Lena Lighting FACTOR LED User manual

FACTOR LED
06.03.2023
8
IK09
IP66 220-240 V
50/60 Hz
FOR 1 - 4 MODULE VERSION

FACTOR LED - INSTALLATION INSTRUCTION
1
DIMENSIONS
2
FACTOR LED - INSTALLATION INSTRUCTION
VERSION WITH ONE MODULE
3
VERSION WITH ONE MODULE
LOOSEN THE SCREWS ON TWO SIDES
TO ADJUST THE ANGLE
4
VERSION WITH ONE MODULE
5
VERSION WITH ONE MODULE
0
270
3
VERSION WITH ONE MODULE
TIGHTEN THE SCREWS ON BOTH SIDES
TO MAINTAIN THE SELECTED ANGLE
MAX!
IP66

FACTOR LED - INSTALLATION INSTRUCTION
5a
ONE MODULE - ACCESORIES
5b
ONE MODULE - ACCESORIES
x4
6
2M, 3M, 4M VERSION
UNSCREW
AFTER UNSCREWING,
REMOVE THE LAMP
7
2M, 3M, 4M VERSION
9
2M, 3M, 4M VERSION
UNSCREW AND LOOSEN THE SCREWS
FACTOR LED - INSTALLATION INSTRUCTION
REMEMBER TO BOLT EVERYTHING DOWN AFTER SETUP
8a
45
DIMENSIONS
8b
PUSH
X2
SCREW
MAX!

FACTOR LED - INSTALLATION INSTRUCTION FACTOR LED - INSTALLATION INSTRUCTION
67
13
11
12
10
2M, 3M, 4M VERSION
YOU CAN ADJUST THE PANEL WITH A M6 SCREW
BY SCREWING IT INTO ONE OF THE THREE HOLES
