EDSVF9333V
.3|7
Ä.3|7ä
System Manual
9300 vector 0.37 ... 90 kW

EVF9321 ... EVF9333
Frequency inverter

Preface and general information
Contents
1
1-1
EDSVF9333V EN 3.0-06/2005
1 Preface
Contents
1.1 How to use this System Manual 1.1-1....................................
1.1.1 Information provided by the System Manual 1.1-1..................
1.1.2 Products to which the System Manual applies 1.1-3.................
1.2 Legal regulations 1.2-1.................................................

Preface and general information
How to use this System Manual
Information provided by the System Manual
1
1.1
1.1.1
1.1-1
EDSVF9333V EN 3.0-06/2005
1.1 How to use this System Manual
1.1.1 Information provided by the System Manual
This System Manual is intended for all persons who design, install,
commission, and adjust the 9300 vector frequency inverter.
Together with the System Manual (extension), document number
EDSV9383V-EXT and the catalogue it forms the basis for project planning for
the manufacturer of plants and machinery.
The System Manual is the basis for the description of the 9300 vector
frequency inverter. Together with the System Manual (extension),
document number EDSVF9383V-EXT, a complete System Manual is
available:
ƒ The features and functions are described in detail.
ƒ Examples describe how to set the parameters for typical applications.
ƒ In case of doubt, the Operating Instructions delivered together with the
9300 vector frequency inverter always apply.
Contents of the System Manual Contents of the System Manual (extension)
1 Preface 1 Preface
2Safety –
3Technical data –
4Installing the basic device –
5Wiring the basic device –
6 Commissioning –
7Parameter setting –
8Configuration 2Configuration
8.1 Description of function blocks
Diameter calculator (DCALC)
Master frequency input (DFIN)
Master frequency output (DFOUT)
Master frequency ramp function
generator (DFRFG)
Master frequency processing
(DFSET)
Internal motor control with V/f
characteristic control (MCTRL1)
Internal motor control with vector
control
(
MCTRL2
)
2.1 Configuring with Global Drive
Control
2.2 Basic configurations
2.3 How to use function blocks
2.4 Function blocks
(Description of the other function
blocks)
2.5 Monitoring
8.2 Code table
8.3 Selection lists
8.4 Table of attributes
9Troubleshooting and fault elimination –
10 DC-bus operation –
11 Safe standstill –
– 3 Application examples
– 4 Signal flow diagrams
12 Accessories –
13 Appendix 5Appendix
Target group
Contents

Preface and general information
How to use this System Manual
Information provided by the System Manual
1
1.1
1.1.1

1.1-2 EDSVF9333V EN 3.0-06/2005
Use the System Manual as the basis. It contains references to the
corresponding chapters in the System Manual (extension):
ƒ Each chapter is a complete unit and informs entirely about a subject.
ƒ The Table of Contents and Index help you to find all information about
a certain topic.
ƒ Descriptions and data of other Lenze products (drive PLC, Lenze geared
motors, Lenze motors, ...) can be found in the corresponding
catalogues, Operating Instructions and Manuals. The required
documentation can be ordered at your Lenze sales partner or
downloaded as PDF file from the internet.
Tip!
Current documentation and software updates for Lenze products
can be found on the Internet in the ”Downloads” area under
http://www.Lenze.com
How to find information

Preface and general information
How to use this System Manual
Products to which the System Manual applies
1
1.1
1.1.2
1.1-3
EDSVF9333V EN 3.0-06/2005
1.1.2 Products to which the System Manual applies
This documentation applies to 9300 frequency inverters as of version:
c d e
Type EVF 93xx – E V Vxxx 3x 7x
Product range
EVF Frequency inverter
Type no. / power
400 V 480 V
9321 0.37 kW 0.37 kW
9322 0.75 kW 0.75 kW
9323 1.5 kW 1.5 kW
9324 3.0 kW 3.0 kW
9325 5.5 kW 5.5 kW
9326 11 kW 11 kW
9327 15 kW 18.5 kW
9328 22 kW 30 kW
9329 30 kW 37 kW
9330 45 kW 55 kW
9331 55 kW 75 kW
9332 75 kW 90 kW
9333 90 kW 110 kW
Design
E Built-in unit (standard mounting)
C Cold plate technique
Version
V Vector-controlled frequency inverter
Variant
–Standard
V003 Cold plate
V004 Safe standstill
V024 Safe standstill and IT system
V100 IT system
Hardware version
Software version

Preface and general information
Legal regulations
1
1.2
1.2-1
EDSVF9333V EN 3.0-06/2005
1.2 Legal regulations
Lenze controllers are unambiguously designated by the contents of the
nameplate.
Lenze Drive Systems GmbH, Hans-Lenze-Straße 1, D-31855 Aerzen,
Germany
Conforms to the EC Low-Voltage Directive
9300 vector frequency inverter and accessories
ƒ must only be operated under the conditions prescribed in this System
Manual.
ƒ are components
– for open and closed loop control of variable speed drives with
asynchronous standard motor or asynchronous servo motors
– for installation in a machine
– for assembly with other components to form a machine.
ƒ comply with the requirements of the Low-Voltage Directive.
ƒ are not machines for the purpose of the Machinery Directive.
ƒ are not to be used as domestic appliances, but only for industrial
purposes.
Drives with 9300 vector frequency inverters
ƒ comply with the EMC Directive if they are installed according to the
guidelines of CE-typical drive systems.
ƒcanbeused
– for operation on public and non-public mains
– for operation in industrial premises and residential areas.
ƒ The user is responsible for the compliance of his application with the
EC directives.
Any other use shall be deemed as inappropriate!
Labelling
Manufacturer
CE conformity
Application as directed

Preface and general information
Legal regulations
1
1.2

1.2-2 EDSVF9333V EN 3.0-06/2005
The information, data, and notes in this System Manual met the state of the
art at the time of printing. Claims on modifications referring to controllers
and components which have already been supplied cannot be derived from
the information, illustrations, and descriptions.
The specifications, processes, and circuitry described in this System Manual
are for guidance only and must be adapted to your own specific application.
Lenze does not take responsibilityfor the suitability of the process andcircuit
proposals.
The specifications in this System Manual describe the product features
without guaranteeing them.
Lenze does not accept any liability for damage and operating interference
caused by:
ƒ Disregarding the System Manual
ƒ Unauthorised modifications to the controller
ƒ Operating errors
ƒ Improper working on and with the controller
See terms of sales and delivery of the Lenze Drive Systems GmbH.
Warranty claims must be made to Lenze immediately after detecting the
deficiency or fault.
The warranty is void in all cases where liability claims cannot be made.
Liability
Warranty

Safety instructions
