Leica A60 S User manual

Leica A60 S
User Manual

Leica A60 S User Manual 2
Safety Instructions
Symbols Used 4
Important Notes 5
Instructions on Use 6
Health Risks and Dangers of Use 8
Information for the Person Responsible for the Instrument 9
Care Instructions 10
Accessories, Maintenance and Repair 11
The Leica A60 S
Congratulations! 13
An Overview of the Leica A60 S 14
Assembling the Leica A60 S
Column and Baseplate 16
Safety Ring and Horizontal Arm 17
Grounding 18
Assembling the Optics Carrier 19
Fastening the Leica A60 20
Assembling the Illuminator 21
Using the Leica A60 S
Adjusting the Working Height 23
The Correct Interpupillary Distance 25
Focusing 26
Magnification Display 27
Dioptric Correction and Parfocality 28
Adjusting the Torque of the Focus Drive 29
Leica A60 LED Ring Illuminator 30
Replacing the Protective Glass 31
Dimensions
Dimensions 33
Optical data
Optical data 35
Table of Contents

Leica A60 S User Manual Safety Instructions 3
Safety Instructions

Leica A60 S User Manual Safety Instructions 4
Warning! Safety hazard!
This symbol indicates especially impor-
tant information that is mandatory to
read and observe.
Failure to comply can cause the following:
OHazards to personnel
OInstrument malfunctions and damage
Warning of hazardous electrical voltage
This symbol indicates especially impor-
tant information that is mandatory to
read and observe.
Failure to comply can cause the following:
OHazards to personnel
OInstrument malfunctions and
damage
Danger due to hot surface
This symbol warns against touching
accessible hot surfaces, e.g. those of
light bulbs.
Important information
This symbol indicates additional infor-
mation or explanations that are intended
to provide clarity.
Symbols Used

Leica A60 S User Manual Safety Instructions 5
Description
The Leica A60S stereomicroscope meets
today's state of the art of technology. Neverthe-
less, hazards may still arise during operation.
The potential risks are described below.
Before installing, operating or using the
instrument, it is mandatory to read this
user manual. In particular, please observe all
safety instructions.
User manual
This user manual includes important instruc-
tions related to operating safety, maintenance
and accessories.
Your Leica A60 S stereomicroscope
includes an interactive CD-ROM
with all relevant user manuals. Keep it in
a safe place, and readily accessible to the
user. You can also download user manu-
als and updates from our website at
www.leica-microsystems.com
Legal requirements
Adhere to general and local regulations relat-
ing to accident prevention and environmental
protection.
EC Declaration of Conformity
Electrically operated accessories are
constructed based on the state of the art of
technology and are provided with an EC Decla-
ration of Conformity.
Important Notes

Leica A60 S User Manual Safety Instructions 6
Intended use
The Leica A60 S stereomicroscope is an opti-
cal instrument for improving the visibility of
objects through magnification and illumina-
tion.
The stereomicroscope may be used only in
closed rooms and must be placed on a solid
substrate.
Always position the stereomicroscope
so that you can disconnect the illu-
mination from the power supply at any time.
The power cable must remain accessible at all
times, because the power cable is intended as a
power disconnect device.
Place of use
Use the stereomicroscope in closed, dust-free
rooms at +10°C to +40 °C. Protect it from oil,
chemicals and extreme humidity. Install elec-
trical devices at least 10 cm from the wall and
away from flammable substances.
In warm and warm-damp climatic zones,
the individual components require
special care in order to prevent the build-up of
fungus.
Non-intended use
Using the stereomicroscope in any way
other than that described in the user
manual may result in personal injury or damage
to property. Doing so can impair the functions
of the protective measures provided.
Never install any other plug (NEMA
5-15P) or unscrew any mechanical
components unless expressly instructed to do
so in the instructions.
The instruments and accessories
described in this user manual have been
tested for safety and potential hazards.
Instructions on Use

Leica A60 S User Manual Safety Instructions 7
The responsible Leica affiliate must be
consulted whenever the instrument is
altered, modified or used in conjunction with
non-Leica components that are outside of the
scope of this manual!
Unauthorized alterations to the instru-
ment or noncompliant use shall void all
rights to any warranty claims.
Transport
If at all possible, use the original packaging for
shipping or transporting individual modules.
In order to prevent damage from vibrations, the
customer should disassemble all moving parts
according to the user manual and pack them
separately.
Disposal
Disposal must comply with locally applicable
laws and regulations.
Integration in third-party products
When installing Leica products into third-party
products, the manufacturer of the complete
system or its dealer is responsible for follow-
ing all applicable safety instructions, laws and
guidelines.
Instructions on Use (Continued)

Leica A60 S User Manual Safety Instructions 8
Health risks
Workplaces with stereomicroscopes
facilitate and improve the viewing task,
but they also impose high demands on the eyes
and holding muscles of the user. Depending on
the duration of uninterrupted work at such a
workplace, impaired vision and problems with
the musculoskeletal system may occur. For this
reason, appropriate measures for reduction of
the workload must be taken:
OOptimum workplace layout
OFrequent changes of activity
OThorough training of the personnel, giving
consideration to ergonomic and organiza-
tional aspects
The ergonomic optical design and construction
of the Leica stereomicroscopes are intended to
reduce the exertion of the user to a minimum.
Danger of infection
Direct contact with eyepieces is a
potential transmission method for
bacterial and viral infections of the eye.
The risk can be kept to a minimum by
using personal eyepieces for each indi-
vidual or detachable eyecups.
Dangers during use
OThe stereomicroscope must be connected
to a grounded outlet.
OThe stereomicroscope may be used when it
is in proper working condition only.
Health Risks and Dangers of Use

Leica A60 S User Manual Safety Instructions 9
Information for the person responsible for
the instrument
OEnsure that the stereomicroscope is used
only by persons qualified to do so.
OEnsure that this manual is always available
at the place where the stereomicroscope is
in use.
OCarry out regular inspections to make
certain that the authorized users are adher-
ing to safety requirements.
OWhen instructing new users, do so thor-
oughly and explain the meanings of the
warning signs and messages.
OAssign individual responsibilities for start-
ing, operating and servicing the instru-
ment and monitor the observance of these
responsibilities.
OOnly use the stereomicroscope in proper
condition.
OInform your Leica representative or Leica
Microsystems (Schweiz) AG, Industry Divi-
sion, 9435 Heerbrugg, Switzerland, imme-
diately of any product defect that could
potentially cause injury or harm.
OIf you use accessories from other manu-
facturers with the stereomicroscope, make
sure that these manufacturers confirm that
the combination is safe to use. Follow the
instructions in the user manual for those
accessories.
OModifications to or service on the stereomi-
croscope may be carried out only by techni-
cians who are explicitly authorized by Leica
to do so.
OOnly original Leica replacement parts may
be used in servicing the product.
OAfter service work or technical modifica-
tions, the device must be readjusted in
accordance with our technical specifica-
tions.
OIf the unit is modified or serviced by unau-
thorized persons, is improperly maintained
(as long as maintenance was not carried
out by us), or is handled improperly, Leica
will not accept any liability.
OThe electric installation in the building
must conform to the national standard, e.g.
current-operated ground leakage protec-
tion (fault-current protection) is suggested.
Information for the Person Responsible for the Instrument

Leica A60 S User Manual Safety Instructions 10
General Instructions
OProtect the stereomicroscope from mois-
ture, fumes and acids and from alkaline,
caustic and corrosive materials. Do not
store chemicals in the vicinity.
OProtect the stereomicroscope from oil and
grease. Never grease or oil mechanical
parts or sliding surfaces.
OFollow the instructions of the disinfectant
manufacturer.
OWe recommend concluding a service
contract with Leica Service.
Cleaning coated parts and plastic parts
ODust and dirt particles should be removed
with a soft brush or lint-free cotton cloth.
ORemove coarse debris with a moistened
disposable cloth.
OAcetone, xylene or nitro-containing thin-
ners must NOT be used.
ONever use chemicals to clean colored
surfaces or accessories with rubberized
parts. This could damage the surfaces,
and specimens could be contaminated by
abraded particles.
Cleaning glass surfaces
ORemove dust using a fine, dry and grease-
free brush made from hair, by blowing with
a squeeze blower, or by using a vacuum.
ORemove dirt using a clean cloth that has
been moistened with distilled water.
ORemove tough dirt using alcohol, chloro-
form or petroleum ether.
Care Instructions

Leica A60 S User Manual Safety Instructions 11
Accessories
Only the following accessories may be used
with the stereomicroscope:
OThe Leica accessories described in this user
manual.
OOther accessories, provided that these have
been expressly approved by Leica Micro-
systems as being technically safe in this
context.
Maintenance
OThe Leica A60 S stereomicroscope is basi-
cally maintenance-free. To ensure that it
always operates safely and reliably, we
recommend that you take the precaution
of contacting the responsible service orga-
nization.
You can arrange for periodic inspections
or, if appropriate, conclude a mainte-
nance contract with them.
OWe recommend concluding a service
contract with Leica Service.
OFor maintenance and repair, only OEM
spare parts may be used.
Repairs and service work
OOnly original Leica Microsystems spare
parts may be used.
OBefore opening the instruments, switch off
the power and unplug the power cable.
OTouching the live circuit can cause injury.
Accessories, Maintenance and Repair

Leica A60 S User Manual The Leica A60 S 12
The Leica A60 S

Leica A60 S User Manual The Leica A60 S 13
Congratulations!
You have just purchased a Leica A60 S – an
excellent choice! The outstanding features of
this stereomicroscope are its flexible design, its
ease of use and absolutely maintenance-free
performance. Sturdy and reliable, it is excep-
tionally well suited to manufacturing tasks,
materials testing, quality control and other
industrial applications.
In developing the Leica A60S, we have placed
great emphasis on simple, self-explanatory
operation. However, please take the time to
read the user manual and the notes on oper-
ating safety to learn about all the features and
capabilities of your stereomicroscope so that
you can use it to its best advantage. Should
you have any questions, please consult your
local Leica representative. We are gladly at your
service!

Leica A60 S User Manual The Leica A60 S 14
An Overview of the Leica A60 S
1. Column
2. Horizontal arm
3. Locking screw on the cross-member
4. Safety ring
5. Baseplate with grounding point
6. Magnification changer (zoom)
7. Eyepieces
8. Focusing drive
9. Optics carrier
10. Leica A60 LED ring Illuminator
4
5
26
9
10
8
1
37

Leica A60 S User Manual Assembling the Leica A60 S 15
Assembling the Leica A60 S

Leica A60 S User Manual Assembling the Leica A60 S 16
Column and Baseplate
Instructions for safe assembly
Due to the heavy weight of the base-
plate, improper use can cause injuries
or damage to the surrounding area. Therefore,
always request assistance for assembly.
Installing the column
1. Push the tapping screw through the base-
plate from below.
2. Fit the serrated lock washer onto the screw.
3. Screw the column in place using the Allen
key provided.

Leica A60 S User Manual Assembling the Leica A60 S 17
Mounting the horizontal arm
1. Push the cross-member with the horizon-
tal arm over the column so that the cross-
member lies securely on the safety ring. You
can now rotate the horizontal arm in any
direction desired.
Safety Ring and Horizontal Arm
Installing the safety ring
The safety ring is the most important
safety element of the entire configura-
tion. It protects the horizontal arm against fall-
ing down accidentally.
1. Slide the safety ring over the column and
tighten the clamping screw.
Fastening the horizontal arm
For safety reasons, you should fasten
the horizontal arm in place when you
leave your workstation.
1. Rotate the horizontal arm into a secure
position.
2. Carefully tighten the clamping screw on
the cross-member.

Leica A60 S User Manual Assembling the Leica A60 S 18
Grounding the baseplate
The rear side of the baseplate has a
grounding point that you can use to
ground the configuration. The grounding cable
is not included in the scope of delivery.
Use
1. Connect the grounding cable to the
grounding point of the baseplate.
Grounding

Leica A60 S User Manual Assembling the Leica A60 S 19
Assembly
1. Insert the connecting pin from below into
the bore of the horizontal arm.
2. Fasten the stereomicroscope using the
washer and safety screw.
Free movement of the stereomicroscope
After you have installed the safety screw, the
stereomicroscope can be rotated freely.
Assembling the Optics Carrier

Leica A60 S User Manual Assembling the Leica A60 S 20
Fastening
The swing-arm stand is designed so
that the Leica A60 S can be moved as
desired. However, it may also be logical in some
instances to fasten the stereomicroscope in
place.
1. Carefully tighten the side clamping screw.
This fastens the stereomicroscope in its
current position.
Fastening the Leica A60
