Lenze L-force 8400 Series User manual

Montageanleitung
EDK84VxCC153xxB
.F7Y
Ä.F7Yä
8400 0.25 ... 45 kW

E84AVxCCxxxx Cold Plate
Frequenzumrichter
Frequency Inverter
Convertisseur de fréquence
Convertidor de frecuencia
Inverter di frequenza
Mounting Instructions
Instructions de montage
Instrucciones para el montaje
Istruzioni per il montaggio
L−force Drives




2 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
0
V
Warnings!
Operation of this equipment requires detailed installation and operation instructions
provided in the Hardware manual intended for use with this product. This information
is provided on the CD−ROM included in the container this device was packaged in. It
should be retained with this device at all times. A hard copy of this information may
be ordered by phone or e−mail, printed on the back of this document.
Gefahr!
Gefährliche elektrische Spannung
ƒDie Leistungsanschlüsse X100 und X105 führen bis zu 3 Minuten nach
Netz−Ausschalten gefährliche elektrische Spannung.
Mögliche Folgen:
ƒTod oder schwere Verletzungen beim Berühren der Leistungsanschlüsse.
Schutzmaßnahmen:
ƒVor Arbeiten am Gerät Netzspannung ausschalten und mindestens 3 Minuten
warten.
ƒPrüfen, ob alle Leistungsanschlüsse spannungsfrei sind.
Beachten Sie auch weitere wichtige Informationen zur Geräte− und Sicherheitstechnik auf der
beiliegenden CD−ROM!
Danger!
Dangerous voltage
ƒThe power terminals X100 and X105 carry dangerous voltages for up to 3 minutes
after mains disconnection.
Possible consequences:
ƒDeath or severe injury if the power terminals are touched.
Protective measures:
ƒSwitch off the mains voltage and wait at least 3 minutes before starting to work on
the device.
ƒCheck that all power terminals are deenergised.
Please also observe more important information on device and safety technology provided on the
enclosed CD−ROM!


3
EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
Danger !
Tension électrique dangereuse
ƒLes raccordements de puissance X100 et X105 sont susceptibles de véhiculer une
tension dangereuse jusqu’à 3 minutes après une coupure réseau.
Risques encourus :
ƒMort ou blessures graves en cas de contact avec les raccordements de puissance
Mesures de protection :
ƒAvant toute manipulation de l’appareil, couper la tension réseau et attendre 3
minutes au minimum.
ƒS’assurer que tous les raccordements de puissance sont hors tension.
Veuillez également tenir compte des consignes importantes sur la technologie des appareils et les
fonctions de sécurité comprises sur le cédérom joint !
¡Peligro!
Voltaje eléctrico peligroso
ƒLas conexiones de potencia X100 y X105 siguen vivas hasta 3 minutos después de
la desconexión de red.
Posibles consecuencias:
ƒMuerte o serias lesiones al tocar las conexiones de potencia.
Medidas de protección:
ƒAntes de trabajar en el equipo, desconectar la alimentación de red y esperar por lo
menos 3 minutos.
ƒComprobar, si todas las conexiones de potencia están libres de voltaje.
Observe también la información importante sobre aspectos relativos a la técnica del dispositivo
y de seguridad incluida en el CD−ROM adjunto!
Pericolo!
Tensione elettrica pericolosa
ƒI collegamenti di potenza X100 e X105 presentano una tensione elettrica pericolosa
fino a 3 minuti dopo la disinserzione della rete.
Possibili conseguenze:
ƒMorte o gravi lesioni in caso di contatto con i collegamenti di potenza.
Misure di protezione:
ƒAttendere almeno 3 minuti prima di eseguire qualsiasi intervento sui collegamenti
di potenza.
ƒControllare tutti i collegamenti di potenza per accertare l’assenza di tensione.
Osservare anche le ulteriori informazioni importanti relative a installazione e sicurezza incluse nel
CD−ROM allegato!


0.25  3.0 kW

4 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0

0.25  3.0 kW
8400HLC075a


0.25  3.0 kW
5
EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
8400HLC082a


0.37  3.0 kW

6 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
0.37  3.0 kW
8400HLC075b


0.37  3.0 kW
7
EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
8400HLC082b


3.0  22 kW

8 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
3.0  22 kW
8400HLC076


3.0  22 kW
9
EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
8400HLC083


30  45 kW

10 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
30  45 kW
8400GG066


30  45 kW
11
EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
8400GG067

[mm]1 0.25  2.2 kW

12 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
1
[mm]
0.25  2.2 kW
StateLine, HighLine
8400SLC047
a b c c1 c3 d1 d2 e f
[kW] [mm] [kg]
E84AVxxC2512xx0 0.25 102 226 173 193 12 80 85 90 12 1.3
E84AVxxC3712xx0 0.37
E84AVxxC3714xx0 0.37
102 276 151 171 12 105 110 90 12 1.5
E84AVxxC551xxx0 0.55
E84AVxxC751xxx0 0.75
E84AVxxC112xxx0 1.1
137 335 151 171 12 135 135 125 12 1.9
E84AVxxC152xxx0 1.5
E84AVxxC222xxx0 2.2

[mm] 10.37  3.0 kW
13
EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
0.37  3.0 kW
StateLine, HighLine
8400GG098
a b c c1 c3 d e f
[kW] [mm] [kg]
E84AVxxC3714xxS 0.37
70 276 151 171 12 227.5 50 20 1.5
E84AVxxC551xxxS 0.55
E84AVxxC751xxxS 0.75
E84AVxxC112xxxS 1.1
70 335 151 171 12 285 50 20 1.9
E84AVxxC152xxxS 1.5
E84AVxxC222xxxS 2.2
E84AVxxC3024xxS 3.0

[mm]1 0.37  3.0 kW

14 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
0.37  3.0 kW
TopLine
8400TLC029
a b c c1 c3 d1 d2 e f
[kW] [mm] [kg]
E84AVTCC3714xx0 0.37
102 276 167 187 39 105 110 90 12 1.5
E84AVTCC551xxx0 0.55
E84AVTCC751xxx0 0.75
E84AVTCC112xxx0 1.1
137 335 167 187 39 135 135 125 12 1.9
E84AVTCC152xxx0 1.5
E84AVTCC222xxx0 2.2

[mm] 10.37  3.0 kW
15
EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
TopLine
8400TLC035
a b c c1 c3 d e f
[kW] [mm] [kg]
E84AVTCC3714xxS 0.37
70 276 167 187 39 227.5 50 20 1.5
E84AVTCC551xxxS 0.55
E84AVTCC751xxxS 0.75
E84AVTCC112xxxS 1.1
70 335 167 187 39 285 50 20 1.9
E84AVTCC152xxxS 1.5
E84AVTCC222xxxS 2.2
E84AVTCC3024xxS 3.0

X100 (230 V)20.25  2.2 kW

16 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
2
X100 (230 V)
0.25  2.2 kW
X100 − TN, TT
1/N/PE AC 230 V
L1
N
PE
F
K
Z
PE
NL1
X100
8400GG029 8400GG003
X100 − IT
1/N/PE AC 230 V
L1
N
PE
F
K
PE
NL1
X100
8400GG034 8400GG004
FL1, N PE
EN 60204 UL
[A] [A] [A] [A] [mm2]
[AWG]
[mm] [Nm]
[lb−in]
[mm2]
[AWG]
[mm] [Nm]
[lb−in]
E84AVxxC2512 6 C6 6 C6 6 6 1 ... 2.5
18 ... 12 70.5 4.4
1 ... 6
18 ... 10 10 1.7 15
E84AVxxC3712 6 C6 6 C6 10 10
E84AVxxC5512 10 C10 10 C10 10 10 1 ... 2.5
18 ... 12 70.5 4.4
1 ... 6
18 ... 10 10 1.7 15
E84AVxxC7512 10 C10 10 C10 15 15
E84AVxxC1122 16 C16 16 C16 20 20
1 ... 6
18 ... 10 80.5 4.4
1 ... 6
18 ... 10 10 1.7 15
E84AVxxC1522 16 C16 20 C20 25 25
E84AVxxC2222 20 C20 25 C25 30 30

X100 (400 V) 20.37  3.0 kW
17
EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
X100 (400 V)
0.37  3.0 kW
X100 − TN, TT
3/N/PE AC 400 V / 500 V
L1
L2
L3
N
PE
F1…F3
K
Z
PE L3
L1 +UG -UG
L2
X100
8400GG035 8400GG007
X100 − IT
3/N/PE AC 400 V / 500 V
L1
L2
L3
N
PE
F1…F3
K
PE L3
L1 +UG -UG
L2
X100
8400GG036 8400GG008
FL1, L2, L3 PE
EN 60204 UL
[A] [A] [A] [A] [mm2]
[AWG]
[mm] [Nm]
[lb−in]
[mm2]
[AWG]
[mm] [Nm]
[lb−in]
E84AVxxC3714 6 C6 6 C6 6 6
1 ... 2.5
18 ... 12 70.5 4.4
1 ... 6
18 ... 10 10 1.7 15
E84AVxxC5514 6 C6 6 C6 6 6
E84AVxxC7514 6 C6 6 C6 6 6
E84AVxxC1124 6 C6 10 C10 10 10
1 ... 2.5
18 ... 12 70.5 4.4
1 ... 6
18 ... 10 10 1.7 15
E84AVxxC1524 6 C6 10 C10 10 10
E84AVxxC2224 10 C10 10 C10 10 10
E84AVxxC3024xxS 10 C10 10 C10 10 10

X1013 0.25  3.0 kW

18 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
3
X101
0.25  3.0 kW
X101
NC
COM
X101
NO
8400GG037 8400GG010
COM, NC, NO
[mm2]
[AWG]
[mm]
E84AVxxC2512
E84AVxxC3712
0.2 ... 1.5
24 ... 16 10
E84AVxxC3714
E84AVxxC551x
E84AVxxC751x
0.2 ... 1.5
24 ... 16 10
E84AVxxC112x
E84AVxxC152x
E84AVxxC222x
E84AVxxC3024xxS
0.2 ... 1.5
24 ... 16 10

X105, X106 40.25  3.0 kW
19
EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
4
X105, X106
0.25  3.0 kW
8400GG038
X105 X106
;
;;
;
84MOTL001_a 84MOTL001_b
U, V, W PE T1, T2
b c e a d f g h
[mm] [mm2]
[AWG]
[Nm]
[lb−in]
[mm] [mm2]
[AWG]
[Nm]
[lb−in]
[mm] [mm2]
[AWG]
E84AVxxC2512
E84AVxxC3712 25 65 7 1 ... 2.5 18 ... 12
0.5
4.4 90 9 1 ... 6 18 ... 10
1.7
15 95 25 10 0.2 ... 1.5 24 ... 16
E84AVxxC3714
E84AVxxC551x
E84AVxxC751x
30 65 7 1 ... 2.5
18 ... 12
0.5
4.4 90 9 1 ... 6 18 ... 10
1.7
15 95 30 10 0.2 ... 1.5 24 ... 16
E84AVxxC112x
E84AVxxC152x
E84AVxxC222x
E84AVxxC3024xxS
30 65 7 1 ... 2.5
18 ... 12
0.5
4.4 90 9 1 ... 6 18 ... 10
1.7
15 95 30 10 0.2 ... 1.5 24 ... 16

X105, X10640.25  3.0 kW

20 EDK84VxCC153xxB DE/EN/FR/ES/IT 4.0
X105 − TN, TT
PEWV
U
J>
M
3~
M
3~
T1
PTC
"
X105
Rb1
T2
T1
T2
+
+
+
Rb2
8400GG039 8400GG013
X105 − IT
PEWV
U
J>
M
3~
M
3~
T1
PTC
"
X105
Rb1
T2
T1
T2
+
+
+
Rb2
8400GG040 8400GG013
