Leviton Omni Pro II User manual

Control & Security System
Installation Manual
Includes the SIA CP-01 Control Panel Standard
Features for False Alarm Reduction
WEB VERSION

WEB VERSION

WARNINGS AND CAUTIONS
• Read and understand all instructions. Follow all warnings and instructions marked on the product.
• Do not use this product near water - e.g., near a tub, wash basin, kitchen sink or laundry tub, in a wet basement,
or near a swimming pool.
• Never push objects of any kind into this product through openings, as they may touch dangerous voltages.
• Never install communications wiring or components during a lightning storm.
•
use in wet locations.
• Never touch uninsulated wires or terminals unless the wiring has been disconnected at the network interface.
• Use caution when installing or modifying communications wiring or components.
• SAVE THESE INSTRUCTIONS.
WEB VERSION

CONTENTS
INTRODUCTION .......................................................................................................................................... 1
PLANNING ........................................................................................................................................................................................ 1
INSTALLATION............................................................................................................................................ 2
CONTROLLER HOOKUP ..............................................................................................................................................................2
ABOUT SECURITY ZONES ........................................................................................................................................................... 4
BURGLAR ZONE HOOKUPS ................................................................................................................................................... 4
ABOUT FIRE ZONES ......................................................................................................................................................................5
TWO-WIRE SMOKE DETECTORS .......................................................................................................................................... 6
FOUR-WIRE SMOKE DETECTORS ........................................................................................................................................6
TELEPHONE CONNECTIONS ......................................................................................................................................................9
DIGITAL SUBSCRIBER LINE (DSL) CONNECTIONS ......................................................................................................... 9
LCD CONSOLE HOOKUP ............................................................................................................................................................ 11
CONSOLE SETUP ..........................................................................................................................................................................12
CONSOLE ADDRESS .............................................................................................................................................................. 12
SOUNDER.................................................................................................................................................................................12
KEY CLICK .............................................................................................................................................................................. 12
KEY BACKLIGHT ...................................................................................................................................................................12
VIEWING ADJUSTMENT ....................................................................................................................................................... 12
LANGUAGE .............................................................................................................................................................................12
EXIT SETUP MODE................................................................................................................................................................. 12
SOUNDER OUTPUTS ....................................................................................................................................................................14
INTERIOR SOUNDER HOOKUP ...........................................................................................................................................14
EXTERIOR SOUNDER HOOKUP ..........................................................................................................................................14
CONTROLLER OUTPUTS ...........................................................................................................................................................16
RESET OUTPUTS...........................................................................................................................................................................16
OUTPUT APPLICATIONS............................................................................................................................................................ 16
GENERAL PURPOSE SWITCHING APPLICATIONS.......................................................................................................... 16
SOUNDER TRIGGERING ....................................................................................................................................................... 16
COMMUNICATOR OUTPUTS ............................................................................................................................................... 17
"ARMED" AND "OK TO ARM"..............................................................................................................................................17
SWITCHED OUTPUT .............................................................................................................................................................. 17
LEVITON COMMUNICATING THERMOSTATS ................................................................................................................17
REMOTE ARM/DISARM SWITCH............................................................................................................................................. 17
LEVITON THERMOSTATS .........................................................................................................................................................19
PROGRAMMABLE ENERGY SAVER MODULES ..................................................................................................................20
TEMPERATURE, OUTDOOR TEMPERATURE, AND HUMIDITY..................................................................................... 21
BUILT-IN SERIAL PORTS ...........................................................................................................................................................23
BUILT-IN ETHERNET PORT ...................................................................................................................................................... 24
CONTROLLER IP ADDRESS, PORT NUMBER, AND ENCRYPTION KEY .....................................................................24
CONTROLLER IP ADDRESS .................................................................................................................................................25
CONTROLLER PORT NUMBER ............................................................................................................................................25
ENCRYPTION KEY ................................................................................................................................................................. 25
OMNIPRO II ETHERNET CONNECTIONS...........................................................................................................................25
CONNECTING TO NETWORK VIA PC ACCESS ................................................................................................................26
SYSTEM POWER UP PROCEDURE ....................................................................................................... 28
CONSOLE CHECK OUT............................................................................................................................................................... 28
TELEPHONE CHECK OUT ......................................................................................................................................................... 28
BURGLAR ZONE CHECK OUT .................................................................................................................................................. 29
FIRE ZONE CHECK OUT ............................................................................................................................................................29
CUSTOMER CHECKOUT ............................................................................................................................................................29
IN CASE OF TROUBLE ................................................................................................................................................................ 30
CONSOLES ............................................................................................................................................................................... 30
CONTROLLER .........................................................................................................................................................................30
WEB VERSION

DIGITAL COMMUNICATOR................................................................................................................... 32
DESCRIPTION OF CONTACT ID ...............................................................................................................................................32
DESCRIPTION OF 4/2 FORMAT.................................................................................................................................................33
3/1 FORMAT ....................................................................................................................................................................................33
OPENING AND CLOSING REPORTS ........................................................................................................................................33
INSTALLER SETUP ................................................................................................................................... 34
SETUP CONTROL..........................................................................................................................................................................34
X-10 HOUSE CODE .................................................................................................................................................................34
UPB NETWORK ID ..................................................................................................................................................................34
X-10 3-PHASE...........................................................................................................................................................................35
OUTPUT TYPES.......................................................................................................................................................................35
Z-WAVE NODE ID...................................................................................................................................................................36
SETUP ZONES ................................................................................................................................................................................37
ZONE EXPANSION..................................................................................................................................................................37
ZONE RESISTORS ...................................................................................................................................................................37
ZONE TYPES ............................................................................................................................................................................38
LATCHING ZONE TYPES.......................................................................................................................................................38
DESCRIPTION OF ZONE TYPES ...........................................................................................................................................39
SETUP DIGITAL COMMUNICATOR ........................................................................................................................................42
FIRST PHONE NUMBER, FIRST ACCOUNT NUMBER .....................................................................................................42
COMMUNICATOR TYPE........................................................................................................................................................42
TWO-WAY AUDIO ..................................................................................................................................................................42
REPORT OPEN/CLOSE ...........................................................................................................................................................43
REPORT BYPASS / RESTORE................................................................................................................................................43
AUTOMATIC TEST TIME.......................................................................................................................................................43
ALARM CODES (4/2 and 3/1 Formats)....................................................................................................................................43
SETUP AREAS ................................................................................................................................................................................44
SETUP AREAS: CONTROL.....................................................................................................................................................44
SETUP AREAS: ZONES...........................................................................................................................................................48
SETUP AREAS: BUTTONS .....................................................................................................................................................48
SETUP AREAS: CONSOLES...................................................................................................................................................48
SET-UP AREAS: THERMOSTATS .........................................................................................................................................49
SETUP AREAS: MESSAGES..................................................................................................................................................49
SETUP TEMPERATURES.............................................................................................................................................................50
TEMPERATURE DISPLAY .....................................................................................................................................................50
THERMOSTAT TYPE ..............................................................................................................................................................50
Z-WAVE THERMOSTAT NODE ID.......................................................................................................................................50
SETUP MISCELLANEOUS ...........................................................................................................................................................51
INSTALLER CODE ..................................................................................................................................................................51
ENABLE PC ACCESS ..............................................................................................................................................................51
PC ACCESS CODE ...................................................................................................................................................................51
CALL BACK PHONE NUMBER .............................................................................................................................................51
OUTSIDE SIREN DELAY........................................................................................................................................................51
DIAL OUT DELAY...................................................................................................................................................................52
ALARM RESET TIME .............................................................................................................................................................52
ARMING CONFIRMATION ....................................................................................................................................................52
FIRE ALARM VERIFICATION...............................................................................................................................................52
SUPERVISE INT SNDR ...........................................................................................................................................................53
SUPERVISE EXT SNDR ..........................................................................................................................................................53
ENABLE EMERGENCY KEYS...............................................................................................................................................53
TIME DISPLAY ........................................................................................................................................................................53
DATE DISPLAY .......................................................................................................................................................................53
AC POWER FREQUENCY ......................................................................................................................................................53
DEAD LINE DETECT ..............................................................................................................................................................54
OFF HOOK DETECT................................................................................................................................................................54
PICKUP AFTER HANGUP ......................................................................................................................................................54
CLOCK ADJUSTMENT ...........................................................................................................................................................54
MODEL AND SOFTWARE VERSION ...................................................................................................................................54
WEB VERSION

RESET SYSTEM EEPROM .....................................................................................................................................................54
RESET SYSTEM RAM............................................................................................................................................................. 55
ETHERNET MAC ADDRESS..................................................................................................................................................55
SETUP EXPANSION ...................................................................................................................................................................... 55
MODULE 1 TYPE.....................................................................................................................................................................55
MODULE 2 TYPE - MODULE 4 TYPE .................................................................................................................................. 56
SERIAL 1 RATE ....................................................................................................................................................................... 56
SERIAL 1 FUNCTION .............................................................................................................................................................56
SERIAL 2 - SERIAL 5 RATE...................................................................................................................................................56
SERIAL 2 FUNCTION .............................................................................................................................................................56
SERIAL 3 FUNCTION .............................................................................................................................................................57
SERIAL 4 - SERIAL 5 FUNCTION .........................................................................................................................................57
SERIAL 6 RATE ....................................................................................................................................................................... 57
SETUP ZONE OPTIONS ............................................................................................................................................................... 58
SWINGER SHUTDOWN NUMBER .......................................................................................................................................58
CROSS ZONE WINDOW......................................................................................................................................................... 58
ZONE 1 OPTIONS – ZONE 176 OPTIONS............................................................................................................................. 58
SIA CP-01 COMPLIANCE ......................................................................................................................... 59
Minimum Equipment Requirements for a CP-01 Compliant Installation:................................................................................59
OMNIPRO II SPECIFICATIONS.............................................................................................................. 60
UNDERWRITER'S LABORATORIES (UL) INSTALLATION REQUIREMENTS .......................... 61
24-HOUR STANDBY BATTERY CAPACITY......................................................................................... 62
SMOKE DETECTOR INSTALLATION GUIDELINES ........................................................................ 63
APPENDIX A – CONTACT ID REPORTING FORMAT ...................................................................... 64
APPENDIX B - DIGITAL COMMUNICATOR CODE SHEET ............................................................ 65
APPENDIX C - ZONE AND UNIT MAPPING......................................................................................... 70
APPENDIX D – FIRMWARE UPDATES ................................................................................................. 71
FIGURES
FIGURE 1 - CONTROLLER HOOKUP.............................................................................................................................................3
FIGURE 2 - OVERALL CONNECTIONS DIAGRAM ..................................................................................................................... 5
FIGURE 3 - TWO-WIRE FIRE ZONE CONNECTIONS.................................................................................................................. 7
FIGURE 4 - FOUR-WIRE FIRE ZONE CONNECTIONS ................................................................................................................ 8
FIGURE 5 - RJ31X JACK CONNECTIONS.................................................................................................................................... 10
FIGURE 6 – DSL SPLITTER CONNECTIONS ..............................................................................................................................11
FIGURE 7 - CONSOLE CONNECTIONS .......................................................................................................................................13
FIGURE 8 - SOUNDER CONNECTIONS....................................................................................................................................... 15
FIGURE 9 - RESETTING CONTROLLER OUTPUTS................................................................................................................... 16
FIGURE 10 - REMOTE KEYSWITCH CONNECTIONS...............................................................................................................18
FIGURE 11 - LEVITON THERMOSTAT CONNECTIONS .......................................................................................................... 19
FIGURE 12 - TEMPERATURE / HUMIDITY SENSOR CONNECTIONS ................................................................................... 21
FIGURE 13 - PESM CONNECTIONS .............................................................................................................................................22
FIGURE 14 - RS-232 CONNECTIONS ...........................................................................................................................................23
FIGURE 15 - RS-485 CONNECTIONS ...........................................................................................................................................24
FIGURE 16 - LOCAL NETWORK...................................................................................................................................................26
FIGURE 17 - LOCAL / WIDE AREA NETWORK ......................................................................................................................... 27
FIGURE 18 - 24-HOUR STANDBY CONNECTIONS ................................................................................................................... 62
WEB VERSION

WEB VERSION

Page 1
INTRODUCTION
This installation guide is intended as an aid to installing the OmniPro II Control & Security System. The installer should also
have thoroughly reviewed and understood the OmniPro II Owner's Manual, which has important information regarding final setup
of the system. This manual assumes that the installer has a basic understanding of installing a security system.
This guide applies to the 20A00-2, -5, and -22 versions of the OmniPro II series controller. Refer to the Underwriters
Laboratories Installation Requirements section for details in the application of each. Failure to install the OmniPro II and its
accessories in accordance with the UL Requirements in this manual and in the Owner's Manual, is a violation of the Listing Mark.
PLANNING
Before you start, your system should be planned as follows:
1. Zones:
•Decide where each contact or detector will be located
•Decide which zone it will occupy
•Decide zone type for each zone
•Decide which area it will occupy
•With the customer, decide what text and voice descriptors will be used. Consult table of voice descriptors, so that you
can choose similar words for the text to avoid customer confusion.
•See SMOKE DETECTOR INSTALLATION GUIDELINES to plan locations for smoke detectors
2. Consoles:
•Consult the customer on the console location. The console should be easily accessible.
3. Interior Sounder and Outside Siren:
•Locate both where they cannot be tampered with.
4. Lighting and Appliance Switches and Modules.
5. Plan for thermostats, energy saver modules, or other options.
6. Give consideration to where the controller will go. Remember that it needs a duplex receptacle not controlled by a switch,
preferably on its own circuit, within 5 feet of the controller.
WEB VERSION

Page 2
INSTALLATION
Go over your plan with your customer.
1. Install the entire system. Refer to sections in this manual to see how to install various components.
2. Follow the Power-Up and Checkout procedures.
3. Explain the basics to the customer. Deliver all manuals and documentation.
4. Follow up with your customer to keep them satisfied.
CONTROLLER HOOKUP
1. When choosing a place to mount the controller, consider the following:
a. A duplex outlet, preferably on its own circuit, is required to be within 5 feet of the controller for the power transformer and
the UPB PIM or X-10 Interface Module.
b. The controller should be protected from weather, temperature extremes, and burglars.
2. GROUND THE CONTROLLER "EARTH GND" TERMINAL TO A COLD WATER PIPE OR TO A 4-FOOT GROUND
ROD TO PRESERVE ITS BUILT-IN TRANSIENT PROTECTION. USE 14 GAUGE WIRE. TRANSIENT
PROTECTION WILL NOT WORK IF THE CONTROLLER IS NOT PROPERLY GROUNDED.
3. Connect the 24 VAC power transformer to the 24 VAC INPUT terminals.
4. Connect the BLACK battery wire to the minus (-) terminal on the battery. DO NOT connect the red wire at this time. DO
NOT reverse the connections; the battery fuse will blow. Note that the unit will NOT START on the battery alone.
5. Connect the Powerline Interface Module to the OmniPro II controller:
a) UPB PIM (P/N: 36A00-1):Plug one end of the 6-conductor modular cable into the connector marked “J3” (SERIAL 3)
on the OmniPro II controller and plug the other end into the modular connector on the PIM.
b) X-10 Interface Module (P/N: TW523): Plug one end of the 4-conductor modular cable into the connector marked “J7”
(X-10) on the OmniPro II controller and plug the other end into the modular connector on the X-10 Interface Module.
6. Refer to FIGURE 1 (CONTROLLER HOOKUP) for this configuration.
WEB VERSION

Page 3
YUASA NP7-12
OR EQUIVALENT
BLACK WIRE TO -
RED WIRE TO +
12V 7AH
BATTERY
ELECTRIC CODE, ANSI/NFPA 70.
ACCORDANCE WITH THE NATIONAL
GOUNDING METHOD MUST BE IN
OR GROUND ROD
COLD WATER PIPE
14 GA. WIRE
OR EQUIVALENT
MODEL RT-2440SL
REVERE
24 VAC 40 VA
POWER TRANSFORMER
WIRING IN THE ENCLOSURE
ALL OTHER POWER LIMITED/CLASS II
MUST BE SEPERATED FROM
LIMITED. THE BATTERY LEADS
THE BATTERY IS NON-POWER
BY AT LEAST 1/4"
SPACING
1/4"
6 CONDUCTOR
Powerline Interface Module
Status
<Program
UPB™
FIGURE 1 - CONTROLLER HOOKUP
WEB VERSION
