LEGRAND 4 306 03 User manual

USER MANUAL
• Keypad with joystick and LCD display
4 306 03
LE03722AA

INTRODUCTION
1. FEATURES...........................................................................................................4
2. HARDWARE OVERVIEW ....................................................................................4
3. SYSTEM CONFIGURATION AND WIRING .........................................................7
SYSTEM INSTALLATION & TYPICAL APPLICATIONS
1. SYSTEM INSTALLATION.....................................................................................8
2. PTZ SETUP ..........................................................................................................8
3. MAIN SETUP........................................................................................................9
4. JOYSTICK CALIBRATION...................................................................................10
5. BASIC FUNCTIONS : SETTING AND CONTROL...............................................11
6. SPECIFICATIONS ................................................................................................13
TABLE OF CONTENTS
- The installation and calibration must be carried out by highly skilled personnel.
- Do not open there may be a risk of electric shock.
Use only for the following temperature conditions: from (-10) to (+50) °C.
Do not use with voltages different from the ones specified.
Warning
Safety instructions
This product should be installed in line with installation rules, preferably by a qualified electrician. Incorrect installation and use can lead to risk of electric shock or fire.
Before carrying out the installation, read the instructions and take account of the product’s specific mounting location.
Do not open up, dismantle, alter or modify the device except where specifically required to do so by the instructions. All Legrand products must be opened and repaired exclusively by personnel trained
and approved by Legrand. Any unauthorised opening or repair completely cancels all liabilities and the rights to replacement and guarantees.
Use only Legrand brand accessories.
2

IMPORTANT SAFEGUARDS
1. READ AND RETAIN INSTRUCTIONS
Read the instruction manual before operating the
equipment.
Retain the manual for future reference.
2. CLEANING
Turn the unit off and unplug from the power outlet
before cleaning. Use a damp cloth for cleaning.
Do not use harsh cleansers or aerosol cleaners.
3. ATTACHMENTS
Do not use attachments unless recommended by
manufactured as they may affect the functionality of the
unit and result in the risk of fire, electric shock or injury.
4. MOISTURE
Do not use equipment near water or other liquids.
5. ACCESSORIES
Equipment should be installed in a safe, stable location.
Any wall or shelf mounting accessory equipment should
be installed using the manufactures instructions.
Care should be used when moving heavy equipment.
Quick stops, excessive force, and uneven surfaces may
cause the equipment to fall causing serious injury to
persons and objects.
6. VENTILATION
Openings in the equipment, if any, are provided for
ventilation to ensure reliable operation of the unit and
to protect if from overheating. These openings must
not be blocked or covered
7. POWER SOURCES
The equipment should be operated only from the type
of power source indicated on the marking label.
If you are not sure of the type of power supplied at the
installation location, contact your dealer.
For equipment designed to operate from battery power,
refer to the operating instructions.
8. GROUNDING OR POLARIZATION
Equipment that is powered through a polarized plug
(a plug with one blade wider than the other) will fit
into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. Do not defeat the
safety purpose of the polarized plug.
Alternate Warning: If the equipment is powered
through a three way grounding type plug, a plug having
a third (grounding) pin, will only fit into a grounding-type
power outlet. This is a safety feature.
Do not defeat the safety purpose of the grounding type
plug. If your outlet does not have the grounding plug
receptacle, contact your local electrician.
9. CORD AND CABLE PROTECTION
Route power cords and cables in a manner to protect
them from damage by being walked on or pinched by
items places upon or against them.
10. LIGHTNING
For protection of the equipment during a lightning storm
or when it is left unattended and unused for long
periods of time, unplug the unit from the wall outlet.
Disconnect any antennas or cable systems that may be
connected to the equipment. This willprevent damage
to the equipment due to lightning or power line surges.
11. OVERLOADING
Do not overload wall outlets and extension cords as
this can result in a risk of fire or electric shock.
12. SERVICING
Do not attempt to service the video monitor or
equipment yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
13. DAMAGE REQUIRING SERVICE
Unplug the equipment from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power supply cord or the plug has been
damaged.
B. If liquid has spilled or objects have fallen into
the unit.
C. If the equipment has been exposed to water or
other liquids.
D. If the equipment does not operate normally by
following the operating instructions, adjust only those
controls that are covered by the operating
instructions. Improper adjustment of other controls
may result in damage to the unit.
E. If the equipment has been dropped or the casing
damaged.
F. When the equipment exhibits a distinct change
in performance.
14. REPLACEMENT PARTS
When replacement parts are required, be sure the
service technician uses replacement parts specified by
the manufacturer or that have the same characteristics
as the original part. Unauthorized substitutions may
result in fire, electric shock, or other hazards.
15. SAFETY CHECK
Upon completion of any service or repairs to the
equipment, ask the service technician to perform safety
checks to verify that the equipment is in proper
operating condition.
16. FIELD INSTALLATION
The installation of equipment should be made by a
Qualified service person and should conform to all local
codes.
3

INTRODUCTION
This remote keyboard is an accessory for PTZ dome camera, etc
It allows the user to control from 1 to 255 cameras.
1. Features
• Controls from 1 to 255 cameras.
• Multiple protocol supported in each channel (CMT, WDS,WCY, CYN, WSL, Pelco).
• RS 485/RS-422 communication (Tx : 3 port , Trx :1 port).
• Programmable user preferences. (preset, tour, group, etc.).
• Built-in 3-Axis proportional joystick
• Easy upload programmed data via serial communication port of PC.
• Built-in 2 lines character LCD.
• User password support.
• Designed for desktop use
• Programmable transmission speed for each ID. (2.4~57.6kbps)
Note: units should be set to the communication protocol and the same baud rate.
2. Hardware Overview
Hardware Components
• This remote keyboard contains easy to use control keys on the front and simple input and output connectors
on the back
Control buttons & connection
• The unit provides the primary operator interface. Most operations are one or two buttons presses.
• The following table contains a description for each buttons on the keyboard and port of cable connection.
Use Figure 1 and Figure 2 as a reference.
Figure 1
4

Number Button Description
1 ESC / POWER Pressing the ESC/POWER button enters the Power on/off or
escape key. Right description led on(red). Pressing it again
exits the POWER OFF.
(Push the button (about 2~3 seconds) and then POWER
OFF)
2 DISPLAY LCD Displays Camera ID, Protocol, Function status, General status,
etc
3 Number Camera ID setting value change, PTZ setup(1+ ),
Main setup(2+ )
4 Controller
Function keys
Hold: System locking
(Unlocking: Input the Pass word 4 digit ****)
SHIFT/TURBO: SHIFT-Key for special function (Customize) /
TURBO -High Speed
AUX: External equipment on/off
SET: PTZ and main setup (1 + ), (2+ )
CLOSE: Exit from tour, preset and pattern functions
OPEN: No action
5 Function keys F1 ~ MENU/AUTO : Function Keys
(Preset, Tour, Pattern, Scan, Auto).
MENU: Used for Camera (Pan/Tilt) Menu adjustment.
6Camera Focus control. Only if the speed dome is configured
(not recommended) in manual setting.
Camera Zoom control.
5

Figure 2
Number Button Description
1 Joystick Telemetry Joystick allows precise control of Pan/Tilt/Zoom
2 DV 12V Input DC 12V Input, 140mA
3
USB PORT
Universal Serial Bus Port, USB Mouse function
(External Equipment communication port)
Not used for Bticino range.
4
TRx Tx3 Tx2
Tx1
RS-485
RS-485/RS-422 communications. (Tx/Rx : 3 port , Trx :1 port)
5 Program Download connector (For Program Update)
Battery change’
Battery allows to save parameters in case of power supply failure.
9 V battery (not supplied)
Battery cover
6

3. System Configuration and Wiring
Basic Installation
Use the Keyboard Configuration when only one keyboard is connected to the controlled units.
Connect the RS-485 output port of Remote keyboard to RS-485 input port of the first controlled unit using the
terminal block
7

SYSTEM INSTALLATION & TYPICAL APPLICATIONS
1. System Installation
Keyboard Installation
Before you start connecting the keyboard equipment to your system, make sure the units to be controlled are completely
installed and everything is working correctly. Before use of this keyboard, you should set the protocol and baud rate
(2.4~57.6kbps) in the PTZ SETUP mode.
Use the following steps to set the communication protocol and baud rate.
2. PTZ SETUP
PTZ SETUP
PTZ Setup mode, select 1+ , (2~3 seconds) setup screen allows you to make change ench programmable
clause.
Note: The baud rate must be the same between the controlled unit and the keyboard.
SAISIE DU MOT DE PASSE (4 CHIFFRES)
REGLAGE DE L ’ ADRESSE (1-225) + ENT.
REGLAGE DU MODELE (WDS/WCY/CYN/WSL/Pelco)
REGLAGE DU PROTOCOLE (PEL-D/PEL-P/W-DRX)
REGLAGE DU DEBIT (2,4-57,6 KBPS)
REGLAGE DE LA PARITE (AUCUNE/PAIRE/IMPAIRE)
PROP. (ON/OFF) : commande de vitesse proportionnelle
SAUVEGARDE DES DONNEES DE CONFIGURATION
QUITTER LE MENU
CHANG. DE NIV. DE MENU DE CONFIG.
Ex_cution de la commande
CONFIG. PTZ
MOT DE PASSE
CONFIG. PTZ
1. ADRESSE: 001
CONFIG. PTZ
2. MODELE : PEL
CONFIG. PTZ
3. PROTOCOLE: PEL-D
CONFIG. PTZ
4. DEBIT: 2,4 K
CONFIG. PTZ
5. PARITE: NON
CONFIG. PTZ
6. PROP: ON
CONFIG. PTZ
7. SAUVEGARDE
CONFIG. PTZ
8. QUITTER
CONFIG. PZT
[PTZ SETUP 1]
PASSWORD [****]
[PTZ SETUP 1]
1. ADDRESS : 001
[PTZ SETUP 1]
2. MODEL : PEL
[PTZ SETUP 1]
3. PROTOCOL : PEL-D
[PTZ SETUP 1]
4. BAUDRATE : 2,4 K
[PTZ SETUP 1]
5. PARITY : NONE
[PTZ SETUP 1]
6. PROP. : ON
[PTZ SETUP 1]
7. SAVE
[PTZ SETUP 1]
8. EXIT
PTZ SETUP
Input password (Factory set : 0000)
: Input camera address by using joystick
(1~255) + ENT
: Find the camera model which user want to control by using joystick
Choose “CMT”
: Set the protocol. Choose “PEL-D”
: Set the baudrate (2,4KBPS - 57,6KBPS)
Choose “2,4KBPS”
: Set the PARITY (NONE/EVEN/ODD)
Choose “NONE”
: Set the camera speed
Slow PTZ => PROP : ON
Speed PTZ => PROP : OFF
Choose “ON”
: Save the data
: Exit PTZ SETUP Menu
8

3. MAIN SETUP
MAIN SETUP
Main Setup mode, select 2+ (2~3 seconds).
Setup screen allows you to make change in each programmable clause.
Note: The baud rate must be the same between the controlled unit and the keyboard.
: Input password (Factory set : 0000)
: Shows software version
Shows software date
Title setting when power on
: ID No. 1 Do not change
: DVR Communication Speed setting
Select 9,6K
: Communication setting
Select RS485
[MAIN SETUP]
7. BACKLIGHT : AUTO
[MAIN SETUP]
8. SLEEP : OFF
[MAIN SETUP]
9. BUZZER : ON
: OFF/ON/AUTO BACKLIGHT setting fot LCD
- Auto : Automatically OFF after 30 sec
- ON
- OFF
: OFF/1 Min/5Min/10Min/30Min/1 (Hour)
Setting to save power in the standby mode
: OFF/ON Select BUZZER ON/OFF
9

4. JOYSTICK CALIBRATION
: OFF/ON Select ON if there are more than 1 speed dome
(the last one has its terminal switch ON).
: Select the time between 2 orders when the keyboard has to re-
peat one (300 ms).
[MAIN SETUP]
15. SAVE/EXIT
This function is useful to set the maximum joystick movements. To be done only if you remark any problem.
If you press button 3 + for 2~3 seconds), you can enter into the JOYSTICK CALIBRATION menu.
: Show the joystick center value
: Move the joystick to the maximum amount of left side and press button
: Move the joystick to the maximum amount of right side and press button
: Move the joystick to the maximum amount of upside and press button
: Move the joystick to the maximum amount of downside and press button
: Turn the joystick head to the maximum amount of counterclockwise (zoom) and
press button
: Select YES or NO and press button
: Turn the joystick head to the maximum amount of clockwise (tele) and
press button
Factory set. All data will be changed to the factory set.
(Move to YES and press ENT)
Save the data or not for the changed setting value.
[MAIN SETUP]
10. TERMINATE : ON
[MAIN SETUP]
11. JOYSTICK SPD
[MAIN SETUP]
12. MOUSE SPD : HIG
[MAIN SETUP]
13. PASSWORD: ****
[MAIN SETUP]
14. FACTORY SET
[MAIN SETUP]
15. SAVE / EXIT
: HIG/MID/LOW Mouse speed setting when operated with DVR
Password change (factory set : 0000)
10

5. BASIC FUNCTIONS : SETTING AND CONTROL
PRESET
User can set the camera positions that have to be repeated automatically.
TOUR
F2
TOUR
F2
TOUR
F2
1
+
1+PSET 3+PSET
2+PSET
PSET
F1
PSET
F1
PSET
F1
1
+
1+PSE
T3
+PSET
2+PSET
SCAN
F4 SCAN
F4
SCAN
F4
1
MENU
AUTO
+
PATT
F3
PATT
F3
PATT
F3
1
+
A pointB point
90
270
PRESET : PRESET NO. + 3sec
PRESET : PRESET NO. + 1sec
PATTERN : PATTERN NO. + 3sec
PATTERN : PATTERN NO. + 1sec
SCAN : SCAN NO. + 3sec
SCAN : SCAN NO. + 1sec
TOUR : TOUR NO. + 3 sec
TOUR : TOUR NO. + 1sec
To exit from preset function, press key when the camera is fixed.
TOUR
When Tour function runs, the camera moves from the preset assigned as the 1st point to the preset assigned as the last point in
sequence. The camera will stay to each point for the time set to the “dwell” time and will move to the next point.
• Tour setting
- Press the key for more than 3 seconds, OSD menu will appear.
- Go to Dome Camera Setup menu with the joystick, and press the k e y.
- Go to Group Setup Menu, press the k e y.
- Go to Group No. option and press Key. Select the group number and press k e y.
- Go to Edit Group +
- Go to No Action Line +
- Go to 1 line +
- Select the first action (preset position, swing, pattern).
- “Dwell” time is the time during which the camera will stay on each preset position, or the time during which the camera
remains fixed after a swing or a pattern.
OPT is camera speed, in degree per second.
setting
operating
TOUR
F2
TOUR
F2
TOUR
F2
1
+
1+PSET 3+PSET
2+PSET
PSET
F1
PSET
F1
PSET
F1
1
+
1+PSET3+PSET
2+PSET
SCAN
F4 SCAN
F4
SCAN
F4
1
MENU
AUTO
+
PATT
F3
PATT
F3
PATT
F3
1
+
A pointB point
90
270
PRESET : PRESET NO. + 3sec
PRESET : PRESET NO. + 1sec
PATTERN : PATTERN NO. + 3sec
PATTERN : PATTERN NO. + 1sec
SCAN : SCAN NO. + 3sec
SCAN : SCAN NO. + 1sec
TOUR : TOUR NO. + 3 sec
TOUR : TOUR NO. + 1sec
11

PATTERN
Camera memorizes the path (mostly curve path) by the controller joystick for an assigned time and revives the path exactly `
as it was memorized.
TOUR
F2
TOUR
F2
TOUR
F2
1
+
1+PSET 3+PSET
2+PSET
PSET
F1
PSET
F1
PSET
F1
1
+
1+PSET3+PSET
2+PSET
SCAN
F4 SCAN
F4
SCAN
F4
1
MENU
AUTO
+
PATT
F3
PATT
F3
PATT
F3
1
+
A pointB point
90
270
PRESET : PRESET NO. + 3sec
PRESET : PRESET NO. + 1sec
PATTERN : PATTERN NO. + 3sec
PATTERN : PATTERN NO. + 1sec
SCAN : SCAN NO. + 3sec
SCAN : SCAN NO. + 1sec
TOUR : TOUR NO. + 3 sec
TOUR : TOUR NO. + 1sec
Consecutively operating
90°C
270°C
• Tour Operating :
To exit from tour function, press key when the camera is fixed.
TOUR
F2
TOUR
F2
TOUR
F2
1
+
1+PSET 3+PSET
2+PSET
PSET
F1
PSET
F1
PSET
F1
1
+
1+PSET3+PSET
2+PSET
SCAN
F4 SCAN
F4
SCAN
F4
1
MENU
AUTO
+
PATT
F3
PATT
F3
PATT
F3
1
+
A pointB point
90
270
PRESET : PRESET NO. + 3sec
PRESET : PRESET NO. + 1sec
PATTERN : PATTERN NO. + 3sec
PATTERN : PATTERN NO. + 1sec
SCAN : SCAN NO. + 3sec
SCAN : SCAN NO. + 1sec
TOUR : TOUR NO. + 3 sec
TOUR : TOUR NO. + 1sec
PATTERN setting : PATTERN NO. + 3 sec
- Move the camera with the joystick.
- Memorize the pattern by pressing k e y.
PATTERN operating : PATTERN NO. + 1 sec
- To exit from Pattern function, press key at the end of the pattern.
TOUR
F2
TOUR
F2
TOUR
F2
1
+
1+PSET 3+PSET
2+PSET
PSET
F1
PSET
F1
PSET
F1
1
+
1+PSET3+PSET
2+PSET
SCAN
F4 SCAN
F4
SCAN
F4
1
MENU
AUTO
+
PATT
F3
PATT
F3
PATT
F3
1
+
A pointB point
90
270
PRESET : PRESET NO. + 3sec
PRESET : PRESET NO. + 1sec
PATTERN : PATTERN NO. + 3sec
PATTERN : PATTERN NO. + 1sec
SCAN : SCAN NO. + 3sec
SCAN : SCAN NO. + 1sec
TOUR : TOUR NO. + 3 sec
TOUR : TOUR NO. + 1sec
TOUR
F2
TOUR
F2
TOUR
F2
1
+
1+PSET 3+PSET
2+PSET
PSET
F1
PSET
F1
PSET
F1
1
+
1+PSET3+PSET
2+PSET
SCAN
F4 SCAN
F4
SCAN
F4
1
MENU
AUTO
+
PATT
F3
PATT
F3
PATT
F3
1
+
A pointB point
90
270
PRESET : PRESET NO. + 3sec
PRESET : PRESET NO. + 1sec
PATTERN : PATTERN NO. + 3sec
PATTERN : PATTERN NO. + 1sec
SCAN : SCAN NO. + 3sec
SCAN : SCAN NO. + 1sec
TOUR : TOUR NO. + 3 sec
TOUR : TOUR NO. + 1sec
Position A Position B
SCAN
Camera moves between 2 positions continually.
12

6. SPECIFICATIONS
Model 391856
Keyboard Communication
Interface: RS-485 (Tx 3 port, Trx 1 port) P
Pan/Tilt operating distance :4700 ft (1029m) No 24 AWG wire
Protocol: Multiple (Pelco-d, etc. ) (Baud rate selectable)
Connector Type Date TERMINAL BLOCK(8p)
Keyboard Keypad Rubber button
Numeric keypad and camera function key
Joystick Stick 3-axis, variable speed with zoom
Input Voltage 12VDC (power supply) o 9VDC (battery)
Power Consumption Max.140mA
LCD Display Graphic display : 16 * 2 Graphic display
Operating Temperature 0 to 45°C
Humidity 10% -70 % non-condensing
Dimension & Weight 280(W) x 174(D) x 92(H), Net : 0.7 Kg Gross: 1.7Kg
Packing include
KEYBOARD, ADAPTOR
Packing include : MANUAL,
TERMINAL BLOCK(8p)
SYSTEM LOCKING
- To lock the key board, press key (2s).
- To unlock it, enter the password (0000 by default).
• Scan setting:
- Press the key for more than 3 seconds, OSD menu will appear.
- Go to Dome Camera Setup + .
- Go to Swing Setup + .
- Select the 2 preset positions.
- Choose the speed between the 2 positions, in degree per second.
- Exit from the menu.
• Scan operating :
TOUR
F2
TOUR
F2
TOUR
F2
1
+
1+PSET 3+PSET
2+PSET
PSET
F1
PSET
F1
PSET
F1
1
+
1+PSET3+PSET
2+PSET
SCAN
F4
SCAN
F4
SCAN
F4
1
MENU
AUTO
+
PATT
F3
PATT
F3
PATT
F3
1
+
A pointB point
90
270
PRESET : PRESET NO. + 3sec
PRESET : PRESET NO. + 1sec
PATTERN : PATTERN NO. + 3sec
PATTERN : PATTERN NO. + 1sec
SCAN : SCAN NO. + 3sec
SCAN : SCAN NO. + 1sec
TOUR : TOUR NO. + 3 sec
TOUR : TOUR NO. + 1sec
To exit from scan function, press key when the camera is fixed.
1 sec.
13
