NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
Copyright 1999, NSI Corp.
Specifications subject to change without notice
NSI
MODULAR DIGITAL DIMMING SYSTEM
DS8/DS12 DIMMER PACKS
INSTALLATION AND OPERATION GUIDE
Version 1.1x Software
Part Number LIT-31665-0 Rev B – 9/25/2000
_________________________________________________________________
Specifications
Number of Channels: Model DS8-12 : 8 channels
Model DS12-12 : 12 channels
Model DS8-24 : 8 channels
Model DS12-24 : 12 channels
Output Capacity: Model DS8-12 : 1200 Watts per channel @ 120VAC
Model DS12-12 : 1200 Watts per channel @ 120VAC
Model DS8-24 : 2400 Watts per channel @ 120VAC
Model DS12-24 : 2400 Watts per channel @ 120VAC
Input Power: Model DS8-12 : 1 phase, 3 wire, 120/240 VAC, 40 Amps, 47 – 63Hz
Model DS12-12 : 1 phase, 3 wire, 120/240 VAC, 60 Amps, 47 – 63Hz or
3 phase, 4 wire, 120/208 VAC, 40 Amps, 47 – 63Hz
Model DS8-24 : 1 phase, 3 wire, 120/240 VAC, 80 Amps, 47 – 63Hz
Model DS12-24 : 1 phase, 3 wire, 120/240 VAC, 125 Amps, 47 – 63Hz or
3 phase, 4 wire, 120/208 VAC, 80 Amps, 47 – 63Hz
Dimmer control system: Microprocessor digital phase control.
Load Filtering: 350μs
Control Input Types: 12 channels of 0 -10VDC [ 15 pin Male D-Sub on back of pack ]
Pins 1 through 12 = Channels 1 through 12, pin 13 = T/C,
Pin 14 = +14.4VDC, Pin 15 = Analog COM
MICROPLEX (in / through) on 3 pin XLR connector
DMX-512 (in / through) on 5 pin XLR connector
Luma-Net - 6 pin Terminal Block
Control Wiring: Class 2 low voltage
Output Panels: PB8/12 – 1 - NEMA 5-15 or 5-20 receptacle per channel or,
SP8/12 – 1- 20 Amp stage pin receptacle per channel or,
KO8/12 – hard-wired terminal blocks.
Cooling System: Thermostatically controlled and monitored fan forced air with individual dimmer module
temperature monitoring. Fan exhaust on right rear side.
Dimensions: 3.5"High x 17.2" Wide x 17.0"Deep. ( 2 EIA 19" Rack Spaces)
Weight: 50lbs
Recommended Ambient
Operating Temperature: 0-25 degrees C ( 32 - 85 degrees F)
Short-Circuit
Current Rating: 10,000A RMS Sym. @ 240VAC
Load Type: AC lighting loads only
Enclosure Type: For indoor use only
Utilizer dans un endroit a l’abri

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 2 -
___________________________________________________________________
Mounting
The DS dimmer packs are designed to be mounted in a standard 19" EIA rack. The packs are provided with two
mounting flanges or ears, which are designed for securing the pack to the front rack mounting rails. The pack may
also be operated as is on top of a sturdy table or shelf.
An optional rear support kit is available and should be used in portable, or rough handling rack mount applications.
The NSI DS dimmers depend on forced air cooling, therefore the following installation rules apply:
1. The rack enclosure shall maintain a 2 inch minimum clearance on the entire right side of the dimmer
rack enclosure for air exhaust. The rack enclosure must not be sealed, and must maintain an air
exhaust clearance area of at least 15 square inches per installed pack for air to flow back to the
ambient room.
2. If the optional rear support kit is used, the right rear support bracket must be cropped to a length
that does not block any of the air exhaust vent on the right side of the rack, once the pack is installed.
Support bracket length can vary depending on cabinet construction and manufacturer, therefore the
bracket should be cropped upon installation.
3. The intake manifold on the front of the dimmer pack cannot not be blocked for any reason.
4. The thermal operation of the dimmer pack will depend on its conditions of installation. Ambient
room temperature must never exceed 104 degrees F or 40 degrees C.
WARNING: If any of the cooling rules above are violated, the packs could suffer permanent damage not
covered under warranty.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 3 -
___________________________________________________________________
Input Power Wiring
WARNING: Because DS packs operate at potentially lethal voltages, installation wiring should be done by
qualified personnel only!
WARNING: Do no connect chassis Ground to Neutral, or operate this equipment without a chassis ground,
otherwise the user could be exposed to potentially lethal voltages.
The DS dimmer pack must be fed with one of the electrical services listed below. The service should be protected by
a suitable circuit breaker. Wiring should be selected, sized and installed in accordance with local electrical codes as
should all aspects of the installation. All wire must be copper, and be rated for 90oC sized for 75oC ampacity.
For convenience, suggested portable cord sizes are shown in parenthesis. They are sized for the full capacity of the
dimmer pack and for the 60oC-rated plug that is likely to be installed on the other end.
Model DS8-12: 1 phase, 3 wire plus ground, 120/240 VAC, 40 Amps, 47 – 63Hz
( Type S/SO, 4 conductor, #6 AWG minimum)
Model DS12-12: 3 phase, 4 wire, 120/208 VAC, 40 Amps, 47 – 63Hz
( Type S/SO, 5 conductor, #4 AWG minimum)
1 phase, 3 wire, 120/240 VAC, 60 Amps, 47 – 63Hz SEE RE-WIRING PROCEDURE
( Type S/SO, 4 conductor, #2 AWG minimum)
Model DS8-24: 1 phase, 3 wire, 120/240 VAC, 80 Amps, 47 – 63Hz
( Type S/SO, 4 conductor, #2 AWG minimum)
Model DS12-24: 3 phase, 4 wire, 120/208 VAC, 80 Amps, 47 – 63Hz
( Type W, 5 conductor, #2 AWG minimum)
( Type G, 4 conductor, #2 AWG minimum)
1 phase, 3 wire, 120/240 VAC, 125 Amps, 47 - 63hz SEE RE-WIRING PROCEDURE
( Type W, 4 conductor, #1 AWG minimum)
( Type G, 3 conductor, #1 AWG minimum)
Connect input feeder wires to labeled input terminal terminals provided.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 4 -
Feeder re-wiring procedure for 12 channel single phase units:
1. All power feeders should be turned off and disconnected.
2. Remove the dimmer pack cover by removing the screws around the edge.
3. Using a flat blade screwdriver, disconnect the 18 AWG red control module power wire from the B phase power
feed terminal block, and move it to the C phase power feed terminal block along with the #18 AWG blue control
module power wire, and terminate using set screw torqued to 35 inch-lbs.
4. Using a flat blade screwdriver, disconnect the red dimmer module feeder wire pairs with the single and double
red tie-wraps (dimmers 5&6 and 7&8) by unscrewing the set screws in the B phase power feed terminal block,
and sliding the wires out of the back slot.
5. Move the red dimmer module feeder wire pair with the single red tie-wrap to the A phase power feed terminal
block, slide in the wires deep in the terminal block mounting holes so no wire is exposed past the walls of the
block, and terminate using set screw torqued to 35 inch-lbs.
6. Move the red dimmer module feeder wire pair with the double red tie-wraps to the C phase power feed terminal
block, slide in the wires deep in the terminal block mounting holes so no wire is exposed past the walls of the
block, and terminate using set screw torqued to 35 inch-lbs.
7. Cross check:
•All black tie-wrapped and single red tie-wrapped feed wire pairs, and the Phase A black 18AWG control module
power wire should be fed by the Phase A feeder block
•All blue tie-wrapped and double red tie-wrapped feed wire pairs, phase B red 18AWG control module power wire,
and the phase C blue 18AWG control module should be fed by Phase C feeder block.
•Phase B feeder block should be empty.
•All load connections should be not exposed, and terminated tightly to 35 inch-lbs.
______________________________________________________________________________________________
Output Power Wiring
DS packs are available in a variety of configurations. NEMA 5-15 or 5-20 receptacle, or Stage Pin receptacle
models feature one output receptacle per dimming circuit, while the hard-wired packs feature terminal blocks and a
rear panel with knock-outs.
The lighting load connected to the dimming circuit should be rated for 115/120V and should not exceed the rating of
the dimmer. The ampacity of the dimmer can be seen in the window near the yellow led load indicator on the front
panel, 10 = 10 Amps, 20 = 20 Amps.
The dimmer is capable of driving incandescent , Advance MARK X fluorescent ballasted, or inductive transformer
loads. The load on the dimmer must include the load of the lamp plus the load of the ballast or transformer; and each
ballast or transformer must be individually fused. Transformers should be over-rated by at an additional 70% of their
rated load when operating on an SCR dimming circuit. Other loads may be unsuitable to operation by a SCR based
switching devices, and may operate in an erratic and/or unpredictable fashion. Contact the manufacturer of the load
equipment for details of their power specification.
The proper wiring of a Stage Pin receptacle is not always evident. The center pin is the green grounding conductor;
the pin nearest the ground pin is the white grounded (neutral) conductor; and the remaining pin is the ungrounded
(hot) conductor.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 5 -
________________________________________________________________
Control Wiring
DMX-512: Input = 5 pin XLR-M Pin# Signal
Through Output = 5 pin XLR-F 1 DGND
2 DATA -
Recommended 3 DATA +
Control Wire: 4 THROUGH
Belden 9729 or 9829 5 THROUGH
Microplex: Input = 3 pin XLR-M Pin# Signal
(MPX) Through Output = 3 pin XLR-F 1 Analog COM
2 +14.4VDC Power
Recommended 3 DATA
Control Wire:
Belden 8760 or 9460
0-10VDC: Input = 15 pin M D-Sub Pin# Signal
Analog 1 Channel 1
Recommended 2 Channel 2
Control Wire: 3 Channel 3
Alpha 1896 4 Channel 4
5 Channel 5
6 Channel 6
7 Channel 7
8 Channel 8
9 Channel 9
10 Channel 10
11 Channel 11
12 Channel 12
13 T/C (Snapshot)
14 +14.4VDC Power
15 Analog COM
Luma-Net Input = 6 pin pluggable terminal block Pin# Signal
Orientation: looking at back of pack, 1 (far right) REM +
with grooved surface on bottom. 2 REM -
3 DGND
Recommended 4 +14.4VDC Power
Control Wire: 5 N/C
Alpha 1898 6 (far left) N/C
IMPORTANT NOTE: Do not route low voltage control wires parallel to or in the same conduit as high voltage
power wires as the control system may exhibit erratic control performance. (like flickering)

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 6 -
___________________________________________________________________
DS Pack Operation
The Operation of the DS Pack has been divided into the following sections:
1. Turn Lights On…Now!
2. Setup
3. Softpatch
4. Analog Submasters
5. Presets
6. Dimmer Feedback
7. Control Module Jumper Settings
8. Contact NSI
__________________
Section 1 1. Make sure all three red led power indicators on the front are lit.
2. Make sure lighting loads are plugged into back of pack .
To turn lights on now: 3. Flip all circuit breakers up to "ON" position.
4. Press test switch oval under each circuit breaker.
1.1 Setting the Test Switch Bump or Latch action and level:
If the test switches have been configured as " latch" action, the lights will stay on at the first press of the test switch,
but if the test switches have been configured as "bump" action, they will only stay on as long as they are pressed.
To change the test switch action, and the test switch intensity, press [CLEAR] until the following menu is displayed:
NSI DSxx xPHASE Note: the 'x's could indicate a variety of settings
STATUS=xxx [MORE]
Now press the switch under [MORE] twice. This switch is a soft switch, that is, the function of the switch is defined
by the bracketed text in the LCD window above. If you are lost or make a mis-entry, just hit [CLEAR]. The menu
will back up one position or one menu each time [CLEAR] is pressed. The LCD should now display:
NSI DSxx xPHASE
[SETUP] [MORE]
Press the soft switch under [SETUP]. Then press [MORE] 2 times. The screen should now display :
SET TEST SWITCH
[ACTION] [MORE]
Select [ACTION]. Two choices will be displayed [LATCH] and [BUMP]. Press the test function you prefer.
This selection will stay in permanent EEPROM memory. Upon selection, another choice will appear:
SET TEST LEVEL = 25%
[CHANGE] [MORE]
If you wish to change the output intensity of the bump switches, select [CHANGE]. This change is in volatile
memory, or RAM , so it will go back to 25% when the power to the pack turned off. The level setting will not take
effect, however, until the test switch is activated again.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 7 -
_______________ __________
Section 2 SETUP
The DS dimmer pack will be ship pre-configured with factory default settings, however, it may be necessary to
change some of those settings in the field based on installation requirements or service conditions. The following
section steps through the various control setup options.
2.1 Number of dimmers selection:
Press [CLEAR] until the following main menu is displayed:
NSI DSxx xPHASE Note: the 'x's could indicate a variety of settings
STATUS=xxx [MORE]
Now press the switch under [MORE] twice. This switch is a soft switch, that is, the function of the switch is defined
by the bracketed text in the LCD window above. If you are lost or make a mis-entry, just hit [CLEAR]. The menu
will back up one position or one menu each time [CLEAR] is pressed. The LCD should now display:
NSI DSxx xPHASE
[SETUP] [MORE]
Press the softswitch under [SETUP]. The first setup menu will appear:
SET # OF DIMMERS
[8/12] [MORE]
The control module can operate either a 8 channel or 12 channel dimmer pack, but it needs to be told how many
dimmers are in the pack. If you wish to change the number of dimmers, press the [8/12] soft switch. The next
selection you make will be permanently stored in the non-volatile EEPROM configuration chip. The LCD will
display:
# OF DIMMERS =
[8] [12]
Select the number of dimmers that are installed in the pack, or press [CLEAR] to go back to the previous menu. If
you change settings, the changes will not be reflected until the pack is powered off, and then back on. A number
selection will return to the display to the main menu.
2.2 Phase power selection:
From the main menu:
NSI DSxx xPHASE Note: the 'x's could indicate a variety of settings
STATUS=xxx [MORE]
Press the key sequence [MORE], [MORE], [SETUP], [MORE]. The following menu will be displayed:
SET PHASE POWER
[1/3 PHASE] [MORE]
An 8 channel dimmer pack will always be setup for 1 phase. A 12 channel dimmer pack may operate as either a
single phase or 3 phase unit. Single phase 12 channel units need to be internally configured for single phase power,
so for single phase 12 channel units, refer to Input Power Wiring section and Re-wiring Procedure. If the wrong
phase power type is selected from the LCD menu no damage will occur to the dimmer pack, but it will not operate
correctly and may operate as a non-dim or with odd dimming curves. Like with the number of dimmers selection,
phase control selection is stored in non-volatile EEPROM and configures on power-up, therefore the pack must be
powered off and back on to have phase changes implemented.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 8 -
2.3 Test Switch Action / Level Selection:
From the main menu:
NSI DSxx xPHASE Note: the 'x's could indicate a variety of settings
STATUS=xxx [MORE]
Press the key sequence [MORE], [MORE], [SETUP], [MORE] [MORE]. The following menu will be displayed:
SET TEST SWITCH
[ACTION] [MORE]
Select [ACTION]. The following menu will be displayed:
SWITCH ACTION =
[LATCH] [BUMP]
If you select [LATCH], the dimmer channel will toggle between the bump level and off each time the test switch
under the circuit breaker is pressed. If you select [BUMP], the dimmer channel will turn on only while the test switch
is being pressed. After selecting the test switch action, the following menu will appear:
SET TEST LVL = 25%
[CHANGE] [MORE]
If you wish to change the test switch bump level, press change, then enter the 'on' control level you wish the
channels to bump or latch to. Note: the bump level selection is only stored in ram, so it will default back to 25%
when the pack is powered off.
2.4 Analog Input Defaults Selection:
The 0-10VDC analog inputs on this DS dimmer pack do not have to be just 0-10VDC control inputs for single
channel dimmer control. The analog inputs can also operate as overlapping submaster scenes with time fade
damping, or trigger inputs to linked presets that can operate in a chase pattern on one of the analog submasters. To
program these functions, refer to the Analog Submaster section of this manual. Enabling [DEFAULTS] in this
menu will erase all the submaster scenes and their fade times, and re-program all inputs to a 1 to 1 patch with
0 time fade damping. ( analog input 1 = channel 1, analog input 2 = channel 2, … analog input 12 = channel 12 ).
From the main menu:
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the key sequence [MORE], [MORE], [SETUP], [MORE], [MORE], [MORE], [MORE]. The following
menu will be displayed:
SET ANALOG INPUT
[DEFAULTS] [MORE]
If you wish to re-patch all the analog inputs back to a 1:1 patch, press [DEFAULTS]. The following menu will
appear:
ARE YOU SURE? IF
SO PRESS [ENTER]
If you are not sure, press any key except [ENTER] to return to the previous menu. If you are sure, press [ENTER],
and a brief message of " WRITING DATA …" will be displayed.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 9 -
2.5 Factory Defaults Selection:
There are an abundance of functions that are initialized if this selection is made:
•All non-analog presets in memory ( Presets 13 through 400 ) are completely erased.
•Both DMX-512 and Microplex softpatches default to 1:1 at full on channels 1 through 12.
•Luma-Net patch defaults to dimmer 1.
•The dimmer pack is set to 12 channel, 3 phase operation.
•All dimmer curves default to dim operation.
•All dimmer maximum levels are set to Full.
•All dimmer minimum levels are set to O.
•Line regulation is set to "ON"
If you wish to continue, from the main menu:
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the key sequence [MORE], [MORE], [SETUP], [MORE], [MORE], [MORE], [MORE], [MORE]. The
following menu will be displayed:
SET FACTORY
[DEFAULTS] [MORE]
If you wish to completely clear all memory other than the analog input patch, press [DEFAULTS]. The following
menu will appear:
ARE YOU SURE? IF
SO PRESS [ENTER]
If you are not sure, press any key except [ENTER] to return to the previous menu. If you are sure, press [ENTER],
and a message of " WRITING DATA …" will be displayed for several seconds while all permanent memory is re-
programmed.
2.6 Luma-Net Start Address
This menu sets the start address for dimmer 1 for Luma-net operation of the dimmer pack. Note that it is not
necessary to softpatch any other functions for Luma-Net operation, because the softpatch and levels are stored in the
Luma-Net stations themselves. If you wish to change the Luma-Net start address, then from the main menu:
NSI DSxx xPHASE
STATUS=xxx [MORE]
press the key sequence [MORE], [MORE], [SETUP], [MORE], [MORE], [MORE], [MORE], [MORE],
[MORE]. The following menu will be displayed:
SET LUMA-NET= 001
[CHANGE] [MORE]
If you wish to change the Luma-Net start address, press [CHANGE], and then enter the start address you desire. The
new address will be stored in permanent EEPROM memory, and will automatically load on power-up.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 10 -
2.7 Set Line Regulation
This menu enables or disables the line regulation feature of the dimmer pack. Line regulation is a feedback system
that monitors the incoming line voltage, and attempts to compensate for surges or sags in the feeder voltage by
inversely dimming the output up or down, thereby maintaining a constant output voltage to the lamp. This feature
operates best when the incoming feed power voltage is about 125VAC. The dimmer pack then has the head room to
keep the lamps operating at their maximum voltage, even if the feed voltage sags or surges a few volts. The DS
dimmer pack should never be fed with line voltage above 130VAC, however, especially while operating in the non-
regulated mode.
Line regulation can be susceptible to operational problems on very soft or very unstable power feeds. For this
reason, the user has the ability to turn off line regulation from this menu. Although this may alleviate most power
feed interaction problems, it can not correct for poor installations with extremely soft and /or noisy feeders and
neutrals, from which can cause false triggering can occur due to false feeder zero cross information.
To change the line regulation setting, from the main menu:
NSI DSxx xPHASE
STATUS=xxx [MORE]
press the key sequence [MORE], [MORE], [SETUP], [MORE], [MORE], [MORE], [MORE], [MORE],
[MORE], [MORE]. The following menu will be displayed:
SET LINE REG = ON
[OFF] [MORE]
The active line regulation setting will be displayed to the right of the equal sign, with the alternate option displayed
for the left soft key function (F1). To toggle the line regulation operation, press the (F1) function key. The new
setting will be stored in permanent EEPROM memory, and will automatically load on power-up.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 11 -
_________________________________
Section 3 SOFTPATCH
The DS dimmer pack has the ability to be patched quickly if only a start address is required and normal full range
dimming is required, or it is capable in the custom patch menu of proportionally patching any DMX-512 or
Microplex multiplexed control signal to any dimmer, setting custom dimming curves, and setting maximum and
minimum control levels. The dimmer pack is factory configured with a 1:1 patch on dimmer channels 1 through 12
for both Microplex and DMX-512 inputs.
3.1 Set DMX-512 Start Address
From the main menu :
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the [DMX#] keypad. If there is not a custom patch in memory, the following menu will be displayed:
SET START ADDRESS
DIMR 01 = DMX# 001
The cursor will be flashing on the most significant DMX# digit. Enter the full DMX# one digit at a time where you
want the operation of dimmer 1 to begin. All DMX-512 proportional control levels will automatically default to full.
If there is a custom DMX-512 patch in memory, the option to [ERASE] or [KEEP] the custom patch will be
displayed. If [KEEP] is pressed, the control module will return to the main menu. If [ERASE] is pressed, the
custom softpatch for DMX-512 will be erased as soon as the start address is entered.
3.2 Set Microplex Start Address
From the main menu :
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the [MICROPLEX#] keypad. If there is not a custom patch in memory, the following menu will be displayed:
SET START ADDRESS
DIMR 01 = MPX# 001
The cursor will be flashing on the most significant MPX# digit. Microplex is capable of handling up to 128 channels.
Enter the full MPX# one digit at a time where you want the operation of dimmer 1 to begin. All Microplex
proportional control levels will automatically default to full.
If there is a custom Microplex patch in memory, the option to [ERASE] or [KEEP] the custom patch will be
displayed. If [KEEP] is pressed, the control module will return to the main menu. If [ERASE] is pressed, the
custom softpatch for Microplex will be erased as soon as the start address is entered.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 12 -
3.3 Custom Softpatch
Please note that all softpatch entries are stored in non-volatile EEPROM, and are automatically loaded on power up.
Softpatch modifications take effect immediately. From the main menu :
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the [DIMMER] keypad. The following menu will be displayed:
DIMMER # = 01
TEMP= xxC [MORE]
The cursor will be flashing on the most significant dimmer number digit. This menu defaults to dimmer 01. Enter a
different dimmer number if you so desire. Note the temperature reading in the bottom left corner of the LCD
display. Refer to the feedback section of the manual for normal operating temperature ranges.
3.31 Custom DMX Softpatch
To custom patch DMX-512 channels, press [DMX#]. To custom patch Microplex channels, press [MICROPLEX#],
then skip down one paragraph to the Microplex menu. If DMX# is pressed the following menu will appear:
DIM=01 @ DMX#001
@LEVEL=FL [MORE]
The cursor will be blinking on the most significant digit of the current DMX# channel where the dimmer is patched.
Enter any DMX channel number between 1 and 512, where the dimmer is to be patched. You may also choose to
enter a proportional level, where the cursor will automatically jump once the DMX channel has been entered. If you
do not wish to enter a proportional level, press [ENTER] .
3.32 Custom Microplex Softpatch
Note that pressing [ENTER] will automatically increment to the next custom patch field, while [CLEAR] will back
up to the beginning of the field, and then to the previous selection, and then to the previous menu. The Microplex
patch menu will appear:
DIM=01 @ MPX#001
@LEVEL=FL [MORE]
The cursor will be blinking on the most significant digit of the current MPX# channel where the dimmer is patched.
Enter any MPX channel number between 1 and 128, where the dimmer is to be patched. You may also choose to
enter a proportional level, where the cursor will automatically jump once the MPX channel has been entered. If you
do not wish to enter a proportional level, press [ENTER].

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 13 -
3.33 Live Dimmer Status
Press [MORE] to display the following status screen:
DIM 01 = xx% DIMR
SOURCE=yyy[MORE]
This screen displays a variety of live functions of the dimmer. This screen not only displays the current control level
for the dimmer, but also indicates where the control source level has been derived. Highest takes precedence Control
sources can be:
DMX for DMX-512
MPX for Microplex
BMP for Test Switch
PRE for Preset
LUM for Luma-Net
A1 for analog submaster 1 …
Through
A12 for analog submaster 12
This live dimmer status screen also indicates the current dimmer curve setting as:
DIMR for a modified square law dimming curve, or
MARK X for a Advance MARK X florescent, or
NON-DIM for an unregulated non-dim.
If a maximum level less than FL has been programmed into the maximum level field, a "^" will appear in the upper
left corner of the LCD screen.
If a minimum level more than 00 has been programmed into the maximum level field, a "v" will appear in the upper
left corner of the LCD screen.
When you are finished viewing all this status information, press [MORE].
3.34 Custom Patch Dimmer Curves
The dimmer curve menu will then be displayed:
DIM 01 = DIMMER
[DIMMER] [MORE]
If the dimmer curve for this dimmer is a normal modified square law dimming curve, then DIMMER will appear to
the right of the equal sign. If NONDIM or MARK X is to the right of the equal sign, and you wish to change the
dimmer to a normal modified square law dimming curve, then press the [DIMMER] soft key. If DIMMER appears
to the right of the equal sign, and you wish to change the curve of the dimmer to that of an unregulated NON-DIM
or MARK X dimmable florescent ballast, then press [MORE] until the desired dimming curve appears in the bottom
left soft key position.
3.35 Custom Patch Maximum Level
To skip entering a dimmer curve selection, press [ENTER], which will advance the control module to the maximum
level selection menu:
DIM 01 MAX LEVEL
= FL% [MORE]
The maximum level selection will keep the dimmer below the specified level for all control inputs, with the
exception of a selected NON-DIM curve, which is an unregulated NON-DIM, and will turn the dimmer on full blast
for a control level over 50%. If you wish to change the maximum level, enter a level between 01% and FL%. If you
wish to skip the max level menu, press [ENTER].

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 14 -
3.35 Custom Patch Minimum Level
The minimum level menu will follow:
DIM 01 MIN LEVEL
= 00% [MORE]
This level is essentially a warmer level. It can be used to keep filaments hot for quick lamp response, or for
emergency circuits that you never want to go off. The NON-DIM curve over-rides this setting, however, and forces
the dimmer to off if the control source is below 50%. If enter is pressed, the control module returns to the main
DIMMER menu where a new dimmer channel selection may be entered.
___________________________
Section 4 Analog Submasters
The 0-10VDC analog inputs on this DS dimmer pack do not have to be just 0-10VDC control inputs for single
channel dimmer control. The analog inputs can also operate as overlapping submaster scenes with time fade
damping, or trigger inputs to linked presets that can operate in a chase pattern on one of the analog submasters.
Please note that the analog scenes are stored in non-volatile EEPROM memory, and they will always automatically
load on power up.
4.1 Analog Submaster Snapshot Procedure
Connect any 12 channel 0-10VDC analog output console or control station to the analog inputs. Connect a switch
between +14.4VDC and the T/C input.
1. Start with all channels on the analog console off, and the T/C switch open or off.
2. When you wish to snapshot a scene, bring up the scene, live, that you desire to be loaded into the submaster
analog channel. Note that at least one channel in the scene must have a level 5% different than the other
channels, otherwise the scene will be interpreted by the pack to be a hold time. The scene may be generated from
either the DMX-512 control input, or the Microplex control input, or the highest takes precedence levels of both
inputs.
Note: In order for the DS pack to enter the snapshot mode, all 12 analog inputs must be off, or below 1/2 volt.
3. With all 12 channels to off on the analog console, close the T/C switch for about 10 seconds. When the pack has
entered snapshot mode, the lights will dim 50%. Note that the T/C input may be daisy -chained between packs.
4. While still keeping the T/C switch closed, raise the analog channel to full where this scene is to be loaded.
5. When the scene has loaded, the lights will return to their full intensity, and the T/C switch can be released or
opened.
6. To disable snapshot from a remote location, keep the T/C switch open.
4.2 Analog Submaster Fadetime Snapshot Procedure
Connect any 12 channel 0-10VDC analog output console or control station to the analog inputs. Connect a switch
between +14.4VDC and the T/C input.
1. Start with all channels on the analog console off, and the T/C switch in the open position.
2. When you are ready to snapshot the fade time, set all 8 or 12 dimmer channels to same level using the
Microplex or DMX-512 control source corresponding to the follwing fade out times:

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 15 -
Approximate damping times
FL = 30 seconds
90% = 9 seconds
80% = 8 seconds
70% = 7 seconds
60% = 6 seconds
50% = 5 seconds
40% = 4 seconds
30% = 3 seconds
20% = 2 seconds
10% = 1 second
0% = instantaneous
3. With all 12 channels to set to the same level on the microplex or dmx-512 console, and all 12 analog control
inputs to 0%, close the T/C switch for about 10 seconds. When the pack has entered snapshot mode, the lights
will dim 50%.
4. While keeping the T/C switch closed, raise the analog input channel to full of the analog channel where this fade
time to be loaded.
5. When the fade time has loaded, the lights will return to their full intensity, and the T/C switch can be released or
opened.
6. To disable snapshot from a remote location, keep the T/C switch open.
4.3 Analog Submaster Editing
The analog submasters and their associated fade times can also be created or edited from the front panel of the DS
dimmer pack itself. The first 12 presets in the [PRESET#] menu correspond to analog submasters 1 through 12.
From the main menu :
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the [PRESET#] keypad. The following menu will be displayed:
PRESET # = 01
[EDIT] [RUN]
Type in the analog submaster channel you wish edit (001= analog channel 1,… 012= analog channel 12) then press
[EDIT]. If you wish to edit channel 1 just press [EDIT]. If the default analog patch has been enabled, the following
menu will be displayed:
DIMMER=01 AT FL
PRESET=001[MORE]
This menu allows you to set the control level of each channel individually. If you wish to edit the control level for
channel 1, press [ENTER]. If you wish to edit the control level of another channel, enter the dimmer number, or
press [ENTER] until the dimmer # you desire appears in the window. Note that [ENTER] steps the menu to the
next entry field, or auto increments to the next dimmer channel. [CLEAR] steps back one field or menu, each time it
is pressed. When you are finished editing levels, press [MORE]. The following menu will appear:
ANALOG INPUT
FADE TIME = 0SEC
From this menu the fade time damping of the analog submaster may be set or edited. Enter any digit 0-9 or FL. The
damping times correspond to the following:

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 16 -
Approximate damping times
FL = 30 seconds
90% = 9 seconds
80% = 8 seconds
70% = 7 seconds
60% = 6 seconds
50% = 5 seconds
40% = 4 seconds
30% = 3 seconds
20% = 2 seconds
10% = 1 second
0% = instantaneous
___________________________
Section 5 Presets
The DS dimmer has the capacity for 400 presets with time fade. The first 12 presets correspond to the analog
submasters described in section 5. The remainder of the presets, termed "deep presets" are capable of being started
manually from the front panel, or triggered by an analog input channel. These 388 deep presets feature 0 to 999.9
second dipless cross fade times, and hold times of between .1 to 999.9 second or forever. These deep presets can
also be linked, so that a chase effect can be created. This section has been divided into three sub sections, Editing
deep presets, running deep presets, and analog triggered deep presets
5.1 Editing Deep Presets
From the main menu :
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the [PRESET#] keypad. The following menu will be displayed:
PRESET # = 01
[EDIT] [RUN]
Type in the preset # you wish edit. Note that presets 1 through 12 are analog submaster scenes. For convenience, lets
choose Preset# 020. Then press [EDIT]. The following menu will be displayed:
DIMMER=01 AT FL
PRESET=020[MORE]
Edit the dimmer control levels you wish to see in the preset. If you wish to edit the control level for channel 1, press
[ENTER]. If you wish to edit the control level of another channel, enter the dimmer number, or press [ENTER]
until the dimmer # you desire appears in the window. Note that [ENTER] steps the menu to the next entry field, or
auto increments to the next dimmer channel. [CLEAR] steps back one field or menu, each time it is pressed. Note
that you cannot change the preset # from this sub menu, although the preset you are editing is displayed in the lower
left corner of the LCD screen. When you are finished editing levels, press [MORE]. The following menu will
appear:
FADE TIME = 000.0s
[MORE]
Set the dipless cross fade time that you wish for this preset to fade in. The previous preset will fade out at the same
rate. A 000.0second fade time fades instantaneously. A 999.9second fade time fades out in 16- 2/3 minutes. Press
[MORE] when you are finished. The following menu will be displayed:
HOLD TIME = 000.0s
[MORE]

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 17 -
Please note that an 000.0 second hold time will hold the preset active forever, when run from the front panel menu
display. An entry of 000.1second to 999.9seconds will hold the preset active for the selected hold time, then will
automatically start the next or linked preset crossfade when the hold time runs out. This operates essentially like an
auto-follow on a theatrical console, and allows the next cue to be activated automatically. Press [MORE] when the
hold time has been entered, then the next menu will appear:
LINKtoPRESET=OFF
[MORE]
The link to preset menu tells the control module which preset to load next. If a preset has a hold time greater than
zero, and the hold time has just completed its countdown, then the control module will automatically look at the link
to preset field to see if there is an entry. If there has been an entry, it will use the LINK to PRESET entry as the
pointer for which preset to execute next. IE… if preset 36 was running and it had a LINK to PRESET of 030, then
Preset 30 would be the next preset executed. If there is not an entry in the LINK to PRESET field, then the display
to the right of the equal sign will indicate OFF, and the control module will automatically increment the preset to be
executed to the next sequential preset. At preset 400, however, the control module stops incrementing.
If you desire, enter the 3 digit LINK to PRESET pointer, of which preset should run next. (13 through 400). When
you are finished, press [CLEAR] 4 times to take you back to the main preset menu. Using the sequence described in
this section, edit all the deep presets you wish. When finished go to the next sub-section, running deep presets.
5.1 Running Deep Presets
From the main menu :
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the [PRESET#] keypad. The following menu will be displayed:
PRESET # = 01
[EDIT] [RUN]
Type in the preset # you wish to run first. Then press [RUN]. The following menu will appear:
FADE LEFT = xxx.x
[STOP] #zzz [GO]
The preset you selected should appear in the bottom center of the display. The fade time for the preset you selected
will appear on the upper line. Note that the display counts from the time that the cue is executed. Press [GO].
The control module will fade in the scene at the rate you selected. When the fade is complete, the control module will
automatically load the hold time for the preset. Note the display change to the following:
HOLD LEFT = xxx.x
[STOP] #zzz [GO]
If there is a 000.0 hold time in the preset, the preset will remain active, and the control module will automatically
load the link pointer, or increment to the next preset. It will not fade in the next preset, however, until the [GO] soft
key is pressed again. [STOP] will stop execution of the preset completely, and bring all preset levels to blackout.
If the preset has a hold time of 000.1 to 999.9 seconds, then as soon as the fade time has completed the control
module will count down the hold time. When the count down reaches 000.0, then the control module will
automatically load the link pointer, or increment to the next preset then it will automatically run that next preset.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 18 -
5.2 Analog Triggered Deep Presets
This section assumes that you understand how to create and run presets, fade times, and links as described in the
previous sections.
If you have been poking around in the edit preset menus, you may have come across a menu after the LINK to
PRESET menu called AUTO TRIGGER. The auto trigger menu enables presets to automatically load into the
analog submasters. Here are the rules:
1. Every preset to be auto triggered must have the analog channel # entered into the auto trigger field . If the next
linked or incremented preset does not have the auto trigger programmed, then the control module will stop.
Example: If a chase is to be programmed into presets 30 through 42 and the chase is to be activated by
analog input 1, then every preset, 30 through 42, must have AUTO TRIGGER = A01 programmed into its
preset.
2. Only one auto-triggered preset or group of presets can be active at a time. The control module automatically
prioritizes the control levels of analog input channels 1 through 12, and uses the lowest channel number input as
the active trigger input.
Example: If a chase programmed into presets 30 through 42 is auto triggered by analog input 1, and another
chase is programmed into presets 50 through 55 auto triggered by analog input 2, then the chase on analog
input 1 will override the chase on analog input 2, if analog channel 1 has a level over 10%
3. The lowest number auto triggered preset is always the first preset to execute when the analog channel raises from
0 to at least 10%.
4. The auto triggered preset loads into its respective submaster scene, therefore the whole preset scene is under the
proportional control of the analog input control level.
When you are sure you understand these features and constraints, select the applicable preset number from the main
preset menu, press [EDIT], and then [MORE] 4 times, and the following menu will be displayed:
AUTO TRIGGER = OFF
[ON] [MORE]
Press [ON]. The LCD menu will change indicting a default trigger channel of analog input 1. Enter the analog trigger
channel that you desire. Press [CLEAR] to back out of the menu, and then enter the trigger channels for all presets
that are to be auto-faded by the trigger input.
The lowest number auto triggered preset will automatically load and run as soon as the associated analog channel is
raised from 0% to over 10%.

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 19 -
____________________________
Section 6 Dimmer Feedback
The DS dimmer has several mechanisms for dimmer feedback. The most readily available feedback is the LED's on
the front panel display.
•The green LED above each circuit breaker fades up and down proportional to the corresponding dimmer level.
•The 3 red phase power indicators show that proper power has been applied to the pack, and all 3 power
transformers are receiving line power.
•The yellow overtemp indicator illuminates if a dimmer module temperature exceeds 80 degrees C, and it also
blinks momentarily when a valid luminet command has been received.
•The green Microplex indicator flashes in a fast, steady fashion if a valid Microplex signal is being received.
•The green DMX indicator flashes in a fast, steady fashion if a valid DMX-512 signal is being received.
The lower line of the main menu displays a status menu that indicates a number of error conditions, like power input
over or under voltage, over-temperature status, configuration memory errors, and thermistor connection errors. It is
normal for some of these error indications to display breifly during power up, but after a few seconds, STATUS
should display "OK" If any of these errors occur consistently or permanently, please refer to section 8.
If the thermistor connection is broken between the control module and the dimmer module, or in the dimmer module
itself, the following message will be displayed on the bottom line of the main menu:
"THERM 1&2" -- if the thermistor connection for dimmers 1 & 2 is broken.
"THERM 3&4" -- if the thermistor connection for dimmers 3 & 4 is broken.
"THERM 5&6" -- if the thermistor connection for dimmers 5 & 6 is broken.
"THERM 7&8" -- if the thermistor connection for dimmers 7 & 8 is broken.
"THERM 9&10" -- if the thermistor connection for dimmers 9 & 10 is broken.
"THERM 11&12" -- if the thermistor connection for dimmers 11 & 12 is broken.
Note: The dimmers in the affected dimmer module cannot turn on until the thermistor connection problem is
rectified. Refer to section 8 of the manual for assistance.
Individual dimmer status can also be monitored. From the main menu :
NSI DSxx xPHASE
STATUS=xxx [MORE]
Press the [DIMMER] keypad. The following menu will be displayed:
DIMMER # = 01
TEMP= xxC [MORE]
Note the temperature reading in the bottom left corner of the LCD display. This is the operational temperature of the
dimmer module of the selected dimmer. The temperature display has a resolution of 1degress C. The operational
temperature range of the DS dimmer module is 0 to 85 degrees C. The dimmer module will go into an over-temp
warning condition at 85 degrees C, and will linearly dim to off by 90 degrees C.
Press [MORE] to display the following status screen:
DIM 01 = xx% DIMR
SOURCE=yyy[MORE]
This screen displays a variety of live functions of the dimmer. This screen not only displays the current control level
for the dimmer, but also indicates where the control source level has been derived. Highest takes precedence Control
sources can be:

NSI DS8/DS12 MODULAR DIGITAL DIMMING SYSTEM
Software Revision 1.1x, 8/24/99
- 20 -
DMX for DMX-512
MPX for Microlpex
BMP for Test Switch
PRE for Preset
LUM for Luma-Net
A1 for analog submaster 1 …
Through
A12 for analog submaster 12
This live dimmer status screen also indicates the current dimmer curve setting as:
DIMR for a modified square law dimming curve, or
MARK X for a Advance MARK X florescent, or
NON-DIM for an unregulated non-dim.
If a maximum level less than FL has been programmed into the maximum level field, a "^" will appear in the upper
left corner of the LCD screen.
If a minimum level more than 00 has been programmed into the maximum level field, a "v" will appear in the upper
left corner of the LCD screen.
_______________________________________
Section 7 Control Module Jumper Settings
It is highly unlikely that a user would ever want to change the jumper settinngs in the control module, however, here
is a listing of their settings and their function. The jumpers are located on the bottom of the control module, towards
the center of the Processor PCB.
JP2 Jumper Installed = Transformer control voltage scaled for 120VAC. This also assumes all 3
Transformers are strapped for 120VAC, and 120VAC dimmer modules are
installed.
Jumper Removed = Transformer control voltage scaled for 240VAC. This also assumes all 3
Transformers are strapped for 240VAC, and 240VAC dimmer modules are
installed.
JP3 Jumper Installed = Slow Line Regulation Algorithm active. This algorithm is recommended for
[Factory Default] moderate line power feeds. (minor surges and sags in the feed). The algorithm
will also operate well on hard power feeds.
Jumper Removed = Fast Line Regulation Algorithm active. This algorithm is recommended for hard
line power feeds.
Note: For soft power feeeds , line regulation should be turned off. Soft power
feeds are usually associated with significant surges or sags in line voltage, and or
soft neutral connections. Refer to section 2.7.
JP5 Jumper Installed = Normal Luma-Net control data rate (7.812K BAUD) for Lumanet Control
[Factory Default] Stations.
Jumper Removed = High speed Luma-Net data rate (38.4K BAUD). High speed data control stations
are not yet available (as of 8/99).
