LEGRAND HPM SERENE CF12DC4BWE User manual

SERENE DC CEILING FANS 4 BLADES
Instruction Manual

Serene DC Ceiling Fans 4 Blades
Cat. No: CF12DC4BWE, CF13DC4BWE
Instruction Manual
1. The hangsure style is suitable for both flat and inclined ceilings (up to maximum angle of 13°).
2. This fan has been supplied with a 6 speed fan control. It is designed to operate a single fan only.
3. The fan is to be installed so that the fan blades are more than 2.1m above floor level. Fan blades should have clearances >300mm
from any obstacles.
4. During installation a switch disconnection should be incorporated in the supply circuit.
5. Blades provided are paired for individual fan and must not be mixed with blades from other fans. This may affect performance
and cause vibration/wobble. If unusual oscillating movement is observed, stop using the ceiling fan immediately and contact
Legrand Australia, its service agent or a suitably qualified person.
IMPORTANT CONSIDERATIONS
PLEASE READ ALL INSTRUCTIONS CAREFULLY. RETAIN FOR FUTURE REFERENCE.
Box contents
CF13DC4BWE
CF12DC4BWE
2
•Motor assembly (x1)
•ABS plastic blades (x4)
•Blade screws (x9)
•Mounting bracket (x1)
•Mounting bracket screw (x2)
(Timber use only)
•Plastic anchors (x2)
• Remote control with 2 x AAA
battery and screws (x1)
• Remote control holder (x1)
INDOOR
OUTDOOR
REVERSIBLE
MODE
SUMMER/WINTER
Product Specifications
CF12DC4BWE CF13DC4BWE
Supply Voltage 230-240 V ~ 50 Hz
Power (Motor) 40 W
Maximum Airflow 11,400 m3/h 12,600 m3/h
Product Weight 6.0 kgs 6.4 kgs
Fan Size 1220 mm, 48” 1320 mm, 52”
Power Factor 0.55 @ 240 V a.c. 50 Hz
1 QUICK-FIT BLADE INSTALLATION
A. Turn the top motor housing
anticlockwise and lift upward.
B. Insert the blade into the rectangular
slot on the side of the motor body.
C. Tighten screws provided in kit. Refit the top
motor housing to the fan body by reversing step1.
Insert blades (x4)
Screws per blade (x2)
Max. Torque:0.5 Nm
Note: Make sure that the blades are oriented as shown above and ensure the top motor housing has locked back into place.

2FIXING THE MOUNTING BRACKET TO CEILING
3 WIRING
1. Connect the mains power supply to the
terminal block (A). Live to “L” terminal,
Neutral to “N” terminal Earth to “ ”
terminal. Ensure the wires are secure and
no bare wires are exposed.
2. Insert the DC remote receiver into the
mounting bracket.
3. Insert the 3-port fixed wire quick connector
to the receiver power input socket.
4. Insert the DC remote receiver output wire
connector to the receiver power output
socket.
5. Join the receiver output wire and the motor
power input wire together via the 4-port
quick connectors.
3
Fix mounting bracket (supplied) firmly to timber or concrete.
This fan hanging system supports a maximum
13° angled ceiling installation.
Angled Ceiling Installation
Select a suitable location for the fan. Use the 2 coach screws provided (or similar) to make an attachment to a solid structural member.
Ensure the mounting method is capable of supporting a hanging weight of 30 kg.
Warning: Ceiling fan must be mounted so that
blades are 2.1m from the floor and
300mm fromthe wall and other
obstructions to the blade tip.
130
Floor
More than 2.1m
More than 300 mm
230-240 ~

A. Connect supply wiring to the terminal block provided in hangsure bracket.
4 POWER SUPPLY CONNECTION TO THE TERMINAL BLOCK
ON
OFF
5
4
• After completing the electrical connection at the mounting bracket
terminal block, connect the ceiling fan by joining the male and female
connector plugs.
• Ensure slot (B) of the hanging ball joint is positioned on notch (A)
of the mounting bracket (C) to prevent the fan from rotating when
in operation (See Fig.1).
• Cover the mounting bracket with the canopy. Ensure all electrical
wiring is tucked inside the canopy and that the wires are not
damaged during this step.
• Secure the canopy to the mounting bracket using the screws
provided (See Fig.2).
Fig.3
Fig.2
Fig.1
AB
C
• Place the remote receiver assembly onto the mounting bracket.
Max. Torque:0.4 Nm
SUPPLY WIRING
BRACKET
L
230-240 V ~
HANGING THE FAN ON THE BRACKET

6 REMOTE CONTROL
a. Fan OFF button
• Press the button to turn the fan OFF.
• Press and hold the button for 5 seconds within 30 seconds of switching
the power to the receiver for pairing the transmitter and receiver.
b. Fan speed control button
Press the speed buttons from 6 to 1, the fan will run from Extra-high speed (6) to
Extra-low speed (1).
c. No function
d. Natural wind button
• Press the button to activate the natural wind mode.
• Press any speed control button to exit the natural wind mode
e. Forward/Reverse button (Only on the remote not on body)
Press the button to activate the reverse running function. The fan must be operating to
activate the reverse function. Press again to return to the forward running function.
f. Timer control button
Press the button to activate the fan timer function, the fan will turn OFF after running
1 hour / 4 hours / 8 hours. To cancel the timer function, just press the fan OFF button.
g. Batteries (2 x AAA 1.5V) supplied.
7 PAIRING THE SPEED CONTROLLER
The remote and receiver have already been paired during manufacturing. When the ceiling fan is installed for the first time, pairing of
the remote and receiver is NOT required. If the remote and receiver lose pairing after installation or during use, the remote and the
receiver must be re-paired. The scenario and method to re-pair the pairing of the DC ceiling fan remote and receiver are below.
Issues:
• Loss of control - Fan is only running at high speed after installation
• Loss of control - No reverse function after installation
• Loss of control - Remote cannot communicate with the receiver
Solution:
• Switch OFF the main power to ceiling fan.
• Press and hold the “FAN OFF” button on the remote for 5 seconds (within 30 seconds of switching the power ON to the receiver
of the ceiling fan). A long “beep” sound to indicate the paring process is activated. Release your finger from the power button.
• After waiting 2-3 minutes, turn the fan ON and change the speed of the ceiling fan by the remote to check the operation and
successful pairing.
• 2 x AAA 1.5 V batteries are used to operate the remote control.
• Loosen the screw from the battery cover.
• Pull out the battery cover and install the batteries.
• Ensure the polarity is correct as shown in the battery compartment.
• Please remove the batteries if you intend not using the ceiling fan for
any long periods of time.
Note: Natural wind mode changes the fan speed from 1 to 6 in 20 sec intervals
creating a wind effect.
Install the fan remote bracket on the wall as shown.
Battery Installation
5

9 DOWNROD INSTALLATION
6
8 ACCESSORIES (SOLD SEPARATELY)
Downrods
Serene Ceiling Fan Extension Downrod
750 mm x 21.5 mm-White
(CFSERDR750WE)
Serene Ceiling Fan Extension Downrod
1500 mm x 21.5 mm-White
(CFSERDR1500WE)
REMOVING THE ROD
Warning: Ceiling fan must be mounted so that blades are 2.1m from the floor and 300mm from the wall and other obstructions to
the blade tip (Refer to Section 2. Fixing the mounting bracket to ceiling on page 2).
6
8
6
6
5
7
4
2
3
1
a. Lower the upper canopy.
b. Unscrew the screw (1) and lower the hanging ball (2).
c. Take out the clevis pin (3).
d. Unscrew the screw (4) and lift the lower canopy up (5).
e. Unscrew the screws (6) on the lower joint of downrod
and take the r-clip (7) out.
f. Remove the clevis pin (8).
g. Detach the downrod and take the connector wire out.
ON
OFF DURING
WIRING
Make sure the power is switched off during installation.
Lower canopy
Upper canopy

PRODUCT NOTES
7
REPLACING WITH DOWNROD
Note: Max. Torque: 0.4 Nm for all screws.
6
7
8
9
6
6
10
1
2
3
1. This product must be installed by a licensed electrician and used as per these instructions.
2. This product contains no serviceable parts and no attempt should be made to repair this product. If the product is faulty it should be
discarded.
3. This product must be cleaned periodically with a damp cloth. Cleaning agents and solvents should never be used.
4. This product has been designed to operate in ambient temperatures between 5°C to 40°C.
5. This product must be securely attached to a structural member for support. Fixing means (brackets) must be fixed to the
structural member with sufficient strength to withstand 4 times the weight of the ceiling fan.
6. During installation the mains supply wiring terminals should be tightened between 0.4Nm and 0.6Nm. Over-tightening may damage
the terminal.Under-tightening may result in hot joints.
7. This product is not intended to be exposed to direct weathering. It is not suitable for installation in hazardous and/or corrosive areas.
It is not suitable for marine environments such as areas subjected to salt spray and/or mist.
8. This product is not intended for use by young children or infirm persons without supervision. Young children should be supervised to
ensure that they do not play with the appliance.
9. Only those accessories as supplied by Legrand are designed for operation with the fan.
10. Extended exposure to UV rays (such as exposure to direct sunlight) may cause discolouration of this product.
11. The material in this product may vary in colour from batch to batch. Colour matching from one batch to another cannot be guaranteed.
12. This product has been designed to operate on a nominal supply voltage of 230-240 V a.c. 50 Hz.
13. After installation this product must be tested as required by the appropriate government and/or statutory regulations.
14. Legrand reserves the right to modify the specification of this product at any time.
a. Assemble the upper and lower canopy onto the new downrod.
b. Connect the male (10) to the female (9) connector at the bottom of the
downrod and pull the wire from the top of downrod.
c. Assemble the downrod in place with all the screws (6), clevis pins (3,8)
and r-clip (7).
d. Ensure both clevis pins (3,8) are secure and all screws are tightened.
e. Place the hanging ball (2) into position and tighten the screw (1).
f. Set the lower and upper canopy onto downroad and tighten the screw (4).
4
Lower canopy
Upper canopy

8
12 / 2022 LE13922AA
■ Legrand (“we or us”) has given each purchaser who is a consumer (“you”) a warranty against defects in its products.
■ As a consumer, you are entitled to the benefit of the Warranty and should read and understand its terms. In addition,for the
purposes of the Australian and New Zealand Consumer Laws, we note the following:
■Our contact details for the purpose of any claims made under the Warranty are below. Any claim under the Warranty must be
sent in writing to the following address:
NEW ZEALAND ONLY
Legrand New Zealand Ltd
106-124 Target Rd
GLENFIELD, AUCKLAND
0800 476 009
[e-mail]
AUSTRALIA ONLY
Legrand Australia Pty Ltd
Nexus Industry Park
Bldg 4, 43-47 Lyn Parade
PRESTONS, NSW 2170
1300 369 777
[e-mail]
Warranty Statements
●If we accept your claim under the Warranty we will reimburse all your reasonable expenses in making and pursuing the claim,
including the cost of reimbursement of any defective products returned in the ordinary course to us at the address above by
post or other agreed means. Any such claim must be made within 14 days of your receiving notice of our acceptance of your
claim and include any necessary supporting documentation or invoices.
●As a consumer, you have rights under the Australian and New Zealand Consumer Laws and may have rights under other
applicable laws which cannot be excluded, restricted or modified. Those rights are in addition to any rights you have under
the Warranty.
■ Legrand offers this product with a 6 year (2 year + 4 year) express warranty. . 6 year warranty doesn’t apply to the remote
control unit. The first 2 years are in-home whereas the following 4 years are parts only. To access this warranty please contact
Legrand. The following conditions apply to this express warranty:
●This warranty commences on the date of purchase.
● Under no circumstances Legrand will be responsible for rectification or costs under this express warranty without prior
written consent.
● The product must be installed by a licenced electrician and in accordance with these installation instructions.
● Minor vibration and variations between individual units is normal and not warrantable fault.
● Humming or vibration caused by ripple control signals is not warrantable fault.
These goods come with guarantees that cannot be excluded under the Australian and New Zealand Consumer Laws. You are
entitled to a replacement or a refund for a major failure and compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
