LG ARNU093CEA2 User manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
(Company) (ProjectManager)
Tag#:
ARNU093CEA2
MultiV™FloorStanding(withcase)
Btu/hIndoorUnit
Performance:
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB
Outdoor
:
95°FDB
Indoor: 70°FDB
Outdoor
:
47°FDB/43°FWB
HeatingCapacity(Btu/h)10,900
Electrical:
PowerSupply(V/Hz/Ø) 208‐230/60/1
RatedAmps(A)0.1
Piping:
Refrigerant:
Condensate:
StandardFeatures:
•LimitedWarrantywithLGCerfiedInstallaon
•TwoYearFunctionalPartsWarranty
ControlsFeatures:
•Autochangeover
(HeatRecoveryonly)
•Autooperaon
•Autorestart
•Childlock
•Dualthermistorcontrol
•Groupcontrol
•E.S.P.control
•Hotstart
•Selfdiagnoscs
•Sleepmode
•Timer(on/off)
•Weeklyschedule
•Sodry(dehumidificaon)
•Fanspeedcontrol
UnitData:
RefrigerantType R410A
RefrigerantControl EEV
Fan:
Type Sirocco
Quantity 1
Motor/Drive BrushlessDigitallyControlled/Direct
Notes:
PowerInput²(W) 30
AirflowRateH/M/L(CFM) 335/300/265
TotalCoolingCapacity¹(Btu/h) 9,600
Filter WashablePre‐filter
1.SeeEngineeringManualforsensibleandlatentcapacies.
2.ThePowerInputisratedathighspeed.
3.Requiresa7‐Dayprogrammablecontroller.
4.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
5.Allcommunicaoncabletobeminimum18AWG,2‐conductor,stranded,shieldedandmust
complywithapplicablelocalandnationalcode.
6.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
7.Thisunitcomeswithadrynitrogencharge.
8.Thisdataisrated0abovesealevel,with25ofrefrigerantlineperindoorunitanda0
leveldifferencebetweenoutdoorandindoorunits.Allcapacitiesarenetwithacombination
ratiobetween95–105%.
9.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
9,600
O
p
tionalAccessories:
CondensateLine(in,OD) 1/2
Factor
y
InstalledPum
p
No
SoundPressure⁴dB(A)(H/M/L) 36/34/32
NetUnitWeight(lbs) 60
ShippingWeight(lbs) 69
LiquidLine(in,OD) 1/4Flare
VaporLine(in,OD) 1/2Flare
Page1of2VRF‐SB‐DL‐002‐US012C22
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lg‐vrf.com
WirelessHandheldRemoteController‐PQWRHDF0
7‐DayProgrammableController(Black)‐PQRCVSL0
SimpleControllerwithMode(Black)‐PQRCVCL0Q
SimpleControllerwithoutMode(Black)PQRCHCA0Q
DryContactUnit‐PQDSB1
WallMountedTemperatureSensor‐PQRSTA0
7‐DayProgrammableController(White)‐PQRCVSL0QW
SimpleControllerwithMode(White)‐PQRCVCL0QW
SimpleControllerwithoutMode(White)‐PQRCHCA0QW
DryContactUnit‐PQDSBC
³

ARNU093CEA2
MultiV™FloorStanding(withcase)
Btu/hIndoorUnit
JobName/Location:
Tag#:
Date:
PONo.:
9,600
Page2of2VRF‐SB‐DL‐002‐US012C22
