Leviton VRCPG User manual

Programmer/Remote
Cat. No. VRCPG
USER GUIDE
1
ON
2
ON
3
ON
4
ON
+
–
••
•
OFF
OFF
OFF
OFF

INTRODUCTION .......................................................1
MENU NAVIGATION & ICONS.............................2–4
STARTUP...................................................................5
Time ...........................................................................5
INSTALLATION CHECKLIST ...................................6
Include Dimmers/Switches....................................6
TEXT EDITOR.......................................................7
Include Controller ...............................................8
Update Controller............................................8, 9
Create Areas ..................................................9, 10
Set Associations .........................................10, 11
Security ........................................................11, 12
Install Complete.................................................12
MAIN MENU SCREEN............................................13
DEVICE LIST...........................................................13
WHO IS.. .............................................................13
AREA ..................................................................14
PROFILE.......................................................14, 15
EVENTS........................................................15, 16
SETTINGS ..........................................................16
TIME ...............................................................16
CONTRAST....................................................17
BUZZER .........................................................17
LOCATION .....................................................17
SECURITY......................................................18
BATTERY LEVEL...........................................18
EVENTS SETUP.............................................18
LCD TIMEOUT ...............................................19
LANGUAGE ...................................................19
SYSTEM SETUP (Advanced Settings)............20
NETWORK ...............................................20–23
ASSOCIATION...............................................23
RS232 SETUP................................................24
RTS DEVICES ...............................................24
UTILITIES.................................................24, 25
TABLE OF CONTENTS

Leviton’s Programmer/Remote, Cat. No. VRCPG, is a multi-
functional device. It uses Z-Wave
TM
technology to act as a
programmer, zone or scene controller, remote and timer for
setting up and operating your Vizia RF +
TM
network. This manual
will guide you through the understanding of your VRCPG
functions as a setup controller. Once your network is installed,
your VRCPG may also be used as a wireless controller for
activating events, and controlling your lighting system.
Your VRCPG comes with rechargeable batteries, a programmer/
remote stand, and a power adapter. NOTE: This product is
designed to work with other Z-Wave
®
enabled devices from
any manufacturer. Z-Wave
®
nodes of other types and product
categories can be added to the system, and will also act as
repeaters if they support this function of repeating the signal
received to other modules in the system. NOTE: Upon initial
installation, you will need to charge your VRCPG for twelve (12)
hours before programming and use.
WARNING: Leviton only supports the use of the supplied
rechargeable Ni-MH "AA" size batteries.
INTRODUCTION
1
1 ON
2 N
3 ON
4 ON
+
–
••
•
OFF
FF
O F
OFF
VRCPG
Programmer/Remote
VRCPG
Stand
Power
Adapter
This equipment has been tested and found to comply with the limits
for a Class B Digital Device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment OFF and
ON, the user is encouraged to try to correct the interference by one or
more of the following measures:
• ReorientorrelocatethereceivingAntenna.
• Increasetheseparationbetweentheequipmentandthereceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthat
to which the receiver is connected.
• Consultthedealeroranexperiencedradio/tvtechnicianforhelp.
FCC COMPLIANCE STATEMENT

MENU NAVIGATION and ICONS
Navigating screens and menus on your VRCPG is
accomplished using the following buttons:
x1
Back
MAIN MENU
1. Device List
2. Who Is...
3. Area
4. Profile
5. Events
Home
8:35A
1 ON
2 ON
3 ON
4 ON
OFF
OFF
OFF
OFF
x1
08:35 AM
Mon 04 28 2008
VRCPG
Default Profile
Stand By Menu
8:35A
LCD
Display
(HOME screen
depicted)
Right Soft
Key
Arrow
Buttons
(up, down,
left, right)
Center
Button
"+"
Button
"–"
Button
Left
Soft Key
2
CENTER BUTTON
efault Prof
tand By
2:0
The right soft key brings
you to the MAIN MENU screen
from the HOME screen and is
used for saving and completing
tasks.
The left soft key is used
to bring you back to the previous
screen.
The up and down arrow buttons allow
you to scroll through each screen and will move
the selection box ( 1. Device List )to each
choice.
NOTE: Selections are made on
each screen by pressing the center
button on the VRCPG unless
prompted otherwise.

Check boxes are used
when multiple selections are
available. Use the and
buttons to select and deselect
from a list.
The Filter is used when
you wish to view only checked
devices, or only unchecked
devices from a list. Use the
right arrow button to toggle
between showing devices
checked, unchecked or all (no
filter).
x1
Back 3/3
Area #1
Who Is
Bedroom
Bathroom
Hall
8:35A
Select? Press
1 N
ON
3
O
F
x1
Back Home
AREA
<< NEW >>
8:35A
Select? Press
<<NEW>> appears on various
screens as a prompt to create
something new (Area, Profile,
Event, etc.)
Leviton also provides various icons that appear on
the screens to provide quick review of the state
of your network, selections made and to assist in
identification of devices (refer to Icon Description
chart). 3
Single brackets
designate that more than one
choice is available. Use the left
and right side arrow buttons
to toggle between
choices.
x1
Cancel Save
EVENT
1. Event #1
2. < Enabled >
3. Action
4. Recurrence
5. 12:00P
8:35A
O
De a l
tand B nu
N
De
tand nu
x1
Back (3)
Area #1
Dimmer #1
Switch #1
Switch #2
Who Is
8:35A
Save? Press
Radio buttons are used
when an "either/or" single choice
is available. Scroll the selection
boxtoyourchoiceandusethe
button to select.
x1
Back
PROFILE
<< NEW >>
Home
Profile #1
Profile #2
8:35A
Select? Press
< Enabled >
Back
A
S
se

DESCRIPTION
Event Time
Undefined device
Action in process
Center button
Remote Control
Zone/Scene Controller (Single or Multibutton)
Dimmer
Switch
Thermostat
Event is Set
Event Disabled or All Events are Disabled
Buzzer OFF (indication)
Buzzer OFF selection
Buzzer ON selection
Error Indication
Event Recurrence
One Time Event Date
Time of Day or Dawn/Dusk Offset
Filter (data on screen is filtered)
Power Adapter
Battery Power
Single choice (radio button) not chosen
Single choice (radio button) chosen
Multiple selection (checkbox) not selected
Multiple selection (checkbox) selected
ICON
4

NOTE: Upon initial power up of
the VRCPG, the Vizia
RF +
TM
logo
will appear briefly and then the
DATE & TIME screen will display,
prompting the user to change
the settings. NOTE: Leviton
recommends setting the date and
time before proceeding. Failure to
do so will disable your events (refer to EVENTS pg.
15). NOTE: The time will blink if the VRCPG loses
power to indicate there may be an error. Set the date
and time for your VRCPG as follows:
STARTUP
x1
Cancel
DATE & TIME
Monday
Save
Time: 08:35 AM
Date: 04 28 2008
Form: 12h mmdd
12:00P
5
TIME
1. Use the arrow buttons to navigate and set the
date & time using the and buttons.
2. Press right soft key (Save).
You will be prompted to START
INSTALLATION CHECKLIST.
Press right soft key (YES).
NOTE: When you select YES to
begin the Installation Checklist,
the LANGUAGE screen will
appear. Use up and down arrow
buttons to scroll between
"ENGLISH" and "SPANISH".
Press center button to select
your language choice and right
soft key (Save) to complete.
1 N
O
3 ON
O
F
F
OF
1
0 5 A
- C G
P l
M u
8 5A
x1
NO
INSTALL CHEKLIST
YES
START
INSTALLATION
CHECKLIST
8:35A
x1
M 0 01 06
D ault P f le
y
1
ON
OFF
x
on 0 .0 .200
De ault Pr file
S and By Menu
x1
Cancel
LANGUAGE
Save
SPANISH
8:35A
ENGLISH

Include Dimmers/Switches
Pressing the center button
to select Include Dim/Swch will
bring you to the INCLUDE DIM/
SWCH screen and put the VRCPG
into Inclusion Mode. You will be
prompted to press a button on your
Dimmer or Switch. These devices
require a simple one step process
(button press) to include into
the network (refer to individual device instruction
sheet). Once the button is pressed on your Dimmer,
Switch or Plug-In Module, the VRCPG will go through
a communication process and assign the node
information for that device. The TEXT EDITOR will
display. You can now name your device.
NOTE: The VRCPG is by default assigned node #1.
STEP 1
x1
Cancel
INCLUDE DIM/SWCH
Press button on
Dimmer/Switch
8:35A
6
Using your VRCPG, follow these steps to set up
your Vizia RF +TM network:
INSTALLATION CHECKLIST
x1
Back
INSTALL CHECKLIST
2. Include Controller
3. Update Controller
4. Create Areas
5. Set Associations
Next Step
8:35A
1. Include Dim/Swch
x1
Back
3.
Update Controller
4. Create Areas
5. Set Associations
6. Security
Next Step
INSTALL CHECKLIST
8:35A
7. Install Complete
Leviton provides the Installation Checklist as a step
by step tool to setup your Vizia RF +
TM
network and
recommends following these steps in order, specifically
if you are a first time user. System design will impact
performance, so it is necessary to include and update
your devices in a specific order to ensure overall system
performance and reliability. The Installation Checklist
steps are shown below. When a step is completed,
simply press the right soft key to select NEXT
STEPandtheVRCPGwillbringyoutothenextscreen.
NOTE: Installation checklist can be accessed any time
using option 7. System Setup on the Main Menu.

7
Using TEXT EDITOR you can
either assign a name from a list of
templates or assign a unique name
to your device.
NOTE: The right soft key will
toggle from Template to Abc to
ABC to abc to 123 and back to
Template again. This feature allows
you to access the template names or to select capital/
undercase letters and numerals to name your device.
To use the pre-made Templates,
with Template displayed, use the
up and down arrow buttons
to select a name.
The VRCPG offers a list of over 100
commonly used names to choose
from. NOTE: The template names
are editable for customization if you
choose to alter them.
To create a unique name or modify text, under
ABC (or Abc, abc, 123) use the up and down arrow
buttons to change each letter or numeral and
side arrow buttons to navigate. The and
buttons can be used to insert and delete characters.
Once your template or created
name is displayed, press the
center button .Your device
has now been included in
the network with your chosen
name. The VRCPG will confirm
inclusion with the name displayed
and prompt you to continue to
INCLUDE DIM/SWCH by pressing the center button
or to continue to the NEXT STEP by pressing
the right soft key . After all Dimmers/Switches are
included, proceed to the NEXT STEP.
x1
TEXT EDITOR
Switch #2
Levito
Save? Press
n
Switch #2
Template
8:35A
TEXT EDITOR
x1
Back Next Step
Node included!
Node ID# 2:
Bedroom
More? Press
INCLUDE DIM/SWCH
8 35A
x1
TEXT EDITOR
Switch #2
Leviton
Bedroom
Abc
Save? Press
8:35A
1
O
2
3
O
ON
OF
OF
FF
FF
1
12:00 PM
Defaul P
S and By Men
1
ON
ON
4
O
OFF
OFF
OFF
x
Mon 0 06
e
S By
N
2
N
O O
D a t ro ile
S an B Menu
2 3
O OF O
D a t ro le
S an B
Menu
3
2
ON
3
4
OFF
O
D a l o
a d y M
1
O
2
ON
3
O
F
OF
O
x1
12 00 PM
on 0 200
Defa lt Pr fil
Stand By Menu
ON
2
ON
3
ON
4
ON
OFF
OFF
OFF
OFF
x1
12:00 PM
n 05 1 2 0
ef lt Pr fi e
Stan By

Include Controller
NOTE: The INSTALL
CHECKLIST screen will appear
withtheselectionboxaround
STEP 2 - Include Controller
when NEXT STEP is chosen from
STEP 1.
Press the center button on
the VRCPG to bring up the
INCLUDE CNTRLLER screen,
where you will be prompted to
place the controller in program
mode.
NOTE: Leviton Controllers require
an inclusion process that differs
from Dimmers and Switches.
Controllers must be placed into
program mode before they can be included into the
network (refer to individual device instruction
sheet).
Once your controller has been placed in program
mode, press the center button on the VRCPG. The
VRCPG will go through the communication process
and assign the node information for that device. The
TEXT EDITOR will display where you can name your
device (refer to TEXT EDITOR pg. 7).
Once your name is displayed,
press the center button .The
VRCPG will confirm inclusion
and prompt you to continue to
INCLUDE CONTROLLER by
pressing the center button or
to continue to the NEXT STEP
by pressing the right soft key
NOTE: The confirmation process will take some time,
specifically in large networks. Remain close to the
controller until the confirmation is complete. After
including all controllers, proceed to the NEXT STEP .
Update Controller
NOTE: The INSTALL
CHECKLIST screen will appear
withtheselectionboxaround
STEP 3 - Update Controller
when NEXT STEP is chosen from
STEP 2.
x1
Back Next Step
Node included!
Node ID #3:
Room Controller
INCLUDE CNTRLLER
More? Press
8:35A
STEP 3
8
x1
Back
INSTALL CHECKLIST
1. Include Dim/Swch
2. Include Controller
4. Create Areas
5. Set Associations
Next Step
8:35A
3. Update Controller
x1
Return
INCLUDE CNTRLLER
Place controller
in program mode
See Instruction sheet
Begin? Press
8:35A
x1
Back
INSTALL CHECKLIST
1. Include Dim/Swch
3. Update Controller
4. Create Areas
5. Set Associations
Next Step
8:35A
2. Include Controller
STEP 2

Press the center button to
bring up the UPDATE CNTRLS
screen where a list of all the
controllers in the network will be
displayed.Withtheselectionbox
around the first controller listed
press the center button . The
VRCPG will prompt you to stand
within 3 feet of that controller.
Press the right soft key (YES)
to update your controller. NOTE:
It is important that you remain
within 3 ft. of the controller
you've selected from the list.
If you are unsure about which
controller you are updating you
can use the "Who Is" command
(see pg. 13). Leviton controllers
will blink during the update
process, confirming you are
updating the correct controller.
Once the VRCPG confirms
UPDATE it will display the updated node information.
Press the center button to finalize.
Continue this process until all of your controllers
have been updated. Each time you successfully
update your controller it will be removed from the
list. Once all of your controllers have been updated,
press the right soft key to continue to the NEXT
STEP.
Create Areas
NOTE: The INSTALL
CHECKLIST screen will appear
withtheselectionboxaround
STEP 4 - Create Areas when
NEXT STEP is chosen from
STEP 3.NOTE: Areas are a set
of devices that will be controlled
as one.
Press the center button to
bring up the AREA screen. With
<< NEW >> selected press the
center button to bring up the
CREATE AREA screen. 9
x1
Back 2/2 Who Is
UPDATE CNTRLS
Hall Controller
Room Controller
8:35A
x1
NO YES
UPDATE
Please stand within
3 ft from controller
and press YES
to continue
8:35A
x1
UPDATE
Node Updated!
Node ID #4
Room controller
8:35A
Finalize? Press
STEP 4
x1
Back Next Step
AREA
8:35A
<< NEW >>
Select? Press
x1
Back
INSTALL CHECKLIST
1. Include Dim/Swch
2. Include Controller
3. Update Controller
5. Set Associations
Next Step
8:35A
4. Create Areas

You can now name your new
area by pressing the center
button (refer to TEXT
EDITOR pg. 7). Once you
name your new area, press the
center button to save the
information and return to the
CREATE AREA screen.
Scroll to and press the center
button to select Add Devices
which will bring up a list of the
dimmers and switches you
included in Step 1 to add to your
new area. Scroll to each device
checkboxandusethe and
buttons to either add or subtract
each device from your area.
NOTE: You can use the
4 ON button on the
bottom of the VRCPG to select
ALL devices simultaneously. The
4 OFF button deselects
ALL devices. This feature will work whenever you
encountercheckboxlists.
Once you have checked the devices for your area
press the center button to save. The AREA
screen will display with your newly created area
and prompt you to continue to create a new area
by
pressing the center button to select <<NEW>>
or
to continue to the NEXT STEP by pressing the right
soft key .
NOTE: You can use the 1 ON button and
1 OFF button on the VRCPG to turn the
lights ON and OFF in an area that has the selection
boxaroundit.
Set Associations
NOTE: The INSTALL
CHECKLIST screen will appear
withtheselectionboxaround
STEP 5 - Set Associations
when NEXT STEP is chosen
from STEP 4.
Press the center button to bring up the
STEP 5
10
x1
Back
INSTALL CHECKLIST
1. Include Dim/Swch
2. Include Controller
3. Update Controller
4. Create Areas
Next Step
8:35A
5. Set Associations
1 ON OF
ON OFF
x1
Back 1/3
AREA #1
Bedroom
Bathroom
Hall
Who Is
Save? Press
8:35A
x1
Back Home
AREA
Area #1
Select? Press
8:35A
<< NEW >>
2
3
08 35 AM
C
e au t P e
M
4 ON OF
ON OFF
x1
Cancel
CREATE AREA
Name: Area #1
Save
Add Devices...
8:35A

ASSOCIATION screen. A list of
controllers included in Step 2
that support association will be
displayed.
Scroll to and press the center
button to select the controller
you wish to associate an area or
areas to.
The CONTROLLER ASSOC
screen will display with the
selectionboxaround1. Button
prompting you to select the
button on your controller that
you wish to associate an area to.
Use side arrow buttons to
toggle if applicable.
Scroll to 2 Area and choose an area you wish to
associate to the button you've selected. This will
allow the button on the chosen controller to control
the desired area.
Selecting 3. Area ON/OFF allows you to set an
AREA ON/OFF or SCENE command to that button
on your controller (for SCENE commands refer to
Advanced Settings).
Once you are done press the right soft key
(Save) to complete. You will be prompted to
continue setting associations or to proceed to the
NEXT STEP by pressing the right soft key .
Security
NOTE: The INSTALL
CHECKLIST screen will appear
withtheselectionboxaround
STEP 6 - Security when NEXT
STEP is chosen from STEP 5.
Press the center button to
bring up the SECURITY screen.
Press the center button to
select 1. Setup Password.
Enter password using four of the
eight buttons on the VRCPG
(1 ON, 1 OFF, 2 ON, 2 OFF etc.)
NOTE: The password you
choose MUST be 4characters
long. 11
x1
Back
ASSOCIATION
Hall Controller
Den Controller
Next Step
Room Controller
8:35A
x1
Cancel
CONTROLLER ASSOC
Dev: Room Controller
2. Area #1
3. Area ON/OFF
Save
1. <Button 1 >
8:35A
STEP 6
x1
Cancel
SECURITY
2. <OPEN >
Save
1. Setup Password
8:35A
x1
Back
2.
Include Controller
3. Update Controller
4. Create Areas
5. Set Associations
Next Step
INSTALL CHECKLIST
8:35A
6. Security
1
O
2
OFF
12: 0 PM
on 0 0 2006
fau t Pro ile
St n By Menu
1
ON
2
ON
OFF O
Mon 05.01.2006
D au t Prof
S nd By
Menu

Install Complete
NOTE: The INSTALL
CHECKLIST screen will appear
withtheselectionboxaround
STEP 8 - Install Complete when
you save your security selection.
Press the center button to
receive your confirmation that
the INSTALL CHECKLIST is
now complete. Press the center
button again to start using
the VRCPG.
The HOME screen of the
VRCPG will be displayed.
x1
INSTALL CHECKLIST
Installation Checklist
complete.
Press button
to start using Primary
8:35A
x1
Stand By Menu
08:35 AM
Mon 04.28.2008
- VRCPG -
Default Profile
8:35A
12
x1
Back
3.
Update Controller
4. Create Areas
5. Set Associations
6. Security
Next Step
INSTALL CHECKLIST
8:35A
7. Install Complete
STEP 7
You will be prompted to, and
must re-enter password.
Scroll to 2. and use the side
arrow buttons to toggle
between choices OPEN, VRCPG
Lock and System Lock.
Press right soft key (Save) to
complete.
NOTE: Selecting <VRCPG Lock>will lock the
VRCPG. When you return to the HOME screen you
will not have access to the MAIN MENU nor any
screens until you press the right soft key and
enter your password.
Selecting <System Lock>will only lock System
Setup, preventing one from changing how the
system is configured until the password is entered
upon prompt.
x1
Cancel
SECURITY
1. Setup Password
Save
2. <VRCPG Lock >
8:35A
O O
F
D fa lt r f e
an B en
1
O
F
OF OF
S By
en

Pressing the right soft key while on the HOME
screen will bring up the MAIN MENU screen where
you can navigate through the various selections to
edit or change settings.
Selecting 1. Device List from the
MENU screen will bring you to
the DEVICE LIST screen where
a list devices included in the
network will appear. From this
list you can rename devices by
pressing the center button to
select a device and using TEXT
EDITOR (pg.7), control ON/OFF and adjust intensity
levels. NOTE: Pressing the 2 OFF button with
theselectionboxaroundadimmingdevicewill
bring up the DEVICE CONTROL menu where you
can use the and buttons to precisely raise
or lower the level with slide control, which will be
displayed at the bottom.
Selecting 2. Who Is from the
MENU screen will bring you to
the WHO IS... screen where you
can identify your devices. Simply
press a button on a network
included device to obtain the node
information.
After the information is received
by the VRCPG, it will display the
device ID and the NAME assigned
to the device you activated.
MAIN MENU SCREEN
x1
Back
MAIN MENU
2. Who Is
3. Area
4. Profile
5. Events
Home
8:35A
1. Device List
x1
Back
MAIN MENU
3. Area
4. Profile
5. Events
6. Settings
Home
8:35A
7. System Setup
DEVICE LIST
WHO IS
x1
Back
WHO IS...
Press button on unit
Acquiring node info
8:35A
x1
Back
WHO IS...
This is node #7
Dimmer Scene Cap
RT Slave
Name: Hall dimmer
8:35A
Another? Press
x1
Back (3)
DEVICE LIST
Who Is
Bedroom
Bathroom
Edit name? Press
8:35A
VRCPG
RC
13
1 ON OFF
3 N
O
2 00 P
M 7 008
D au ofi e
a
1
x1
2
n 0 0 0
D u P f

Selecting 3. Area from the MENU screen will bring
you to the AREA screen. You can create a new area,
renameanexistingarea,modifydevicesinanarea
or delete an area (refer to Step 4 of INSTALLATION
CHECKLIST - Create Areas pg. 9).
Selecting 4. Profile from the MENU screen will
bring you to the PROFILE screen. Up to 16 profiles
can be created to control different areas of your
house with your VRCPG. Each device may be
controlled by assigning an area to one of the four
buttons on the VRCPG. NOTE: Default profile will
control the first four areas created with ON/OFF
control using the 1 ON , 1 OFF through
4 ON , 4 OFF buttons respectively.
Withtheselectionboxaround
<<NEW>> press the center
button . You can name your
new profile by pressing the center
button to select Name: (refer
to TEXT EDITOR pg. 7).
Once you name your new profile,
press the center button to
save and scroll to Button. Use
side arrow buttons to
toggle between button choices.
The displayed button will be the
button on your controller that
your profile will react to.
Scroll to Area and use side arrow
buttons to choose the area
you wish to affect with this profile.
Scroll to Action and use side
arrow buttons to choose
an ON/OFF or SCENE (1-255)
command. Scene commands will
also give you a Fade option. Use
side arrow buttons to toggle
between fade choices DEFAULT, IMMEDIATE, or 1
SECOND thru 127 MINUTES.
Press the right soft key (Save) to complete.
AREA
PROFILE
x1
Back
PROFILE
Home
Select? Press
8:35A
<< NEW >>
x1
Cancel
NEW PROFILE
Save
Button: 1
Area: Area #1
Action: ON/OFF
Name: Profile #1
8:35A
x1
Back
PROFILE
Home
Profile #1
Pro ile #2
Select? Press
8:35A
<< NEW >>
14
N N
O
FF
O
De a t ro ile
S an B Me u
ON
FF
O F
De a t Pro ile
S nd By
Me u
ON
3
ON
OFF O F OF
1
N
O
4
ON
OFF
F
OFF OFF
1
ON ON ON
OFF O
D fa lt rof le
S n By Me u
1
O O ON
OFF O O
e u
O O
OFF
De a t Prof l
S nd B e u
O O
FF
De a t rof le
S nd B
Me u
1 ON F
4 ON OFF

15
The PROFILE screen will display
with your newly created profile.
NOTE: Using the button to
select a profile will make it your
default profile and be displayed
on the HOME screen. Use the
side arrow buttons to
toggle between profiles when on
the HOME screen. Default Profile will display when
none are selected. Use the button to deselect
a profile.
Selecting Events from the MAIN
MENU screen will bring you to the
EVENTS screen where you can
program up to 64 timed events.
An area can be set to MAX, ON/
OFF, or a SCENE command
for a desired time, a specified
recurrence or a value relative to
sunrise or sunset. The following
explainshowtocreateanevent:
Withtheselectionboxaround
<<NEW>> press the center
button . You can name your
new event by pressing the center
button to select 1. Event # 1
(refer to TEXT EDITOR pg. 7).
Once you name your new event,
press the center button to
save and scroll to 2. Enabled
which allows you to ENABLE or
DISABLE your event. Use side
arrow buttons to toggle.
Selecting 3. Action allows you
to select the area you wish to
affect, the action that will take
place (ON, OFF, MAX or SCENE
1-255), and the Fade rate
(1 second - 127 minutes).
Selecting 4. Recurrence allows
you to set the recurrence of
the event. Use the side arrow
EVENTS
x1
Cancel
EVENT
2. Enabled
3. Action
4. Recurrence
5. 12:00P
Save
8:35A
1. Event #1
x1
Cancel
ACTION
2. ON
3. Default Fade
Save
8:35A
1. <Area #1>
x1
Cancel
RECURRENCE
Save
8 35A
Daily
2
N
4
O
1
2
ON ON
on 05. . 0 6
De au t ro ile
S and B Menu
ON ON ON
Defa t Prof le
S and By
Me u
2
O
F
Defa t P of e
and B Menu
N
2 3
OFF O O F
and By
Menu
x1
Stand By
- VRCPG -
Default Profile
Menu
8:35 AM
Mon 04.28.2008
8:35A
x1
Back
EVENTS
Home
8:35A
<< NEW >>

buttons to toggle between
choices (DAILY, WEEKDAYS,
WEEKENDS, ONE TIME,
MONTHLY, or WEEKLY).
Press right soft key (Save) to
complete your choice.
Selecting 5. 12:00P allows you to
set the event time. Use side arrow
buttons to toggle between
TIME OF DAY, DAWN or DUSK.
DAWN or DUSK allows for an
event to occur at a specified time
relative to sunrise or sunset by
using the or buttons and
inputting the time period. NOTE:
you must have a correct location
inputed for this choice (refer to
LOCATION pg. 17).
There is also a Randombox
you can check or uncheck using
the or buttons that will
provide daily variations when
selected.
Press right soft key (Save) to complete. The
EVENTS screen will display with your newly created
event. The left soft key (Back) will return you to
the MAIN
MENU screen.
x1
Cancel
EVENT TIME
12:00P
Random
Save
8:35A
Time of Day
x1
Back
EVENTS
Event #1
Home
<< NEW >>
8:35A
x1
Back
SETTINGS
2. Contrast
3. Buzzer
4. Location
5. Security
Home
8:35A
1. Time
x1
Back
SETTINGS
7.
8. LCD Timeout
5. Battery Level Security
6.
Events Setup
Home
8:35A
9. Language
SETTINGS
Selecting 6. Settings from the MAIN MENU screen
will bring you to the SETTINGS screen.
x1
Back
MAIN MENU
1. Device List
2. Who Is...
3. Area
4. Profile
5. Events
Home
8:35A
TIME
Sets the date and time for your VRCPG (refer to
STARTUP pg. 5)
16
N N
N N
O
x
12 00 P
De u f e
00 P
D t P o
OFF
2 0 PM
N
3
O F
12 00 M
e r
3
ON
N
ON
4
N

17
BUZZER
Turns the buzzer on the VRCPG keypad ON or
OFF. When the buzzer is ON, a beep will be heard
when pressing the keypad. When the buzzer
is OFF, a click will be heard when pressing the
keypad. The default setting is buzzer ON. Adjust the
buzzer as follows:
1. Select Buzzer.
2. Use the side arrow
buttons to turn buzzer ON
or OFF.
3. Press right soft key
(Save) to complete.
x1
Cancel
BUZZER
Save
Buzzer
ON
8:35A
LOCATION
This feature is used when calculating of DAWN or
DUSK for EVENTS is required and to enable or
disable Daylight Savings time. Set the location for
your VRCPG as follows:
1elect Location.
2Use the arrow buttons
to navigate and set
the location using the and
buttons.
3. Use or button to
enable or disable Daylight
Savings (DLS).
NOTE: Select US, EU or MEX with button.
4. Press right soft key (Save) to complete.
x1
Cancel
LOCATION SETUP
Save
Latitude : N 041˚
Longitude : W 074˚
Time Zone : GMT-5
DLS:Enable
EU MEXUS
8:35A
CONTRAST
Sets the contrast for your
VRCPG LCD screen as follows:
1. Select Contrast.
2. Use the and
buttons to adjust
the percentage of contrast.
3. Press right soft key
(Save) to complete.
x1
Cancel Save
CONTRAST
8:35A
060%
1
2
3
4
a t ofi e
ON
ON
3
O
O
O F
O
1 0 M
on 0 08
d
e
ON
O F OF
0 PM
.0 2006
Defa lt ro le
d By Menu
ON
OFF OFF
M 5.01.200
efault ro e
and B
Me u
ON
F
12 00 P
Mon 5 01 20 6
De ault P ofi
d y M nu
1 2
ON
F F
0 PM
1 6
De au P fil
St nd By
M nu
Mo
Stand By Menu
N
2
O
2
Mo 05
ile
ON
ON
O
4
O F
O F
O
O
12 0 PM
S
1
O
2
3
O
4
N
O
1 0 PM
2
3
12
1
O
2
N
3
N
4
O
OF
FF
12 00 PM
u
1
O
O F
1
2 00 P
04 7
De au t P i e

18
SECURITY
Sets the password and lock level for your VRCPG
or System (refer to INSTALLATION CHECKLIST -
Security pg. 11).
BATTERY LEVEL
Displays the battery level and
charger status for your VRCPG
as follows:
1. Select Battery Level.
2. Battery level will be
displayed when charger is
OFF.
Battery level and DC Power
will be displayed when
charger is ON. NOTE:
Power Adapter icon will
show on top of screen when
charging
x1
Back
BATTERY LEVEL
Home
- 2.88 +
Battery Power
8:35A
x1
Back
BATTERY LEVEL
Home
- 2.88 +
DC Power
8:35A
EVENTS SETUP
Allows you to enable or disable
ALL events for your VRCPG as
follows:
1. Select Events Setup.
2. Use up and down
arrow buttons to scroll
between "Enable All
Events" and "Disable All Events".
3. Use button to select and
press right soft key (Save) to complete.
x1
Cancel
EVENT SETUP
Save
Disable ALL
8:35A
Enable ALL
ON
12 00 PM
y
x1
12 0
file
y
1
ON
x1
1 0
5 0
