Leviton Vizia RF RZCPG User manual

Programmer/Remote
Cat. RZCPG
USER GUIDE
Compatible with enabled products!
TM
1
ON
2
ON
3
ON
4
ON
+
–
••
•
OFF
OFF
OFF
OFF

INTRODUCTION .......................................................1
MENU NAVIGATION & ICONS.............................2–4
STARTUP...................................................................5
INSTALLATION CHECKLIST ...................................5
Include Dimmers/Switches....................................6
TEXT EDITOR...................................................6, 7
Include Controller ...........................................7, 8
Update Controller............................................8, 9
Create Areas ..................................................9, 10
Set Associations .........................................10, 11
Security ..............................................................11
Install Complete.................................................12
MAIN MENU SCREEN............................................13
DEVICE LIST...........................................................13
WHO IS.. .............................................................13
AREA ..................................................................14
PROFILE.......................................................14, 15
EVENTS........................................................15, 16
SETTINGS ..........................................................16
DATE & TIME .................................................16
CONTRAST....................................................17
BUZZER .........................................................17
LOCATION .....................................................17
SECURITY......................................................18
BATTERY LEVEL...........................................18
EVENTS SETUP.............................................18
SYSTEM SETUP (Advanced Settings)............19
NETWORK ...............................................19–22
ASSOCIATION...............................................22
HAI SETUP ....................................................23
RTS DEVICES ...............................................23
UTILITIES.................................................23, 24
TABLE OF CONTENTS

Leviton’s Programmer/Remote, Cat. No. RZCPG, is a multi-
functional device. It uses Z-Wave
TM
technology to act as a
programmer, zone or scene controller, remote and timer for
setting up and operating your Vizia
TM
RF network. This manual
will guide you through the understanding of your RZCPG
functions as a setup controller. Once your network is installed,
your RZCPG may also be used as a wireless controller for
activating events, and controlling your lighting system.
Your RZCPG comes with rechargeable batteries, a
programmer/remote stand, and a power adapter.
NOTE: Upon initial installation, you will need to charge your
RZCPG for twelve (12) hours before programming and use.
WARNING: Leviton only supports the use of the supplied
rechargeable Ni-MH "AA" size batteries.
INTRODUCTION
1
1
ON
2
ON
3
ON
4
ON
+
–
••
•
OFF
OFF
OFF
OFF
RZCPG
Programmer/Remote
RZCPG
Stand
Power
Adapter
This equipment has been tested and found to comply with the limits
for a Class B Digital Device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment OFF and ON, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving Antenna.
• Increase the separation between the equipment and the
receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/tv technician for help.
FCC COMPLIANCE STATEMENT

The right soft key brings
you to the MAIN MENU screen
from the HOME screen and is
used for saving and completing
tasks.
The left soft key is used
to bring you back to the previous
screen.
The up and down arrow buttons allow
you to scroll through each screen and will move
the selection box ( 1. Device List )to each
choice.
NOTE: Selections are made on
each screen by pressing the center
button on the RZCPG unless
prompted otherwise.
MENU NAVIGATION and ICONS
Navigating screens and menus on your RZCPG is
accomplished using the following buttons:
x1
Back
MAIN MENU
1. Device List
2. Who Is...
3. Area
4. Profile
5. Events
Home
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
LCD
Display
(HOME screen
depicted)
Right Soft
Key
Arrow
Buttons
(up, down,
left, right)
Center
Button
"+"
Button
"–"
Button
Left
Soft Key
2
CENTER BUTTON
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu

The Filter is used when
you wish to view only checked
devices, or only unchecked
devices from a list. Use the
right arrow button to toggle
between showing devices
checked, unchecked or all (no
filter).
x1
Back (3)
Area #1
Who Is
Bedroom
Bathroom
Hall
selected 3
1
ON
2
ON
3
ON
4
ON
OFF OFF OFF OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By
Menu
x1
Back Home
AREA
<< NEW >>
<<NEW>> appears on various
screens as a prompt to create
something new (Area, Profile,
Event, etc.)
Leviton also provides various icons that appear on
the screens to provide quick review of the state
of your network, selections made and to assist in
identification of devices (refer to Icon Description
chart). 3
x1
Back (3)
All Devices
Dimmer #1
Switch #1
Switch #2
selected 1
Who Is
x1
Back
PROFILE
<< NEW >>
Done
Scene
Zone
Single brackets
designate that more than one
choice is available. Use the left
and right side arrow buttons
to toggle between
choices.
x1
Cancel Save
All Devices
1. All Devices
2. < ON >
3. Default Fade
x1
Cancel Save
All Devices
1. All Devices
2. < ON >
3. Default Fade
1
ON
2
ON
3
ON
4
ON
OFF OFF OFF OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF OFF OFF OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
Check boxes are used
when multiple selections are
available. Use the and
buttons to select and deselect
from a list.
x1
Back (3)
All Devices
Dimmer #1
Switch #1
Switch #2
selected 1
Who Is
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By
Menu
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By
Menu
x1
Back (3)
Area #1
Who Is
Bedroom
Bathroom
Hall
selected 3
Radio buttons are used
when an "either/or" single choice
is available. Scroll the selection
box to your choice and use the
button to select.
x1
Back
PROFILE
<< NEW >>
Home
Profile #1
Profile #2
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By
Menu

DESCRIPTION
Event Time
Undefined device
Center button
Remote Control
Zone/Scene Controller (Single or Multibutton)
Dimmer
Switch
Thermostat
Event is Set
Event Disabled or All Events are Disabled
Buzzer OFF (indication)
Buzzer OFF
Buzzer ON
Error Indication
Event Recurrence
One Time Event Date
Time of Day or Dawn/Dusk Offset
Filter (data on screen is filtered)
Power Adapter
Battery Power
Single choice (radio button) - not chosen
Single choice (radio button) - chosen
Multiple selection (checkbox) - not selected
Multiple selection (checkbox) - selected
ICON
4

1. Use the arrow buttons to navigate and set the date
& time using the and buttons.
2. Press right soft key (Save).
You will be prompted to
START INSTALLATION
CHECKLIST.
Press right soft key (YES). The
INSTALL CHECKLIST screen will
appear.
NOTE: Upon initial power up of
the RZCPG, the VIZIA
TM
RF logo
will appear briefly and then the
DATE & TIME screen will display,
prompting the user to change
the settings. NOTE: Leviton
recommends setting the date and
time before proceeding. Failure to
do so will disable your events (refer to EVENTS
pg. 15). Set the date and time for your RZCPG as
follows:
STARTUP
x1
Cancel
DATE & TIME
Time: 09: 00 AM
Date: 06. 07. 2007
Wednesday
Save
INSTALLATION CHECKLIST
x1
Back
INSTALL CHECKLIST
1. Include Dim/Swch
2. Include Controller
3. Update Controller
4. Create Areas
5. Set Associations
Next Step
x1
Back
3. Update Controller
4. Create Areas
5. Set Associations
6. Security
7. Install Complete
Next Step
INSTALL CHECKLIST
5
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
Leviton provides the Installation Checklist as a step
by step tool to setup your Vizia
TM
RF network and
recommends following these steps in order, specifically
if you are a first time user. System design will impact
performance, so it is necessary to include and update
your devices in a specific order to ensure overall system
performance and reliability. The Installation Checklist
steps are shown below. When a step is completed,
simply press the right soft key to select NEXT STEP
and the RZCPG will bring you to the next screen.
DATE & TIME
x1
NO
INSTALL CHEKLIST
YES
START
INSTALLATION
CHECKLIST

Include Dimmers/Switches
Pressing the center button
to select Include Dim/Swch
will bring you to the INCLUDE
DIM/SWCH screen and put the
RZCPG into Inclusion Mode.
You will be prompted to press a
button on your Dimmer, Switch or
Plug-In Module. These devices
require a simple one step process (button press) to
include into the network (refer to individual device
instruction sheet). Once the button is pressed on
your Dimmer, Switch or Plug-In Module, the RZCPG
will go through a communication process and assign
the node information for that device. The TEXT
EDITOR will display. You can now name your device.
NOTE: The RZCPG is by default assigned #1.
Using TEXT EDITOR you can
either assign a name from a list
of templates or assign a unique
name to your device.
NOTE: The right soft key will
toggle from Template to Abc to
ABC to abc to 123 and back to
Template again. This feature allows you to access
the template names or to select capital/undercase
letters and numerals to name your device.
To use the pre-made Templates,
with Template displayed, use the
up and down arrow buttons
to select a name. The RZCPG
offers a list of over 100 commonly
used names to choose from.
NOTE: The template names are
editable for customization if you
choose to alter them.
STEP 1
x1
Cancel
INCLUDE DIM/SWCH
Press button on
Dimmer/Switch
x1
TEXT EDITOR
Switch #2
Levito
Save? Press
n
Switch #2
Template
TEXT EDITOR
x1
TEXT EDITOR
Switch #2
Leviton
Bedroom
Abc
Save? Press
6
Using your RZCPG, follow these steps to set up
your ViziaRFTM network:
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu

7
To create a unique name or modify text, under
ABC (or Abc, abc, 123) use the up and down arrow
buttons to change each letter or numeral and
side arrow buttons to navigate. The and
buttons can be used to insert and delete characters.
Once your template or created
name is displayed, press the
center button .Your device
has now been included in
the network with your chosen
name. The RZCPG will confirm
inclusion with the name displayed
and prompt you to continue to
INCLUDE DIM/SWCH by pressing the center button
or to continue to the NEXT STEP by pressing the
right soft key .
Include Controller
NOTE: The INSTALL
CHECKLIST screen will appear
with the selection box around
STEP 2 - Include Controller
when NEXT STEP is chosen from
STEP 1.
Press the center button on
the RZCPG to bring up the
INCLUDE CNTRLLER screen,
where you will be prompted to
place the controller in program
mode.
NOTE: Leviton Controllers
require an inclusion process
that differs from Dimmers, Switches and Plug-In
Modules. Controllers must be placed into program
mode before they can be included into the network
(refer to individual device instruction sheet).
Once your controller has been placed in program
mode, press the center button on the RZCPG.
The RZCPG will go through the communication
process and assign the node information for that
device. The TEXT EDITOR will display where you
can name your device (refer to TEXT EDITOR
pg. 6).
x1
Back Next Step
Node included!
Node ID# 2:
Bedroom
More? Press
INCLUDE DIM/SWCH
STEP 2
x1
Return
INCLUDE CNTRLLER
Place controller
in program mode
See Instruction sheet
Begin? Press
x1
Back
INSTALL CHECKLIST
1. Include Dim/Swch
2. Include Controller
3. Update Controller
4. Create Areas
5. Set Associations
Next Step
1
ON
2
ON
3
ON
4
ON
OFF OFF OFF OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF OFF OFF OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By
Menu
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu

Once your name is displayed,
press the center button .The
RZCPG will confirm inclusion
and prompt you to continue to
INCLUDE CONTROLLER by
pressing the center button or
to continue to the NEXT STEP
by pressing the right soft key
NOTE: The confirmation process will take some
time, specifically in large networks. Remain close to
the controller until the confirmation is complete.
Update Controller
NOTE: The INSTALL
CHECKLIST screen will appear
with the selection box around
STEP 3 - Update Controller
when NEXT STEP is chosen
from STEP 2.
Press the center button to
bring up the UPDATE CNTRLS
screen where a list of all the
controllers in the network will be
displayed. With the selection box
around the first controller listed
press the center button . The
RZCPG will prompt you to stand
within 3 feet of that controller.
Press the right soft key (YES)
to update your controller. NOTE:
It is important that you remain
within 3 ft. of the controller
you've selected from the list.
If you are unsure about which
controller you are updating
you can use the "Who Is"
command (see pg. 13).
Leviton controllers will blink
during the update process,
confirming you are updating
the correct controller.
Once the RZCPG confirms
UPDATE it will display the updated node
information. Press the center button to finalize.
x1
Back Next Step
Node included!
Node ID #3:
Room Controller
INCLUDE CNTRLLER
More? Press
STEP 3
x1
Back (2)Who Is
UPDATE CNTRLS
Room Controller
Hall Controller
x1
NO YES
UPDATE
Please stand within
3 ft from controller
and press YES
to continue
x1
Return
UPDATE
Node Updated!
Node ID #4
Room controller
8
x1
Back
INSTALL CHECKLIST
1. Include Dim/Swch
2. Include Controller
3. Update Controller
4. Create Areas
5. Set Associations
Next Step

Continue this process until all of your controllers
have been updated. Each time you successfully
update your controller it will be removed from the
list. Once all of your controllers have been updated,
press the right soft key to continue to the NEXT
STEP.
Create Areas
NOTE: The INSTALL
CHECKLIST screen will appear
with the selection box around
STEP 4 - Create Areas when
NEXT STEP is chosen from
STEP 2.
Press the center button to
bring up the AREA screen. With
<< NEW >> selected press the
center button to bring up the
CREATE AREA screen. You
can now name your new area
by pressing the center button
(refer to TEXT EDITOR pg. 6).
Once you name your new area,
press the center button to
save the information and return
to the CREATE AREA screen.
Scroll to and press the center
button to select Add Devices
which will bring up a list of the
dimmers and switches you
included in Step 1 to add to your
new area. Scroll to each device
check box and use the and
buttons to either add or subtract
each device from your area.
NOTE: You can use the
4 ON button on the
bottom of the RZCPG to select
ALL devices simultaneously. The
4 OFF button deselects
ALL devices. This feature will
work whenever you encounter
check box lists.
9
STEP 4
x1
Cancel
CREATE AREA
Name: Area #1
Add Devices...
Save
x1
Back (3)
AREA #1
Bedroom
Bathroom
Hall
selected 1
Who Is
x1
Back Next Step
AREA
<< NEW >>
Area #1
x1
Back Next Step
AREA
<< NEW >>
x1
Back
INSTALL CHECKLIST
1. Include Dim/Swch
2. Include Controller
3. Update Controller
4. Create Areas
5. Set Associations
Next Step
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
4 ON OFF
4 ON OFF

Once you have checked the devices for your area
press the center button to save. The AREA
screen will display with your newly created area
and prompt you to continue to create a new area by
pressing the center button to select <<NEW>> or
to continue to the NEXT STEP by pressing the right
soft key .
NOTE: You can use the 1 ON button and
1 OFF button on the RZCPG to turn the
lights ON and OFF in an area that has the selection
box around it.
Set Associations
NOTE: The INSTALL
CHECKLIST screen will appear
with the selection box around
STEP 5 - Set Associations
when NEXT STEP is chosen
from STEP 4.
Press the center button to
bring up the ASSOCIATION
screen.
A list of controllers included in
Step 2 that support association
will be displayed.
Scroll to and press the center
button to select the controller
you wish to associate an area or
areas to.
The CONTROLLER ASSOC
screen will display with the
selection box around 1. Button
prompting you to select the
button on your controller that
you wish to associate an area to. Use side arrow
buttons to toggle if applicable.
Scroll to 2. Area and choose an area you wish to
associate to the button you've selected. This will
allow the button on the chosen controller to control
the desired area.
Selecting 3. Area ON/OFF allows you to set an
AREA ON/OFF or SCENE command to that button
on your controller (for SCENE commands refer to
Advanced Settings).
STEP 5
x1
Back
ASSOCIATION
Room Controller
Hall Controller
Den Controller
Next Step
x1
Cancel
CONTROLLER ASSOC
Dev: Room Controller
1. <Button 1 >
2. Area #1
3. Area ON/OFF
Save
10
x1
Back
INSTALL CHECKLIST
1. Include Dim/Swch
2. Include Controller
3. Update Controller
4. Create Areas
5. Set Associations
Next Step
1 ON OFF
1 ON OFF
1
ON
2
ON
3
ON
4
ON
OFF OFF OFF OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF OFF OFF OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By
Menu

Once you are done press the right soft key
(Save) to complete. You will be prompted to
continue setting associations or to proceed to the
NEXT STEP by pressing the right soft key .
Security
NOTE: The INSTALL
CHECKLIST screen will appear
with the selection box around
STEP 6 - Security when NEXT
STEP is chosen from STEP 5.
Press the center button to
bring up the SECURITY screen.
Press the center button to
select 1. Setup Password.
Enter password using four of the
eight buttons on the RZCPG
(1 ON, 1 OFF, 2 ON, 2 OFF etc.)
NOTE: The password you
choose MUST be 4characters
long.
You will be prompted to, and
must re-enter password.
Scroll to 2. and use the side
arrow buttons to toggle
between choices OPEN, RZCPG
Lock and System Lock.
Press right soft key (Save) to complete.
NOTE: Selecting <RZCPG Lock>will lock the
RZCPG. When you return to the HOME screen you
will not have access to the MAIN MENU nor any
screens until you press the right soft key and
enter your password.
Selecting <System Lock>will only lock System
Setup, preventing one from changing how the
system is configured until the password is entered
upon prompt.
11
STEP 6
x1
Back
SECURITY
1. Setup Password
2. <OPEN >
Save
x1
Back
SECURITY
1. Setup Password
2. <RZCPG Lock >
Save
x1
Back
2. Include Controller
3. Update Controller
4. Create Areas
5. Set Associations
6. Security
Next Step
INSTALL CHECKLIST
1
ON
2
ON
3
ON
4
ON
OFF OFF OFF OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By Menu
1
ON
2
ON
3
ON
4
ON
OFF OFF OFF OFF
x1
12:00 PM
Mon 05.01.2006
Default Profile
Stand By
Menu
