillating movement is observed, stop using the ceiling fan immediately and contact Legrand Australia, its
service agent or a suitably qualied person.
Important considerations
D. Assemble the cover plate back to
the motor.
Quick- connect wiring Quick- connect wiring
Box contents
• Motor assembly
• 4 blades
• 3-speed fan controller
• Instruction Sheet
• Glass Diuser (RCFL12H4WE only)
• Screw pack
• Mounting Bracket
• 3-speed fan controller and switch (RCFL12H4WE only)
RCF12H4 Series RCFL12H4WE
The HPM ceiling sweep fan comes complete with a capacitive 3-speed controller on a wall plate with standard 84mm xing centres.
RCFL12HWE comes with 3-speed controller with light switch on a wall plate. Please refer to instructions supplied with the speed controller.
Connecting the speed controller
8
3 - Speed fan controller
with light switch
3 - Speed fan controller
(ED3FCWE)
RCFL12H4WE only
05/2020
RCF12H4 Series
Specications
Motor 50 W
LED Lamp (RCFL12H4WE only) 15 W (Non Dimmable)
1
4
If intending to use a remote control kit (not supplied)
then do not mount the wall plate. CFREMOTEH is not compatible with RCFL12H4 fan
“IF INSTALLING A REMOTE CONTROL, IT MUST BE INSTALLED IN CONJUNCTION WITH A WALL SWITCH TO ISOLATE POWER.”

Hang-sure Mounting
Fix mounting bracket (supplied) rmly to timber or concrete.
4
5
Hanging the fan on the bracket
Connect the quick connectors
Hang-sure Bracket
Hang the fan on the bracket. Ensure bracket guide pin is tted into
slot on ball joint and that all wires are clear of the ball joint.
Click the quick connect plug into the socket connector from the fan.
N
L
A. Connect supply wiring to the terminal block provided.
Refer to instructions for Remote Control Kits (CFREMOTEH) for installation and mounting requirements.
Hang-sure Canopy
Tighten with 4 screws to the bracket. Make sure wires are not trapped in between.
6 Slide upper canopy into position and secure
7Diuser Installation for RCFL12H4WE
2
3
Fixing of mounting bracket to ceiling
Supply connection to fan
Select a suitable location for the fan. Use the 2 coach screws provided (or similar) to make an attachment to a solid structural member. Ensure
the mounting method is capable of supporting a hanging weight of 30 kg.
N
L
N
L
Bracket
Supply wiring
Guide
pin
Slot
N
L
x 2 Screws
x 2 Screws
L
A
AF
RCFL12H4WE only
RCFL12H4WE only
1. Install fan in the ceiling as shown.
2. Remove diffuser from the packaging.
3. Align the dimples on the diffuser with slots in the fan body, rotate
clockwise until it is secured. Do not apply excessive force.
For cleaning
a. Ensure the fan is switched o from the mains supply.
b. Remove the glass diuser carefully from the fan before cleaning by turning it anti-clockwise.
c. Turn the diuser clockwise to install it back to the fan. (Follow the diuser installation step 3
from this section)
RCF12H4 Series
RCF12H4 Series
23
