LEGRAND Mallia Senses with Netatmo 2 815 02DS/MB/MW Original operating instructions

Cat. No(s): 2 815 02DS/MB/MW - 2 815 04DS/MB/MW
2 815 06DS/MB/MW
Technical data sheet: F03691EN/00 Updated: Created: 11/04/2022
1/2
MalliaTM Senses with Netatmo
Connected switches with neutral
128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex
Tel: [phone] - Fax: [phone]
www.legrand.com
3. DIMENSIONS (mm)
4. CONNECTION
Terminal type : with screws
Terminal capacity: 2 x 1.5 mm2 - 2 x 2.5 mm2- 1 x 4 mm2
Stripping length: 8 mm
1. USE
For local or remote control of lighting devices and other controls.
Can be combined with one or more wireless lighting controls.
Can be installed in place of an existing switch in a flush-mounting box 25 mm deep (minimum).
2. RANGE
A B C D
86 86 32.5 12
B
A
C
D
Description Silver Black White
Product for use in conjunction with the starter pack.
With LED indicator (locator) and RESET button (hidden) used to return to factory
settings.
Locator and indicator modes can be activated from the Home + Control App.
Complete delivered with protection lm and 2 screws M3.5 for BS boxes.
2 815 02DS
1-gang
2 815 02MB
1-gang
2 815 02MW
1-gang
2 815 04DS
2-gang
2 815 04MB
2-gang
2 815 04MW
2-gang
2 815 06DS
3-gang
2 815 06MB
3-gang
2 815 06MW
3-gang
5. OPERATION
LED indicator:
- useful during installation
- illumination function can be activated
from the Home + Control app
RESET button
used to return to factory settings
ON/OFF
when press
2 815 02DS/MB/MW
1-gang: 2 815 02DS/MB/MW
2 815 04DS/MB/MW 2 815 06DS/MB/MW

2/2
Cat. No(s): 2 815 02DS/MB/MW - 2 815 04DS/MB/MW
2 815 06DS/MB/MW
MalliaTM Senses with Netatmo
Connected switches with neutral
Technical data sheet: F03691EN/00 Updated: Created: 11/04/2022
Caution: Always test before using special cleaning products.
6. TECHNICAL CHARACTERISTICS
6.1 Mechanical characteristics
Protection against impacts: IK 04
Protection against solid bodies and liquids: IP 20
IP 40 mounted product
6.2 Material characteristics
Rocker plate: PC
Plate: PC
Mechanism casing: PC
Halogen-free
UV-resistant
Self-extinguishing:
850°C/30 s for insulating components holding live parts in place.
650°C/30 s for other insulating components.
6.3 Electrical characteristics
Voltage: 110/240 V~
Frequency: 50/60 Hz
Compatible with all loads:
LEDs and CFL lamps: 150 W LED
Incandescent and halogen lamps: 500 W
ELV halogen and CFL lamps with separate ballast: 300 VA
Note:
LED: or 10 lamps max. For comfortable lighting, we recommended using
bulbs of the same type and brand.
Use only with transformers designed to work with electronic switches.
Take account of transformer losses when calculating power.
Transformers must be loaded at more than 60% of their power.
Zigbee technology
Frequency: 2.4 GHz to 2.4835 GHz
Power level: < 100 mW
Range: 200 m of unobstructed space
10 m between products indoors
6.4 Climate characteristics
Storage temperature: 0°C to + 45°C
Usage temperature: +5°C to + 35°C
7. CARE
Clean the surface with a cloth.
Do not use acetone, tar-removing cleaning agents or trichloroethylene.
Resistant to the following products: Hexane, methylated spirit, soapy
water, diluted ammonia, bleach diluted to 10%, window-cleaning pro-
ducts, pre-impregnated wipes.
8. STANDARDS AND APPROVALS
Compliant with installation and manufacturing standards.
See e-catalogue.
The undersigned, LEGRAND, declares that the radio-electric equipment
type (2 815 02DS/MB/MW - 2 815 04DS/MB/MW - 2 815 06DS/MB/MW)
complies with directive 2014/53/EU.
The full text of the EU declaration of conformity is available on the
following website: www.legrandoc.com
5. OPERATION (continued)
LED indicator:
- useful during installation
- illumination function can be activated
from the Home + Control app
RESET button
used to return to factory settings
ON/OFF
when press
LED indicator:
- useful during installation
- illumination function can be activated
from the Home + Control app
RESET button
used to return to factory settings
ON/OFF
when press
2-gang: 2 815 04DS/MB/MW
3-gang: 2 815 06DS/MB/MW
