C O L L E C T I O N B Y L E V I T O N
Switching Controller
(Multi-Location)
Cat. No. CN220
24VDC
24mA, 0.6W
For use w/Dimming Power Pack
and other LCnet products
For more information go to
www.leviton.com/centura
INSTALLATION INSTRUCTIONS
DI-000-CN220-00A-Pilot
Frame
Strap
Service
Switch
Snaps
Push in 2 Locations
ON/OFF
LED
Upper
Rocker
Service
Switch ON/OFF
LED
Lower
Rocker
Figure 1 - Entry Station Functions
Figure 2 - Color Conversion
FEATURES
•Leviton’s Decora®Style design •Rocker mechanism for easy lighting control
•Enables address settings of Controller •Color conversion available
•Low-Voltage for easy installation •Fits standard wall box
INTRODUCTION
The Switching Controller, Cat No. CN220, allows easy-to-use manual control of a Centura Lighting
Control System. The Controller can be used to turn ON and OFF dimming loads, but it is intended to
control non-dimming loads. The Controller has a rocker mechanism to provide simple control of your
Power Pack. This allows manual control of your lights and the programming of the address for your Power
Pack from a standard wall box in an easy-to-reach location. In using the Controller, you may override the
automatic operation of the Power Pack to give the most convenience to your lighting needs.
DESCRIPTION
The Controller has a user friendly rocker design. There are two buttons on the face, from top down they
are ON and OFF. The Controller has a removable face so that the colors can be changed.
The Controller is a component of the Centura Lighting System. It is used to provide local user control of
the lights. It provides the ability to program the Power Pack address for multiple Power Pack installations.
The programming sequence is described under the “TO OPERATE”section.
FCC COMPLIANCE STATEMENT
This device complies with part 15, part A of the FCC Rules. Operation is subject to the following two
conditions: (1) This device must not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
INSTALLATION INSTRUCTIONS
WARNING: TO BE INSTALLED AND/OR USED INACCORDANCE WITH APPROPRIATE ELECTRICAL
CODES AND REGULATIONS.
WARNING: IF YOUARE NOT SURE ABOUTANY PART OF THESE INSTRUCTIONS, CONSULT A
QUALIFIED ELECTRICIAN.
CAUTION: DISCONNECT POWER WHEN SERVICING FIXTURE OR CHANGING LAMPS.
CAUTION: THE SWITCHING CONTROLLER OPERATES OFF OF LOW-VOLTAGE (24VDC), SO
CARE MUST BE TAKEN WHEN REPLACING A LIGHT SWITCH. CONSULT LOCAL BUILDING CODES
AND REGULATIONS FOR PROPER LOW-VOLTAGE INSTALLATION.
TO INSTALL:
1. WARNING: TOAVOID FIRE, SHOCK, OR DEATH; TURN OFF POWER AT CIRCUIT BREAKER OR
FUSE AND TEST THAT POWER IS OFF BEFORE WIRING!
2. Remove existing wallplate and switch or dimmer, if applicable
CAUTION: IF APPLICABLE, ENSURE THAT CIRCUIT CONDUCTORS ARE PROPERLY CAPPED
OFF WITH WIRE CONNECTORSAND REMOVED FROM WALL BOX.
3. Connect lead wires per appropriate WIRING DIAGRAM as follows: Twist strands of each lead tightly
and, with low-voltage wires, push firmly into appropriate wire connector. Screw connectors on
clockwise making sure that no bare conductor shows below the wire connectors. Secure each
connector with electrical tape.
4. Carefully position all wires to provide room in outlet box for Controller. Mount Controller into box with
mounting screws supplied.
5. Restore power at circuit breaker or fuse. INSTALLATION IS COMPLETE.
COLOR CONVERSION PROCEDURE
The color of this device can be changed to suit your interior design requirements. Simply obtain a color
conversion kit of the appropriate color from your Leviton distributor and proceed as follows (please note
that wallplate must be removed).
1. Select the color of the face you desire.
2. The frame has snaps on its sides. Using a small screwdriver, gently remove the frame from the strap
(refer to Figure 2).
DI-000-CN220-00A-Pilot1 9/21/01, 4:34 PM1

Power (24VDC) (Green/White)
CAN_H (Blue)
CAN_L (Blue/White)
DC Gnd (Green) Twisted Pair
to Power Pack
ON/OFF Controller
Twisted Pair
to Power Pack
Power (24VDC)
CAN_H
CAN_L
DC Gnd
ON/OFF Controller ON/OFF Controller
Power (24VDC) (Green/White)
CAN_H (Blue)
CAN_L (Blue/White)
DC Gnd (Green)
Communication
LED
Address
Wheel
Service Switch ON/OFF LED
Figure 3 - Settings
Wiring Diagram 2 - Two Location Application
Wiring Diagram 1 - Single Station Application
NOTE: Both Controllers must have
the same address for multiple
location control of 1 Power Pack.
3. Take the new frame and position it properly to the strap. Notice that the frame has a
cutout for the Service Switch lever. Line up the plastic snaps with the square holes
in the strap. Insert the snaps on one side of the frame into the strap.
4. Firmly press sideways and down to slip the other snaps into place. The frame snaps
in with an audible click. Ensure that all four snaps are secure. Replace Decora®
wallplate. The color conversion is complete.
TO OPERATE
ON: Press the upper half of the rocker. The lights will fade ON.
OFF: Press the lower half of the rocker. The lights will fade to OFF (ON/OFF LED lit).
FULL BRIGHT: If the lights ON, pressing the upper half of the rocker will turn lights ON
to the maximum level.
SERVICE SWITCH: On the lower left corner of the switch plate, there is a Service
Switch (refer to Figure 1). When servicing a controlled fixture, pull lever out (OFF
position). This will send a message to the Power Pack to keep the lights OFF. After
servicing is complete, push the lever in (ON position) to restore power. The lever must
be pushed in all the way (ON position) for normal operation.
COMMUNICATION LED: The communication LED will flash when the Controller
transmits a message, and when it receives a valid message. It is located under the
wallplate (under the screwless wallplate adapter, not shown) (refer to Figure 3). It is
visible in the space between the frame and the wallplate adapter.
POWER PACK ADDRESS:
The Controller and the Power Pack must have the same address in order to communi-
cate to each other. The default address is the same, but when installing multiple Power
Packs, each Power Pack must have a different address.
The Controller has a rotary switch for addressing. If there is only one Power Pack on
the bus then the rotary switch DOES NOT have to be adjusted. For installations where
there are multiple Power Packs, the rotary switch is used to set the Power Pack’s
address (refer to the Power Pack Instruction Sheet for further details).
To set the Power Pack’s address, proceed as follows:
1. Remove wallplate and frame (may have to remove screwless wallplate adapter as
well).
2. Using a small screwdriver rotate the rotary switch to next unused address.
3. Pull out Service Switch.
4. Press the Address Selection button on the Power Pack. The Address is now
selected.
5. Return Service Switch to the IN position.
6. Address selection is finished.
NOTE: Only one Power Pack can be programmed at a time.
MULTI-LOCATION:
Up to 4 Controllers can be connected in parallel. All Controllers MUST be on the same
address.
TROUBLESHOOTING
•If the LED is not on; there is no power
- Check wiring.
•Communication LED does NOT light when the button is pressed
- Check power wiring connections.
For Multiple Power Packs on the Bus:
•The Controller has power (the OFF LED is ON) but pressing the buttons have no
effect on the lights; there is no communication between the Controller and the
Power Pack
- If the communication LED does NOT flash when a button is pressed, see above.
- If the communication LED does flash check the address of the Power Pack and
Controller (refer to Dimming Power Pack Instructions).DI-000-CN220-00A-Pilot
