Lenze i550 Series Technical manual

Inverter
Inverter i550 Cabinet 0.25 ... 75 kW
Project planning | EN

Contents
About Lenze4
The 5 phases 4
Porolio overview 5
Inverter overview 6
About this document8
Document descripon 8
Notaons and convenons 9
Project planning 10
Procedure of an inverter conguraon process 10
Dimensioning 10
Operaon in motor and generator mode 13
Overcurrent operaon 14
Safety instrucons 15
Applicaon as directed 15
Handling 16
Residual hazards 17
Control cabinet structure 18
Arrangement of components 18
Cables 19
Earthing concept 19
EMC-compliant installaon 20
i550 22
Appendix 136
Good to know 136
Approvals/direcves 136
Operang modes of the motor 137
Motor control types 138
Switching frequencies 140
Enclosures 140
Contents
3

About Lenze
The 5 phases
Lenze makes many things easy for you.
With our movated and commied approach, we work together with you to create the best
possible soluon and set your ideas in moon - whether you are looking to opmise an exist-
ing machine or develop a new one. We always strive to make things easy and seek perfecon
therein. This is anchored in our thinking, in our services and in every detail of our products.
It's as easy as that!
1 Developing ideas
Are you looking to build the best machine possible and already have some inial ideas? Then
get these down on paper together with us, starng with small innovave details and stretch-
ing all the way to completely new machines. Working together, we will develop an intelligent
and sustainable concept that is perfectly aligned with your specic requirements.
2 Draing concepts
We see welcome challenges in your machine tasks, supporng you with our comprehensive
experse and providing valuable impetus for your innovaons. We take a holisc view of the
individual moon and control funcons here and draw up consistent, end-to-end drive and
automaon soluons for you - keeping everything as easy as possible and as extensive as nec-
essary.
3 Implemenng soluons
Our easy formula for sased customers is to establish an acve partnership with fast decision
making processes and an individually tailored oer. We have been using this principle to meet
the ever more specialised customer requirements in the eld of machine engineering for
many years.
4 Manufacturing machines
Funconal diversity in perfect harmony: as one of the few full-range providers in the market,
we can provide you with precisely those products that you actually need for any machine task
— no more and no less. Our L-force product porolio a consistent plaorm for implemenng
drive and automaon tasks, is invaluable in this regard
5 Ensuring producvity
Producvity, reliability and new performance peaks on a daily basis these are our key success
factors for your machine. Aer delivery, we oer you cleverly devised service concepts to
ensure connued safe operaon. The primary focus here is on technical support, based on the
excellent applicaon experse of our highly-skilled and knowledgeable aer-sales team.
About Lenze
The 5 phases
4

Porolio overview
Lenze products undergo the most stringent tesng in our own laboratory. This allows us to
ensure that you will receive consistently high quality and a long service life. In addion to this,
ve logiscs centres ensure that the Lenze products you select are available for quick delivery
anywhere across the globe.
As easy as that.
Controllers
Gearboxes
Motors
Visualisation
Inverters
Time and event-controlled
motion
Speed and torque-controlled
motion
Controlling and
visualising events
Automating and visualising
machine modules
Logic Control Machine module-Control
Automating and
visualising machines
Machine Control
Position-controlled single-axis
and multi-axis motion
Mains operation Inverter operation Servo inverter operation
About Lenze
Porolio overview
5

Inverter overview
Comparison of i500
Inverter i510 i550
Applicaon area Pumps and fans, conveyor, travelling, winding, forming, tool and hoist drives
Electrical supply sys-
tem
1/N/PE 1/3/PE 3/PE 1/N/PE 1/3/PE 3/PE 3/PE
AC 170 ... 264 V AC 170 ... 264 V AC 340 ... 528 V AC 170 ... 264 V AC 170 ... 264 V AC 170 ... 264 V AC 340 ... 528 V
45 ... 65 Hz 45 ... 65 Hz 45 ... 65 Hz 45 ... 65 Hz 45 ... 65 Hz 45 ... 65 Hz 45 ... 65 Hz
Motor power 0.25 ... 2.2 kW 0.25 ... 2.2 kW 0.37 ... 2.2 kW 0.25 ... 2.2 kW 0.25 ... 2.2 kW 4.0 ... 5.5 kW 0.37 ... 75 kW
Inverter output cur-
rent
1.7 ... 9.6 A 1.7 ... 9.6 A 1.3 ... 5.6 A 1.7 ... 9.6 A 1.7 ... 9.6 A 16.5 ... 23 A 1.3 ... 150 A
Inverter eciency
class
IE2 according to EN 50598-2
Max. inverter output
current
150 % at an overload me of 60 s
200 % at an overload me of 3 s
RFI lters Integrated not integrated Integrated Integrated not integrated Integrated Integrated
Dissipaon of regen-
erave energy
- - - Brake resistor Brake resistor Brake resistor Brake resistor
DC-bus connec-
on
Inverter version Control cabinet
Degree of protecon IP20 according to EN 60529
Inverter mounng
type
Installaon, easy mounng via keyhole suspension
Control connecons
and networks
Basic I/Os Standard-I/O
5 digital inputs - 1 digital output 5 digital inputs - 1 digital output
2 analog inputs - 1 analog output 2 analog inputs - 1 analog output
HTL incremental encoder via 2 digital inputs
Modbus or CANopen (switchable) Modbus
CANopen
EtherCAT
EtherNet/IP
PROFIBUS
PROFINET
Applicaon I/O
7 digital inputs - 2 digital outputs
2 analog inputs - 2 analog outputs
HTL incremental encoder via 2 digital inputs
More connecons Relay Relay
Connecon for PTC or thermal contact
External 24 V supply
Funconal safety Without STO (Safe torque o)
Approvals CE, RoHS2, UL (for USA and Canada), EAC
Interference suppres-
sion
Residenal areas C1, industrial premises C2
About Lenze
Inverter overview
6

Funcon Inverter Available as of rmware version
i510 i550 V1.1 V2.1 V3.0
Motor control
V/f characterisc control linear/square-law (VFC plus) ● ● ●
V/f characterisc control Midpoint ● ● ●
Sensorless vector control (SLVC) ● ● ●
Energy saving funcon (VFCeco) ● ● ●
Servo control for asynchronous motors ● ●
Torque mode ● ● ●
Motor funcons
Flying restart circuit ● ● ●
Slip compensaon ● ● ●
DC braking ● ● ●
Oscillaon damping ● ● ●
Skip frequencies ● ● ●
Automac idencaon of the motor data ● ● ●
Brake energy management ● ● ●
Holding brake control ● ● ●
Rotaonal Energy Ride Through (RERT) ● ● ●
Speed feedback (HTL encoder) ● ●
Applicaon funcons
Process controller ● ● ●
Parameter change-over ● ● ●
S-shaped ramps for smooth acceleraon ● ● ●
Motor potenometer ● ● ●
Flexible I/O conguraon ● ● ●
Access protecon ● ● ●
Automac restart ● ● ●
Sequencer ● ● ●
Posion counter ● ●
Monitoring
Short circuit, earth fault ● ● ●
Device overload monitoring (I x t) ● ● ●
Motor overload monitoring (I2x t) ● ● ●
Mains phase failure, motor phase failure ● ● ●
Stalling protecon ● ● ●
Motor current limit ● ● ●
Maximum torque ● ● ●
Ulmate motor current ● ● ●
Motor speed monitoring ● ● ●
Load loss detecon ● ● ●
Motor temperature monitoring ● ●
Diagnoscs
Error history buer, logbook ● ● ●
LED status display ● ● ●
Network
CANopen ● ● ●
Modbus ● ● ●
PROFIBUS ● ●
EtherCAT ● ●
EtherNet/IP ● ●
PROFINET ● ●
Funconal safety (oponal)
STO (Safe torque o) ● ●
About Lenze
Inverter overview
7

About this document
Document descripon
This document is aimed at all persons who want to project inverters with the described prod-
ucts.
The data and informaon compiled here serve to support you in dimensioning and selecng
and preparing the electrical and mechanical installaon. You will receive informaon on prod-
uct extensions and accessories.
More informaon
For certain tasks, more informaon is available in addional documents.
Document Contents/topics
Commissioning document Seng and parameterising the inverters
Mounng Instrucons Basic informaon for the mechanical and electrical installaon
•Is supplied with each component.
"Funconal safety" conguraon document Informaon on this (oponal) funcon
Informaon and tools with regard to the Lenze products can be found on the
Internet:
hp://www.lenze.com à Download
About this document
Document descripon
8

Notaons and convenons
This document uses the following convenons to disnguish dierent types of informaon:
Numbers
Decimal separator Point In general, the decimal point is used.
Example: 1 234.56
Warning
UL warning UL Are used in English and French.
UR warning UR
Text
Programs » « Soware
Example: »Engineer«, »EASY Starter«
Icons
Page reference ¶Reference to another page with addional informaon
Example: ¶ 16 = see page 16
Documentaon reference ,Reference to another documentaon with addional informaon
Example: , EDKxxx = see documentaon EDKxxx
Layout of the safety instrucons
DANGER!
This note refers to an imminent danger which, if not avoided, may result in death or serious
injury.
WARNING!
This note refers to a danger which, if not avoided, may result in death or serious injury.
CAUTION!
This note refers to a danger which, if not avoided, may result in minor or moderate injury.
NOTICE
This note refers to a danger which, if not avoided, may result in damage to material assets.
About this document
Notaons and convenons
9

Project planning
Procedure of an inverter conguraon process
Dimensioning
3 methods for dimensioning
Fast: Selecon of the inverter based on the motor data of a 4-pole asynchronous motor.
Detailed: In order to opmise the selecon of the inverter and all drive components, it is
worth to execute the detailed system dimensioning based on the physical requirements of the
applicaon. For this purpose, Lenze provides the «Drive Soluon Designer» (DSD) design pro-
gram.
Manual: The following chapter guides you step by step to the selecon of a drive system.
Workow of a conguraon process
Dene required input variable
Calculate range of adjustment and determine rated point
Determine motor based on the rated data
Dene correcon factors for the inverter
Determine inverter based on the rated data
Check motor/inverter combinaon
Determine brake resistance
Final conguraon
Dene required input variables
Operang mode S1 or S6
Max. load torque ML,max Nm
Max. load speed nL,max rpm
Min. load speed nL,min rpm
Site altude H m
Temperature in the control cabinet TU°C
Calculate range of adjustment and determine rated point
Calculaon
Seng range
=L,max
L,min
n
Vn
Project planning
Procedure of an inverter conguraon process
Dimensioning
10
